Dragon Touch DF01 User manual

USER MANUAL
Dragon Touch DF01 DRONE
V1.0
AGES
DISCLAIMER & SAFETY GUIDELINES
1. For novices, please fly no higher than 20 meters (65 feet).
2. Do not look directly into the drone light.
3. Do not treat this product as household waste.
4. Do not fly above or near obstacles, crowds, open water, public roads,
high-voltage power lines, or trees.
5. Do not use the drone in severe weather conditions such as wind, snow, rain,
smog, hail, lightning, tornadoes, or hurricanes.
6. Stay away from the rotating propellers and motors.
7. Keep your drone in eyesight at all times. Please do not rely solely on a first-
person-view camera to control your drone.
8. This product is NOT a toy and is not recommended for users under the age of 14.
9. Be sure to observe all local regulations, obtain appropriate authorizations, and
understand the risks.
Note: It is solely your responsibility to comply with all flight regulations.
DRAGON TOUCH accepts no liability for damage, injury, or any legal responsibility
incurred directly or indirectly from the use of this product. The user shall observe
safe and lawful practices including, but not limited to, those set forth in these
Safety Guidelines.
MAINTENANCE AND CARE
1. Thoroughly check the drone after a crash or violent impact.
2. Do not charge the battery before it cools down.
3. Remove the batteries if you don't plan on using the drone for a long time.
4. Do not overcharge the battery. Unplug the charger once it's fully charged.
5. Store the drone and remote in a cool dry place away from direct sunlight.
6. Avoid bringing the camera into direct contact with water or other liquids.
Wipe dry with a soft absorbent cloth if it gets wet.
7. Do not charge the battery next to flammables, such as carpets, timber floors, or
on the surface of electro-conductive objects. Please always keep an eye on the
battery while charging.
8. To avoid losing your drone, fly it in the open air after you've gained plenty of
experience and are very confident in handling it.
DRONE DIAGRAM
Propeller B
Wi-Fi Camera
LED
Power Switch
Motor
Propeller A
1
TRANSMITTER DIAGRAM
INSTALLING THE BATTERY
REPLACING THE PROPELLER
1. The propellers are not identical. Propellers have either an "A" or "B" mark at the
bottom and they should be installed in the position with a corresponding mark.
Make sure you install them in the correct positions. Failure to do so will result in
an inability to control the drone.
2. When flying, propeller A rotates clockwise and propeller B rotates
counterclockwise.
INSTALLING THE PROTECTIVE COVER
Snap the protective frame connectors into the shackles.
Speed switch
1One-key Return
2One-key Takeoff/landing
3
Headless Mode
7Emergency stop
8
(Short press to enter fine-tuning mode, press the
joystick to slightly adjust the front, back, left and
right. Press again to exit fine adjustment.Long
press for an emergency stop.)
9
Turn left/turn right
ascend/descend
4Phone Clamps
5360° Flip
6
Video
10
11
Turn on/off
12
16
2
3
49
7
8
12 11 10
5
Transmitter: 3x 1.5V AA Battery (Batteries not included)
RECHARGING THE DRONE BATTERY
Take the battery out of the drone. To charge the battery,
plug the battery's USB connector into a USB port on a
computer (or USB power adapter). The LED indicator
light on the cable will turn red while it is charging and
turn off when it is fully charged. The charging time is
about 120-150 minutes.
Note: Only use the provided charging cable to
charge the battery. It is forbidden to use the
provided charging cable to charge other products.
MADE IN CHINA
AA 1.5V
AA 1.5V
AA 1.5V
Insert the battery into the drone (3.7V 1000mAh Li-Po battery included)
Direction
READY TO FLY
Note:
① Make sure the propellers and propeller protective covers are correctly installed
and tightened.
② Before flying, please pair the drone with the remote control and calibrate the
drone and the remote control.
1. HOW TO PAIR YOUR DRONE WITH THE REMOTE CONTROL
① Turn on the fuselage power switch and place the drone on a level surface.
② Turn on the remote control power switch.
③ Place the drone on a level surface. Push the left joystick upwards to the top,
then pull downwards as far as possible. At this time, you will hear two beeps
from the remote control, and the indicator light will change from quick flashing
to constant on, indicating that pairing is successful.
①②③
2. HOW TO CALIBRATE AND TAKE OFF
① Place the drone on a level surface. Push the left and right joysticks as shown
above simultaneously for 2-3 seconds. The drone lights will flash fast and
turn to constant 'on' in 2-3 seconds, indicating the calibration is successful.
542 3
