Draper SLX17 Operating instructions

Copyright © 2010 Draper Inc. Form SLXScissorLift_Inst10 Printed in U.S.A.
Caution:
①Read instructions completely before proceeding.
②Test lift prior to installation.
③Follow instructions carefully. Installation contrary to instructions
invalidates warranty.
④Do not obstruct operation of Scissor Lift SLX with fingers or any object.
Serious injury or damage could result.
⑤Maximum lifting capacity is 350 Lbs.
⑥Scissor Lift SLX is designed to accommodate ceiling suspended
equipment. Equipment should not be allowed to rest on optional ceiling
closure during operation (refer to section titled “Installing Projector”).
⑦Entire bottom of unit must be unobstructed to permit proper operation.
Sufficient clearance must be allowed below projector or optional ceiling
closure: 10' for Model SLX10, 14' for Model SLX14, etc.
⑧Unit must be installed level (use a carpenter’s level).
⑨Unit operates on 110-120V AC 60 Hz. current.
⑩ Verify the show position when testing lift. Make required changes by
referring to adjustment instructions on page 4 of this document.
CAUTION: Before servicing unit, disconnect hardwired control and
any remote control.
Note: Unit has been thoroughly inspected and tested at factory and found
to be operating properly prior to shipment.
Planning
①Based on screen location and projector specifications, determine proper
position for projector installation.
②Confirm that there is adequate space for installation and operation.
Minimum clearance above ceiling level varies according to Scissor Lift
model, plus height of projector, optional mounting bracket, optional ceiling
closure, and optional Environmental Air Space Housing.
③Arrange to provide service access to the unit.
④Maximum lifting capacity is 350 Lbs.
As Soon As Scissor Lift Arrives
①Open carton and inspect for damage.
②Locate the following parts:
A. The unit itself
B. Controls
C. Optional equipment: Environmental Air Space Housing, Universal
Projector Mount, closure panel or ceiling finish kit (all ship in separate
cartons).
③Test lift prior to installation.
Installation/Operating Instructions
SLX Scissor Lift Video Projector Lift by Draper
Hanging Unit
Please note: If using Environmental Air Space Housing option, go to
Environmental Air Space Housing instructions on page 3.
The Scissor Lift may be installed in a variety of ways; recessed above
the ceiling, or suspended below the ceiling. The lift should be supported by
four ½" threaded mounting rods. If ceiling recessed, the entire unit (including
the projector) should set approximately 1½" above the finished ceiling in its
“stored” position. The threaded rods should pass through the corner mounting
flanges and be secured by nuts above and below. The unit should then be guy
wired or blocked to prevent swinging.
All installations should observe the following guidelines:
①If installing above a hard ceiling, optional Draper Access Panels are
available to allow access to the unit.
②Installer must ensure that all fasteners and supports are of adequate
strength to securely support Scissor Lift and projector.
③Fastening methods must be suitable for mounting surface, and securely
anchored so that vibration or abusive pulling on unit will not weaken
installation.
④Unit should be level, with weight shared more or less equally by all four
threaded mounting rods.
⑤Bottom of unit must be unobstructed after installation. Sufficient clearance
must be allowed below projector or optional ceiling closure.
Electrical Connections
Unit operates on 110-120V AC, 60 Hz. current.
Opening the electrical box exposes terminals for field connections. Unit
is shipped with internal wiring complete.Wire to connect unit to power
supply should be furnished by installer. Connections should be made in
accordance with wiring diagram, and wiring should comply with national and
local electrical codes. All operating switches should be “off” before power is
connected.
Caution: Make sure electrical supply has been disconnected before
attempting to connect Scissor Lift to electricity.
Scissor Lift should be operated and checked prior to installing projector and/or
optional ceiling closure.
Low Voltage Control Switch shown below comes with 75' of cable and should
be plugged in to Control Panel on top frame of lift for control of the "Closed"
and "Show" positions. Momentary Key Switch shown below comes with 75' of
cable and should be plugged in to Control Panel on top frame of lift for control
of the "Service" position.
®
If you encounter any difficulties installing or servicing your Scissor Lift, call your dealer
or Draper, Inc. in Spiceland, Indiana, 765-987-7999, or fax [phone].
⑥Do not use unit to support adjacent ceiling, light fixtures, etc.
⑦Do not complete the ceiling below unit until electrical connections have
been completed and unit has been operated successfully.
⑧We recommend that safety cables be attached to the Scissor Lift SLX for
added security (a sound installation practice with overhead equipment).
⑨When the Scissor Lift SLX is to be installed in “other space used for
environmental air” the optional environmental air space housing must
be installed per instructions to isolate the lift from the “other space
used for environmental air.”
Operation
When unit is first operated, be cautious! If unit fails to operate when the
“down” button is pressed, press “off” and recheck electrical connections before
proceeding. Cycle unit down and up several times to confirm satisfactory
operation.
Caution: Do not pull on or touch safety belt when unit is in motion. If belt
locks, the cables will unspool.
Caution: Obstructing bottom pan may cause cables to unspool.
Standard Single Station Control (See Fig. 1)—One three-button switch with
“up”, “down”, and “off” buttons. Lift starts up or down when appropriate button is
pressed, and may be stopped by pressing “off” button. Factory set limit switches
stop lift automatically when projector is in “show” position. One momentary key
switch lowers lift from “show” to “service” position.
Optional Multiple Station Control—Optional, moves lift from “stored” to “show”
position only. Each switching station has a three-button switch with “up”, “down”,
and “off” buttons. Lift starts up or down when appropriate button is pressed,
and may be stopped by pressing “off” button. Factory set limit switches stop lift
automatically when projector is in “show” position.
Optional Key Operated Switch—If ordered, the standard LVC-S can be replaced
with a second single station, momentary key-operated three position (up/off/down)
switch. Multiple Station Control required for this option. Moves lift from “stored” to
“show” position only.
Optional Infrared or Radio Frequency Remote Control—If ordered, a three-
button transmitter is provided, with “up”, “down”, and “stop” buttons. Unit starts up
or down when appropriate button is pressed, and may be stopped by pressing
“off” button. Factory set limit switches stop unit automatically when projector is in
“show” position. Only controls "show" and "stored" positions.
Optional RS232 Control—For Serial communication an R2D7 Serial
Communications Interface is optionally available.
Low Voltage Trigger—Input provided for Low Voltage Trigger from projector (see
diagram on page 4).
Please Note: Scissor Lift SLX must be installed in accordance with the requirements
of the Local Building Codes, the Canadian Electrical Code (CEC), CAN/CSA
C22.1 and the National Electric Code (NEC), NFPA 70, as required. An appropriate
disconnect device shall be provided as part of the building installation.
UP
OFF
DOWN
UP DOWN
OFF
LVC-S SP-KSM
Closed & Show Service
Figure 1
Caution: Beware
of pinch points

Scissor Lift SLX by Draper page 2 of 7
Installing Projector
Generally, the video projector should be suspended from the Projector
Pan according to projector manufacturer’s instructions and recommended
standard ceiling mounting hardware.
The Scissor Lift SLX has a grounded 110-120V AC, 60 Hz power cord for
projector power supply. The power cord is laced down the back scissor and is
“hot” at all times.
Control cables should be laced through our Cable Management System.
Make sure to use flexible cables, and to allow enough cable at each turn
so cables do not stretch or kink. This will ensure that cords do not become
tangled and damaged during Scissor Lift SLX operation.
Unit and projection system should be operated, checked and adjusted as
necessary at this time.
NOTE: Immediately upon completion of the surrounding ceiling, units should
be operated to confirm that optional ceiling closure panel stops just short of
touching ceiling in closed position.
Warning: Keep fingers and other objects away from automatic ceiling
closure and scissor mechanisms when unit is operating. Serious injury or
damage could result.
www.draperinc.com (765) 987-799
9
Installing Optional Universal Projector Mount
If you ordered the unit with optional Universal Projector Mount pre-installed,
disregard these instructions.
If you did not order the mount pre-installed, you will need to install a new
Projector Pan, which includes the Universal Projector Mount's rectangular
plate.
①Lower unit until the Bottom Pan is resting on a tabletop or other stable and
sturdy surface.
②Remove Lifting Cable Bar from Bottom Pan (see Fig. 2).
③Remove bolts holding Projector Pan to Bottom Pan (see Fig. 2).
④Remove Projector Pan and set aside.
⑤Place new Projector Pan with Universal Mount into place.
⑥Re-attach Projector Pan to Bottom Pan.
⑦Re-attach Lifting Cable Bar to Bottom Pan.
3
15
/ 16 "
12"
2
1
/ 16 "
7"
Secondary Method—Adjusting Lifting Cable Bar
(if above does not work)
3
/ 8 "-18 x 1" hex head cap
screws for attaching Lifting
Cable Bar to Bottom Pan
Run the unit to its "Service" position and make sure pan is level. Try and set
so that pan is not more than ¾" out of level. However, the pan does not
have to be perfectly level, as long as the positioning is consistent and
repeatable in "Show" and "Closed" positions.
①Make sure Bottom Pan is supported.
②Remove screws holding Lifting Cable Bar to the Bottom Pan (see Fig. 2).
③Move Lifting Cable Bar forward or back (see Fig. 2).
④Replace screws.
⑤Check level again. If still not level, repeat.
Preferred Method—Adjusting Projector Pan
The Projector Pan can be moved forward or back.
①Make sure Bottom Pan is supported.
②Remove the Lifting Cable Bar (see Fig. 2).
③Remove screws holding Projector Pan on Bottom Pan (see Fig. 2).
④Move Bottom Pan forward or back.
⑤ Replace screws.
⑥Replace Lifting Cable Bar.
Attachment points
for Lifting Cables
¼"-20 x ¾" hex head
cap screws for attaching
Projector Pan to Bottom Pan
Figure 2
Figure 3
Adjusting for Level or Center of Gravity
Lifting Cable Bar

Scissor Lift SLX by Draper page 3 of 7
Installing Optional Ceiling Closure
If your Scissor Lift SLX is equipped with optional ceiling closure, it can be used
as is, or in conjunction with a square of existing ceiling tile (see Fig. 5).
①If installing with ceiling tile, you may need to cut tile so that its overall
dimensions are the same as (or slightly less than) the closure panel. Place tile
into trim frame. Lay closure panel on top (back side) of ceiling tile, and tighten
screws to hold in place.
②Attach provided angle brackets to side of Bottom Panel of Scissor Lift SLX.
③Attach
5
/ 16 " threaded rods to angle bracket.
④Run unit “up” until bottom pan stops at highest position. Mark position on
5
/ 16 "
rods even with ceiling level and cut to length (remove from pan if convenient).
⑤Run unit “down” until bottom pan stops at “show” position.
⑥Attach closure to lower end of
5
/ 16 " rods by slipping into four corner slots and
secure with nuts above and below slots.
Caution: Make sure nuts are completely tightened.
⑦Run unit “up” again to highest position. Measure distance by which panel fails to
reach required “closed” height for surrounding ceiling.
⑧Run unit “down” then re-adjust mounting of
5
/ 16 " rods in traveling grid to raise
panel required distance.
⑨Test unit operation to confirm that panel will stop in closed position just before
touching ceiling.
Caution: DO NOT hang from, "ride" or pull down on the unit. This could
create a failure and cause damage and/or injury.
PLEASE NOTE: Immediately upon completion of the surrounding ceiling,
unit should be operated to confirm that optional ceiling closure panel by
Draper or by others stops
1
/ 8 " short of touching ceiling in closed position.
If closure panel touches, the motor may continue operating after the lift is
closed. If it continues to cycle once the lift is closed, a motor failure may
occur.
www.draperinc.com (765) 987-799
9
Installing Optional Ceiling Trim Kit
The Scissor Lift SLX is available with a ceiling trim kit, which consists of
the lower section of the Environmental Air Space Housing and the optional
closure panel (see Fig. 6).
➀Install Scissor Lift SLX as previously described in these instructions.
➁Install bottom section of Environmental Air Space housing and Trim Ring in
opening. This can be accomplished by suspending with wire, or by mounting
directly to the ceiling joists (if space permits).
➂Install projector and attach optional ceiling closure to Scissor Lift SLX,
according to the instructions included in this document.
Ceiling tile
(by others)
Lower section of
Environmental Air
Space Housing
Trim Ring
6
1
23
89
7
4
75
Item Qty Part Number Description
①1 C028.546 Frame, SLX Closure Trim
②1 C044.181.07SA Panel, SLX Assembled Closure
③2 C002.845.07SA Bracket, SLX Closure
④4 C077.035.49 Rod
3
/ 8 "-16 x 17
7
/ 8 " L Threaded , Zinc
⑤8 C013.050 Washer .375 I.D. x .875" O.D.
x .064" TK GRD 2 Zinc Flat
⑥8 C020.082 Screw, 10-16 X ½" 6 Lobe
Truss Head AB E-White
⑦16 C018.027 Nut,
3
/ 8 "-16 Hex GRD 2 NSF
⑧4 C020.322 Screw,
5
/ 16 "-18 x ¾" Long Grade 5 HH Zinc
⑨4 C018.045 Nut,
5
/ 16 "-18 Zinc Hex KEPS
Installing Projector Using Universal Projector Mount
The universal projector mount includes:
-2 x long arms
-4 x short arms
-4 x M3, 4 x M4, 4 x M5 and 4 x M6 mounting bolts (30mm in length)
-4 spacers (½" [13 mm], 5/8" [16 mm], ¾" [19 mm], 7/8" [22 mm])
①Determine which size mounting bolts suit your projector, and set others
aside. They are no longer required. If your projector has only three
mounting holes, set aside one of the mounting arms (see Fig. 3).
②Attach the appropriate mounting arms to the rectangular plate via center
bolt. Spread out the arms so each end is over one of the mounting holes.
③Connect projector mounting arms.
④Tighten the mounting bolts.
⑤Use the ¼" (6.35 mm)-20 bolts and springs which hold the rectangular
plate to the bottom pan to adjust roll and tilt (the springs will ensure that the
projector is held still during motion). The center 5/16" (8 mm) bolt provides
Yaw adjustment (see Fig. 4).
Detail: ¼" (6.35 mm)-20
bolts and Spring
¼" (6.35 mm)-20
Bolt and Washer
Spring
Figure 4
Figure 5
Figure 6

RP/RQ Bus Ports for
remote controls such as
IR Eye, RF Receiver, LED
Wall Switch and RS232
Low Voltage Trigger
(6-24 VDC)
Function Indicator
KEY
WALL
RP/RQ RP/RQ
LVT
DCU
Green
Black
Yellow
LVC-S
Pin
1 2 3 4 5 6
Y G R B
Red - Down
Black - Com
Black - Com
Blue - Up
Green
Yellow
Black
KS-3
Pin
1 2 3 4 5 6
Y G R B
To RS232 Port:
Yellow = Rx (Data from control system)
Green = Tx (Data to control system)
Red = Unused
Black = Gnd (Signal Ground)
Pin
1 2 3 4 5 6
Y G R B
Pin
6 5 4 3 2 1
B R G Y
Scissor Lift SLX by Draper page 4 of 7
www.draperinc.com (765) 987-799
9
“Show” position
Adjustment Knob
Nut must be
loosened to
enable use of the
Adjustment Knob,
then re-tightened.
Connecting Controls
Limit Adjustments
Adjustments
CAUTION: Be sure all switches are in “off” position before adjusting limit
switch. Always be prepared to shut lift off manually when new adjustment is
being tested. Please refer to wiring diagram.
Limit switches for the Scissor Lift SLX are preset at the factory. The “Up”
(closed) limit switch is set for fully closed. The “down” (show) limit switch is set
for "Show" position for the size lift you have ordered. The limit switch assembly
is located inside the lift and behind the Lifting Cable Drum.
Adjusting “Down” (show) position—“Down” position may be adjusted by
Turning the Limit Switch Adjustment Knob.
Adjusting “Up” (closed) position—Because the “up” (closed) position is
preset at the factory, Draper does not recommend changing this position
using the limit switch. The “up” position of the closure may be changed by
changing the length of threaded rod used to attach the closure (see closure
instruction section).
Caution: Do not adjust the threaded rods so that the motor is still
running after the lift is closed.This could result in damage to the motor.
Controls plug into the data cable inputs on the Control Panel,
which is located on the Top Frame on the front side of the lift,
using RJ14 connectors.
For IR or RF Remote Control, use data cable with RJ14
connectors on both ends.
Please Note:
Data cable connections must be made using electrically straight 4-conductor
modular cable (RJ14). If making your own cables, this means colors do not cross
over: blue leads to blue, green to green, etc. (see diagram below).
Please Note: When adjusting
the limit switch, make sure
the bracket engages the
outside edge of the snap
switch.
Bracket Snap Switch
Pin
1 2 3 4 5 6
Y G R B
Pin
1 2 3 4 5 6
Y G R B
For serial control of "Show" position, use data cable with RJ14
connectors on both ends and an R2D7 Serial Control Interface.
Plug into the "RP/RQ" input.

Scissor Lift SLX by Draper page 5 of 7
www.draperinc.com (765) 987-799
9
RP/RQ Bus Ports for remote controls such as Eye Port for IR Eye, RF Receiver, LED Wall Switch and RS232.
Dashed wiring by electrician
Low voltage wiring by others
WH
RD
WH
RD
Show Limit Switch
Down Limit Switch
Up Limit Switch
RD
RD
BK
RD
BN BN
BK
RD
WH
YL
BK
YL/GN
Motor
125V 10A Outlet
BL BL
WH
WH
WH
BK BK
WH
GN
Key Switch
Wall Switch
Low Voltage Trigger (6 - 24 VDC)
N
110 - 120 Vac Supply

Scissor Lift SLX by Draper page 6 of 7
www.draperinc.com (765) 987-799
9
36
3
/ 16 "
38
5
/ 16 "
35
9
/ 16 "
37
11
/ 16 "
See
Ta b l e
A
35
7
/ 16 "
37
1
/ 16 "
42"
36¼"
39
11
/ 16 "
42"
35" 1
5
/ 8 "
1
/ 8 "
Scissor Lift SLX Dimensions
Table A
Closed Extended
Model Height Height
SLX10 141/16" 10'7"
SLX14 165/16" 14'2"
SLX17 189/16" 17'8"
SLX21 2013/16" 21'3"
SLX24 231/16" 24'9"
SLX28 255/16" 28'5"
SLX32 279/16" 32'1"
5"
20¾"
41½"
48½"-22½"
19"
40
5
/ 8 "

Scissor Lift SLX by Draper page 7of 7
www.draperinc.com (765) 987-799
9
Installing Optional Environmental Air Space Housing
The Environmental Air Space Housing is shipped in pieces, and must be
assembled by the installer. The height of the Environmental Air Space Hous-
ing can be adjusted by moving the screws to different mounting holes in side
panels. Aluminum tape is provided to cover unused holes. It is recommended
that an access panel be installed in the ceiling to allow future access. The
optional environmental air space housing must be installed per instructions to
isolate the lift from the “other space used for environmental air.”
Caution: Be careful when handling Environmental Air Space
Housing Panels. The panels could have sharp edges.
11
11 11
11
11
11 11
7
11
1
3
5
93
9
10
2
4
6
3
4
3
8
5
Front/Back
Side
Item Qty Part Number Description
①1 C028.544.02SA Frame, SLX Plenum
②1 C028.545.07SA Frame, SLX Trim Ring
③4 C044.178SA Panel, SLX Plenum Side
④4 C044.180SA Panel, SLX Plenum End
⑤2 C044.179SA Panel, SLX Middle End
⑥2 C044.177SA Panel, SLX Plenum Middle Side
⑦1 C095.123SA Cover, SLX Plenum
⑧28 C020.325 Screw, 8-32 x
3
/ 8 " Type 1 HWH
⑨40 C018.051 Nut #8-32 Zinc Hex KEPS
⑩ 12 C013.070 Washer, .188 I.D. x .5 O.D. x .07" TK Nylon Flat
⑪ 24 C020.112 Screw, 8-32 x
3
/ 8 " Type F HWH
Do not use
electrical knockouts
on bottom sections
①Attach Environmental Air Space Housing top frame to top of Scissor Lift
SLX with bolts provided.
②Install top panel to Environmental Air Space Housing frame.
③Attach assembly to overhead structure. Allow clearance between Environ-
mental Air Space Housing top and structure for ease of future access.
④Install side and end panels, and trim frame.
