INTRODUCTION
Thank you for acquiring the latest addion to DT Research’s line of tablets — the
DT340T. Featuring a slim yet robust enclosure, the DT340T with a 14” TFT display is
powered by the Intel® processor, oering opmal combinaons of performance and
power savings. The DT340T is available with Microso® Windows® operang system.
The soware operang system features web browser, client/ server compung
soware, media player, accessories, and applicaons support.
PACKAGE CONTENTS
• One DT340T with Two Baery Packs
• AC-DC Power Adapter with Power Cord
• Basic Operaon Guide
DT340T
Federal Communication Commission Interference
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protecon against harmful interference in
a residenal installaon. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instrucons, may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcular
installaon. If this equipment does cause harmful interference to radio or
television recepon, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Cauon: Any changes or modicaons not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operaon is subject to the following two condions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operaon.
This device and its antenna(s) must not be co-located or operang in
conjuncon with any other antenna or transmier.
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du
Canada.

2 3
PRECAUTIONS
• Always exercise care when operang and handling the DT340T
• Do NOT apply excessive pressure to the display screen.
• We recommend using the Digital Pen (oponal) to keep the screen clean.
• Avoid prolonged exposure of the display panel to any strong heat source.
Wherever possible, the DT340T should face away from direct light to reduce
glare.
• If the AC-DC power adapter is used to recharge or power the tablet, do NOT use
any AC-DC adapter other than the one provided or acquired from the manufac-
turer or its partners.
• In the unlikely event that smoke, abnormal noise, or strange odor is present,
immediately power o the DT340T and disconnect all power sources. Report the
problem to your device provider immediately.
• Never aempt to disassemble the DT340T, as this will void the warranty.
BASIC FEATURES
The DT340T wireless tablet integrates a bright display, one USB port, and embedded
networking elements such as wireless LAN and Bluetooth or oponal mobile
broadband. The DT340Tis complemented by a suite of accessories, including baery
expansion, charging cradles, and baery charger kit, for a comprehensive user
experience.
A DT340T typically integrates an 802.11ac wireless LAN (WLAN) adapter that may
connect to other wireless devices or access points. If your DT340T does not come
with such a network adapter, please consult your device provider to establish the
desired network connecvity.
Power/Battery LED Status:
• Blue indicates the baery is 25% to 100% charged
• Blinking blue indicates the baery is charging
• Orange indicates that the baery is between 11% to 25%
• Blinking Orange indicates that the baery is below 10%
Button Functions
BUTTON ACTION
Power Buon
Programmable Buons
Baery Latch *Push the switch up to unlock the latch, then slide the latch le to remove the baery.
Input/ Output Ports
Ethernet Port (RJ45)
USB 3.0 Port
HDMI Output
Audio Jack
DC-in
Smart Card Reader
Tabletop Stand
1
2
3
A
B
C
D
F
G
E
Power LED Baery Indicator
3
3
F
E
A
C
G
D
B
B
2
1

Start Up
If the power up (from Standby mode or otherwise) is successful, the appropriate
interface will be displayed aer a launch sequence of several seconds. The wireless
LAN connecon may take 10-15 seconds to be established.
Configuring the Mobile Tablet
The DT340T may be congured using the ulies and methods dictated by the
soware operang system. The DT340T should be congurable for various properes
such as user proles, network features, and several system elements.
Wireless Networking
Wireless LAN
The DT340T is oen delivered with an embedded (user-inaccessible) 802.11ac WLAN
adapter equipped with a hidden custom antenna.
• Through the support of typical WLAN adapters, the DT340T should be able to
detect all 802.11 access points in the vicinity for you to select the access point of
your choice for connecon.
• The SSID and WEP/WPA/WPA2 (if enabled) parameters on the DT340T and the
access points have to match. The SSID is case-sensive and it is recommended
that you enable WEP/WPA/WPA2 encrypon (or advanced alternaves) for
secure access.
• When WEP/WPA/WPA2 is enabled, you may need to consult your network
administrator or your networking equipment literature to properly congure
associated sengs such as Authencaon mode, etc.
• Refer to the access point operang manuals for seng up the 802.11 access
points.
Bluetooth
The Bluetooth conguraon applicaon is enabled from the System Tray or from the
Windows Mobility Center. Follow the instrucons and opons provided within the
applicaon to congure and invoke Bluetooth connecvity with the corresponding
peripherals.
OPERATION
Powering ON and OFF
To acvate the DT340T, push and quickly release the Power Buon. The display will
come on in a few seconds. To put the DT340T in Standby mode, push and quickly
release the Power Buon. To turn the DT340T o for extended storage, power o
safely using any soware funcon that “shuts down computer” provided in the
soware operang system.
NOTE:
The baery packs shipped with your tablet may be low in power—please use
the AC-DC adapter with the DT340T when seng up for the rst me to fully
charge the baery packs. You may charge the baery packs while aached to
the DT340T, or with the oponal external baery charger kit.
NOTE:
When the baery pack(s) is (are) charging, the blue-colored Baery LED should
blink slowly. If plugging in the AC-DC adapter does not trigger this blinking
acvity and the LED stays dark, the baery pack(s) may have been drained
substanally. Try unplugging/ replugging the AC-DC adapter to the DT340T a few
mes to acvate the charging process.
NOTE:
To conserve power, use (push and quick release) the Power Buon to put the
tablet in “Standby” mode while not in use. Pushing briey on the same buon
will wake up the system within seconds.
NOTE:
Avoid using the Power Buon (“hold 4+ seconds” feature) to turn o the
tablet—this form of hardware shutdown is intended to be a means of recovery
from lockups, and not as normal operaon.
45

USING THE MOBILE TABLET
Peripherals Support
Through its USB 3.0 ports, the DT340T supports a wide range of USB-based peripher-
als. These peripherals are applicable for soware installaon, applicaons storage,
data storage, and system soware recovery and updates.
For More Support
Users can download the Tablet Modules Basic Operaon Guides from the DT
Research website.
If the DT340T comes with a mobile broadband module, please contact your product
and/or service provider for the SIM Card installaon procedures.
67
To Hold the Tablet
Le hand: grip the le back side of the tablet
with your le hand four index ngers, with
thumb resng on the top of the back side of the
tablet and palm securely against the back.
Right hand: grip the right back side of the tablet
with your right hand four index ngers, with
thumb resng on the top of the back side of the
tablet and palm securely against the back.
ENERGY STAR® Partner
As an ENERGY STAR® Partner, DT Research Inc. follows the EPA’s product
qualicaon and cercaon process to ensure the products marked with the
ENERGY STAR® logo are ENERGY STAR® qualied for energy eciency.
The ENERGY STAR® program specicaons for computers were to promote
energy eciency and reduce air polluon through more energy-ecient
equipment in homes, oces, and factories. One way products achieve this
goal is by using the Microso Windows power management feature to reduce
power consumpon when the product is not in use. The power management
feature enables the computer to iniate a low-power or “sleep” mode aer a
period of user inacvity.
To take advantage of these potenal energy savings, users should use the
default power management sengs that are provided with ENERGY STAR
qualied computers. The default power management sengs on ENERGY
STAR® qualied computers are preset to behave in the following ways :
Turn o display aer 10 minutes of user inacvity.
Iniate a low power sleep mode for the computer aer 30 minutes of user
inacvity.
Briey press the power buon will bring the computer out of sleep mode.
Addional informaon on the ENERGY STAR® program, its environmental
benets and the potenal energy and nancial savings of the power manage-
ment feature can be found on the EPA ENERGY STAR® Power Management
Web site at
hp://www.energystar.gov/powermanagement.
