DT Research ACC-DC282-01 Assembly instructions

BASIC OPERATION GUIDE
Instrucons:
Connect the AC-DC adapter cable to the USB
Type-C port, and then insert the Tablet system
properly for charging.
Thank you for purchasing the Desktop Charging
Cradle (ACC-DC282-01) by DT Research, available for
charging one (1) Rugged Tablet. The Desktop Charging
Cradle features one (1) USB Type-C port (as power
input), one (1) LAN port, one (1) HDMI-output port,
and four (4) USB ports.
CAUTION:
This charger must only be used with the specic tablet models for which it is designed.
Failure to do so may result in ba�ery or charger damage, or personal injury.
Package Contents:
1. Desktop Cradle
2. Basic Operaon Guide
Desktop Charging Cradle
Precauons
1. Always exercise care when operang and handling.
2. Do not disassemble any poron of the charger and adapter, as this will void any product
warranty.
3. Do not use any power adapter other than the one provided with the device or acquired
from the manufacturer or its partners.
4. In the unlikely event that abnormal noise, strange odor, or smoke is present, immediately
disconnect all power sources. Please report the problem to your device provider
immediately.

signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 www.dtresearch.com
Copyright © 2020, DT Research, Inc. All Rights Reserved. BOG 052620 DC282 ENG
I/O Ports
USB Type-C (power-input) 1
LAN Port (oponal) 1
HDMI 1
USB Ports 4 (2 on the back panel, 1 on the le side, 1 on the right side)
Mechanical and Environmental
AC/DC Adapter Input: 100 – 240V AC; Output: 20V DC, 3.25A
Dimensions (H x W x D) 1.93 in x 7.13 in x 6.10 in / 49.1 mm x 179.7 mm x 151.3 mm
Weight 1.39 lbs / 630 g
Temperature Operaon: 0°C – 40°C; Storage: -20°C – 60°C
Humidity 0% – 90% non-condensing
* Specicaons subject to change without noce.
Specificaons
Back View
Side View
CAUTION:
Only use the Power Adapter that is provided from DT Research.
The power adapter, charger, and the tablet may become hot during normal use. Allow for
proper venlaon around the power adapter, charger, and charging tablet.
Never force a tablet into a charging bay. Check for any obstrucons before inseron.
USB Type-C Port
(power-input)
LAN Port HDMI Output
USB Ports
USB Port USB Port
