Dreamline Aqua User manual

Rev 2.2 1

AQUA

SHOWER / TUB DOOR INSTALLATION INSTRUCTIONS

IMPORTANT

DreamLineTM reserves the right to alter, modify or redesign products at any time without

prior notice. For the latest up-to-date technical drawings, manuals or any other details

please refer to the support.BathAuthority.com web page.

Please carefully read the instructions before installing. If you have any questions regarding

installation, please call our technical support specialists Monday through Friday 9:00 AM –

5:00 PM EST at 1-866-731-8378, ext. 3 or e-mail our technical support group at

[email protected].

For more information on DreamLineTM Shower Door and Tub Door please visit www.BathAuthority.com

Rev 2.2 2

Preparation

1. After opening all boxes and packages, read this introduction carefully. Check that all of the

needed parts are included in the package, by marking all the components on the “Detailed

Diagram of Shower/Tub Door Components”. Examine boxes and packages for shipping

damage. If the unit has been damaged, has a finishing defect, or has missing parts, please

contact our customer support department within 3 business days of the delivery date. Please

note that DreamLine TM will not replace any damaged products or missing parts free of

charge after 3 business days or if the product has been installed. Feel free to contact

DreamLineTM if you have any questions.

2. If this unit is going to be installed in a new construction, please, install all of the required

plumbing and drainage before installing the shower. Use a competent and licensed (if

required by local code) plumber for all plumbing installation

3. Please note that you should consult your local building codes with questions on

installation compliance standards. Building and plumbing codes may vary by location,

and DreamLine is not responsible for code compliance standards for your project.

4. Please insure that prior to the installation the installation surface is leveled and solid and will be

able to support the total weight of the unit. Also make sure the walls are at right angles. While

some adjustment in leveling of the door is possible, irregular installation surface level or

improper angle of side walls will result in serious problems for your installation. Please, note

that some adjustments and drilling might be necessary during the installation process.

Tools Required

Caulk Tape

Measure Pencil Screwdriver

Phillips (Ø=5/16")

Drill bit

Level Gun

Caulk Drill

Electric Hammer (Ø=1/8")

Drill bit

Rev 2.2 3

Detailed Diagram of Tub Door Components

Packing List

01a Wall profile (External) 1pc 08 Decorative plug 4pcs

01b Wall profile (Internal) 1pc 09 Countersunk screw ST4.2×15 4pcs

02 Stationary glass 1pc 10 Round head screw ST4.2×30 6pcs

03 Support bar 1pc 11 Connected anti-water strip 1pc

04 Hinge 2pcs 12 Bottom anti-water strip 1pc

05 Glass door 1pc 13 U-shape seal gasket 1pc

06 Handle 1pc 14 Bottom bracket 1pc

07 Wall anchor 5pcs 15 Screw cover 1pc

NOTE: Unpack your unit carefully and inspect it. Lay it out and identify all parts using the detailed

diagram and packing list in your manual as a reference. Before discarding the carton, check for

small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or

missing, please contact DreamLineTM for replacement.

Rev 2.2 4

Shower/Tub Door Installation

1. Place the Wall profile (External) (01a) to the wall

above the Shower base or Tub and level it

vertically.

See Fig. 1 for details.

Fig. 1

2. Mark the drilling holes on the wall

through the holes in the Wall profile

(External) (01a).

Place the Wall profile (External)

aside, drill the holes using Ø5/16” drill

bit and insert the Wall anchors (07).

Apply silicone caulk along the wall

profile and around the holes on the

wall.

Place the Wall profile (External)

back into the designated position and

secure it to the wall using the Round

head screws ST4.2×30 (10).

See Fig. 2 for details.

Fig. 2

Ø5/16"

Rev 2.2 5

3. Push U-Shape seal gasket (13)

over the vertical edge of the

Stationary glass (02).

Place the Stationary glass with

attached U-Shape seal gasket onto

the Shower base and slide it into

the Wall profile (External) (01a).

Attach the Wall profile (Internal)

(01b) to the Wall profile (External)

and the Stationary glass using

Countersunk screws ST4.2×15

(09).

Level the Stationary glass vertically

and fasten the screws.

See Fig. 3 and Fig. 4 for details.

Fig. 3

Fig. 4

Rev 2.2 6

4. Take apart the Bottom bracket

(14), place the mounting part into

the U shape hole on the Stationary

glass (02) from inside and mark

the drill hole on the threshold, tray

or bathtub.

Remove the glass, drill the hole

using Ø1/8” drill bit and secure the

mounting part of the Bottom

bracket with Round head screw

ST4.2×30(10).

See Fig. 5 for details.

Fig. 5

5. Place the Stationary glass (02) back

into the Wall profile.

Assemble the Bottom bracket (14).

Fasten tight the Stationary glass (02)

in the Wall profiles and cover screw

holes with Decorative plugs (08).

See Fig. 6 and Fig. 7 for details.

NOTE: Make sure to use clear

rubber gasket to prevent glass to

metal connection.

Fig. 6

Ø1/8"

Rev 2.2 7

Fig. 7

6. Mark the hole for the Support bar (03) on the

wall according to the measurements.

See Fig. 8 for details.

Fig. 8

5/8"

43/4"

Rev 2.2 8

7. Drill the hole in the wall using Ø5/16”

drill bit and insert Wall anchor (07).

Remove the bracket from Support

bar (03) and attach it to the wall with

Round head screw ST4.2×30(10).

See Fig. 9 for details.

Fig. 9

8. Place the Support bar (03) with

channel on the Stationary glass

(02) and insert the other end into

the bracket.

Tighten the set-screws provided at

both ends of the Support bar (03).

See Fig. 10 and Fig. 11 for details.

NOTE: Make sure to use clear

rubber gasket to prevent glass

to metal connection.

Fig. 10

Ø5/16"

Rev 2.2 9

Fig. 11

9. Install the Hinges (04) on the Stationary glass (02) with

the decorative non-screw side facing outwards. Hang the

Glass door (05) from the inside. You will need assistance

in this process.

NOTE: Use clear rubber gasket to prevent glass to

metal connection.

Start first from the top hinge when you begin to hang the

door on. Make sure that until both hinges are installed

securely, do not swing around or lean/bend to any side the

Glass door because this can cause the hinge to snap and

breakage of the glass.

After the hinges are installed open and close the door to

make sure it’s operation is nice and smooth. Perform

necessary adjustment to have the top edge of the door

aligned with the stationary glass.

See Fig. 12 and Fig. 13 for details.

Fig. 12

Rev 2.2 10

Fig. 13

10. Install the Handle (06) onto the

Glass door (05).

Attach the Connected anti-

water strip (11) over the vertical

edges of the Glass door and the

Stationary.

Push the Bottom anti-water

strip (12) to the glass door.

Attach the Bottom anti-water

strip (12) over the bottom edge

of the Glass door.

See Fig. 14 for details.

Fig. 14

Rev 2.2 11

11. Apply caulk inside and outside along

bottom and vertical edge of the

stationary glass and wall profile.

See Fig. 15 for details.

Fig. 15

Product maintenance

To insure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth. To

clean the acrylic back walls use non-abrasive sprays or cream based cleaners. Never use abrasive cleansers,

metal brushes or scrapers that could scratch or dull the surface.

To insure long lasting life for your glass shower products, wipe them off after each use with a soft cloth.

Rinse and wipe of the glass using either soft cloth or squeegee to prevent soap buildup. Never use abrasive

cleaners and cleaning products that contain scoring agent because this may scratch the surface. Never use

bristle brushes or abrasive sponges.

To assure a long lasting finish wipe off the metal parts after each use with a soft cloth. Do not use abrasive

cleaners or cleaning products containing ammonia, bleach or acid. If accidentally used, rinse the surface as

soon as possible to prevent finish peeling or corrosion. After cleaning the shiny finishes, rinse thoroughly

and wipe dry with soft cloth. Clean stainless steel surfaces at least once a week. When applying stainless

steel cleaner or polish, work with (not across) the grain. Never use abrasive sponge or cloth, steel wool or

wired brushes.

CAULK

DREAMLINE™LIMITED WARRANTY

This is Bath Authority LLC’s (“DreamLine”) exclusive written warranty effective April 2, 2012

This warranty extends only to the original owner/end-user for household use only and is not transferable to a subsequent owner. This warranty applies only

to DreamLine™ products purchased from an authorized dealer and installed in United States or Canada. Proof of purchase (original sales receipt) must be

provided with all warranty claims. In no event shall the liability of DreamLine™ exceed the purchase price of the unit.

If DreamLine™ shower & tub doors, shower enclosures and shower bases are used commercially, DreamLine™ warrants such products to be free from

defects in material and workmanship for one (1) year from initial date of purchase from an authorized dealer, with all other terms of this warranty applying

except duration. If DreamLine™ vanities, vessel sinks and shower columns are used commercially, DreamLine™ warrants such products to be free from

defects in material and workmanship for three (3) months from initial date of purchase from an authorized dealer, with all other terms of this warranty ap-

plying except duration. DreamLine™ Jetted and Steam Shower Cabins are not intended for commercial use and there is no warranty extended

for these products for commercial use.

DreamLine™ hereby disclaims all warranties for products sold as dealer or store displays. DreamLine™ hereby disclaims all warranties for products used outside of

the United States or Canada whether expressed or implied, including but not limited to the implied warranties of merchantability and tness for a particular purpose.

DreamLine™ will, at its election, repair, replace with product of equal value or make appropriate adjustment where DreamLine’s analysis or inspection of

warranty claim discloses any such defects occurring in normal usage within the warranty period. DreamLine warranty obligation shall be discharged upon

tender of replacement or repair. Purchaser’s refusal to accept the tender terminates warranty obligation.

Cost of freight for returning products to DreamLine™ for repairs or replacement under this limited warranty are the responsibility of the customer. Cost of

freight associated with shipping of replacement product or parts to the customer may be charged to customer. Any product replaced or repaired during the

warranty period will be covered only for the remaining period of the original warranty. In no event will DreamLine be liable for costs of repair or replacement

of any installation material, including but not limited to tiles, marble, etc. DreamLine™ is not responsible for installation, removal or reinstallation

costs of any product requiring warranty services.

Improper modication or alteration of any DreamLine™ products will void the warranty. DreamLine product installations and repairs must be performed

by either a DreamLine authorized agent or a licensed experienced professional contractor - installation or repairs performed by any other party shall void

the warranty. This warranty shall not apply to breakage or damages caused by normal wear and tear, fault, carelessness, abuse, misuse, misapplication,

improper maintenance, alteration or modication of the unit, as well as chemical or natural corrosion, accident, re, ood, act of God or any other casu-

alty. Improper care and cleaning will void the warranty. Use of cleaners containing abrasive cleansers, ammonia, bleach, acids, waxes, alcohol, solvents

or other products not recommended for chrome or similar nish, glass or acrylic will void the warranty. For additional product maintenance instructions

please refer to product installation manual. DreamLine™ is not responsible for any issues arising in connection with errors or omissions in information

provided on DreamLine’s websites. The warranty does not extend to any non-DreamLine™ plumbing or components installed by installers, end users

or by any party other than DreamLine™.

THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT NOT

LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. BATH AIU-

THORITY LLC (“DREAMLINE”) AND/OR SELLER DISCLAIM ALL LIABILITY FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL

DAMAGES. DREAMLINE™ IS NOT LIABLE FOR PERSONAL INJURIES OR DEATH TO ANY PERSON OR FOR ANY DIRECT,

SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGE, LOSS OF USE, LOSS OF TIME, LOSS OF PROFITS, INCONVENIENCE,

INCIDENTAL EXPENSES, LABOR OR MATERIAL CHARGES, OR ANY OTHER COSTS RESULTING FROM THE USE OF ITS

PRODUCTS OR PERTAINING TO THE APPLICATION OF THE PRESENT WARRANTY, OR RESULTING FROM THE REMOVAL OR

REPLACEMENT OF ANY PRODUCT OR ELEMENT OR PART COVERED BY THIS WARRANTY.

DreamLine™ is not responsible for product code compliance or for verifying building code restrictions on installation or use and any such compliance is

excluded from this warranty. DreamLine™ reserves the right to modify this warranty at any time - such warranty modication will not alter warranty ap-

plicable at the time of sale of the products in question. The warranty terms for specic products are:

SHOWER & TUB DOORS, SHOWER ENCLOSURES AND SHOWER BASES

DreamLine™ warrants shower & tub doors, shower enclosures and shower bases to be free from defects in workmanship and materials under

normal residential use for a period of ve (5) years from the initial date of purchase by the owner/end-user, contractor or builder from an authorized dealer.

SHOWER CABINS (JETTED & STEAM)

DreamLine™ warrants glass, acrylic and nish to be free from defects in workmanship for a period of ve (5) years from initial date of purchase by

the owner/end-user, contractor or builder from an authorized dealer; and plumbing, electrical and steam generator components for a period of

one (1) year from the initial date of purchase by the owner/end-user, contractor or builder from an authorized dealer.

SHOWER COLUMNS

DreamLine™ warrants shower columns to be free from defects in workmanship and materials under normal residential use for a period of one

(1) year from the initial date of purchase by the owner/end-user, contractor or builder from an authorized dealer.

VANITIES AND VESSEL SINKS

DreamLine™ warrants bathroom vanities and vessel sinks to be free from defects in workmanship and materials under normal residential use

for a period of one (1) year from the initial date of purchase by the owner/end-user, contractor or builder from an authorized dealer.

Some states/provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of special, incidental or consequential

damages, so these limitations and exclusions may not apply to you. This warranty gives you specic legal rights. You may also have other rights, which

vary from state/province to state/province.

WARRANTY
