Dsc Pk5500 User manual

WARNING: Please refer to the System Installation Manual for information on limitations regarding product use and func-

tion and information on the limitations as to liability of the manufacturer.

NOTE: These instructions shall be used in conjunction with the system Installation Manual of the Control Panel with

which this equipment is intended to be used.

警告 - 本手册包含有关产品使用和功能的限制信息以及有关制造厂商的责任限制的信息。请认真阅读整本手册。

注意：这些说明必须同设备控制面板的《系统安装手册》一起使用。

PK5500 v1.3

Installation Instructions /安装说明

123

456

29008941R001

The PK5500 keypad can be used on security systems with up to 64

zones. These keypads are compatible with the latest version of the foll-

lowing DSC security systems:

Specifications

• Temperature range: -10°C to +55°C (14°F to 131°F)

• Humidity (MAX): 93% R.H., non-condensing

• Plastic enclosure protection degree: IP30, IK04

• Voltage rating: 12VDC nominal

• Connects to control panel via 4-wire Keybus

•1keypadzoneinput/PGMoutput*

• PK5500 Current Draw: 50mA (standby)/125mA (maximum)

• Wall mount tamper

• 5 programmable function keys

• Ready (Green LED),Armed (Red LED), Trouble (Yellow LED), AC(Green LED)

• Low temperature sensor: Alarm 6°C (43°F)/Restore 9°C (48°F)

NOTE: * Zone not to be programmed as Fire type or 24h type.

Unpacking

The Power keypad package includes the following parts:

Mounting

Mount the keypad where it is accessible to designated points of entry

and exit. Once you have selected a dry and secure location, perform

the following steps to mount the keypad.

Disassemble Keypad

1. Insert a flat head screwdriver into the provided slot (first of two).

2. Move screwdriver toward the back plastic and lift as in the following

diagram. This will unhook one side of the front plastic.

3. Repeat step # 1 and 2 on the second provided slot to disconnect

the front plastic and allow access for wiring.

Mount and Wire Keypad

1. Secure Keypad to wall using mounting holes. Use all 4 screws provided

unless mounting on a single gang box.

2. Place keypad into hooks on the backplate and swing down to engage.

3. Run wire through wiring slot or knockouts. Connect Keybus and PGM/Zone

wiring to keypad. Place tamper switch into tamper hole on backplate.

4. Remove keypad from hooks. Place keypad into backplate, ensure the wire

is pushed back into the wall as much as possible. Route the wire inside

the keypad ensuring high components are avoided. Snap the front assem-

bly closed, ensuring there is no pressure to the keypad from the wire

below.

NOTE: If any tension found between the front keypad assembly

and wiring, please open the keypad reroute the wire and close

again. Repeat these steps until the keypad is closed properly.

Wiring

1. Before wiring the unit, ensure that all power (AC transformer and battery)

is disconnected from the control panel.

2. Connect the four Keybus wires from

the control panel (red, black, yellow

and green) to the keypad terminals.

Refer to diagram.

3. If programmed as an input, you can

connect a device - such as a door

contact - to the “P/Z” terminal of the

keypad. This eliminates the need to

run wires back to the control panel for

the device. To connect the zone, run one wire from the device to the “P/Z”

terminal and the other wire from the device to the B (black) terminal. For

powered devices, run the red wire to the R (positive) terminal and the

black wire to the B (negative) terminal. When using end of line supervi-

sion, connect the zone according to one of the configurations outlined in

your system’s Installation Manual.

4. If the P/Z terminal is programmed as an output, the output follows the

PGM programmed in Section [080]. A small relay, buzzer or other DC

operated device may be connected between the positive supply voltage

and the P/Z terminal (maximum load is 50mA).

Applying Power

Once all wiring is complete, and the equipment is secured to the building

structure with at least two screws apply power to the control panel:

1. Connect the battery leads to the battery.

2. Connect the AC transformer.

For more information on control panel power specifications, see the control

panel Installation Manual.

•PC580 •PC585 •PC1555MX •PC1565

•PC1616 •PC1832 •PC1864 •PC5005

•PC5008 •PC5010 •PC5015 •PC5016

•PC5020

•One Power keypad •Keypad inner door labels

•Four mounting screws •1 tamper switch

•2 end-of-line resistors •Installation Instructions

Knock Out

Wiring Slot

Tamper

Hooks

Swing

to engage

Press to Snap

1. 2.

3. 4.

Ta m p e r

Hooks

PK5500

RED

BLK

YEL

GRN

To zone or

PGM output

Programming the Keypad

There are several programming

options available for the key-

pad. These are described below.

Programming the keypad is

similar to programming the rest of the system. When you are in the keypad

programming sections, the keypad will display which options are turned on

along the bottom of the display. To turn an option on or off, press the

number corresponding to the option on the number pad. The numbers of

the options that are currently turned ON will be displayed. For example, if

options 1 and 4 are on, the display will look like diagram shown on the

different keypad displays.

For information on programming the rest of your security system, please

refer to your system’s Installation Manual.

Broadcasting LCD Labels

All LCD programming is done per keypad. If more than one LCD keypad is

present on the system, labels programmed at one keypad can be broadcast

to all other LCD keypads. Perform the following procedure in order to

broadcast labels:

Step 1 - Program one LCD keypad completely.

Step 2 - Make sure all LCD keypads are connected to the Keybus.

Step 3 - Enter keypad programming by pressing [,][8][Installer

Code][,], then enter section [998] at the keypad that was programmed.

The keypad will now broadcast all the information programmed to all the

other LCD keypads on the system.

Step 4 - When the keypad is finished press the [#] key to exit.

NOTE: LCD Label broadcast from this keypad is only compati-

ble with PC1616/1832/1864 control panels and other

PK5500 keypads.

Language Programming

Hold the [<][>] keys for 2 seconds to enter language programming,

scroll to the desired language and Press [,] to select.

NOTE: If section [077] option 4 is OFF, language programming

can only be performed while in installers programming.

Enrolling the Keypad

The keypad will need to be assigned to a partition and slot if supervision or

keypad zones are being used. Keypad assignments and keypad option

programming must be done at each keypad individually.

The 1st digit of keypad assignment is used to determine partition assign-

ment (1 to 8). If partitioning is not used, enter [1]. For Global Keypads,

enter [0].

The 2nd digit of keypad assignment is used to determine slot assignment

for keypad supervision. Each keypad will be assigned a different slot num-

ber from 1 to 8. PK5500 LCD keypads come defaulted in slot 8. If multi-

ple LCD keypads are used one LCD keypad must remain in slot 8.

Enter the following at each keypad installed on the system:

1. Enter Installer Programming by pressing [,][8][Installer’s Code].

2. Press [000] for Keypad Programming.

3. Press [0] for Partition and Slot Assignment.

4. Enter the 1st digit (0 to 8 for partition assignment).

5. Enter the 2nd digit (1 to 8 for slot assignment supervision).

6. Press the [#] key twice to exit programming.

7. After assigning all keypads, perform a supervisory reset by entering

[,][8][Installer’s Code][902] and wait for 60 seconds.

8. Press the [#] key to exit programming.

Programming Labels

1. Enter keypad programming by pressing [,][8][Installer Code][,].

Enter the 3-digit section number for the label to be programmed.

2. Use the arrow keys [<][>] to move the underline bar underneath the

letter to be changed.

3. Press the number keys [1] to [9] corresponding to the letter you require.

The first time you press the number the first letter will appear. Pressing

the number key again will display the next letter, etc.

NOTE: To select lower case letters press [*], scroll to “lower case”

and press [*] again to select.

4. When the required letter or number is displayed use the arrow keys

[<][>] to scroll to the next letter.

5. When you are finished programming the Zone Label, press the [,] key,

use the [<][>] keys to scroll to “Save” then press [,].

6. Continue from Step 2 until all labels are programmed.

Entering ASCII Characters

To enter ASCII characters, press [,], scroll to “ASCII Entry” then press

[,] to select. Enter the corresponding three-digit number and press

[,] to save and exit.

Changing Brightness/Contrast

1. Press [,][6][Master code].

2. Use the [<][>] keys to scroll to either Brightness Control or Contrast

Control.

3. Press [,] to select the setting you want to adjust.

4. a) ‘Bright Control": There are multiple backlighting levels. Use the

[<][>] keys to scroll to the desired level.

b) ‘Contrast Control": There are 10 different display contrast levels. Use

the [<][>] keys to scroll to the desired contrast level.

5. To exit, press [#].

Changing the Buzzer Level

1. Press [,][6][Master Code].

2. Use the [<][>] keys to scroll to Buzzer Control.

3. There are 21 different levels, use the [<][>] keys to scroll to the

desired level.

4. To exit, press [#].

Emergency Keys

Press the ( ) key for 2 seconds to send a Fire transmission.

Press both ( ) keys simultaneously for 2 seconds to send a

Panic transmission.

Broadcasting Door Chime

All door chime programming is done per keypad. If more than one key-

pad is present on the system, door chime programmed at one keypad

can be broadcast to all other keypads. Perform the following procedure

in order to broadcast door chime:

Step 1 - Program one keypad completely.

Step 2 - Make sure all keypads are connected to the Keybus.

Step 3 - Enter keypad programming by pressing [,][8][Installer

Code][,], then enter section [994] at the keypad that was programmed.

The keypad will nowbroadcast all the doorchime information programmed

to all the other keypads on the system.

Step 4 - When the keypad is finished press the [#] key to exit.

Hereby, DSC, declares that this device is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC.

The complete R&TTE Declaration of Conformity can be found at http://

www.dsc.com/listings_index.aspx.

EN50131-1 Grade 2, Class II

Operating Instructions shall be made available to the user.

Toggle Option

1 _ _ 4 _ _ _ _

[1] - A, B, C, 1 [4] - J, K, L, 4 [7] - S, T, U, 7 [0] - Space

[2] - D, E, F, 2 [5] - M, N, O, 5 [8] - V, W, X, 8

[3] - G, H, I, 3 [6] - P, Q, R, 6 [9] - Y, Z, 9,0

Keypad Enrollment

Enter keypad programming by pressing [,][8][Installer’s Code][000].

[0] Partition / Slot Assignment

[1]-[5] Function Key Assignment

Keypad Function Keys

Refer to your system installation manual for a complete list of all function key options available for your system.

Keypad Programming

Enter keypad programming by pressing [,][8][Installer Code][,]

[001]-[064] Zone Label 1 to 64

ex. For Zone 1 enter section [001], for Zone 2 enter section [002] etc. Default: “Zone 1” - “Zone 64”

Digit Option Valid Range Default

1st Partition Assignment (0=Global Keypad) 0 to 8 1 I________I

2nd Slot Assignment 1 to 8 8 I________I

Function Key Button Valid Range Default Function

[1] Function Key 1 Assignment 00 to 32 03 Stay Arm I________I________I

[2] Function Key 2 Assignment 00 to 32 04 Away Arm I________I________I

[3] Function Key 3 Assignment 00 to 32 06 Chime On/Off I________I________I

[4] Function Key 4 Assignment 00 to 32 14 Sensor Reset I________I________I

[5] Function Key 5 Assignment 00 to 32 16 Quick Exit I________I________I

[00] - Null [08] - Bypass Mode [16] - Quick Exit [26] - Time & Date Program

[01] - Partition 1 Select [09] - Trouble Display [17] - Activate Stay/Away [27] - Partition 3 Select

[02] - Partition 2 Select [10] - Alarm Memory [18] - *Global Away Arm [28] - Partition 4 Select

[03] - Stay Arm [11] - User Programming [19] - Command Output 3 [29] - Partition 5 Select

[04] - Away Arm [12] - User Functions [21] - Command Output 4 [30] - Partition 6 Select

[05] - No Entry Arm [13] - Command Output 1 [22] - *Global Disarming [31] - Partition 7 Select

[06] - Chime On/Off [14] - Command Output 2 [23] - Bypass Recall [32] - Partition 8 Select

[07] - System Test [15] - *Global Stay Arm [24] - Bypass Group Recall [33] - Local PGM Activate

*Available only on the PC1616/PC1832/PC1864 version 4.2 or higher.

Section Zone Label

[001] to [064] 1 to 64 I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

[065] Fire Alarm Label (28 Characters)

Default:“Fire Zone”

[066] Fail to Arm Event Message

Default: “System Has Failed to Arm”

[067] Alarm When Armed Event Message

Default: “Alarm Occurred While Armed < >”

[071] First User Display Mask

[072] Second User Display Mask

[073] Download LCD Message Duration

Default: 003 I_______I_______I_______I (Valid entries are 000-255), 000=Unlimited Message Disp. This number represents the number of times the downloaded

message is cleared by pressing any key while the message is up after timeout).

[065] I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

[066] I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

[067] I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

Default Option ON OFF

ON I____I 1 Hold [P]anic Key prompt ON Hold [P]anic Key prompt OFF

ON I____I 2 Auto-arm Control/Time prompt ON Auto-arm Control/Time prompt OFF

ON I____I 3 Quick Arm prompt ON Quick Arm prompt OFF

ON I____I 4InteriorArmpromptON Interior Arm prompt OFF

OFF I____I 5 Quick Exit prompt ON Quick Exit prompt OFF

OFF I____I 6 Thermostat Control prompt ON Thermostat Control prompt OFF

OFF I____I 7 ACK All Trouble Prompt ON ACK All Trouble Prompt OFF

OFF I____I 8 Music Input prompt ON Music Input prompt OFF

Default Option ON OFF

ON I____I 1 User-initiated Call-up prompt ON User-initiated Call-up prompt OFF

OFF I____I 2ForFutureUse

OFF I____I 3 Walk Test prompt ON Walk Test prompt OFF

ON I____I 4 Command Output#1 prompt ON Command Output#1 prompt OFF

ON I____I 5 Command Output#2 prompt ON Command Output#2 prompt OFF

OFF I____I 6 Command Output#3 prompt ON Command Output#3 prompt OFF

OFF I____I 7 Command Output#4 prompt ON Command Output#4 prompt OFF

OFF I____I 8ForFutureUse

[074] Key Options

[076] First Keypad Options

[077] Second Keypad Options

[080] PGM Terminal 1

Default: 01 I_______I _______I 1-14 Follow PGM Output Number, 15 Local PGM Pulse , 16 Local PGM Toggle

[082] Local PGM Output Pulse Activation Time

Default: 00 I_______I _______I Minutes (Valid Range 00-99)

Default: 05 I_______I _______I Seconds (Valid Range 00-99)

[101]-[108] Partition Labels

ex. For Partition 1 enter section [101], for Partition 2 enter section [102] etc.

NOTE: Partition 1 Label is also used as the System Label.

Default Option ON OFF

ON I____I 1 [F]ire Key Enabled [F]ire Key Disabled

ON I____I 2ForFutureUse

ON I____I 3 [P]anic Key Enabled [P]anic Key Disabled

OFF I____I 4-8 For Future Use

Default Option ON OFF

ON I____I 1 Display Code when Programming Display “Xs” when Programming

ON I____I 2 Local Clock Display ON Local Clock Display OFF

OFF I____I 3 Local Clock Displays 24-hr Time Local Clock Displays AM/PM

ON I____I 4 Auto Alarm Memory Scroll Enabled Auto Alarm Memory Scroll Disabled

OFF I____I 5 Local Display of Temperature ON Local Display of Temperature OFF

ON I____I 6 Bypass Options prompt ON Bypass Options prompt OFF

OFF I____I 7ForFutureUse

OFF I____I 8 Auto-Scroll Open Zones ON Auto-Scroll Open Zones OFF

Default Option ON OFF

ON I____I 1 Chime Enabled for Zone Openings Chime Disabled for Zone Openings

ON I____I 2 Chime Enabled for Zone Closings Chime Disabled for Zone Closings

OFF I____I 3 5th Terminal is Keypad PGM Output 5th Terminal is Keypad Zone Input

ON I____I 4 Language Selection Enabled Language Selection Disabled

OFF I____I 5 Power LED Enabled Power LED Disabled

ON I____I 6 Power LED indicates AC present Power LED indicates AC absent

ON I____I 7 Alarms always Displayed When Armed Alarms not Displayed When Armed

OFF I____I 8 *Low Temperature Warning Enabled Low Temperature Warning Disabled

*The Low Temperature Warning is violated at 6°C (43°F) and restored at 9°C (48°F).

Section Partition Label

[101] to [108] 1 to 8 I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

[120]-[151] Command Output Labels

Default: “Command_O/P_1” - “Command_O/P_4”

[201]-[264] Door Chime Sound Programming

You can program the keypad to make up to four different door chime sounds for individual zones.

ex. For Zone 1 enter section [201], for Zone 2 enter section [202] etc.

[994][,] Initiate Global Keypad Chime Broadcast

[995][,] Reset Keypad Options to Factory Default

[996][,] Label Default

[997] View Software Version

[998][,] Initiate Global Label Broadcast

[999][,] Reset Keypad EEPROM to Factory Defaults

Keypad Display Symbols

For Partition 1 Command O/P 1 to 4 enter [120] to [123] For Partition 5 Command O/P 1 to 4 enter [136] to [139]

For Partition 2 Command O/P 1 to 4 enter [124] to [127] For Partition 6 Command O/P 1 to 4 enter [140] to [143]

For Partition 3 Command O/P 1 to 4 enter [128] to [131] For Partition 7 Command O/P 1 to 4 enter [144] to [147]

For Partition 4 Command O/P 1 to 4 enter [132] to [135] For Partition 8 Command O/P 1 to 4 enter [148] to [151]

Section Part Cmd.

Output Label

[120]-[151] 1to8 1to4 I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

Default Option ON OFF

ON I____I 1 6 Beeps Disabled

OFF I____I 2 “Bing-Bing” Sound Disabled

OFF I____I 3 “Ding-Dong” Sound Disabled

OFF I____I 4AlarmTone Disabled

OFF I____I 5-8 For Future Use

8Bypass – Indicates that there are zones automatically or manually bypassed.

9For Future Use

10 Arm Mode – Indicates the mode the panel is armed in.

Stay – Indicates that the panel is armed in the Stay Mode. It will turn on at the beginning of the Exit

Delay

1Fire – Indicates that there are fire alarms in memory.

2Memory – Indicates that there are alarms in memory. Away – Indicates that the panel is armed in the Away Mode. It will turn on at the beginning of the

Exit Delay

3Ready Light (green) – If the Ready light is on, the system is ready for arming.

4Armed Light (red) – If the Armed light is on, the system has been armed successfully. 11 Chime – This icon turns on when Door Chime is enabled on the system and will turn off when Door

Chime is disabled.

5System Trouble – Indicates that a system trouble is active.

12 Open – When zones are opened, the open zones will be displayed.6AC – Indicates that AC is present at the main panel.

7Program – Indicates that the system is in Installer’s Programming, or the keypad is busy.

12 9

12 7

LIMITED WARRANTY

Digital Security Controls (DSC) warrants that for a period of 12 months from

the date of purchase, the product shall be free of defects in materials and

workmanship under normal use and that in fulfilment of any breach of such

warranty, DSC shall, at its option, repair or replace the defective equipment

upon return of the equipment to its repair depot. This warranty applies only

to defects in parts and workmanship and not to damage incurred in shipping

or handling, or damage due to causes beyond the control of Digital Security

Controls such as lightning, excessive voltage, mechanical shock, water dam-

age, or damage arising out of abuse, alteration or improper application of the

equipment. The foregoing warranty shall apply only to the original buyer,

and is and shall be in lieu of any and all other warranties, whether expressed

or implied and of all other obligations or liabilities on the part of Digital

Security Controls. Digital Security Controls neither assumes responsibility

for, nor authorizes any other person purporting to act on its behalf to modify

or to change this warranty, nor to assume for it any other warranty or liability

concerning this product. In no event shall Digital Security Controls be liable

for any direct, indirect or consequential damages, loss of anticipated profits,

loss of time or any other losses incurred by the buyer in connection with the

purchase, installation or operation or failure of this product.

WARNING

Digital Security Controls recommends that the entire system be completely

tested on a regular basis. However, despite frequent testing, and due to, but

not limited to, criminal tampering or electrical disruption, it is possible for

this product to fail to perform as expected.

IMPORTANT INFORMA-

TION

: Changes/modifications not expressly approved by DSC could void

the user’s authority to operate this equipment.

IMPORTANT - READ CAREFULLY: DSC Software purchased with or

without Products and Components is copyrighted and is purchased

under the following license terms:

• This End-User License Agreement (“EULA”) is a legal agreement

between

Yo u

(the company, individual or entity who acquired the Software

and any related Hardware) and

Digital Security Controls, a division of

Tyco Safety Products Canada Ltd.

(“DSC”), the manufacturer of the inte-

grated security systems and the developer of the software and any related

products or components (“HARDWARE”) which You acquired.

• If the DSC software product (“SOFTWARE PRODUCT” or “SOFT-

WARE”) is intended to be accompanied by HARDWARE, and is NOT

accompanied by new HARDWARE, You may not use, copy or install the

SOFTWARE PRODUCT. The SOFTWARE PRODUCT includes computer

software, and may include associated media, printed materials, and “online”

or electronic documentation.

• Any software provided along with the Software Product that is associated

with a separate end-user license agreement is licensed to You under the terms

of that license agreement.

• By installing, copying, downloading, storing, accessing or otherwise

using the Software Product, You agree unconditionally to be bound by the

terms of this EULA, even if this EULA is deemed to be a modification of any

previous arrangement or contract. If You do not agree to the terms of this

EULA, DSC is unwilling to license the Software Product to You, and You

have no right to use it.

SOFTWARE PRODUCT LICENSE

The SOFTWARE PRODUCT is protected by copyright laws and

international copyright treaties, as well as other intellectual property laws and

treaties. The SOFTWARE PRODUCT is licensed, not sold.

1. GRANT OF LICENSE

This EULA grants You the following rights:

(a)

Software Installation and Use

- For each license You acquire, You

may have only one copy of the SOFTWARE PRODUCT installed.

(b)

Storage/Network Use

- The SOFTWARE PRODUCT may not be

installed, accessed, displayed, run, shared or used concurrently on or from

different computers, including a workstation, terminal or other digital

electronic device (“Device”). In other words, if You have several

workstations, You will have to acquire a license for each workstation where

the SOFTWARE will be used.

(c)

Backup Copy

- You may make back-up copies of the SOFTWARE

PRODUCT, but You may only have one copy per license installed at any

given time. You may use the back-up copy solely for archival purposes.

Except as expressly provided in this EULA, You may not otherwise make

copies of the SOFTWARE PRODUCT, including the printed materials

accompanying the SOFTWARE.

2. DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS

(a)

Limitations on Reverse Engineering, Decompilation and

Disassembly

- You may not reverse engineer, decompile, or disassemble the

SOFTWARE PRODUCT, except and only to the extent that such activity is

expressly permitted by applicable law notwithstanding this limitation. You

may not make any changes or modifications to the Software, without the

written permission of an officer of DSC. You may not remove any

proprietary notices, marks or labels from the Software Product. You shall

institute reasonable measures to ensure compliance with the terms and

conditions of this EULA.

(b)

Separation of Components

- The Software Product is licensed as a

single product. Its component parts may not be separated for use on more

than one HARDWARE unit.

(c)

Single INTEGRATED PRODUCT

- If You acquired this

SOFTWARE with HARDWARE, then the SOFTWARE PRODUCT is

licensed with the HARDWARE as a single integrated product. In this case,

the SOFTWARE PRODUCT may only be used with the HARDWARE as

set forth in this EULA..

(d)

Rental

- You may not rent, lease or lend the SOFTWARE PRODUCT.

You may not make it available to others or post it on a server or web site.

(e)

Software Product Transfer

- You may transfer all of Your rights

under this EULA only as part of a permanent sale or transfer of the

HARDWARE, provided You retain no copies, You transfer all of the

SOFTWARE PRODUCT (including all component parts, the media and

printed materials, any upgrades and this EULA), and provided the recipient

agrees to the terms of this EULA. If the SOFTWARE PRODUCT is an

upgrade, any transfer must also include all prior versions of the SOFTWARE

PRODUCT.

(f)

Termination

- Without prejudice to any other rights, DSC may

terminate this EULA if You fail to comply with the terms and conditions of

this EULA. In such event, You must destroy all copies of the SOFTWARE

PRODUCT and all of its component parts.

(g)

Trademarks

- This EULA does not grant You any rights in connection

with any trademarks or service marks of DSC or its suppliers.

3. COPYRIGHT

- All title and intellectual property rights in and to the

SOFTWARE PRODUCT (including but not limited to any images,

photographs, and text incorporated into the SOFTWARE PRODUCT), the

accompanying printed materials, and any copies of the SOFTWARE

PRODUCT, are owned by DSC or its suppliers. You may not copy the

printed materials accompanying the SOFTWARE PRODUCT. All title and

intellectual property rights in and to the content which may be accessed

through use of the SOFTWARE PRODUCT are the property of the

respective content owner and may be protected by applicable copyright or

other intellectual property laws and treaties. This EULA grants You no rights

to use such content. All rights not expressly granted under this EULA are

reserved by DSC and its suppliers.

4. EXPORT RESTRICTIONS

- You agree that You will not export or

re-export the SOFTWARE PRODUCT to any country, person, or entity

subject to Canadian export restrictions.

5. CHOICE OF LAW

- This Software License Agreement is governed by

the laws of the Province of Ontario, Canada.

6. ARBITRATION

- All disputes arising in connection with this

Agreement shall be determined by final and binding arbitration in

accordance with the Arbitration Act, and the parties agree to be bound by the

arbitrator’s decision. The place of arbitration shall be Toronto, Canada, and

the language of the arbitration shall be English.

7. LIMITED WARRANTY

(a) NO WARRANTY

- DSC PROVIDES THE SOFTWARE “AS IS”

WITHOUT WARRANTY. DSC DOES NOT WARRANT THAT THE

SOFTWARE WILL MEET YOUR REQUIREMENTS OR THAT

OPERATION OF THE SOFTWARE WILL BE UNINTERRUPTED OR

ERROR-FREE.

(b) CHANGES IN OPERATING ENVIRONMENT -

DSC shall not be

responsible for problems caused by changes in the operating characteristics

of the HARDWARE, or for problems in the interaction of the SOFTWARE

PRODUCT with non-DSC-SOFTWARE or HARDWARE PRODUCTS.

ALLOCATION OF RISK

- IN ANY EVENT, IF ANY STATUTE

IMPLIES WARRANTIES OR

CONDITIONS NOT STATED IN THIS

LICENSE AGREEMENT, DSC’S ENTIRE LIABILITY UNDER ANY

PROVISION OF THIS LICENSE AGREEMENT SHALL BE LIMITED

TO THE GREATER OF THE AMOUNT ACTUALLY PAID BY YOU

TO LICENSE THE SOFTWARE PRODUCT AND FIVE CANADIAN

DOLLARS (CAD$5.00). BECAUSE SOME JURISDICTIONS DO NOT

ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR

CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE

LIMITATION MAY NOT APPLY TO YOU.

(d) DISCLAIMER OF WARRANTIES -

THIS WARRANTY

CONTAINS THE ENTIRE WARRANTY AND SHALL BE IN LIEU OF

ANY AND ALL OTHER WARRANTIES, WHETHER EXPRESSED OR

IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE)

AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON THE PART

OF DSC. DSC MAKES NO OTHER WARRANTIES. DSC NEITHER

ASSUMES NOR AUTHORIZES ANY OTHER PERSON PURPORTING

TO ACT ON ITS BEHALF TO MODIFY OR TO CHANGE THIS

WARRANTY, NOR TO ASSUME FOR IT ANY OTHER WARRANTY

OR LIABILITY CONCERNING THIS SOFTWARE PRODUCT.

(e) EXCLUSIVE REMEDY AND LIMITATION OF WARRANTY -

UNDER NO CIRCUMSTANCES SHALL DSC BE LIABLE FOR ANY

SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES

BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT,

NEGLIGENCE, STRICT LIABILITY, OR ANY OTHER LEGAL

THEORY. SUCH DAMAGES INCLUDE, BUT ARE NOT LIMITED TO,

LOSS OF PROFITS, LOSS OF THE SOFTWARE PRODUCT OR ANY

ASSOCIATED EQUIPMENT, COST OF CAPITAL, COST OF

SUBSTITUTE OR REPLACEMENT EQUIPMENT, FACILITIES OR

SERVICES, DOWN TIME, PURCHASERS TIME, THE CLAIMS OF

THIRD PARTIES, INCLUDING CUSTOMERS, AND INJURY TO

PROPERTY.

WARNING: DSC recommends that the entire system be

completely tested on a regular basis. However, despite frequent testing,

and due to, but not limited to, criminal tampering or electrical disruption,

it is possible for this SOFTWARE PRODUCT to fail to perform as

expected.

The trademarks, logos, and service marks displayed on this document are

registered in the United States [or other countries]. Any misuse of the

trademarks is strictly prohibited and Tyco International Ltd. will aggres-

sively enforce its intellectual property rights to the fullest extent of the

law, including pursuit of criminal prosecution wherever necessary. All

trademarks not owned by Tyco International Ltd. are the property of

their respective owners, and are used with permission or allowed under

applicable laws.

Product offerings and specifications are subject to change without notice.

Actual products may vary from photos. Not all products include all fea-

tures. Availability varies by region; contact your sales representative.

Words Table/ 字一览表

Item # Text/ 字Item # Text/ 字Item # Te xt/ 字Item # Text/ 字Item # Text/ 字Item # Text/ 字Item # Text/ 字Item # Text/ 字Item # Text/ 字

001 Aborted 028 Bypass 055 Downstairs 082 Gallery 109 Light 136 Panic 163 Service 190 West 217 O

002 AC 029 Bypassed 056 Drawer 083 Garage 110 Lights 137 Partition 164 Shed 191 Window 218 P

003 Access 030 Cabinet 057 Driveway 084 Gas 111 Living 138 Patio 165 Shock 192 Zone 219 Q

004 Active 031 Cancelled 058 Duct 085 Glass 112 Load 139 Pet 166 Shop 193 0 220 R

005 Activity 032 Car 059 Duress 086 Goodbye 113 Loading 140 Phone 167 Side 194 1 221 S

006 Alarm 033 Carbon 060 East 087 Gym 114 Low 141 Please 168 Siren 195 2 222 T

007 All 034 Central 061 Energy 088 Hallway 115 Lower 142 PM 169 Sliding 196 3 223 U

008 AM 035 Chime 062 Enter 089 Heat 116 Main 143 Police 170 Smoke 197 4 224 V

009 Area 036 Closed 063 Entry 090 Hello 117 Master 144 Pool 171 Son’s 198 5 225 W

010 Arm 037 Closet 064 Error 091 Help 118 Mat 145 Porch 172 Sound 199 6 226 X

011 Armed 038 Closing 065 Exercise 092 High 119 Medical 146 Power 173 South 200 7 227 Y

012 Arming 039 Code 066 Exit 093 Home 120 Memory 147 Press 174 Special 201 8 228 Z

013 Attic 040 Communicator 067 Exterior 094 House 121 Menu 148 Program 175 Stairs 202 9 229 (Space)

014 Auxiliary 041 Computer 068 Factory 095 In 122 Monoxide 149 Progress 176 Stay 203 A 230 ’ (Apostrophe)

015 Away 042 Control 069 Failure 096 Install 123 Mother’s 150 Quiet 177 Sun 204 B 231 - (Dash)

016 Baby 043 Date 070 Family 097 Interior 124 Motion 151 Rear 178 Supervisory 205 C 232 _ (Underscore)

017 Back 044 Daughter’s 071 Father’s 098 Intrusion 125 No 152 Receiver 179 System 206 D 233 *

018 Bar 045 Degrees 072 Feature 099 Invalid 126 North 153 Report 180 Tamper 207 E 234 #

019 Basement 046 Delay 073 Fence 100 Is 127 Not 154 RF 181 Temperature 208 F 235 :

020 Bathroom 047 Den 074 Fire 101 Key 128 Now 155 Right 182 Test 209 G 236 /

021 Battery 048 Desk 075 First 102 Kids 129 Number 156 Room 183 Time 210 H 237 ?

022 Bedroom 049 Detector 076 Floor 103 Kitchen 130 Off 157 Safe 184 To 211 I

023 Bonus 050 Dining 077 Force 104 Latchkey 131 Office 158 Saver 185 Touchpad 212 J

024 Bottom 051 Disarmed 078 Foyer 105 Laundry 132 OK 159 Schedule 186 Trouble 213 K

025 Breezeway 052 Door 079 Freeze 106 Left 133 On 160 Screen 187 Unbypass 214 L

026 Building 053 Down 080 Front 107 Level 134 Open 161 Second 188 Unit 215 M

027 Bus 054 Download 081 Furnace 108 Library 135 Opening 162 Sensor 189 Up 216 N

PK5500

键盘可以在最多

个防区的报警控制主

机上使用。这些键盘兼容如下

DSC

安防系统的

最新版本 :

规格

• 温度范围 : -10°C 至+55°C (14°F 至131°F)

• 湿度（最大值）: 93% R.H., 无冷凝

• 塑料外壳保护等级 : IP30, IK04

• 额定电压：额定 12V

• 通过 4 路通信总线连接到控制主机

• 一个键盘防区输入 /PGM 输出 *

• 电流消耗：50mA（待机）/125mA（最大）

• 壁挂式防拆装置

• 5 个可编程功能键

•就绪（绿色 LED）、设防（红色 LE D）、故障（黄

色 LED）、AC（绿色 LED）

• 低温传感器 :

报警

6°C (43°F)/ 恢复 9°C (48°F)

* 备注：请勿将防区编程设定为火警类型或全天类

型。

打开包装

Power 键盘包装箱中包括以下部件 :

安装

您应将键盘安装在指定入口和出口的附近。

请选择干燥安全的位置并按照下述步骤安装

键盘。

拆卸键盘

1.用平口螺丝起插入两个槽沟中的一个。

2.如下图所示，将螺丝起向背板塑胶方向旋转，

这将松开前部面板的一侧。

3.对另一个槽沟重复步骤 1 和 2，完全分开前部

面板，开始接线。

安装键盘和布线

1. 使用安装孔将键盘固定到墙上。除非在单组盒

上安装，否则使用提供的全部 4 个螺丝钉。

2.从吊钩上卸下键盘。把键盘放到底盘中，务必

尽可能把电线推回墙内。将电线引到键盘内，

确保避开较高的组件。吧嗒一声关上前部组

合件，确保下面的电线没有挤压到键盘。

3.将键盘放到底盘上的吊钩中，并向下旋转以啮

合。

4.通过布线槽或镂空推板布线。将

Keybus

和

PGM/Zone

配线连接到键盘。把防拆器放到底

盘上的防拆孔中。

注意：如果前部键盘组合件之间存在压力，请打

开键盘，重新布线并再次关上前部键盘组合件。重

复执行上述步骤，直到键盘正确关闭。

连线

1. 装置连线前，确保断

开控制主机上的所

有电源（交流变压

器和电池）。

2.将四根通信总线

（红、黑、黄、绿）从

控制主机连接到

键盘终端。见图：

3.如果 ”P/Z” 端口编程设定为输入口，可以

给键盘的”P/Z”端口连接就近的门触点之类的

装置。这样就不需要重新将信号线连接到控

制主机。要连接防区，请将信号线的一端从

探测器连接到 ”P/Z” 端口，将另一条线连接到

B（黑色）端口。对于有源设备，将红色电线连

接到 R（正极）端口，黑色电线连接到 B

（负极）端口。使用末端电阻监控时，按《系

统安装手册》中介绍的配置之一连接防区。

4.如果 ”P/Z” 终端被编程为输出口，则按区段

[080] 中的 PGM 编程输出。电源电压正极和

”P/Z” 端口之间可以连接小型继电器、蜂鸣器

或其他 DC 装置（最大负荷 50mA）。

安装说明

• PC580 • PC585 • PC1555MX • PC1565 • PC5020

• PC1616 • PC1832 • PC1864 • PC5005

• PC5008 • PC5010 • PC5015 • PC5016

• 一个 Power 键盘 • 键盘内门标签

• 四个安装螺钉 • 一个防拆开关

• 两个线末电阻 • 一份安装说明

柑䴉㘷㨎

を兎㲌

⚙朸

棁㕕ⷣ

1. 2.

3.. 4.

⚙朸

棁㕕ⷣ

㡚懻ⅴ⟽⚗

㖘ₚ␂ₙ

PK5500

P/Z

接通电源

一旦完成所有布线工作，用至少两个螺丝钉把

设备固定到建筑物结构上，并给控制面板通电：

1. 将电池导线连接到电池。

2. 连接交流变压器。

有关控制主机功率规格的详细信息，请参见控制

主机的安装手册。

键盘编程

键盘有几个编程

选项。请参见下面

的介绍。键盘编程

与系统其他部分的

编程类似。进入

键盘编程部分后，键盘会在屏幕顶部显示开启了

哪些选项。要打开或关闭选项，请按数字键区上

与选项相应的号码。屏幕上会显示当前打开的

选项数量。例如，如果打开了选项 1 和 4，不同

键盘的屏幕显示如上图。有关系统其他部分的编

程信息，请参见系统的安装手册。

广播 LCD 标签

所有 LCD 编程都通过键盘完成。如果系统中有

一个以上的 LCD 键盘，则在一个键盘上编程的

标签会被广播到所有其他 LCD 键盘。要广播

标签，请执行以下过程：

步骤 1 －完全编程一个

LCD

键盘。

步骤 2

－确保所有

LCD

键盘都连接到通信总线。

步骤 3 －按 [,][8][ 安装人员代码 ]，进入键盘编

程，然后在要编程的键盘上输入区段

[998]

。键盘

即可将编程的所有信息广播到系统中的所有其

他

LCD

键盘。

步骤 4 - 完成键盘编程后，按 [#] 键退出。

备注：从此键盘广播的标签只与 PC1616/1832/1864

安防系统和 PK5500 键盘兼容。

语言编程

按住 [<][>] 键 2 秒种进入语言编程，滚动到要使

用的语言并按 [,] 进行选择。

备注：如果 [077] 选项 4 为关，则仅当安装人员编

程时，才能执行语言编程。

注册键盘

如果使用了监管或键盘防区，则必须为该键盘分

配一个分区和位置。每个键盘都必须单独进行

键盘分配和键盘选项编程。键盘分配的第一位数

字用于确定分区分配（1 到 8）。如果未使用分

区，则输入 [1]。对于全局键盘，输入 [0]。

键盘分配的第二位数字用于确定键盘监管的位

置分配。为每个键盘分配一个不同的位置编号

（1 到 8）。PK5500 LCD 键盘默认分配至位置 8。

在系统上安装的每个键盘上输入以下内容：

1. 按 [

][8][ 安装人员代码 ]，进入安装人员编程 ]。

2.按 [000] 进入键盘编程。

3.按 [0] 进行分区和位置分配。

4.输入第一位数（0 到 8 指定分区）。

5.输入第二位数（1 到 8 指定位置）。

6.按两次 [#] 键退出编程。

7.指定所有键盘后，输入 [,][8][ 安装人员代

码 ][902] 进行监控重置并等待 60 秒。

8.60 秒后按 [#] 键退出编程。

可编程标签

1. 按 [,][8][ 安装人员代码 ][,] 进入编程。为要编

程的标签输入三位数的区段号。

2. 用箭头键 [<][>] 将下划线符号移动到要改变

的字母下面。

3. 按与所需字母对应的数字键 [1] 到 [9]。按一

次数字会出现第一个字母。再按一次数字键

会显示下一次字母。

4.显示所需的字母或数字后，用箭头键 [<][>]

滚动到下一个字母。

5.完成防区标签编程后，按 [,] 键，滚动到

”Save”，然后再按 [,]。

6.重复步骤 2，直到完成标签编程。

ASCII 条目

要输入 ASCII 字符，按 [,] 滚动到 ‘ASCII 条目 ’，

然后按 [,] 进行选择。输入相应的 3 位数字，然

后按 [,] 保存并退出。

更改亮度 / 对比度

1. 按 [,][6][ 主代码 ]。

2. 使用 [<][>] 健滚动到 ” 亮度控制 ”

(

Brightness

Control

)

” 对比度控制 ”

(Contrast Control)

。

3.按 [,]，选择想要调整的设置。

4. a)

” 亮度控制 ”

(Brightness Control)

: 有多个背光

等级。请使用 [<][>] 键滚动到所需的背光等级

。

b) ” 对比度控制 ” (Contrast Control): 有 10 个不同

的显示屏对比度等级。请使用 [<][>] 键滚动到所需

的对比度等级。

5.要想退出，请按 [#]。

更改蜂呜器等级

1. 按 [,][6][ 主代码 ]。

2.使用 [<][>] 健滚动到 “ 蜂鸣器控制 ”(Buzzer

Control)。

3.有 21 个不同的等级，您可以使用 [<][>] 键滚动

到所需的蜂鸣器等级。

4.要想退出，请按 [#]。

辅助按钮

按下 (F) 或 (P) 键 2 秒钟可产生火警或紧

急报警。

广播门铃

每个键盘都可以进行门铃功能编程。如果系统中

存在多个键盘，则任一个键盘的门铃功能编程均

可广播至所有其它键盘。

根据以下步骤完成广播门铃功能：

步骤 1 - 完全编程一个键盘。

步骤 2 - 确认所有键盘连接到键盘总线。

步骤 3 - 输入 [,][8][ 安装员码 ][*] 进入键盘编程，

输入编程项 [994]。

步骤 4 - 按 [#] 退出。

Toggle Option

1 _ _ 4 _ _ _ _

[1] - A, B, C, 1 [4] - J, K, L, 4 [7] - S, T, U, 7 [0] - Space

[2] - D, E, F, 2 [5] - M, N, O, 5 [8] - V, W, X, 8

[3] - G, H, I, 3 [6] - P, Q, R, 6 [9] - Y, Z, 9, 0

键盘注册

按 [,][8][ 安装人员代码 ][000] 进入键盘编程。

[0] 分区 / 位置分配

[1]-[5] 功能键分配

键盘功能键

有关系统可用的所有功能键选项的完整列表，请参见系统的《安装手册》。

键盘编程

按 [,][8][ 安装人员代码 ][,] 进入键盘编程。

[001]-[064] 防区标签 1 到 64

例如：对防区 1，输入 [001]，对防区 2，输入 [002]，依此类推。默认值：

“Zone 1” - “Zone 64”

[065] 火警标签（28 个字符）

默认值：“Fire Zone”

[066] 设防失败事件信息

默认值 : “System Has Failed to Arm”

[067] 出现设防事件信息时发出警报

默认值 : “Alarm Occurred While Armed < >”

[071] 第一个用户显示掩码

[072] 第二个用户显示掩码

[073] 下载 LCD 信息的持续时间

默认值： 003

I______I______I______I

( 有效的输入是 000-255, 000 = 信息显示不

限 ) 这个编号代表信息出现并超时之后，按任意键清除已下载信息的次数 )。

位数选项有效范围

默认值

第

位数

分区分配（0

= 全局键盘）

0 - 8

I_______I

第

位数

位置分配

1 - 8

LCD=8

I_______I

功能键按钮

有效范围默认值功能

[1] 功能键 1 分配

00 - 32 03

有人设防

I_______I_______I

[2] 功能键 2 分配

00 - 32 04

无人设防

I_______I_______I

[3] 功能键 3 分配

00 - 32 06

门铃开 / 关

I_______I_______I

[4] 功能键 4 分配

00 - 32 14

探测器复位

I_______I_______I

[5] 功能键 5 分配

00 - 32 16

快速退出

I_______I_______I

[00] - 空 [11] - 访问代码编程 [23] - 旁路恢复

[01] - 分区 1 选择 [12] - 用户功能 [24] - 旁路组恢复

[02] - 分区 2 选择 [13] - 命令输出选项 1 [26] - 时间和日期编程

[03] - 有人设防 [14] - 命令输出选项 2 [27] - 分区 3 选择

[04] - 无人设防 [15] - * 全局留守布防 [28] - 分区 4 选择

[05] - 无进入延迟设防 [16] - 快速退出 [29] - 分区 5 选择

[06] - 门铃开 / 关 [17] - 激活有人 / 无人防区 [30] - 分区 6 选择

[07] - 系统测试 [18] - * 全局外出布防 [31] - 分区 7 选择

[08] - 旁路模式 [19] - 命令输出选项 3 [32] - 分区 8 选择

[09] - 故障显示 [21] - 命令输出选项 4 [33] - 本地 PGM 可编程输

出触发

[10] - 警报内存 [22] - * 全局撤防

* 仅可用在 PC1616/PC1832/PC1864 版本 4.2 或更高。

区段防区标签

[001]-[064] 1 - 64

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

[065]

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

[066]

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

[067]

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

默认值选项开关

I____I 1

按住 [P] 键（应急）提示打开按住 [P] 键（应急）提示关闭

I____I 2

自动设防控制 / 时间提示打开自动设防控制 / 时间提示关闭

I____I 3

快速设防提示打开快速设防提示关闭

I____I 4

内部设防提示打开内部设防提示关闭

OFF

I____I 5

快速退出提示打开快速退出提示关闭

OFF

I____I 6

恒温控制提示打开恒温控制提示关闭

OFF

I____I 7

确认全部故障提示打开确认全部故障提示关闭

OFF

I____I 8

音乐输入提示打开音乐输入提示关闭

默认值选项开关

I____I 1

用户发出的呼叫提示打开用户发出的呼叫提示关闭

OFF

I____I 2

备用

OFF

I____I 3

步行测试提示打开步行测试提示关闭

I____I 4

命令输出 1 提示打开命令输出 1 提示关闭

I____I 5

命令输出 2 提示打开命令输出 2 提示关闭

OFF

I____I 6

命令输出 3 提示打开命令输出 3 提示关闭

OFF

I____I 7

命令输出 4 提示打开命令输出 4 提示关闭

OFF

I____I 8

备用

[074] 按键选项

[076] 第一个键盘选项

[077] 第二个键盘选项

[080] PGM 终端 1

默认值： 01 I_______I _______I 1-14 PGM 可编程输出跟随 , 15 本地 PGM 可编

程输出脉冲 , 16 本地 PGM 可编程输出触发器

。

[082]

本地

PGM

可编程输出脉冲激活时间

默认值： 00 I_______I _______I 分钟 ( 有效范围 00-99)

默认值： 05 I_______I _______I 秒 ( 有效范围 00-99)

[101]-[108] 分区标签

例如：对分区

，输入区段

[101]

，对分区

，输入区段

[102]

，依此类推。

备注：分区 1 标签也用作系统标签

。

[120]-[151] 命令输出标签

默认值：

“Command_O/P_1” - “Command_O/P_4

”

[201]-[264] 门类型编程

您可以对键盘编程，以便为具体防区设置四种不同的门铃音。例如，对防区

1，输入区段 [201]，对防区 2，输入 [202]，依此类推。

[994][,] 启动全局键盘门铃广播

[995][,] 将键盘选项重置为出厂默认值

[996][,] 标签默认值

[997] 查看软件版本

[998][,] 启动全局标签广播

[999][,] 将 LCD EEPROM 重置为出厂默认值

键盘显示符号

默认值选项开关

I____I

[F] 火警键启用 [F] 火警键禁用

I____I

[A] 辅助键启用 [A] 辅助键禁用

I____I

[P] 应急键启用 [P] 应急键禁用

OFF

I____I

4-8

备用

默认值选项开关

I____I

编程时显示代码编程时显示 “

”

I____I

启用本地时钟显示禁用本地时钟显示

OFF

I____I

本地时钟显示

小时时间时钟显示

AM/PM

I____I

启用自动警报内存滚动禁用自动警报内存滚动

OFF

I____I

本地温度显示本地温度显示

I____I

启用旁路选项提示禁用旁路选项提示

OFF

I____I

备用

OFF

I____I

启用自动滚动开放区域禁用自动滚动开放区域

默认值选项开关

I____I

防区打开时启用门铃防区打开时禁用门铃

I____I

防区恢复时启用门铃防区恢复时禁用门铃

OFF

I____I

第 5 终端是键盘

PGM

输出第 5 终端是键盘防区输入

OFF

I____I

启用选择语言禁用选择语言

OFF

I____I

启用

Power LED

禁用

Power LED

I____I

Power LED

显示有

电源

Power LED

显示无

电源

I____I

设防时始终显示警报设防时不显示警报

OFF

I____I

启用低温警告禁用低温警告

备注 : 低温报警在 6°C (43°F) 触发 , 在 9°C (48°F) 恢复

。

区段分区标签

[101]-[108] 1 - 8

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

对于分区

命令

O/P

1 到

输入

[120]

到

[123]

对于分区

命令

O/P

1 到

输入

[136]

到

[139]

对于分区

命令

O/P

1 到

输入

[124]

到

[127]

对于分区

命令

O/P

1 到

输入

[140]

到

[143]

对于分区

命令

O/P

1 到

输入

[128]

到

[131]

对于分区

命令

O/P

1 到

输入

[144]

到

[147]

对于分区

命令

O/P

1 到

输入

[132]

到

[135]

对于分区

命令

O/P

1 到

输入

[148]

到

[151]

区段分区命令输出标签

[120]-[151] 1 - 8 1 - 4

I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I_____I

默认值选项开关

I____I

次蜂鸣声

禁用

OFF

I____I

2 “乒-乒”声禁用

OFF

I____I

3 “叮-咚”声禁用

OFF

I____I

4 警报声禁用

OFF

I____I

5-8 备用

AC – 表示控制主机连接有交流电。

Program（编程）- 表示系统处于安装人员编程状

态，或者键盘忙。

Bypass（旁路）- 表示有自动或人工旁路的防区。

9备用

Fire（火警）- 表示存储器中有火警。 10 Arm 设防模式） - 表示系统的设防模式。

Memory（记忆）- 表示存储器中有警报。 Stay（有人）– 表示系统留守设防。它会在

退出延迟开始时打开。

Ready Light（就绪指示灯）（绿色）- 如果就

绪指示灯发光，表示系统已准备设防。 Away（无人）– 表示系统外出设防。它会在

退出延迟开始时打开。

Armed Light（设防指示灯）（红色）- 如果设

防指示灯发光，表示系统已成功设防。 11

Chime

（门铃）- 当按下门铃功能键，启用系

统门铃时，此图标打开。再次按下门铃功能键禁用

门铃时，它会关闭。

System Trouble（系统故障）- 表示存在系统

故障。 12

OPEN（防区打开）- 此图标与时钟位的 1 和 2 一

起使用，指示系统上被触发的防区（非警报）。当

防区断路时，会显示 OPEN（打开）图标，和打开

防区会滚动显示遭到触发的号。

12 9

12 7

812

Notes / 笔记 :

_________________________________________

Notes / 笔记 :

_________________________________________

有限担保

Digital Security Controls (DSC) 担保，在购买产品后的 12 个月内，产品

在正常使用情况下不会存在材料和制造问题；若出现问题

Digital Security Controls 将在修理地收到退还的设备时选择修理或

更换故障设备。此担保仅适用于零部件和制造缺陷，不适用

于运输或搬运途中导致的损坏或在 Digital Security Controls 无法控

制的条件下导致的损坏，例如闪电、过电压、机械冲击、水

致损害，也不适用于因滥用、改变或不正确应用设备而导致

的损坏。

上述担保仅适用于原买家，并将取代所有其他明示或暗示

的担保。除此之外， DSC 不承担任何其他义务或责任。 DSC

不承担也不授权任何其他方代表其承担修改或改变本担保

的责任，也不承担关于本产品的任何其他担保或责任。

在任何情况下， Digital Security Controls 均不承担买方在购买、安

装、操作或不能操作本产品而导致的任何直接、间接或后果

性损失、预期利润损失、时间损失或任何其他损失。

警告：

Digital Security Controls

建议定期对整个系统进行全面测试。

但是，尽管频繁测试，由于罪犯分子破坏或电力中断等原因，

本产品仍有可能无法发挥应有的效果。

重要信息：在未经

Digital Security Controls

明确许可的情况下进行修

改或更改会导致用户操作本设备的权利失效。

重要 - 请仔细阅读：无论是单独购买，还是产品和部件附带

的 DSC 软件，其版权都有归属，对其购买要遵循以下条款：

·该最终用户许可协议 (“EULA”) 是您（已获取该软件和相关

硬件的公司、个人和团体）和加拿大泰科安全设备有限公司

分公司 —— 数码保安控制公司（“DSC”）之间的法律协

议。该公司是集成安防系统的制造商，也是您已获取的该软

件和相关硬件或部件的开发商。

·如果 DSC 软件产品（“ 软件产品 ” 或 “ 软件 ”）和硬

件绑定销售，但没有和新硬件绑定，那么您不能使用、拷贝

或安装软件产品。软件产品包括计算机软件，可能还有相关

多媒体、印刷资料和在线或电子文档。

·提供与另外最终用户许可协议相关的软件产品时附带的任

何软件按照该许可协议的条款对您实行授权。

·一旦安装、复制、下载、储存、访问或使用了软件产品，

您将无条件同意接受本 EULA 条款，即使本 EULA 被视为是先前

协议或合约的修订。如果您不同意该 EULA 中条款， DSC 则不

能将 SOFTWARE PRODUCT 授权给您，您则无权使用它。

软件产品许可

本软件产品受版权法，国际版权条约和其他相关知识产权法

和条款保护。本软件仅授权使用，非出售。

1. 协议授予 : 本EULA 授予您以下权利：

(a)软件安装与使用对于您获得的每个许可，您可以安装仅

一份软件产品拷贝。

(b)存储 /网络应用不能同时在或从不同计算机中安装、访

问、显示、运行、共享或使用该软件产品，包括工作站、终

端、或其他数字电子设备。换而言之，如果您有几个工作

站，那么你必须为每个要应用该软件的工作站获取一个许

可证。

(c)备份拷贝您可以多次备份拷贝该软件产品。但是在给定

时间仅允许安装每个许可的一份拷贝。备份拷贝仅用于存

档。除在本协议中明确说明，否则不得另外复制本软件产

品，包括其印刷品。

2. 其他权利和限制说明 :

(a)反向工程，反编译，反汇编限制除非或仅在法律明确准

许范围之内（尽管有此限制），否则您不能对本软件实施反

响工程、反编译或反汇编。未经 DSC 官方书面允许，您不能

改变或修改该软件，不能从软件删除任何专有标记、商标或

标志。您要采取合理措施来确保符合 EULA 的条款和条件。

(b) 组件拆分本软件产品作为独立的产品进行授权。它的

组件不能被拆分、并用于一个以上的硬件单元。

件，那么软件产品和硬件作为一个独立的集成产品被授权。

在这种情况下，正如 EULA 阐述一样，仅在使用硬件时才能

使用软件产品。

(d) 转售不得出租，租赁或出借本软件产品。也不得转于他

人使用，或在服务器或网站上发布。

(e) 软件转让如果您没有保留任何拷贝并且您要转让全部

软件产品（包括部件、多媒体和印刷材料、任何升级版本

和该 EULA），如果接收者同意 EULA 中条款，那么您可以将

您所有 EULA 授予的权利仅作为永久销售的一部分转让或将

硬件转让。如果本软件产品是旧版本的更新，转让必须包含

所有旧版软件产品。

(f) 终止协议如果您违反了 EULA 条款和条件， DSC 在不伤

害您其他权利的情况下终止该 EULA。在这种情况下，您必须

销毁所有软件产品拷贝及其所有部件。

(g) 商标本协议并未授权您是使用任何DSC商标权或其供应

商的服务商标。

3. 版权 : 本软件产品、附带印刷材料及软件拷贝中的所有所

属权和知识产权 (包括但不限于软件中的图片、照片和文字

归DSC 或其供应商所有。不得复制附带的印刷材料。通过使

用该软件产品而获悉的某些内容的所有所属权和知识产权属

于这些内容的拥有者，并受版权或其他知识产权法律和条约

保护。EULA 没有授权您使用这些内容。EULA 没有明确授予的

所有权利归 DSC 及其供应商所有。

4. 出口限制 : 不得将本软件产品出口或转出口到任何受加拿

大出口限制的国家，个人或团体。

5. 法律管辖 : 本软件许可协议受加拿大安大略省法律管辖。

6. 仲裁 : 由本协议引发的所有争议将根据仲裁法案进行仲

裁。仲裁是终局的，对双方均有约束力。双方都要服从仲裁

决定。仲裁地点应在加拿大，多伦多，仲裁语言应为英语。

7. 有限担保 :

(a)免除担保 DSC 只 “ 按原样 ” 提供软件本身，并不作其他方

面的担保。 DSC 不会保证该软件能满足您的需要、其运行无

障碍、无错误。

(b)改变运行环境针对因硬件操作环境改变或与非 DSC 软硬件

产品进行交互引起的问题， DSC 不负责任。

(c)赔偿责任限制；保证中的风险分配在任何情况下，如果任

何法令包含了该许可协议中没有阐述的担保或条件，根据该

许可协议条款， DSC 的全部责任局限于在您为该软件产品的

许可协议实际支付的数额和 5加元（CAD$5.00）中选择较大

的数额作为赔偿。因为有些司法管辖区不允许排除或限制间

接或意外损坏，所以上述限制可能对您不适用。

(d)免责声明本担保涵盖完整的担保条款，并取代任何及所有

其他担保，无论是明示还是暗示 (包括适销性和特定适宜性的

所有暗示保证 )，也取代 DSC 的所有其他责任或义务。DSC 不

承诺其他担保，不委托或授权他人修改或改变该担保，不承

担关于该软件产品的其他担保和责任。

(e)免除赔偿和担保限制在任何情况下，针对因违反该担

保、协议，或因法律疏忽和严重错误，或以其他法律理论为

基础而产生的任何特殊的、意外的、继发的或间接的损坏，

DSC 不承担任何责任。这种损害包括，但不仅限于，利润损

失，软件产品或任何相关的设备损坏，资金成本，替代或更

换设备的费用，设施或服务，停机时间，购买时间，包括客

户的第三方索赔和财产损失。

警告： DSC 推荐对整个系统定期进行系统检测。但是，即使

频繁检测，因为（但不限制于）非法入侵、电子干扰或其

他原因，本软件产品仍有可能运行不正常。

本手册中所包含的商标、标识、服务标记已在美国【或

其他国家】注册。严禁任何不当使用，如有违反，Tyco

International Ltd. 将在法律许可的最大范围内积极保护其

知识产权，包括诉诸刑事法律。Tyco International Ltd.

所有的商标是其各自所有者的财产，须经许可使用或适

用法律允许方可使用。

产品和技术规格如有变更，恕不另行通知。实际产品可能

与照片有所不同。并非所有的产品会包括所有功能，会因

地区而异，具体请联系您的销售代表。

Printed in

Other manuals for PK5500

Table of contents

Popular Keypad manuals by other brands

perixx

perixx Value Creator PERIPAD-205 user manual

Craftsman

Craftsman CMXZDCG440 user manual

Elkron

Elkron KP100 quick start guide

Velleman

Velleman PC50001 user manual

United Technologies

United Technologies interlogix ACL875SU installation manual

EMX Industries

EMX Industries KPX-100 instruction manual

GE 60-924-3-01 - ITI Simon 3 Wireless Touch Talk... Installation guidelines

Bentel Security

Bentel Security ALISON/S manual

Speco

Speco SG-WM200 instruction manual

DMP Electronics

DMP Electronics Thinline Aqualite 7000 Series Installation and programming guide

Crow

Crow Runner Series user guide

Nerival

Nerival NED-2022 user manual

Bosch

Bosch D1255RB operating instructions

Global Industrial

Global Industrial 493722 user manual

Genie

Genie Wireless Keypad instructions

Digit-KD

Digit-KD VISION series instruction manual

Risco

Risco RW132KPPW3 manual

eufy Security

eufy Security T8960 user manual

DSC PK5500 User manual

Popular Keypad manuals by other brands
