LP20

Dual Channel Programmer

Part number 25039DR

Installation & User Guide

For GREENSTAR CDi, GREENSTAR i JUNIOR and GREENSTAR Si MODELS also

GREENSTAR i SYSTEM and GREENSTAR CDi SYSTEM MODEL(only when used with

the optional integral diverter).

Support

PLEASE READ THESE INSTRUCTIONS

CAREFULLY BEFORE STARTING.

These instructions are applicable to the

Drayton model(s) stated on the front

cover of this manual only and must not

be used with any other make or model.

These instructions apply in the UK only

and should be followed except for any

statutory obligation.

If you are in any doubt contact the

Drayton technical helpline.

This accessory must be tted by a

competent person. Failure to comply

could lead to prosecution.

Leave these instructions with the user

or at the appliance.

Abbreviations

CH = Central Heating

DHW = Domestic Hot Water

DLS = Daylight Saving

BST = British Summer Time

GMT = Greenwich Mean Time

C= Celsius (Centigrade)

IP = Ingress Protection

V= Volt

m= metre

mA = milliAmpere

Denitions (DLS/BST)

Summer time begins: Last Sunday in March at

1:00 am GMT (Clocks are put forward by 1 hour)

Summer time ends: Last Sunday in October at

2:00 am BST (Clocks are put back by 1 hour)

Protect your environment

Proper battery recycling

Electronic devices and batteries, rechargeable or not,

should not be disposed of into ordinary household waste.

Instead, they must be recycled properly to protect

the environment and cut down the waste of precious

resources. Your local waste management authority

can supply details concerning the proper disposal of

batteries.

Symbols

Central Heating

Domestic Hot Water

Sales: +44(0)845 1305522

Technical: +44(0)845 1307722

customer.care@draytoncontrols.co.uk

www.draytoncontrols.co.uk

 @DraytonHeating

/DraytonControls

Installation & User Guide

06515084001 ISSB

Client Drayton File Name 7342 Drayton Amends LP20 06515084001 ISSB

Artworker -

Proof Stage PRINT

Finished Size A5 148x210mm

Creative Director Mike Lane Artwork % 100%

Modification Date 19/03/15 10:01AM Bleed 3mm

Table of contents

Technical Data .............................................................................................................................. 2

Installation Guide .......................................................................................................... 3

LP20 Installation ......................................................................................................... 4

User Guide ....................................................................................................................... 5

LP20 Programmer....................................................................................................... 6

The Standard Program ................................................................................................ 7

Changing the Program ................................................................................................ 8-13

Maintenance .............................................................................................................................. 13

1LP20

06515084001 ISSB

LP20

Electrical supply 24v DC ‹65mA

Ambient operating temperature 0°C to +50°C

Humidity operating range 30 - 95% non-condensing up to 45°C

Class of protection II

Degree of protection IP20

Accuracy @ 25°C ‹± 1 sec/day

Battery life 10 years

Battery backup time & date 10 years min.

Shortest switching period 1 minute

DHW & CH On/Off periods 3

DHW & CH Programs 7 days

Pollution Class 2

Software Class A

Ball pressure test 90°C

Technical Data

Relevant EC Directives:

2006/95/EC Low Voltage Directive

2004/108/EC Electromagnetic Compatibility Directive

1999/5/EC R&TTE Directive

2006/66/EC Battery Directive

2011/65/EU RoHS Directive

Applied Standards:

EN60730-1; EN60730-2-7

Pack Contents:

Programmer

Instructions

Specications:

 Dual channel programmer for CH &

DHW mounted into the boiler fascia

 7 day programmer

 3 on/off periods per day

 Automatic BST settings

 Pre-programmed on/off periods

 Dedicated advance buttons

 12 or 24 hour back-lit digital display

 Holiday function

 Pre-wired with PCB connector

2Installation & User Guide

06515084001 ISSB

Client Drayton File Name 7342 Drayton Amends LP20 06515084001 ISSB

Artworker -

Proof Stage PRINT

Finished Size A5 148x210mm

Creative Director Mike Lane Artwork % 100%

Modification Date 19/03/15 10:01AM Bleed 3mm

Installation Guide

LP20

3LP20

06515084001 ISSB

CAUTION:

Isolate the mains electricity supply

before starting any work and observe

all relevant safety precautions.

Observe electro-static discharge

precautions: do not touch the pcb

circuit.

DANGER:

230 volts do not touch the electrical

components or circuits.

Installation Guide LP20 Programmer

Clips

Cover panel

Tab

Blanking

plate

Tab

Cover panel

Clips

Screw

Programmer

Recess

Programmer

Ribbon cable

Connector plug

Screw

Clips

Cover panel

Tab

Blanking

plate

Tab

Cover panel

Clips

Screw

Programmer

Recess

Programmer

Ribbon cable

Connector plug

Screw

Clips

Cover panel

Tab

Blanking

plate

Tab

Cover panel

Clips

Screw

Programmer

Recess

Programmer

Ribbon cable

Connector plug

Screw

LP20 Installation NOTE:

This accessory must be tted by a competent person.

Failure to comply could lead to prosecution.

1. Remove the boiler outer casing and control panel

fascia to gain access to the boiler control panel.

2. Release the securing screws.

3. Pull the cover panel up to remove.

4. Grip the tab and pull upwards to disengage clips,

pull forward to remove blanking plate or existing

programmer.

5. Align the connector plug pins into socket on the

PCB and push fully home.

6. Feed the ribbon cable into the recess.

7. Align the programmer and locate the clips, push

into the slots then down to secure.

8. Locate the cover panel in place and secure with

the screw.

9. Replace fascia cover and outer casing before

switching on the electrical supply and boiler.

J Switch boiler on when completed.

4Installation & User Guide

06515084001 ISSB

Client Drayton File Name 7342 Drayton Amends LP20 06515084001 ISSB

Artworker -

Proof Stage PRINT

Finished Size A5 148x210mm

Creative Director Mike Lane Artwork % 100%

Modification Date 19/03/15 10:01AM Bleed 3mm

User Guide

LP20

5LP20

06515084001 ISSB

User Guide LP20 Programmer

Central

heating

ON light

Central heating advance button:

turns ON until next OFF time OR

turns OFF until next ON time

Press OK to adjust each

program setting

Pre-heat advance button:

turns ON until next OFF time OR

turns OFF until next ON time

Hot water pre-heat

mode indicator

Central heating

mode indicator

+ and - changes ON/OFF

programmed times

Press to select each setting:

date, time, program and

holiday function

Time and day

indication

}

{

Hot water

pre-heat

ON light

LP20

Central heating

select button, moves

the indicator up and

down to select mode

and accepts changes

Pre-heat select

button, moves the

indicator UP and

DOWN to select

mode and accepts

changes

Central heating

modes:

off = continuously off.

timed = on for up to 3

periods a day as

program

once = on for 1 period a

day, from the start of

1st ON to the end of

3rd OFF as program.

on = continuously ON

Hot water pre-heat

modes:

off = continuously off.

timed = on for up to 3

periods a day as

program

once = on for 1 period

a day, from the start of

1st ON to the end of

3rd OFF as program.

on = continuously ON

If the engineer has set your program and timings – you do

not need to do anything else. Just keep this guide in a safe

place for future reference.

Introduction

The programmer will automatically switch your central

heating and hot water on and off at times that suit you.

The green light on the front of the programmer shows

when each one is on. LP20RF has a 7-day program

allowing for different timings on each day of the

week, with central heating and hot water working

independently for up to 3 heating periods each day.

If the engineer hasn’t set your timings for you, your

programmer will work with a standard program that has

been set at the factory. If this doesn’t suit you, it’s very

easy to change it.

NOTE:

Advance has no effect with constantly on

or off is selected on the receiver or when

there is no demand from the transmitter.

LP20 Programmer

6Installation & User Guide

06515084001 ISSB

Client Drayton File Name 7342 Drayton Amends LP20 06515084001 ISSB

Artworker -

Proof Stage PRINT

Finished Size A5 148x210mm

Creative Director Mike Lane Artwork % 100%

Modification Date 19/03/15 10:01AM Bleed 3mm

User Guide LP20 Programmer

LP20

NOTE:

The ON/OFF periods pre-programmed for Central

Heating and Hot Water pre-heat are shown in the

table below. These factory installed settings can

be used without any further programming of the

receiver. The time and date are pre-programmed and

should not require adjustment.

If you need to restore the factory pre-set program

times then:

Press the + and - buttons together, for three seconds or

longer, to restore the default program times to those

shown in the table opposite.

Switching Weekdays Weekends

HW CH HW CH

1st ON - start of rst timed period 6.30am 6.30am 7.00am 7.00am

1st OFF - end of rst timed period 8.30am 8.30am 9.00am 9.00am

2nd ON - start of second timed period 12.00pm 12.00pm 12.00pm 12.00pm

2nd OFF - end of second timed period 12.00pm 12.00pm 12.00pm 12.00pm

3rd ON - start of third timed period 4.30pm 4.30pm 4.00pm 4.00pm

3rd OFF - nal swith-off of the day 10.30pm 10.30pm 11.00pm 11.00pm

NOTE:

Two ON/OFF periods can be used instead of three,

by setting the second ON/OFF periods to 12:00 as

shown in the default program table. One ON/OFF

period can be achieved by setting the second and

third ON/OFF periods to the same times.

See Changing the Program on the next page, if changes

are required to the clock time or pre-programmed

settings.

The Standard Program

7LP20

06515084001 ISSB

User Guide LP20 Programmer

Setting Central Heating (CH) MON - FRI

1. Press set? until SET and PROG? are shown in the

display.

2. Press OK to enter program.

3. Press OK to select MON-FRI.

4. Press OK to select CH.

5. Press + or - to change the ON time.

6. Press set? to set the ON time and select the

OFF time.

NOTE:

Speed up the display by holding down the +or -

buttons.

PROG?

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

PROG

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

6:30

PROG

MON TUE WED THU FRI

6:30

PROG

OFF

HW ON

MON TUE WED THU FRI

8:30

6:30

PROG?

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

PROG

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

6:30

PROG

MON TUE WED THU FRI

6:30

PROG

OFF

HW ON

MON TUE WED THU FRI

8:30

6:30

PROG?

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

PROG

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

6:30

PROG

MON TUE WED THU FRI

6:30

PROG

OFF

HW ON

MON TUE WED THU FRI

8:30

6:30

PROG?

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

PROG

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

6:30

PROG

MON TUE WED THU FRI

6:30

PROG

OFF

HW ON

MON TUE WED THU FRI

8:30

6:30

PROG?

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

PROG

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

6:30

PROG

MON TUE WED THU FRI

6:30

PROG

OFF

HW ON

MON TUE WED THU FRI

8:30

6:30

Setting Hot Water (HW) MON - FRI

7. Press + or - to change the OFF time.

8. Press set? to set the OFF time and select the next

ON time.

9. Press OK to select the rst ON time.

Repeat operations 5 to 8 to set the rst, second and third

HW ON/OFF times.

NOTE:

After pressing set? for the third HW OFF time the

display shows SET MON ...see next page.

Repeat operations 5 to 8 to set the second and third CH

ON/OFF times.

PROG?

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

PROG

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

6:30

PROG

MON TUE WED THU FRI

6:30

PROG

OFF

HW ON

MON TUE WED THU FRI

8:30

6:30

PROG?

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

PROG

MON TUE WED THU FRI

PROG?

MON TUE WED THU FRI

6:30

PROG

MON TUE WED THU FRI

6:30

PROG

OFF

HW ON

MON TUE WED THU FRI

8:30

6:30

NOTE:

After pressing set? for the third CH OFF time the

display shows SET MON ...see next page.

Changing the Program

8Installation & User Guide

06515084001 ISSB

Client Drayton File Name 7342 Drayton Amends LP20 06515084001 ISSB

Artworker -

Proof Stage PRINT

Finished Size A5 148x210mm

Creative Director Mike Lane Artwork % 100%

Modification Date 19/03/15 10:01AM Bleed 3mm

User Guide LP20 Programmer

Setting individual weekdays:

NOTE:

If you do not require individual weekday times, then

press set? until SET SAT-SUN are displayed and

continue on the next page.

If you do not wish to change the setting for the day

displayed, then press set? until the rst day you want

to change is displayed.

Setting Central Heating (CH) individual

weekdays:

1. Press OK to select weekday.

2. Press OK to select CH.

3. Press + or - to change the ON time.

4. Press set? to set the ON time and select the OFF

time.

Repeat operations 3 to 6 to set the second and third

ON/OFF times.

NOTE:

Speed up the display by holding down the +or -

buttons.

PROG?

MON

MON TUE WED THU FRI

PROG

PROG?

6:30

PROG

6:30

PROG

OFF

HW ON

8:30 6:30

PROG?

MON

MON TUE WED THU FRI

PROG

PROG?

6:30

PROG

6:30

PROG

OFF

HW ON

8:30 6:30

PROG?

MON

MON TUE WED THU FRI

PROG

PROG?

6:30

PROG

6:30

PROG

OFF

HW ON

8:30 6:30

PROG?

MON

MON TUE WED THU FRI

PROG

PROG?

6:30

PROG

6:30

PROG

OFF

HW ON

8:30

6:30

5. Press + or - to change the OFF time.

6. Press set? to set the OFF time and select the next

ON time.

7. Press OK to select the rst ON time.

Repeat operations 3 to 6 to set the rst, second and third

HW ON/OFF times.

NOTE:

After pressing set? for the third HW OFF time,

SET and the next weekday are displayed.... after

completing the steps above for FRI the display shows

SET SAT-SUN. see next page....

NOTE:

After pressing set? for the third CH OFF time, SET

and HW for that weekday are displayed.

Setting Hot Water (HW) individual

weekdays:

PROG?

MON

MON TUE WED THU FRI

PROG

PROG?

6:30

PROG

6:30

PROG

OFF

HW ON

8:30 6:30

PROG?

MON

MON TUE WED THU FRI

PROG

PROG?

6:30

PROG

6:30

PROG

OFF

HW ON

8:30 6:30

9LP20

06515084001 ISSB

User Guide LP20 Programmer

Repeat operations 3 to 6 to set the second and third

ON/OFF times.

NOTE:

After pressing set? for the third CH OFF time, SET

and HW for the weekend are displayed.

Setting Hot Water (HW) SAT - SUN:

Setting Central Heating (CH) SAT - SUN:

1. Press OK to select weekend.

2. Press OK to select CH.

3. Press + or - to change the ON time.

4. Press set? to set the ON time and select the OFF

time.

5. Press + or - to change the OFF time.

6. Press set? to set the OFF time and select the next

ON time.

PROG?

SAT SUN

PROG

PROG?

PROG

9:00

PROG

OFF

HW ON

9:00 6:30

PROG?

SAT SUN

PROG

PROG?

PROG

9:00

PROG

OFF

HW ON

9:00 6:30

PROG?

SAT SUN

PROG

PROG?

PROG

9:00

PROG

OFF

HW ON

9:00

6:30

NOTE:

Speed up the display by holding down the +or -

buttons.

7. Press OK to select the rst ON time.

Repeat operations 3 to 6 to set the rst, second and third

HW ON/OFF times.

NOTE:

After pressing set? for the third HW OFF time, SET

and SAT are displayed....see next page.

NOTE:

If you do not require individual weekend day times,

then press set? until the normal display is shown.

PROG?

SAT SUN

PROG

PROG?

PROG

9:00

PROG

OFF

HW ON

9:00 6:30

PROG?

SAT SUN

PROG

PROG?

PROG

9:00

PROG

OFF

HW ON

9:00 6:30

10 Installation & User Guide

06515084001 ISSB

Client Drayton File Name 7342 Drayton Amends LP20 06515084001 ISSB

Artworker -

Proof Stage PRINT

Finished Size A5 148x210mm

Creative Director Mike Lane Artwork % 100%

Modification Date 19/03/15 10:01AM Bleed 3mm

User Guide LP20 Programmer

Repeat operations 3 to 6 to set the second and third

ON/OFF times.

NOTE:

After pressing set? for the third CH OFF time, SET

and HW for that day are displayed.

Setting Hot Water (HW) individual weekend

days:

NOTE:

Speed up the display by holding down the +or -

buttons.

Setting individual weekend days:

NOTE:

If you do not require individual weekend day times,

then press set? until the normal display is shown.

If you do not wish to change the settings for SAT, then

press set? to move to SUN.

Setting Central Heating (CH) individual

weekend days:

1. Press OK to select the day displayed.

2. Press OK to select CH.

3. Press + or - to change the ON time.

4. Press set? to set the ON time and select the OFF

time.

5. Press + or - to change the OFF time.

6. Press set? to set the OFF time and select the next

ON time.

PROG?

SAT SUN

PROG

PROG?

PROG

OFF

HW ON

9:00

6:30

PROG?

SAT

SUN

SAT

PROG?

SAT SUN

PROG

PROG?

PROG

OFF

HW ON

9:00

6:30

PROG?

SAT

SUN

SAT

PROG?

SAT SUN

PROG

PROG?

PROG

OFF

HW ON

9:00

6:30

PROG?

SAT

SUN

SAT

PROG?

SAT SUN

PROG

PROG?

PROG

OFF

HW ON

9:00

6:30

PROG?

SAT

SUN

SAT

7. Press OK to select the rst ON time.

Repeat operations 3 to 6 to set the rst, second and

third HW ON/OFF times. Pressing set? until the normal

display is shown.

PROG?

SAT SUN

PROG

PROG?

PROG

OFF

HW ON

9:00

6:30

PROG?

SAT

SUN

SAT

PROG?

SAT SUN

PROG

PROG?

PROG

OFF

HW ON

9:00

6:30

PROG?

SAT

SUN

SAT

11LP20

06515084001 ISSB

User Guide LP20 Programmer

Setting holidays:

1. Press the set? button until SET and HDAY? are

displayed.

2. Press OK and the display shows 00.

3. Press + or - to set the number of days you require

the system to be off.

4. Press set? then HDAY is shown in the display and

no demand for heating will be made from the

programmer. The program will return to normal

after the set number of days. To cancel the holiday

setting and return to normal operation, press any

button.

NOTE:

The programmer counts each pass through midnight

as a day. e.g. if you do not want heating from Saturday

morning until Tuesday morning, set for three days.

HDAY?

HDAY

6:30

HDAY?

HDAY

6:30

HDAY?

HDAY

6:30

HDAY?

HDAY

6:30

Setting the clock and time

1. Press the set? button until SET and CLOCK? are

shown in the display.

2. Press OK to display 24hr and ON.

3. Press + to switch between 24hr and 12hr display.

4. Decide between 24 hour or 12 hour display and

press set? to select, now the hours will ash.

5. Press + or - to set the correct hour.

6. When the correct hour has been selected, press

set? to select, now the minutes will ash.

7. Press + or - to set the correct minutes.

8. When the correct minutes have been set, press set?

to select that setting.

 Now SET and DATE will be displayed.

 If the day and date needs resetting, refer to

the next page for SETTING THE DATE.

 If the day and date are correct, press set? to

return to the normal display.

NOTE:

Speed up the display by holding down the +or -

buttons.

CLOCK?

DATE?
