D 232 / D 232 ONE

TECHNICAL MANUAL

V2020.05

1. GENERAL ............................................ 3

2. OVERVIEW ........................................... 6

3. SERVICE KITS...................................... 7

4. SERVICE AND CARE ........................... 13

5. TROUBLE SHOOTING.......................... 14

6. SMALL SERVICE ................................. 17

7. FULL SERVICE .................................... 24

D 232 - Technical Manual V2020.05 3

1. GENERAL

1.1 VALIDITY

This manual describes the component specied on the front page and the footer. This manual is

valid for the design of the product as of 29.05.20. Deviations are possible and all items are subject to

technical changes.

1.2 SAFETY

The safety and warning instructions are classied as follows:

DANGER

...indicates a hazardous situation that, if not avoided, will result in death or serious injury.

CAUTION

… indicates a hazard with a medium level of risk which, if not avoided, may result in minor or

moderate injury.

NOTE

… indicates a potentially hazardous situation that may result in damage to property.

1.3 TARGET GROUP

This manual is intended for the user of the component and dealers. This manual offers the

experienced user the possibility to carry out minor service work himself. If you have any doubts about

your own abilities, you should denitely contact a specialist or a DT Swiss Service Center.

Any warranty claims will lapse if work is not carried out properly.

1.4 LAYOUT

The cover page and the footing provide information about the type of product and manual as well as

the version of the manual. The DT Swiss contact details can be found on the back. A list of all DT Swiss

service centers can be found at www.dtswiss.com.

This manual is intended for being printed as an A5 booklet. Only print this manual if electronic usage is

not possible.

1.5 DT SWISS MANUAL CONCEPT

The DT Swiss manuals are split into the following types of manuals:

• User Manual: Information for the end user on how to install and use the component.

• Technical Manual: Detailed information for the end user and the dealer on how to maintain the

component, spare parts and technical data.

1.6 HOW TO USE THE MANUAL

The steps described in this manual must be carried out in the order they are shown. If steps are

ignored or executed in a wrong order, the function of the component cannot be guaranteed.

Instructions begin with the table «Preparatory Steps» and end with the table «Closing Steps». The

instructions in these tables must be carried out.

1.7 CROSS REFERENCES

In order to simplify the use of this manual, some text is edited as hypertext. After clicking you will be

automatically redirected to the target of the reference.

If the text is formatted underlined, it is a cross-reference.

Example: Example: Click here:“1. General” on page 3 to jump to the beginning of this chapter.

1.8 GENERAL MAINTENANCE INFORMATION

Unless otherwise specied, moving parts, threads, O-rings and seals must be greased before

assembly.

CLEANING

For an optimal result of the maintenance works, every component that will be disassembled must be

cleaned. Only use cleaners which do not damage the components. Especially the cleaning of O-rings

and sealings requires mild cleaners. Observe the instructions for use of the respective cleaner.

DT Swiss recommends the following cleaners:

• Motorex Rex

• Motorex Swissclean

• Motorex OPAL 2400, 3000 OPAL, OPAL 5000

Use soapy water or similar mild cleaners for external cleaning.

TOOLS

To ensure a damage-free mounting and dismounting of the components, only use the tools which

are mentioned in this manual. Special tools are indicated at the beginning of a chapter in the table

"Required material".

The use of different tools is at the discretion of the user. If components are damaged by the usage of

differing tools, the user is liable.

DT Swiss special tools are precision tools. Damage-free mounting and dismounting of the components

can only be ensured if the tools are working properly and if the condition of the tools are perfect.

Always keep the tools in their original packaging or adequate devices to prevent damage.

D 232 - Technical Manual V2020.05 5

1.9 ENVIRONMENTAL PROTECTION

The statutory regulations shall apply. Whenever possible, avoid creating waste. Waste, especially

carbon, lubricants, cleaners and any other uids must be disposed in an environmentally compatible

manner.

Only print this manual if electronic usage is not possible.

1.10 EXCLUSION OF LIABILITY

The activities listed in this manual may only be carried out by persons with sufcient specialist

knowledge. The user is liable for any damage or consequential damage caused by wrongly maintained

or installed components. If you have doubts, please contact your region‘s DT Swiss pro level service

center.

1.11 WARRANTY

Warranty conditions can be found at www.dtswiss.com.

2. OVERVIEW

1617

Pos Description included in Service Kit

1 barrel nut (2x) D232 SEAT CLAMP KIT / D232 SEAT CLAMP SCREW KIT

2 upper seat clamp D232 / D232 ONE SEAT CLAMP KIT

3lower seat clamp D232 / D232 ONE SEAT CLAMP KIT

4seat clamp screw (2x) D232 / D232 ONE SEAT CLAMP KIT

D232 / D232 ONE SEAT CLAMP SCREW KIT

5 slider tube D232 / D232 ONE SLIDER TUBE KIT

6coil spring D232 REPLACEMENT SPRING

7outer coil spring guide D232 GUIDING KIT

8upper stop for release piston D232 LATCH SYSTEM KIT

9release piston D232 LATCH SYSTEM KIT

10 coil spring release piston D232 LATCH SYSTEM KIT

11 guide for release piston D232 LATCH SYSTEM KIT

12 raster ring D232 LATCH SYSTEM KIT

13 O-ring D232 GUIDING KIT

14 lock nut D232 SLIDER TUBE NUT KIT

15 guide ring D232 GUIDING KIT

16 guide key D232 / D232 ONE SLIDER TUBE KIT

17 latch (5x) D232 LATCH SYSTEM KIT / D232 BALL REPL. KIT*

18 seat tube D232 / D232 ONE SEAT TUBE REPLACEMENT*

19 internal actuating spoke D232 QUICK CONNECTOR KIT

20 O-ring D232 QUICK CONNECTOR KIT

21 lower seat tube cover D232 / D232 ONE QUICK CONNECTOR CAP KIT

22 quickrelease slider D232 QUICK CONNECTOR KIT

23 quickrelease housing D232 QUICK CONNECTOR KIT

24 O-ring D232 QUICK CONNECTOR KIT

*only available for DT Swiss Service Center

D 232 - Technical Manual V2020.05 7

3. SERVICE KITS

D232 SLIDER TUBE KIT

Item No: DWKD232S30508S

1x guide key

1x slider tube aluminium

1x spring guide

The spring guide is pre-assembled in the

slider tube.

D232 ONE SLIDER TUBE KIT

Item No: DWKD232S30507S

1x guide key

1x slider tube carbon

1x spring guide

The spring guide is pre-assembled in the

slider tube.

D232 LATCH SYSTEM KIT

Item No: DWKD232X30510S

1x upper stop for release piston

1x release piston

1x coil spring release piston

1x guide for release piston

1x raster ring

5x latch

D232 QUICK CONNECTOR CAP KIT Ø27.2

Item No: DWKD232X30511S

1x lower seat tube cover Ø27.2 mm

1x O-ring Ø18 x 2.5 mm

D232 QUICK CONNECTOR CAP KIT Ø30.9

Item No: DWKD232X30512S

1x lower seat tube cover Ø30.9 mm

1x O-ring Ø22 x 2.5 mm

D232 ONE QUICK CONNECTOR CAP KIT

Ø27.2

Item No: DWKD232X30514S

1x lower seat tube cover Ø27.2 mm

1x O-ring Ø18 x 2.5 mm

D232 ONE QUICK CONNECTOR CAP KIT

Ø30.9

Item No: DWKD232X30513S

1x lower seat tube cover Ø30.9 mm

1x O-ring Ø22 x 2.5 mm

D232 QUICK CONNECTOR KIT

Item No: DWKD232X30515S

1x quickrelease housing

1x O-ring Ø6 x 1.5 mm

1x quickrelease slider

2x threaded pin M4 x 4 mm

1x Internal actuating spoke

D 232 - Technical Manual V2020.05 9

D232 SLIDER TUBE NUT KIT

Item No: DWKD232X30516S

1x guide ring Ø28 x 32 x 10 mm

1x lock nut

1x wiper seal

The wiper seal and guide ring are pre-

assembled in the lock nut.

D232 GUIDING KIT

Item No: DWKD232X30517S

1x guide ring Ø25 x 28 x 10 mm

2x O-ring Ø23 x 3 mm

1x outer coil spring guide Ø27.5 x 20.9 x 27 mm

D232 ONE CARBON SEAT CLAMP KIT

Item No: DWKD232C30518S

1x upper seat clamp carbon

1x lower seat clamp carbon

2x barrel nut

1x seat clamp screw Ti M6 / Ø10 x 36 mm

1x seat clamp screw Ti M6 / Ø10 x 46 mm

D232 ALUMINIUM SEAT CLAMP KIT

Item No: DWKD232S30519S

1x upper seat clamp aluminium

1x lower seat clamp aluminium

2x barrel nut

1x seat clamp screw M6 / Ø10 x 36 mm

1x seat clamp screw M6 / Ø10 x 46 mm

D232 ONE TITAN SEAT CLAMP SCREW KIT

Item No: DWKD232S30520S

2x barrel nut

1x seat clamp screw Ti M6 / Ø10 x 36 mm

1x seat clamp screw Ti M6 / Ø10 x 46 mm

D232 STEEL SEAT CLAMP SCREW KIT

Item No: DWKD232N30521S

2x barrel nut

1x seat clamp screw M6 / Ø10 x 36 mm

1x seat clamp screw M6 / Ø10 x 46 mm

D232 REPLACEMENT SPRING

Item No: DWKD232N30522S

1x coil spring
