DT Research DT1363 Assembly instructions

DT1363
ENGLISH
Embedded Controller/
System
BASIC OPERATION GUIDE
DT1363
ENGLISH 4
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131 hp://www.dtresearch.com
Copyright © 2016, DT Research, Inc. All Rights Reserved.
BOG 091515 DT1363 ENG
Introducon
Thank you for acquiring the latest addion to DT Research’s line of Embedded Controllers/ Systems
- the DT1363, featuring compact, robust construcon powered by the high-performance and energy
efficient Intel® Core™ i7 processor. The DT1363 supports major embedded operang msystems as
well as Microso® Windows® operang systems and provides complete soluons for a variety of
compung needs. The user is offered a choice of soware soluons on a plaorm characterized by
the following:
High-integraon and energy-efficient processor technology•
Expanded graphics capabilies for mulmedia applicaons•
Robust construcon for reliable operaon•
Cost-effecve compung in compact and versale packaging•
Package Contents
1. DT1363
2. AC/DC Power Adapter
3. Basic Operaon Guide
NOTE: The actual package contents may vary depending on the configuraon acquired.
21
Opons
The DT1363 is designed to work with a range of custom and off-the-shelf opons to enhance its
applicability for various deployments.
Built-in wireless LAN, with external antenna•

DT1363
ENGLISH 23ENGLISH
Precauons
Always exercise care when operang and handling the DT1363.•
Never disassemble any poron of the enclosure as this will void any product warranty on the DT1363.•
Do not use any AC/DC adapter other than the one provided with the DT1363 or acquired from•
the manufacturer or its partners.
In the unlikely event that smoke, abnormal noise, or strange odor is present, immediately power•
down the DT1363 and disconnect all power sources.
Please report the problem to your device provider immediately.•
The DT1363
NOTE: If you are connecng an DT1363 player to ONLY ONE screen, do not use its A0 port. Instead,
you can use the A1 or A2 port.
Powering ON and OFF
The Power Buon is located in the front of the DT1363. The Power Buon may be configured to
funcon differently depending on the power opons of the operang system. In general, to turn the
DT1363 on, push and release the Power Buon on the front bezel. The power LED will be lit (blue)
and the corresponding interface will be displayed on the display monitor.
To turn offthe device, again depending on soware operang system, push and release the Power
Buon or use a soware shutdown interface. In the event of system lockup, the Power Buon may
be used to perform a reset on the device. To do that, push and hold the Power Buon for at least 4
seconds. The system will shut down and all unsaved work may be lost. Pushing on the Power Buon
again will restart the device.
Device Ports
The DT1363 features an opmal set of I/O ports while preserving the compact size of the system.
The HDMI connectors, network (10/100/1000 BaseT Ethernet), and power ports are supplemented
by a set of USB (4) and audio (1) ports. Through its USB ports, the DT1363 supports a wide range
of USB-based peripherals, applicable in providing the means for soware installaon, applicaon
storage, data storage, and system soware recovery and updates.
Memory and Storage
The DT1363 may be available in storage configuraons ranging from 32GB to 512GB Flash.
Depending on base soware configuraon, the user may use the internal memory of the DT1363
for user’s installed soware and storage. The user may also supplement storage space with USB-based
peripherals such as flash disks. RAM capacity is from 4GB to 8GB.
Front View
Audio jack HDMI (A0) 1920 x 1080 @ 60Hz
(Hot-plug not supported)
USB 3.0 ports HDMI (A1) 3840 x 2160 @ 24Hz
1920 x 1080 @ 60Hz
Power buon HDMI (A2) 3840 x 2160 @ 24Hz
1920 x 1080 @ 60Hz
DC-in Ethernet ports
USB 2.0 ports
Rear View
A
B
C
D
E
F
G
ED FG
B
AC
