DREAM MULTIMEDIA Dreambox DM 7025 User manual

Dreambox DM 7025
Bedienungsanleitung
Digitaler Satellitenempfänger zum Empfang von freien und
verschlüsselten DVB-Programmen mit optionaler digitaler
Aufzeichnungsmöglichkeit.
Mit Kommunikations-Schnittstelle
und PCMCIA-Schnittstelle für CI-Module
Anschluss für interne Festplatte
Compact Flash Schacht
Grafisches LC-Display
Twin Tuner steckbar
Smartcard Leser
Linux OS
User Manual
Digital satellite receiver for free and encrypted Digital
Video Broadcasting (DVB) with
optional digital recording capability.
Communication-Port
PCMCIA-Slot for CI-Modules
Internal hard disk connector
Compact Flash Slot
Graphical LC-Display
Pluggable Twin Tuner support
2 Smartcard Readers
Linux OS

- 2 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
Table of contents
1. Before initial operation of the receiver
1.1 Safety instructions......................................................................- 5 -
1.2 Packaging contents....................................................................- 8 -
1.3 Views..........................................................................................- 9 -
1.3.1 Explanation front panel...................................................- 10 -
1.3.2 Explanation rear panel....................................................- 11 -
1.4 Remote control.........................................................................- 13 -
2. Installation
2.1 Turning the device on...............................................................- 19 -
3. Start wizard
3.1 Language selection ..................................................................- 20 -
3.2 Tuner setup ..............................................................................- 21 -
3.3 Service scan.............................................................................- 21 -
4. Basic operation
4.1 Turning your Dreambox on and off...........................................- 22 -
4.2 Service selection ......................................................................- 22 -
4.3 Changing channels using the service list .................................- 23 -
4.4 Controlling the volume..............................................................- 23 -
4.5 Changing the audio track..........................................................- 23 -
4.6 Sub services.............................................................................- 24 -
4.7 TV/Radio switching...................................................................- 24 -
4.8 Infobar ......................................................................................- 25 -
5. Electronic Program Guide - EPG
5.1 Channel-EPG ...........................................................................- 26 -
5.2 Multi-EPG.................................................................................- 27 -

- 3 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
6. Edit the channellist
6.1 Add a service to favorites.........................................................- 28 -
6.2 Remove a service from favorites..............................................- 29 -
6.3 Moving a service to favorites....................................................- 30 -
7. Hard disk operation
7.1 Mounting guidelines .................................................................- 31 -
7.2 Management ............................................................................- 37 -
7.3 Recording.................................................................................- 38 -
7.3.1 Instant recording.............................................................- 38 -
7.3.2 Stop recording ................................................................- 38 -
7.3.3 Recording by timer..........................................................- 39 -
7.3.4 Timeshift.........................................................................- 41 -
7.4 Watch a recording....................................................................- 42 -
7.5 Delete a recording....................................................................- 43 -
8. Setup
8.1 Language selection..................................................................- 44 -
8.2 Usage settings..........................................................................- 45 -
8.3 Time zone.................................................................................- 47 -
8.4 Audio / Video............................................................................- 48 -
8.5 UHF-Modulator.........................................................................- 50 -
8.6 LC-Display (LCD) ....................................................................- 51 -
8.7 Network....................................................................................- 52 -
8.8 Common Interface....................................................................- 54 -

- 4 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
9. Service searching
9.1 Satelliteconfig...........................................................................- 55 -
9.1.1 Single satellite – direct connection .................................- 56 -
9.1.2 Two satellites via Toneburst A/B ....................................- 57 -
9.1.3 Two satellites via DiSEqC A/B........................................- 58 -
9.1.4 Four satellites via DiSEqC A/B/C/D................................- 59 -
9.1.5 Stab positioner using USALS .........................................- 60 -
9.1.6 Tuner 2 setup..................................................................- 61 -
9.2 Automatic scan.........................................................................- 62 -
9.3 Manual scan.............................................................................- 64 -
10. System information
10.1 Service ...................................................................................- 65 -
10.2 About (Hard- and Software) ..................................................- 66 -
11. Troubleshooting.........................................................................................- 67 -
12. TV-Mode setup
12.1 Programming the remote control............................................- 68 -
12.2 Device list...............................................................................- 69 -
13. Technical data.............................................................................................- 74 -
14. Contact & support information...............................................................- 77 -
15. Copyright notes..........................................................................................- 78 -
15.1 GNU GPL (General Public License).......................................- 79 -
16. Service Slip........................................................................see PDF attachments
17. Menu overview............................................................................................- 83 -
Note: The Dreambox DM 7025 carries the CE-Sign and fulfills all requirements from the EU.
Version: 02-22-06
Subject to change without prior notification.

- 5 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
1. Before initial operation of the receiver
1.1 Safety instructions
Please read the safety instructions completely and carefully, before using the Dreambox.
The Manufacturer takes no responsibility for damages as a result of incorrect handling of the
Dreambox.
-Allow enough space around the Dreambox for sufficient ventilation.
- Do not cover the top of the Dreambox and allow enough space to other devices. The
louvers of the devices must be free at all times to allow sufficient heat transfer from
inside the device.
- Never put vases or any other liquid filled containers on top of the device. Do not expose
the device to dripping or splashing liquids.
- Do not place open flame sources, such as lit candles, on top of the device.
-The device may only be operated in moderate climate.
- Do not remove the cover. Risk of electric shock. If it is necessary to open the device
please contact a trained professional.
-Do not put any metal things into the slots or ventilation openings.
-The installation of a hard disk is only allowed by skilled personal or your local dealer.
ATTENTION!
Modifications and changes to the Dreambox lead to loss of warranty if not
performed and documented by skilled personal.
ATTENTION!
We recommend the installation of a hard disk by your local dealer.
Unskilled installation of a hard disk leads to loss of warranty.

- 6 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
Shut down
-In case your Dreambox is in use for a longer period of time disconnect the power plug
from the power outlet.
- During thunder storm the unit should also be physically disconnected from the power
outlet.
Additional safety instructions
- (Dis-)Connecting to a LNB:
Turn the Dreambox off before you connect or disconnect a cable coming from or going to
a LNB.
- Connecting to a TV:
Before connecting or disconnecting your Dreambox to/from a TV please turn it off.
- In case you notice any damage to the power cord or power plug immediately disconnect
the device from the power outlet.
- In case the device was exposed to humidity immediately disconnect the device from the
power outlet.
- In case you notice any serious damage to the outer shell of the device immediately
disconnect the device from the power outlet.
-Do not expose the Dreambox to direct sunlight, lightning or rain.
- Grounding:
The LNB cable must be grounded.
The grounding system must meet SABS 061 requirements.
- Cleaning:
Disconnect the mains power cord before cleaning the cover. Use a slightly damp cloth
without cleaning agents.
- Connect the Dreambox only to suitable sockets. Do not allow overloads to occur.

- 7 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
Disposal instructions
The packaging of the Dreambox only consists of reusable materials. Please recycle if
possible.
This symbol on the product or on its packaging indicates that this product must not be
disposed of with your other household waste. Instead, it is your responsibility to dispose of
your waste equipment by handing it over to a designated collection point for the recycling of
waste electrical and electronic equipment. The separate collection and recycling of your
waste equipment at the time of disposal will help to conserve natural resources and ensure
that it is recycled in a manner that protects human health and the environment.
For more information about where you can drop off your waste equipment for recycling,
please contact your local city office, your household waste disposal service or the shop
where you purchased the product.
Please note that empty batteries and electric waste is not to be put into the regular garbage.

- 8 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
1.2 Packaging contents
Please check the completeness of the box’s contents.
Included in box:
Remote control
Dreambox DM 7025
1 User manual (most recent version online:
http://www.dream-multimedia-tv.de )
2 Batteries
(1,5V Mignon / AA / LR6)
1 Power cord
1 IDE-Cable
(already installed inside the
device)
1 HDD power cable (already installed
inside the device)

- 9 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
1.3 Views
Front panel
Rear panel
CI-Slot Com
p
act Flash Slot
Smartcard Reader Channel u
p
/down Power button
LC-DisplayRemote control sensor
Mains switch Mains
connection Video
out
VCR Scart
UHF Modulator
in/out USB port
Digital audio out
Mini DIN Port
LNB ins/outs
Analog
audio
out
TV Scart
Network interface
Modem port 0 / 12V out
Serial Port

- 10 -
U s e r M a n u a l D r e a m b o x D M 7 0 2 5 english
e d i e n u n g s a n l e i t u n g D r e a m b o x D M 7 0 2
1.3.1 Explanation Front Panel
CI-Slot
Plug in here any CI- Module of your choice.
Compact Flash Slot
The Compact Flash Slot is meant to hold a Compact Flash Module. The Compact Flash
Module can be plugged in during regular operation.
Smartcard reader
Insert your Dreamcrypt Smartcard with the golden chip facing down and forward into one of
the two Smartcard reader slots. Dreamcrypt is a registered trademark of Dream-Multimedia.
Remote control sensor
The remote control sensor receives the infrared signals of the Dream Remote Control.
Channel up/down
Using the channel-up and –down buttons you can switch the channels directly on your
Dreambox.
LC-Display (LCD)
The graphical LC-Display shows all major Information for the selected service.
Power button
The Power-Button switches your Dreambox on and off.
