DSE DK-MG1 User manual

Document: DK-MG1 1D4 Document: DK-MG1 1D4 Document: DK-MG1 1D4
Page: 1 Page: 1
OWNER'S MANUAL DK-MG1 camera with recorder mug for drinks
DSE srl - Digital Surveillance Equipment - www.dse.eu
DK-MG1
Camera with recorder mug for drinks
PRODUCT DESCRIPTION
The DK-MG1 is a VCR equipped with a built-in camera concealed in a thermos for drinks that
allows hidden cameras professional level; It is also equipped with high-sensitivity microphone.
ACCESSORIES AND PRODUCT DETAILS
• Thermos beverage
• Extra cover with camera and recorder
• USB cable
• 8GB Micro SD card with SD adapter
1. Slot external memory 1. Slot external memory
2. Formatting external memory key 2. Formatting external memory key
3. Microphone 3. Microphone
4. Switch ON / OFF Vibration 4. Switch ON / OFF Vibration
5. On / off key and start / stop 5. On / off key and start / stop
registration
6. RESET hole 6. RESET hole
7. HD / VGA Selector 7. HD / VGA Selector
8. USB 8. USB
9. Objective CMOS 9. Objective CMOS
OPERATION DVR
Insert Micro SD card
The first thing to do is to insert the micro SD card into the compartment with the inscription of the
MICRO SD DK-MG1. To access the SD card compartment is necessary to open the lid as shown
in the picture below.
E 'can use SD cards with capacities up to 32 GB. Attention to the SD card inserting direction that
will slide in its seat only with the gold contacts facing downwards.
The package includes a micro SD card the memory capacity of 8GB.
Charge the battery
Before using the equipment it is advisable to fully charge the battery.
To do this we need to open the cover as shown previously for the insertion of the SD card, and
then connect the cable, supplied in the package, to the USB port of the computer or to a 5V
battery charger with USB port as our RE-AL4USB . At this point turns on a green LED that a full battery charger with USB port as our RE-AL4USB . At this point turns on a green LED that a full battery charger with USB port as our RE-AL4USB . At this point turns on a green LED that a full
charge will turn off. The duration of the refill lasts about two hours. Once the charging close the
lid to proceed to the first recording.
registration
Once the optimal settings set you can proceed with registration. Pressing the ON / REC button
(with the lid on the button is in correspondence of the area 10 in the figure below) the device turns
on and starts recording.

Document: DK-MG1 1D4 Document: DK-MG1 1D4 Document: DK-MG1 1D4
Page: 2 Page: 2
OWNER'S MANUAL DK-MG1 camera with recorder mug for drinks
DSE srl - Digital Surveillance Equipment - www.dse.eu
It lights the blue LED (standby) and then the red (rec) together to indicate that the device is
recording. To stop recording, you must hold the ON / REC (5/10 in the figure), the device after
stopping the recording will go out and save the file to the memory card inserted. The
intermittent flashing of the red LED indicates the
presence of an anomaly. To check the correct
integration and smooth operation of the SD card.
vibration switch
If you move the switch to ON the vibration function is activated. The device will vibrate to alert the
recording starting and stopping.
HD / VGA Selector
With this selector will tax the resolution
image. The HD resolution of 1280x720 and VGA is 640x480. The recordings in HD resolution
occupy more space in memory. In HD resolution you can store up to 10 hours on a 32GB SD
card. In VGA resolution on the same SD card you store up to 16 hours of recording.
Viewing files on PC
To manage the files recorded with computers you can connect the device to your PC with the
USB cable. E 'can connect the DK-MG1 to your computer or just remove the micro SD card and
insert it into an SD card reader. Once connected to the PC press the Room button ignition, the
device will be present in the computer's resources such as removable disk drive (mass storage)
and behaves like a common USB stick. The video files are saved in MOV format. Once copied or
moved
the PC file you can
play them with any media player like VLC Videolan or Windows Media Player.
Setting Date and Time
The DK-MG1 sovraimprime date and time on the recordings. To update the date and time, if they
are not correct, you have to create a text file with the Windows Notepad named settime.txtare not correct, you have to create a text file with the Windows Notepad named settime.txt
In this file you have to write the current date and time in the following format:
04.17.2014 10:28:00
(First 4 digits = year = 2 digit month, 2-digit day = space = 2 digit hour, 2 digits = minutes, 2
= second digit).
The example set April 17 2014 hours 10:28.
The file must be saved and copied to the root folder of the memory of DK-MG1.
Remove the DK-MG1 from the USB port and turn it on to store the new time.
FORMAT button
The DK-MG1 has the ability to format the memory card inserted. To do this, press and hold the
FORMAT buttons and ON / REC together for a few seconds. BLUE LED lights up, do not let the
buttons until the red LED will not blink then leave.
The device memory is now completely empty.
RESET hole
If due to incorrect or inconsistent commands, the device should cease to respond to commands it
is possible to perform a RESET by inserting a pointed object into the reset hole. Hold for a few
seconds to restore the factory settings.
Main features
Sensor 5 megapixel CMOS
Resolution VGA 640X480 HD
1280X720
Frame Rate 30f / sec
video Format MOV
overlay Date hour
Time maximum of
continuous recording
3 hours in VGA resolution two hours in
HD resolution
Temperature of
operation
- 10 ° + 60 °
Notifications 2 LED
operating temperature -10 ° to + 60 ° C operating temperature -10 ° to + 60 ° C
Memory MicroSD
Memory Capacity Maximum 32GB
Supply 5V DC power supply
USB Interface USB 2.0 Mini
Operating system All
Consumption 190 mA - 390 mA
Weight 276g
dimensions 66x165 mm
