DT Research DT301 Assembly instructions

BASIC OPERATION GUIDE
DT301/ DT311 Baery Charger Kit
Instrucons:
The charger is designed to charge one DT301/ DT311 baery pack. To connect the
baery pack to the charger:
• Place the charger pack with LED-light facing up.
• Place the baery with top facing up (top is the side that is viewable when on
the DT301/ DT311 tablet).
• Align the baery pin connector facing the charger opening. Please see images.
Slowly insert the baery pack into the charger,
making sure the baery pin connector lines
up with the charger pins. Push the baery
pack all the way into the charger, the LED light
on the charger should come on.
Thank you for purchasing the DT301/ DT311 Baery Charger Kit by DT Research.
This device enables charging of one DT Mobile Tablet (DT301/ DT311) baery pack.
Please follow this guide for operaonal instrucons.
CAUTION: This charger must only be used with the specific baery models for which it is
designed. Failure to do so may result in baery or charger damage, or personal injury.
ACC-001-311 for charging the 45W baery pack
ACC-001-34 for charging the 60W or 90W baery pack

Indicator Light:
The top of the Baery Charger features an LED light to
indicate the baery charge status.
Package Contents:
1. DT301/ DT311 Baery Charger
2. AC Power Adapter
3. AC Power Cord
4. Basic Operaon Guide
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2017, DT Research, Inc. All Rights Reserved. BOG 120717 311CHENG
Light color Status
Yellow Charging
Green Fully Charged
CAUTION: Only use the AC Power Adapter that is provided with your charger.
The power adapter, charger and the baery may become hot during the normal use.
Allow for proper venlaon around the power adapter, charger and charging baeries.
Never force a baery into the charger. Check for any obstrucons before inseron.
