DTS DTS450 User manual

Before this model has being significantly changed to another new version, the parts, appearance and the existing version can be developed and
modified that would lead to a slight difference from the original design. DTS reserve ALL the Rights of change of parts and contents WITHOUT
specified notification.
35A Brushless Motor ESC
.
Swash Servos*3(1.2kg cm,0.08s/60 )
.
Tail Servos*1(0.6kg cm,0.04s/60 )
6-Channel Transmitter
11.1V 2200mAh 30C Li-polymer Battery
GWY2013
GWY 6TL V2 2.4GHz
3-axis Gyro
DTS450
DTS
R
Specifications
Length:645mm
Height:215mm
Main Rotor Diameter: 725mm
Tail Rotor Diameter: 145mm
Weight:Approximately 675g (with Battery)
2216 Brushless Motor

Statement
Check of package's parts and accessories
Electronic Parts and Connection Procedure
2
3
7
10
1
Thank you for choosing DTS's product. For better understand usage of DTS450 helicopter, please
read this manual carefully before installation and operation. This can ensure proper usage and safe
operation! For your convenience of adjustment, maintenance and other operation, please keep this
manual in a proper manner.
For further information, please visit our website: www.zondahobby.com
11
12
13
14
15
16
17
18
19
21
Main Blade Grip Assemble Procedure
Hiller Control Arms Assemble Procedure
Main Frame Assemble Procedure
Main Gear Assemble Procedure
Tail BoomAssemble Procedure
Tail Rotor BladeAssemble Procedure
Push-rod Assemble Procedure
Power System Assemble Procedure
Canopy Assemble Procedure
Exploded View
Spare Parts List
Pre-Flight Controls Test
Flight Operation Procedure
4
8
Main Blade Adjustment
Tail Drive Servo Adjustment
Tail Drive Belt Adjustment
9
9
Foreword
Table of Contents

An RCHelicopter is nota toy! For avoiding accidentsand damage, pleaseoperate the helicopterproperly.
Since the consumerhave purchased thehelicopter, theyshould take allthe risks in the usage.To ensure
your safety, if you are a beginner, you are recommended to consult or get assistance from experienced RC
modelers or yourlocal hobby stores.
Youshould buy theauthorized DTS accessorieswhen you choosingthe accessories. Otherwise, some
RC functions may not be matched or function unproperly.
Please keep instruction manual to properly maintain your model.
RC helicopter is controlled by radio signals. It may be interfered by other radio signals during operation.
These interference may cause the helicopter lose control.
1.An RC Model is not a toy! Improper operation or misuse may lead to serious damage or loss. It is
prohibited for childrenunder 14 yearsto operate thisproduct.
2.Keep it awayfrom high temperatureenvironment and corrosivechemicals for storageand flight.
(the operation temperature: from:-10 to 50 )
3.If you are not an experienced pilot or have not flown this type of model before, we recommend that
you get assistance of an experienced pilot for your first flights. Please avoid flying with other RC models
with same frequency.
4.Please choose aopen flight areaand use thetraining gear setfor your firstfight in orderto minimize
your loss dueto control mistakes.
1.To avoid the loss of the property of others, please keep away from high tension power lines, high
buildings or any other obstacles while flying
2.Keep away fromcrowds in caseof accidents
3.Do NOT operate in rain,thunder, storms,lighting, strong windor any otherbad weathers toensure
,
your and thehelicopter s safety
4.Please avoid using in a bathroom or a rainy day to prevent moisture or water vapor from entering the
helicopter inside whichmay lead mechanicalor electronic componentsmalfunction and causeunex-
pected accidents
5.Do Not re-equip, upgrade or repair your helicopter with the accessories outside the DTS parts catalog
in order to ensure the safety of the model structure!
6.Keep people andobjects away fromthe spinning unitand parts incase of damageor injury!
1.Please make surethe helicopter frequencywill not interferedwith others beforeevery flight.
2.You should confirm the batteries of your transmitter and helicopter are fully charged before every flight
and your firstflight.
3.Both the throttle stick (left-hand stick) andthrottle trim MUST be in their lowestposition before every
flight. Each time before your flight, you must ALWAYS turn on the transmitter power first before con-
necting the flight battery to the receiver. After your flight, you should disconnect the flight battery from
the receiver before turn off the transmitter.
4.Please make sure that every servos function properly with correct directions after powering on.
5.Make sure every connection of pushrods is proper and the helicopter battery placed in fixed position.
Statement
Warning Label Legend
Do not attemptunder any circumstances.
Mishandling due tofailure to followthese instructions mayresult in danageor injury.
Mishandling due to failure to follow these instructions may result in danger.
CAUTION
WARNING
FORBIDDEN
Safety Precautions and Warning
Pre-flight check
1
WARNING
FORBIDDEN

2
2
1
7
346
5
1
1
1
1
1
1
1
1.
2.6TL V2
3.
4.
5.
6.
7.
RC Helicopter
2.4GHz 6-Channel Transmitter
2S & 3S Batery Charger
SD Card
11.1 V, 2200 mAh Li-Po Battery
Tool Pack
Battery Bandage
Check of package's parts and accessories
Please check the parts and accessories in the package. In the event of defective or missing parts, please contact the
retailer for help.
Package Box Content RTF WOB RFR RFR with AH6 Radio System
DTS 450
6TL - 2.4GHz 6-Channel Transmitter
AH6T - 2.4GHz 6-Channel Transmitter
GWY2013 - Receiver & Gyro
G02 - Gyro
AH6R - Receiver
2S & 3S Battery Charger
Li-Po Battery : 2200mAh 3S1P 11.1V
Battery Bandage
SD Card - Manual
ToolPack

3
Electronic Parts and Connection Procedure
Brushless Motor
Li-Po Battery
Rudder Servo
Brushless ESC
Elevator Servo
Aileron Servo
Pitch Servo
GWY2013
Receiver 3-axis Gyro
Receiver Connection Procedure
Aux 02
Pitch Servo Plug
Aux 01
Gyro Gain Signal Plug
Brushless ESC Plug
Aileron Servo Plug
Elevator Servo Plug
Gyro Rudder Plug
Power Supply Plug

Push up the throttle stick slowly until the motor rotate. Make sure that the motor rotates clockwisely and the main
blade rotates anti-clockwisely.
Throttle Position: LeftThrottle Position: Right
4
Pre-Flight Controls Test
1.Control Test: Throttle
Please don't pushthe throttle stickupward over 1/5.The motor will spins athigh velocity ifthe throttle stickis
over pushed. This may cause damage on the product or self injury. Besides flight operation, when performing
maintenance or adjustment and fine-tuning indoor, please remove the connection between the motor and the
ESC. This can prevent themotor from unpredictablespinning and causeacidents.
Swashplate's Back and
Front end movement
2.Control Test: Elevator
Throttle Position: Right Throttle Position: Left

5
3.Control Test: Pitch (only aerobatics use)
Swashplate's upward and
downward movement
4.Control Test: Aileron
Swashplate's Left and Right declining movement (The rudder's control is the same in both
left and right-hand throttle transmitter)
Rear View
Throttle Position: Right Throttle Position: Left
Rear View Rear View

6
5.Control Test: Rudder
Tail rotor blades pitch change (The rudder's control is the same in both
left and right-hand throttle transmitter)
6.Gyro adjustment
Disconnect the connection between ESC and motor, turn on the power of the transmitter and helicopter,
move the pushrod to check the sercos direction.
1. Hold the helicopter rotates around the main shaft, gyro will control the tail servo to compensate the
movement of the rotation direction.
E.g. When helicopter tail rotates rightward, the gyro will control the tail servo to rotates the tail leftward.
(Picture A)
2. Hold the helicopter and tilt the fuselage to a certain direction, the swashplate will be tilted toward the
opposite direction of the fuselage.
E.g. When the helicopter tilted forward, the swashplate will be tilted backwards. When the helicopter tilted
backward, the swashplatewill be tiltedfoward. (Picture B)
If the helicopter tilt laterally, the swashplate will becorrected in theopposite direction. (PictureC)
When the fuselage return to the initial horizontal position, the swashplate will also return to the initial position.
Picture A Picture B
Picture C
Tail Rotate Direction
Fuselage direction
Swashplate
direction
Swashplate
direction
Fuselage
direction
Fuselage
direction
Swashplate
direction
Swashplate
direction

7
1
2
Mode1
Mode2
4
3
1
3
2.End-flight procedure
Disconnect the helicopter's
electricity
Switch off the transmitter Takeout the battery
Flight Operation Procedure
1.Take Off Procedure
Insert the batteryto the batterynotch Fix the battery's position with the bandage
Adjust the antenna to the shown position. Pull the
throttle to the most downward position then switch
on the transmitter.
Connect helicopter's electricity

2
34
1
Main Blade Adjustment
1
DTS 450
Blade tracking is an important step to affect the flight performance. Main rotor blades that are out of track may cause vibration and
instability. Although the main rotor blades of each models are tracked at the factory, minor adjustment to blade tracking
may be required after blade changes. Thus one of the main blades pasted a coloured tracking tape to identify which blade is running
low or high in the blade tracking process.
Caution: Be sure to maintain a safe distance from the helicopter (3~5meter) when tracking the main rotor blades.
Coloured tracking tape
(From the topto the bottom)
Adjusting Pushrod When 2 mainblades stay onthe same rotatingrail,
the main bladeadjustment is completed.
2 After confirming which blade is running low and high, switch off the helicopter power supply before making any necessary
adjustments to the linkage. You can increase the pitch of the low blade by shortening the mixing arm to inner swashplate linkage.
This is achievable by turning one of the Ball Link ends in by one-half to one full turn at a time. Or, you can decrease the pitch of the
high blade by lengthening the same linkage.
3Remark: The blade you choose to raise or lower when making tracking adjustments will depend on the pitch of each blade. Open the
3D aerobatics (the tail motor power supply wire should be cut off) and the throttle/ collective stick in the middle position, both rotor
blades should be close to 0 degrees. You can easily identify which rotor blade to adjust. If one blade is lower than 0 degree, raise
it to match the other blade. If one blade is higher than 0 degree, lower it to match the other blade.
4 Generally, there is not much adjustment should be necessary to properly track the main rotor blades. If significant adjustments are
required, be sure to double-check the length of both mixing arm to inner swashplate linkages. You should also check the blades for
any damaged or twists. In fact, you should be able to get both blades tracking perfectly in the same helicopter. However, the small
defects in the ball links and threaded linkage rods/ pushrods may not always be possible to affect the blade tracking. Don't worry, the
helicopter should be able to have a good flying performance even the blade tracking is adjusted as close as possible.
Coloured tracking tape
8

Tail Drive Servo Adjustment
As this model is a precise craft, unexpected self-rotationduring flight couldbecause of severalreasons.
Could adjust throughfollowing procedure: (disconnectthe motor andthe ESC can avoid unexpected accidents)
First switch onthe transmitter.Then connect the helicopter with electricity, and tilt the rudder stick and trim to
the middle position(Figure 1); Keepthe tail driveservo boom mountand the tailboom perpendicular (Figure 2).
Adjust the position of the tail drive servo and keep the distance between the Tail Pitch Control Slider Ring and
the tail case (approximately 1/3 of the spindle) (Figure 3). Keep the servo and the servo arm perpendicular
(Figure 4).
Rudder position:
Middle
Figure 1
Figure 3 Figure 4
Figure 2
Loosen Belt is one of the reason for tail-lock fail besides gyro setting. Adjust by following the above:
Loosen the screws that mounting the tail boom to the main frame, then pull the tail boom backward. Pay
attention to the belt's elasticity. Fasten the screws back when the belt is adjusted.
Tail Drive Belt Adjustment
Throttle Position: Right
9

Main Blade Grip Assemble Procedure
10
015
014
M2*6Hexagon Socket Head Screw
Spacer
3* 8*3.5 2Thrust Bearing
2
6.5* 8*0.3
Washer
44* 8*3
Bearing
4* 5.8*2.3Brass Spacer
Blade Grips
2
4* 7.5*0.5
Step Washer
Spindle
2
3.6* 7.1*3.6
O-ring
Main Rotor Head
2
005 2
004
1001
2
002
2* 5*0.5 2
003 1
011
012
009
008
006
007
010
013
QuantitySpecificationNo. Name
016
Linkage Ball S 4*6.36 2
Centre Hub Cap
M2*5 1
1
Nylon Insert Lock Nut
M2*12
M2.0
1
1
061 Main Shaft 5*124 1
Paste necessary amount
of thread-locking fluid
013
011
010
009
008
007
007 006
004
002
4.0Linkage Ball(M2*6.36)
Hexagon Socket Head Screw
(M2*6)x2
(M2*5)x1
003 005
012
015
016
(M2x12mm)
M2.0 Nylon Insert Lock Nut
014
061
001
Paste necessary amount oflubricant on the thrustbearing
Smaller inner diameter
Greater inner diameter
Hexagon Socket Head Screw
Hexagon Socket Head Screw
Hexagon Socket Head Screw
Paste necessary amount
of thread-locking fluid
CAUTION
Proper torque is fine when locking a screw into
plastic parts,redundant torque may lead to
screw strip or fracture.
Please confirm that the screw is fastened
tightly before use.
Apply a little amount of T43 thread lock
when fixing a metal part.
Hexagon Socket Head Screw

027
1
026 4
ST1.4*4
QuantitySpecificationNo. Name
2
020
023
022
028
018
019
2017
Phillips Pan Head Bolt 4
1
3
025
029
030
024
021
Washout Control Arm
Washout Control Arm Link
Bearing
Brass Spacer 2* 3*1 2
Step Washer 2* 3.8*0.4 4
2* 5*2 4
Hexagon Socket Head Screw M2*14 2
1.5* 4*2 4
Swashplate
Linkage Ball S 4*6.5
S 4*7.5
Anti-Rotation Pin 2.0*14
4
21.4*28
Ball Link
Pushrod
Bearing
Linkage Ball
Hexagon Socket Head Screw
Hiller Control Arms Assemble Procedure
11
M2x14mm)
Phillips Pan Head Bolt
(M1.4*4mm)x4
4.0Linkage Ball
(M2*6.5)
025
026
028 027
46
28
021
020
019
018
017
019
024
023
022
023
024
029
030
4.0Linkage Ball
(M2*7.5mm)x4
CAUTION
Proper torque is fine when locking a screw into
plastic parts,redundant torque may lead to
screw strip or fracture.
Please confirm that the screw is fastened
tightly before use.
Apply a little amount of T43 thread lock
when fixing a metal part. Paste necessary amount
of thread-locking fluid

Main Frame Assemble Procedure
12
Pan Head Phillips Screw
(ST1.7*4mm)x2
Pan Washer Head Phillips Screw
(ST2*6mm)x2
( ST1.7 *9mm)x16
042
045
044
042
043
041
031
016
015
Fasten the screws after
installed the tail boom.
037
039 038
037
036
035
034
033
032
031
Hexagon Socket Head Screw
(M2x12mm)x4
010
046
040
016
CAUTION
Proper torque is fine when locking a screw into
plastic parts,redundant torque may lead to
screw strip or fracture.
Please confirm that the screw is fastened
tightly before use.
Apply a little amount of T43 thread lock
when fixing a metal part.
Paste necessary amount
of thread-locking fluid
Paste necessary amount
of thread-locking fluid
Pan Head Phillips Screw
Hexagon Socket Head Screw
Pan Head Phillips Screw
Pan Head Phillips Screw
Pan Washer Head Phillips Screw
1
2* 5*0.5
Spacer010
046
033 1
ST2*6
2
ST1.7*4
M2*12
1Main Frame, Left
35* 10*4
M2.0
016 Nylon Insert Lock Nut
Canopy Mount Rod Connector
ST1.7*9
2
4Landing Skid End Cap
Landing Skid 2
043
042
044
045
2
Landing Gear Strut
041
3* 7*3
040
015
039
038
037
035
034
032
031
1Main Frame, Right
Canopy Mount Rod 2
5
Tail DrivePulley Cap 1
1Tail DriveBelt
Tail DrivePulley 1
2Bearing
Secondary TailDrive Gear 1
4
16
036
NameNo. Specification Quantity
Bearing

4
1
1
1
1
1
1
1
1
1
1
5* 6*22.2
110T
6* 10*1
140T
ST2*6
6* 10*12
M2.0
M2*12
M3x3
Main Shaft Retaining Collar
One Way BearingShaft
Main TailDrive Gear
Nylon Insert Lock Nut
Hexagon Socket Head Bolt
Set Screw
Spacer
Main Gear
Hexagon Flat Head Screw
One Way Bearing
One way bearing sleeve
054
053
048
047
049
050
051
052
016
015
055
NameNo. Specification Quantity
Set Screw
Hexagon Socket Head Bolt
Main Gears Assemble Procedure
13
(M2x12mm)x1
016
015
055
054
053
052
051
050
048
047
049
M2.0Nylon Insert Lock Nut
M3 M3x3mm)x1
CAUTION
Proper torque is fine when locking a screw into
plastic parts,redundant torque may lead to
screw strip or fracture.
Please confirm that the screw is fastened
tightly before use.
Apply a little amount of T43 thread lock
when fixing a metal part.
Paste necessary amount
of thread-locking fluid

064
2
ST2*8
088
5
ST1.7*9
Pan Head Phillips Screw
041
1
Vertical Fin
Tail Case,Left
Tail RotorShaft Drive Pulley Cap
2
4* 8*3Bearing
Tail Case,Right
Tail PushrodGuide
Tail Boom
NameNo. Specification Quantity
1
065
057
056
058
059
060
007
062
1
Tail RotorShaft Drive Pulley 1
Horizontal Fin Mount
1
1
2
Tail ServoBoom Mount
2
063
1
Flange Head Phillips Screw
Tail Boom Assemble Procedure
14
Pan Head Phillips Screw
(ST1.7 *9mm)x5
088
065
041
063
062
064
007
007
060
058
059
058
057
057
056
Flange Head Phillips Screw
(ST2*8mm)x2
Approximately
128 mm
58 mm
!CAUTION
1.Check to rotate the belt 90 degrees when
assembling
2.Belt tension:Recommend to lightly tighten
the drive belt after assembling tail boom
to avoid vibration,belt friction and rotation
slip
Drive belt illustration
Back
Front
CAUTION
!
Tighten the mount after insertion.
Match the slot of tail servo boom mount to
the notch of the tail boom
Notice and aim the slot of the tail boom and
the tail servo boom mount before insert
Approximately
CAUTION
Proper torque is fine when locking a screw into
plastic parts,redundant torque may lead to
screw strip or fracture.
Please confirm that the screw is fastened
tightly before use.
Apply a little amount of T43 thread lock
when fixing a metal part.

Linkage Ball
Linkage Ball Bolt
2
084
021
083
082
1
1
026 S 4*6.5
081
080
Metal TailRotor Hub
116
Linkage Ball
Pan Head Phillips Bolt 2
ST2*4
M2*14
Hexagon Socket Head Bolt
Step Washe 2
079
1
2.1* 3.6*2
M3x3Set Screw
1.5*5
25* 8*2.5
Bearing
2
070 2.5* 6*3
069
Thrust Bearing
45.1* 6*0.1Washer
3* 6*2.5
Bearing
S 4*7.5Linkage Ball 2
066 Tail RotorBlade Grip 2
1
068
027
067
078
071
Tail RotorBlade
1
2
2Brass Spacer
4
2
073
072
2
117
Tail RotorPitch Control Slide Bushing 1
1
3* 4.5*1.6
Tail RotorPitch Control Slider Ring
076
075
2Tail RotorPitch Control Ball Link
Pin 2
1055
074
1Tail RotorPitch Control Fork
077
Tail RotorPitch Lever
NameNo. Specification Quantity
Cap Washer
Hexagon Pan Head Screw M2*10 2
Brass Spacer
Tail Rotor Blade Assemble Procedure
15
068
071
M3 Set Screw (M3x3mm)x1
4.0Linkage Ball
(M2*6.5)x1
080
076 077 076
075
074
073
072
117
116
070
069
068
067
027
066
4.0Linkage Ball
(M2*7.5mm)x2
Hexagon Socket Head Bolt
(M2*14mm)x1
079
081
082
021
084
068
083
068
083 026
Hexagon Pan Head Screw
(M2*10mm)x2
055
078
Paste necessary amount
of thread-locking fluid
Paste necessary amount
of thread-locking fluid
CAUTION
Proper torque is fine when locking a screw into
plastic parts,redundant torque may lead to
screw strip or fracture.
Please confirm that the screw is fastened
tightly before use.
Apply a little amount of T43 thread lock
when fixing a metal part.

Push-rod Assemble Procedure
16
093
Approximately310mm
096
085 086
088
095
026
088
087
016
046
091
092
094
046
099
097
098
029
089
090
4.0Linkage Ball
(M2*6.5) x1
Pan Head Phillips Screw
(ST1.7*6mm)x2
Pan Head Phillips Screw
(ST1.7*4mm)x1
099
M2 .0 Nylon Insert Lock Nu x1
Hexagon Socket Head Screw
(M2*16mm)x1
Flange Head Phillips Screw
(ST2*8mm)x4
Flange Head Phillips Screw
(ST2*6mm)x4
Please install the
Linkage Ball in the
indicated dimension
8
90
098
097
093
092
1
2ST1.7*6
Tail Linkage
Pan Head Phillips Screw099
029
1ST1.7*4Pan Head Phillips Screw
096
1M2.0Nut
087
1.4*26 1Tail PushrodJoiner Rod
095
1
1
1
QuantitySpecification
2*270
Name
Tail Pushrod
Tail PushrodJoiner
Tail Linkage
094
No.
026 1S 4*6.5Linkage Ball
Servo Arm
Servo
4
ST2*6
046
Horizontal Fin
M2.0Nylon Insert Lock Nu016
M2*16
Hexagon Socket Head Screw
3*250
Tail BoomSupport End, Angled
NameNo. Specification Quantity
2
091
085
086
088
089
1
1
1
1
2Tail BoomSupport End, Straight
4
2
Tail BoomSupport Rod
090
1
ST2*8
Flange Head Phillips Screw
Flange Head Phillips Screw
CAUTION
Proper torque is fine when locking a screw into
plastic parts,redundant torque may lead to
screw strip or fracture.
Please confirm that the screw is fastened
tightly before use.
Apply a little amount of T43 thread lock
when fixing a metal part.
to let the servo arm have enough
space of movement and response time.

Flange Head Phillips Screw
QuantitySpecificationNo. Name
106
026
094
046
055
108
109
110
107
112
111
113
103
104
030
029
105
100
101
Servo
Servo Arm
Linkage Ball
Pan Head Phillips Screw
Flange Head Phillips Screw
Set Screw
Motor Mount
Spacer
Hexagon Socket Head Screw
Cap Washer
Hexagon Pan Head Screw
Hexagon Socket Head Bolt
Nylon Insert Lock Nut
Main Blade
Pushrod
Ball Link
Pushrod
Brushless Motor
Pinion Gear
ST1.7*4
S 4*6.5
ST2*6
M3x3
3.1* 8*1
M3x8
M2.5x7
M3x18
M3
1.4*28
1.4*32
1
3
3
3
3
2
1
2
4
4
2
2
2
1
6
2
1
1
1
Anti Rotation Bracket102 1
ST2*8 2088
Power System Assemble Procedure
17
13mm
Pan Head Phillips Screw
(ST1.7*4mm)x3
4.0Linkage Ball
(M2*6.5)x3
M3 Set Screw M3x3mm)x1
Hexagon Socket Head Bolt
(M3*10mm)x2
Hexagon Socket Head Screw
(M3*18mm)x2
M3.0 Nylon Insert Lock Nut
Flange Head Phillips Screw
(ST2*8mm)x2
Flange Head Phillips Screw
(ST2*6mm)x2
102
46
28
026
109
32
48.5
113
112
111
026
100
109
110
108
107
055
093
Hexagon Pan Head Screw
(M3*8mm)x2
100
026
093
100
046
094
101
029 098
094
110
088
103
101
094
106
105
104
101
093
CAUTION
Proper torque is fine when locking a screw into
plastic parts,redundant torque may lead to
screw strip or fracture.
Please confirm that the screw is fastened
tightly before use.
Apply a little amount of T43 thread lock
when fixing a metal part.
Paste necessary amount
of thread-locking fluid
Paste necessary amount
of thread-locking fluid

Canopy Assemble Procedure
18
115
114
115
1
2
Canopy
Canopy Mount Grommet
QuantitySpecificationNo. Name
114
115
