DTS SOPRANO Series User manual

User Manual Ver. 1.0.1 1 di 31
SOPRANO
Release
1.0.1
Code: 0517I367
For more information
Language
EN
All other trademarks, both marked and not marked, are the property of their respective owners.

User Manual Ver. 1.0.1 2 di 31
SOPRANO
ITA
Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è
assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può
essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S.
Illuminazione.
D.T.S. Illuminazione si riserva il diritto di apportare senza preavviso cambiamenti e modifiche estetiche funzionali
o di design a ciascun proprio prodotto. D.T.S. Illuminazione non assume alcuna responsabilità sull’uso o
sull’applicazione dei prodotti o dei circuiti descritti.
ENG
The information contained in this publication has been carefully prepared and checked. However, no
responsibility will be taken for any errors. All rights are reserved and this document cannot be copied,
photocopied or reproduced, in part or completely, without prior written consent from D.T.S. Illuminazione
D.T.S. Illuminazione reserves the right to make any aesthetic, functional or design modifications to any of its
products without prior notice. D.T.S. Illuminazione takes no responsibility for the use or application of the products
or circuits described herein.
FRA
Les informations contenues dans le présent manuel ont été rédigées et contrôlées avec le plus grand soin. Nous
déclinons toutefois toute responsabilité en cas d'éventuelles inexactitudes. Tous droits réservés. Ce document
ne peut être copié, photocopié ou reproduit, dans sa totalité ou partiellement, sans le consentement préalable
de D.T.S. Illuminazione.
D.T.S. Illuminazione. se réserve le droit d'apporter toutes modifications et améliorations esthétiques,
fonctionnelles ou de design, sans préavis, à chacun de ses produits. D.T.S. Illuminazione décline toute
responsabilité sur l'utilisation ou sur l'application des produits ou des circuits décrits.
ESP
Las informaciones contenidas en este documento han sido cuidadosamente redactadas y controladas. Con todo,
no se asume ninguna responsabilidad por eventuales inexactitudes. Todos los derechos han sido reservados y
este documento no puede ser copiado, fotocopiado o reproducido, total o parcialmente, sin previa autorización
escrita de D.T.S. Illuminazione.
D.T.S. Illuminazione se reserva el derecho a aportar sin previo aviso cambios y modificaciones de carácter
estético, funcional o de diseño a cada producto suyo. D.T.S. Illuminazione no se asume responsabilidad de
ningún tipo sobre la utilización o sobre la aplicación de los productos o de los circuitos descritos.

User Manual Ver. 1.0.1 3 di 31
SOPRANO
Table of Contents
1Symbols........................................................................................................................................................ 5
2General Warning.......................................................................................................................................... 6
3Safety and Operation ................................................................................................................................... 6
3.1 Fire prevention..................................................................................................................................... 6
3.2 Prevention of electric shock................................................................................................................. 7
3.3 Level of protection IP........................................................................................................................... 7
3.4 Safety................................................................................................................................................... 7
3.5 Waste Electrical and Electronic Equipment (WEEE) directive............................................................. 8
4General Warranty Conditions....................................................................................................................... 8
5Features....................................................................................................................................................... 9
5.1 Color Generation - Only HQS models.................................................................................................. 9
5.2 White Generation - Only HDW models................................................................................................ 9
5.3 Single White models............................................................................................................................ 9
5.4 Control ................................................................................................................................................. 9
6Technical Specifications............................................................................................................................. 10
6.1SOPRANO 3...................................................................................................................................... 10
6.2 Soprano 5 .......................................................................................................................................... 11
6.3 Zoom Lens......................................................................................................................................... 12
6.4 Dimensions........................................................................................................................................ 13
7Included Items............................................................................................................................................ 14
8Installation.................................................................................................................................................. 14
8.1 Safety Cable ...................................................................................................................................... 14
9Mains Connection....................................................................................................................................... 15
9.1 Protection........................................................................................................................................... 16
10 DMX Signal Connection............................................................................................................................. 16
10.1 DMX terminator.................................................................................................................................. 16
10.2 DMX Modes....................................................................................................................................... 17
10.3 Setting Up the DMX address ............................................................................................................. 17
11 RDM-DMX - Display Functions, Error messages....................................................................................... 18
12 Updating the Firmware............................................................................................................................... 18
13 Accessories and their installation............................................................................................................... 18
13.1 Accessories on Request.................................................................................................................... 18
13.2 Accessories specifically designed for TENORE and SOPRANO ...................................................... 18
13.3 Install Zoom Lens Assembly.............................................................................................................. 19
13.4 Zoom- Foscus Adjustment................................................................................................................. 20
13.5 Shutter Blades rotation ...................................................................................................................... 21
13.5.1 Gel Holder ................................................................................................................................. 21
13.5.1.1 GEL placement.................................................................................................................. 21
13.5.2 Gel Holder placement................................................................................................................ 22
13.5.3 Gobo Holder .............................................................................................................................. 23
13.5.4 Gobo Holder placement............................................................................................................. 24

User Manual Ver. 1.0.1 4 di 31
SOPRANO
13.5.5 Iris placement.............................................................................................................................25
13.5.6 Barndoors ..................................................................................................................................26
13.5.7 Barndoors placement.................................................................................................................27
13.5.8 Safety cable for Barndoors and Gel Holder ...............................................................................27
14 Periodic Cleaning........................................................................................................................................28
14.1 Opening the Housing..........................................................................................................................28
14.2 Lenses................................................................................................................................................28
14.3 Fans and Air Passages......................................................................................................................28
15 Periodic Check-ups.....................................................................................................................................29
15.1 Mechanical Parts................................................................................................................................29
15.2 Electrical Components .......................................................................................................................29
16 Product Disposal.........................................................................................................................................29
17 Troubleshooting..........................................................................................................................................30
NOTES................................................................................................................................................................31

User Manual Ver. 1.0.1 5 di 31
SOPRANO
1 Symbols
Symbol
Meaning
General risk.
Electric shock risk
Hot surface
Suitable for indoor use only.
Maximum operating ambient temperature.
Minimum distance from illuminated objects.
Do not stare at the operating light source.
Photobiological safety risk group 2
Never expose the front lens to sunlight or any strong artificial Light source from any
angle to avoid damage of head internal parts.
European Community Directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE).

User Manual Ver. 1.0.1 6 di 31
SOPRANO
2 General Warning
Carefully read the instruction contained in this User Manual, as they give important information regarding your
safety and others during installation, use, and maintenance of the product.
The unit is not suitable for domestic use and must be installed by qualified personnel only.
The device must always be equipped with an efficient ground connection.
3 Safety and Operation
Do not attempt to install and use the device before carefully reading this manual and understanding all warning
symbols. Installing the device without following the instructions in this document may be dangerous and cause
damage, injury, or death.
Any ordinary maintenance operation not described in this manual must be done only by a qualified technician.
Failing to follow the instructions on this “User Manual” shall cancel the warranty issued by D.T.S. Illuminazione
Srl. Before installation, please carefully read this “User Manual” and make sure to check the latest technical
updates available on the D.T.S. Illuminazione Srl’s website – (www.dts-lighting.it).
3.1 Fire prevention
Minimum distance from illuminated surface.
Never expose the front lens, from any angle, to direct sun light or strong artificial
light sources in order to avoid damage to the internal parts of the product.
The front lens may act as a powerful magnifying glass if exposed towards the sun
or any strong artificial light source; this will cause damage to the internal parts of
the moving head, even if exposed for a few seconds, and even when the unit is
turned off.
It is strongly recommended to leave the front lens directed towards the ground
when switching off or leaving the unit unattended.
The unit features various air inlets and cooling fans located on both the base and
the head of the fixture. Under no circumstances should these be blocked or
obstructed whilst the projector is operating. Doing so may cause the fixture to
seriously overheat, damaging it and compromising its proper operation.
Each fixture produces heat and must be installed in a well-ventilated place.
Connect the projector to mains power via a thermal magnetic circuit breaker.

User Manual Ver. 1.0.1 7 di 31
SOPRANO
3.2 Prevention of electric shock
High voltage is present inside the unit.
Unplug the unit prior to performing any function which involves handling of the
insides of all parts of the product.
Class I Appliance: Connection must be made to a mains system fitted with an
efficient earthing.
SOPRANO requires the assistance of specialized personnel for all servicing. Please
always refer to an authorized DTS service center.
3.3 Level of protection IP
The projector is classified as an ordinary appliance and its protection level against
the penetration of solid and liquid objects is IP20.
The projector contains electric and electronic components which should under no
circumstances come into contact with oil, water, or any other liquid. The proper
functioning of the unit would be compromised should this occur.
Suitable for indoor use only.
3.4 Safety
Before carrying out any installation, check that all parts of the product are intact. In the
event that parts are broken, not fully functional or damaged, do not install the product
and send it to the nearest repair centerThese products must be installed by qualified
personnel only, following national laws and local regulation.
These products must be installed by qualified personnel only, following national laws
and local regulation.
Do not exceed the specified input voltage and current.
Do not drop, hit, or shake the product. Strong accelerations or shocks can damage the
device and cancel its warranty.
The fixing point must always be capable of supporting the weight of the unit.
Always use a safety cable to sustain the weight of the unit in case of failure of the main
fixing point.
The light source contained in this fixture cannot be replaced..
Burn risk –hot surface.
The external surface of the unit’s body, at various points, may exceed 50 °C.
Never handle the unit until at least 5 minutes have elapsed since the unit was turned off.

User Manual Ver. 1.0.1 8 di 31
SOPRANO
The ambient temperature should not exceed 45°C
This fixture is intended for use where humidity does not exceed 90% (non-
condensing).
If the product has been subjected to drastic temperature variances, for example,
following transportation, do not connect the fixture until it has reached ambient
temperature, as moisture condensation may cause electric shock and product
damages.
After storage, and before switching on the fixture, please ensure that its ambient
temperature has been restored to acceptable values.
Never install the fixture in places that lack a constant air flow.
Risk Group 2 product according to IEC 62471
Do not look directly at the light output and do not stare at the light beam through optical
instruments or any other device that may concentrate the light beam.
May be harmful to the eyes and skin.
The luminaire should be positioned so that prolonged staring into the luminaire from a
minimum distance of is not expected.
Minimum distance for different models
Minimum distance
Models
Led
Risk Group
m
ft
SOPRANO 3
White
Risk Group 2
9,29
30.48
HQS HDW
Risk Group 2
10,91
35.79
SOPRANO 5
White
Risk Group 2
13,71
44.98
HQS HDW
Risk Group 2
18,21
59.74
3.5 Waste Electrical and Electronic Equipment (WEEE) directive
Electrical and Electronic Equipment
The projector, accessories and packaging should be sorted for environmental-friendly
recycling. European Community Directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE).
(For EC countries: according to the European Directive 2012/19/EU for Waste Electrical
and Electronic Equipment and its implementation into national right, luminaires that are no
longer usable must be collected separately and disposed of in an environmentally correct
manner)
4 General Warranty Conditions
The unit is guaranteed for 36 months from the date of purchase against manufacturing material defects.
The warranty covers defects in materials and workmanship. The warranty is not applicable where a defect is
caused by misuse or unauthorized repair of the product.
Any functional or/and physical modification of the product is not allowed.

User Manual Ver. 1.0.1 9 di 31
SOPRANO
5 Features
5.1 Color Generation - Only HQS models
6-color LED engine
Linear CCT (1,800 K –10,000 K)
Linear ‘green saturation’
Tungsten emulation function
100 gel filter emulations:
Linear crossfade from gel filters emulation to CCT whites
Linear crossfade between emulated gel filters
True color of gel filters emulation at any CCT values
“Raw” RGBACL color-mixing in ‘Advanced’ mode
Dimming: Hi-Q Dimming technology
5.2 White Generation - Only HDW models
6-color LED engine
Linear CCT (1,800 K –10,000 K)
Linear ‘green saturation’
Tungsten Emulation
Dimming: Hi-Q Dimming technology
5.3 Single White models
Single White LED engine
Color Temperature: 3000 K, 5700K
Dimming: PWM Dimming technology
5.4 Control
Protocols: RDM; DMX 512 A
Firmware updatable: via DTS firmware uploader dongle
DMX MODES: refer to paragraph number 10.2
Fan modes (DMX-selectable): ‘Standard’, ‘Silent’, ‘Ultra Silent’ and ‘Automatic’
Model
Noise level @
"Standard” mode
Full Power
Noise level @
"Silent” mode
Full Power
Noise level @
"Ultra Silent” mode
Full Power
SOPRANO 3 WHITE
24 dBA @ 1m
23 dBA @ 1m
22 dBA @ 1m
SOPRANO 3 HQS or HDW
24 dBA @ 1m
23 dBA @ 1m
22 dBA @ 1m
SOPRANO 5 WHITE
30 dBA @ 1m
26 dBA @ 1m
25 dBA @ 1m
SOPRANO 5 HQS or HDW
34 dBA @ 1m
29 dBA @ 1m
26 dBA @ 1m

User Manual Ver. 1.0.1 10 di 31
SOPRANO
6 Technical Specifications
6.1 SOPRANO 3
Model
SOPRANO 3
HQS HDW
WHITE
Source
LED detail
Six color LED engine
White cob led
Colors
Red, Green, Blue, Amber, Cyan
Lime
CCT 3000 K - CCT 5700 K
Lumen output (Optic 15-30)
4700 lm
4900 lm - 5700 lm
Lumen output (Optic 25-50)
5900 lm
5800 lm - 6800 lm
Led lifespan
20000 hours (70% lumen output)
Optical
Lenses
Interchangeable lens tubes
Linear zoom range
Soprano Optic 15/30 –Soprano Optic 25/50
Electrical
Power supply
Auto-ranging SMPS
Supply voltage
100 ÷ 240 Vac –50/60 Hz
Max Input Current
1,9 A
1,4 A
Max Power
190 W
145 W
Power factor
PF >0.94 / 230Vac
PF >0.95 / 230Vac
Inrush current
30A/115Vac –60A/230Vac
65A/230Vac
Internal Protection Devices
Overvoltage and over temperature circuits protection
Mechanical
Weight
6,8 kg (15.0 lb)
6,6 kg (14.6 lb)
IP grade
IP20
Body Materials
Aluminium, ABS
Color
Black
Thermal
Operating temperature
-10 to 45 °C (14 °F to 113 °F)
Storage temperature
-20 to 60 °C (-4 °F to 140 °F)
Operating humidity
<90% r.H. non-condensing
Storage humidity
<90% r.H. non-condensing
User Interface
Display
Blu & White LCD graphic display

User Manual Ver. 1.0.1 11 di 31
SOPRANO
Input system
Jog wheel with push button
Connections
Connection
Power supply
powerCON TRUE1 In/Out panel connectors
DMX
XLR 5-pole In/Out panel connectors
6.2 Soprano 5
Model
SOPRANO 5
HQS HDW
WHITE
Source
LED detail
Six color LED engine
White cob led
Colors
Red, Green, Blue, Amber, Cyan
Lime
CCT 3000 K, CCT 5700 K
Lumen output (Optic 15-30)
9600 lm
8100 lm - 9900 lm
Lumen output (Optic 25-50)
11100 lm
9600 lm - 11800 lm
Led lifespan
20000 hours (70% lumen output)
Optical
Lenses
Interchangeable lens tubes
Linear zoom range
Soprano Optic 15/30 –Soprano Optic 25/50
Electrical
Power supply
Auto-ranging SMPS
Supply voltage
100 ÷ 240 Vac –50/60 Hz
Max Input Current
3,8 A
2,5 A
Max Power
390 W
260 W
Power factor
PF >0.94 / 230Vac
Inrush current
40A/115Vac –80A/230Vac
75A/230Vac
Internal Protection Devices
Overvoltage and over temperature circuits protection
Mechanical
Weight
8,0 kg (17.6 lb)
7,7 kg (17.0 lb)
IP grade
IP20
Body Materials
Aluminium, ABS
Color
Black
Thermal
Operating temperature
-10 to 45 °C (14 °F to 113 °F)
Storage temperature
-20 to 60 °C (-4 °F to 140 °F)
Operating humidity
<90% r.H. non-condensing
Storage humidity
<90% r.H. non-condensing

User Manual Ver. 1.0.1 12 di 31
SOPRANO
User Interface
Display
Blu & White LCD graphic display
Input system
Jog wheel with push button
Connections
Connection
Power supply
powerCON TRUE1 In/Out panel connectors
DMX
XLR 5-pole In/Out panel connectors
NOTE:
As for all electrical devices, LEDs will degrade through time with a consequent reduction in their luminosity.
This explains why it is almost impossible to obtain identical photometric performances between two different
LED devices with different operating lifetime. LEDs lifespan varies greatly and is the result of a complex
formula which considers multiple factors such as operating efficiency, continuous operating time, and
environment conditions (e.g., ambient temperature).
All semi-conductor devices, such as LEDs, are subject to inherent variables related to their technical features.
In order to improve output and performance uniformity, D.T.S. Illuminazione Srl uses selected LEDs
considering the aforementioned factors, reducing to the minimum variations in output luminosity, color
temperature and tone shift in color between devices.
6.3 Zoom Lens
Model
SOPRANO
15 ÷ 30
25 ÷ 50
Optical
Zoom Lens
Changeable optics
Linear zoom range (*)
15 ÷ 30
21 ÷ 46
Lenses material
Optical glass
Rotating barrel
± 32º
Shutter blade
Three-plane stainless-steel shutter blade assembly
Mechanical
Weight
5,2 kg (11.5 lb)
5,9 kg (13 lb)
Max. length
mm
Body Materials
Aluminium, ABS,
Color
Black
Accessory slot
2
(*) See photometric curves for more information.

User Manual Ver. 1.0.1 13 di 31
SOPRANO
6.4 Dimensions
A
B
C
D for
Optic 15/30
D for
Optic 25/50
E
Model
mm
in
mm
in
mm
in
mm
mm
mm
in
mm
in
SOPRANO 3
HQS/HDW
291
11.46
452
17.78
715
28.15
360
14.17
332
13.09
355
13.98
SOPRANO 3
WHITE
287
11.3
360
14.17
661
26.04
360
14.17
332
13.09
301
11.85
SOPRANO 5
HQS/HDW
331
13.03
484
19.06
737
29.03
360
14.17
332
13.09
377
14.84
SOPRANO 5
WHITE
322
12.68
394
15.51
682
26.85
360
14.17
332
13.09
322
12.67

User Manual Ver. 1.0.1 14 di 31
SOPRANO
7 Included Items
1x PowerCON TRUE1 female connector (Code 0520P066)
1 x XLR 5 pins female cable connector (Code 0508B147)
1 x XLR 5 pins male cable connector (Code 0508B148)
1 x Gel Holder black finishing ( Code 02M093424.49 for SOPRANO 3-5)
8 Installation
The unit is suitable for dry locations only.
The product is supplied with the blades fully inserted, remove them completely before turning on the headlight.
The blades are able to completely close the light output but this is a situation to be avoided in normal operation.
Before carrying out any installation, check that all parts of the product are intact. In the event that any broken,
not fully functional or damaged parts are observed, do not install the product
and send it to the nearest repair center.
SOPRANO may be either ceiling or floor mounted on tripod.
For ceiling mounting installations, DTS recommend the use of appropriate
clamps to fix the unit to the mounting surface.
The supporting structure from which the unit is hung should be capable of
bearing the weight of the unit, as should any clamps used to hang it.
One hole, on the center of the bracket, allow SOPRANO to hang by using an
appropriate clamp.
8.1 Safety Cable
A safety cable must be securely fixed to SOPRANO and to the suspension truss in order to
avoid the fixture accidentally falling, should the main fixing point fail.
The safety cable used must be approved by a notified body according to IEC 60598-2-17 and
must be capable of bearing at least 10 times the weight of the unit. For more information,
please refer to an authorized DTS service center.
A suitable safety cable (code 0521A049) is available on demand.
Securely fix the safety cable to the unit’s mounting bracket and to the support structure of the projector as
shown in the next picture.

User Manual Ver. 1.0.1 15 di 31
SOPRANO
.
9 Mains Connection
Prior to connecting the unit to the mains, ensure that your local mains electricity supply properties are
compatible with those of the product.
Strict adherence to regulatory norms is strongly recommended.
MAINS IN
100 - 240 Vac 50 / 60Hz
male PowerCON TRUE1 panel
connector
MAINS OUT
100-240Vac 50-60 Hz
(SOPRANO 3 MAX 14A)
(SOPRANO 5 HQS/HDW MAX 12A)
(SOPRANO 5 WHITE MAX 13A)
female PowerCON TRUE1 panel connector

User Manual Ver. 1.0.1 16 di 31
SOPRANO
9.1 Protection
The use of a thermal magnetic circuit breaker is recommended for each unit.
Class I appliance: connection must be made to a mains system fitted with an efficient earthing.
10 DMX Signal Connection
The unit operates using the digital USITT DMX512 signal.
Connection between the light controller and the projector, or between projectors, must be carried
out using a two-pair screened ø 0.5 mm cable, and a XLR 5 pins connector.
Ensure that the conductors do not touch each other. Do not connect the ground cable to the XLR
chassis. The housing of the plug must be isolated.
Connect the light controller to the DMX IN panel connector of the projector; to create a link to the
next projector, simply connect the DMX OUT plug of the first unit to the DMX IN plug of the next
fixture in line.
Following this procedure, all the projectors will be cascade connected.
PS. If the display showing the DMX address flashes, then one of the following errors has occurred:
- DMX signal not present
- DMX reception problem
10.1 DMX terminator
The use of a DMX terminator is recommended.
The DMX terminator is a male XLR 5-pins connector with a 120 Ω resistor between pin 2 and pin 3.
The DMX terminator must be plugged in into the last unit’s DMX OUT panel connector of the DMX line.
Place a 120 Ω resistor between pin 2 and 3 of a male XRL
connector;
Plug the resistor into the DMX OUT panel connector of the last unit
connected to the DMX line.
USITT DMX512
controller

User Manual Ver. 1.0.1 17 di 31
SOPRANO
10.2 DMX Modes
SOPRANO can be used in different DMX modes:
SOPRANO 3_5 HQS / TENORE 3_5 HQS can be used in five different DMX modes:
CCT (Default) -Correlated color Temperature
Advanced - Correlated Color temperature plus Raw control for color channels RGBACL
Basic –Correlated Color Temperature with priority on Gel Library and RGBACL color
Expo - Dimmer 8 bit and Correlated Color Temperature priority on Gel Library
CMY Emulation –Cyan, Magenta, Yellow and CTO emulation Mode.
e.g.when using the unit in“CCT”(Default) mode(10 DMX channels),set the following addresses on the light desk
Projector 1 A001
Projector 2 A011 If you want to select the next projector, just add “10” to the former DMX address
Projector 3 A021
….. A….
Projector 6 A051
TENORE 3_5 HDW / SOPRANO 3_5 HDW can be used in two different DMX modes:
CCT (Default) - Dimmer 16 bit with Correlated color Temperature and Green saturation control.
Basic –Dimmer 8 bit with Correlated color Temperature control.
e.g.when using the unit in“CCT”(Default) mode(10 DMX channels),set the following addresses on the light desk
Projector 1 A001
Projector 2 A007 If you want to select the next projector, just add “6” to the former DMX address
Projector 3 A013
….. A….
Projector 6 A031
TENORE 3_5 / SOPRANO 3_5 can be used in three different DMX modes:
4ch (Default) –Shutter, Dimmer 16bit and Fixture Control channel.
1ch –Dimmer 8bit
Fine –Dimmer 16bit.
e.g.when using the unit in “4ch” (Default) mode, set the following addresses on the light desk:
Projector 1 A001
Projector 2 A005 If you want to select the next projector, just add “4” to the former DMX address
Projector 3 A009
….. A….
Projector 6 A021
10.3 Setting Up the DMX address
1 Rotate the jog shuttle until you reach the desired DMX address. The numbers on the display will start
flashing (new DMX address hasn't yet been set).
2 Push to confirm your selection. The numbers on the display will stop flashing; the projector is now set to
the new DMX address.

User Manual Ver. 1.0.1 18 di 31
SOPRANO
11 RDM-DMX - Display Functions, Error messages
All information regarding RDM, DMX, DISPLAY FUNCTION, ERROR MESSAGES and how to update the
firmware is available in the RDM/DMX Manual
TENORE/SOPRANO HDW-RDM DMX MANUAL 0517I368
TENORE/SOPRANO HQS-RDM DMX MANUAL 0517I369
TENORE/SOPRANO WHITE-RDM DMX MANUAL 0517I370
12 Updating the Firmware
In order to update to the latest firmware release of the SOPRANO, you will need:
DTS firmware uploader dongle (code 03.LA.206).
“DTS Firmware Upgrade Utility v.2.02” program installed on PC (Windows OS).
Latest firmware release available for the SOPRANO unit. (Depends on the model)
Updating to the latest firmware release:
To perform the update, please follow the procedure as described below:
1 Connect the DTS Firmware Uploader Dongle to a spare USB port on the PC.
2 Connect the unit’s DMX IN to the DTS Firmware Uploader Dongle’s DMX OUT with a standard DMX cable
and turn on the fixture.
3 Send the new firmware release into the unit by using “DTS Firmware Upgrade Utility v.2.02” program.
During software upgrade the led will blink.
At the end of the procedure, the unit will reboot.
For more information, please refer to an authorized DTS service center.
13 Accessories and their installation
13.1 Accessories on Request
Aliscaf clamp for Ø 48-51 mm tube - max load 200 Kg (code 0521A033)
Indicated for any kind of loads, both vertical and/or horizontal.
Professional G-QUICK clamp - max load 100 Kg (code 0521A037)
Not indicated for horizontal load.
Safety cable 3 x 600 mm - max load 20 Kg (code 0521A049)
Safety cable for Barndoors and Gel holder (code 0521A048)
DTS firmware uploader dongle (code 03.LA.206)
13.2 Accessories specifically designed for TENORE and SOPRANO
The different accessories, which can be installed, are specifically designed for projectors TENORE and
SOPRANO. The accessories can be ordered separately from the product
