Du Pont WFPT200 User manual

V4.6
®
INSTALLATION INSTRUCTIONS
INSTRUCCIONES DE INSTALACIÓN

INSTALLATION INSTRUCTIONS
mirage Filtered
Water Pitc er
Model Series WFPT200
traditional Filtered
Water Pitc er
Model Series WFPT100
vista Filtered
Water Pitc er
Model Series WFPT075
PROPER INSTALLATION: Please read all instructions specifications and
precautions before installing and using your water filter system.
®
WFPT200 / WFPT100 / WFPT075
Information & Assistance
www.waterfiltration.DuPont.com
866-709-2086 Toll Free 800-441-7515
For Service Requests & Product Information For Safety & Health Questions
Protect Plus LLC • Hickory NC 28601 USA

2 V4.6
Mirage Filtered Water Pitcher
Components & Features
PARTS & HARDWARE INCLUDED
•Mirage Pitcher with Reservoir
•One (1) Great Taste Universal Pitcher Cartridge
TOOLS & MATERIALS
NEEDED FOR INSTALLATION
•Cold running water.
•One tall water glass, large enough to soak the cartridge.
•Mild soap for washing the pitcher.
Filter
Cartridge
Reservoir
Lid
Pitcher
WFPT200 / WFPT100 / WFPT075

3
PARTS & HARDWARE INCLUDED
•Traditional Pitcher with Reservoir
•One (1) High Protection/High Capacity Filter
TOOLS & MATERIALS
NEEDED FOR INSTALLATION
•Cold running water.
•One tall water glass, large enough to soak the cartridge.
•Mild soap for washing the pitcher.
Filter
Cartridge
Reservoir
Lid Filter Life
Calendar
Pitcher
V4.6
WFPT200 / WFPT100 / WFPT075
Traditional Filtered Water Pitcher
Components & Features

4 V4.6
Vista Filtered Water Pitcher
Components & Features
PARTS & HARDWARE INCLUDED
•Vista Pitcher with Reservoir
•One (1) Great Taste Universal Pitcher Cartridge
TOOLS & MATERIALS
NEEDED FOR INSTALLATION
•Cold running water.
•One tall water glass, large enough to soak the cartridge.
•Mild soap for washing the pitcher.
Filter
Cartridge
Reservoir
Lid
Pitcher
WFPT200 / WFPT100 / WFPT075

5
Wash You Hands
Wash your hands with soap and water and remove the cartridge from the
cartridge bag.
Step
Soak Ca t idge
Soak the cartridge upright in cold tap water for 15
minutes. Your cartridge is packed dry to preserve the
carbon freshness. Soaking activates the carbon and
prepares the cartridge for use. You may need to use
weights to keep the cartridge submerged during
this step.
2
WFPT200 / WFPT100 / WFPT075
1
Step
Installation
V4.6

6 V4.6
4
Step
Flush Ca t idge
After the cartridge has soaked for 15 minutes flush the
cartridge by holding it upright under cold running tap
water for 15 seconds.
Wash Pitche
Hand wash the pitcher lid and reservoir with mild soapy water and rinse well.
3
Step
Installation

7
D ain Excess Wate
Allow excess water to drain completely from the cartridge.
6
Step
Inse t Ca t idge
Insert the cartridge into the reservoir by lining up the notch in the cartridge with
the rib in the cartridge reservoir. Press the cartridge in
firmly to ensure a tight seal. Fill the reservoir with cold tap
water. It is normal for carbon particles to appear in the
first few fillings. Use the first two pitchers of filtered water
to water plants or simply discard.
WFPT200 / WFPT100 / WFPT075
5
Step
Installation
V4.6

8 V4.6
Fill Rese voi
Fill the top reservoir with cold tap water and allow it to drain into the pitcher.
Enjoy the refreshing taste of filtered water.
NOTE: Before refilling your pitcher press firmly on the
cartidge in the reservoir to assure a good seal.
8
Step
Set Filte Life Calenda o Ma k Calenda
For Pitchers with a built-in Filter Life Calendar set the
calendar for two months from now. Remember to change
your DuPont cartridge every two months for refreshing
great tasting water. Otherwise please mark your calen-
dar two months from now.
Water Temp < 85F/29C
Do Not Filte Hot Wate
7
Step
Installation

10 V4.6
Replacement Cartridges
DuPont™ Filtered Water Pitchers
Usage and quality of water in your incoming water line affect the life of filter cartridges and determine
when the cartridge should be changed. Cartridges should be replaced sooner if water flow rate begins
to slow noticeably or if the filter fails to perform satisfactorily.
All DuPont™ Pitcher Cartridges and DuPont™ Pitchers are interchangeable. All DuPont™ cartridges
are designed to filter water in any similar DuPont™ system. A filter cartridge’s stated reduction
capacity is tied to the cartridge’s performance within a specific filtration system for which is it has
been tested and certified. Please see the Performance Data Sheet for the certified performance of
specific systems with stated cartridges.
•These filters are not water purifiers. Do not use with water that is microbiologically
unsafe or of unknown quality without adequate disinfection before or after the system.
•This unit is not designed to filter sulfur (rotten egg odor). Use of carbon filters to treat
sulfur may intensify taste/odor problems.
•Please comply with all state and local regulations regarding the installation of water
treatment devices.
•The contaminants or other substances reduced by the water filter device are not
necessarily in your water.
Cartridge Model Number/
System Sold With
WFPTC050
W
WFPTC100Y
FPTC100
Mirage Filtered Water Pitcher
WFPT200 Series
Traditional Filtered Water Pitcher
WFPT100 Series
Original System Certification
WFPTC050
Vista Filtered Water Pitcher
WFPT075 Series
CAUTION

9
Instructions for Use
1. To use your DuPont™ pitcher remove the pitcher lid and fill the upper
reservoir with cold water. The water will filter by gravity to the lower
portion of the pitcher.
2.If you prefer to have your water chilled place the entire pitcher in the
refrigerator.
3.At the end of two months replace the cartridge using the
instructions described.
WFPT200 / WFPT100 / WFPT075
Operation/Maintenance Data
These units are intended for non-commercial use. They should be used only in ambient
air temperature of between 35 degrees F / 2 degrees C and 85 degrees F / 29 degrees C.
Placement of these units in direct sunlight or use of electrical heating equipment on
these units must be avoided. Replace filter cartridge when and as directed in the
installation/operation instructions included with each cartridge. Replacement filter
cartridges are available at retail outlets.
V4.6

11
WFPT200 / WFPT100 / WFPT075 V4.6

INSTRUCCIONES DE INSTALACIÓN
jarra de agua
filtrada mirage
Modelo serie WFPT200
jarra de agua
filtrada tradicional
Modelo serie WFPT100
jarra de agua
filtrada vista
Modelo serie WFPT075
INSTALACIÓN CORRECTA: Antes de instalar y usar su sistema de filtrado de agua lea
todas las instrucciones especificaciones y precauciones.
®
12 V4.6
Información y asistencia
www.waterfiltration.dupont.com
866-709-2086 Gratis 800-441-7515
Para solicitudes de servicio e información de producto Para formular preguntas sobre salud y seguridad
Protect Plus LLC • Hickory NC 28601 USA

Jarra de agua filtrada Mirage
Componentes y características
PIEZAS Y ELEMENTOS DE MONTAJE INCLUIDOS
• Jarra Mirage con depósito
• Un (1) cartucho universal de la jarra del gran gusto
MATERIALES NECESARIOS PARA
LA INSTALACIÓN
• Agua corriente fría.
• Un vaso de agua alto de tamaño suficiente para remojar el cartucho.
• Jabón suave para lavar la jarra.
13
WFPT200 / WFPT100 / WFPT075
Cartucho
del filtro
Depósito
Tapa
Jarra
V4.6

Jarra de agua filtrada Traditional
Componentes y características
PIEZAS Y ELEMENTOS DE MONTAJE INCLUIDOS
• Jarra Traditional con depósito
• Un (1) alta filtros de la protección/de la alta capacidad
MATERIALES NECESARIOS PARA
LA INSTALACIÓN
• Agua corriente fría.
• Un vaso de agua alto de tamaño suficiente para remojar el cartucho.
• Jabón suave para lavar la jarra.
14
WFPT200 / WFPT100 / WFPT075
Cartucho
del filtro
Depósito
Tapa Calendario
de vida útil
del filtro
Jarra
V4.6

Jarra de agua filtrada Vista
Componentes y características
PIEZAS Y ELEMENTOS DE MONTAJE INCLUIDOS
• Jarra Vista con depósito
• Un (1) cartucho universal de la jarra del gran gusto
MATERIALES NECESARIOS PARA
LA INSTALACIÓN
• Agua corriente fría.
• Un vaso de agua alto de tamaño suficiente para remojar el cartucho.
• Jabón suave para lavar la jarra.
15
WFPT200 / WFPT100 / WFPT075
Cartucho
del filtro
Depósito
Tapa
Jarra
V4.6

Lávese las manos
Lávese las manos con agua y jabón y retire el cartucho de su envoltorio.
Paso
Remoje el ca tucho
Sumerja y remoje el cartucho en posición vertical en
agua corriente fría durante 15 minutos. Su cartucho
está empaquetado en seco para preservar la frescura
del carbón. El remojo activa el carbón y prepara el
cartucho para usar. Puede ser necesario usar
contrapesos para mantener sumergido el cartucho
durante este paso.
2
16 V4.6
1
Paso
Instalación

4
Paso
Lave el ca tucho
Después de remojar el cartucho durante 15 minutos lávelo
sosteniéndolo en posición vertical bajo el agua fría corriente
del grifo durante 15 segundos.
Lave la ja a
Lave la jarra la tapa y los depósitos a mano con agua jabonosa suave y
enjuague bien.
17
WFPT200 / WFPT100 / WFPT075
3
Paso
Instalación
V4.6

Escu a el exceso de agua
Permita que el exceso de agua se escurra completamente del cartucho.
6
Paso
Inse te el ca tucho
Inserte el cartucho en el depósito alineando la muesca del
cartucho con la del depósito del mismo. Presione firme-
mente el cartucho para asegurar un sellado hermético.
Llene el depósito con agua fría del grifo. Es normal que
aparezcan partículas de carbón en los primeros llenados.
Use las dos primeras jarras de agua filtrada para regar las
plantas o simplemente deséchelas.
18 V4.6
5
Paso
Instalación

Llene el depósito
Llene el depósito superior con agua fría del grifo y déjela escurrir hacia
la jarra. Disfrute el sabor refrescante del agua filtra-
da.
NOTA: Antes de volver a llenar la jarra presione firmemente
el cartucho en el depósito para asegurar un buen sellado.
8
Paso
Coloque el calenda io de vida del filt o o
ma que en el calenda io
Para jarras con un calendario de vida de filtro integrado
coloque el recordatorio en la tapa del depósito para dos
meses a partir de ahora. Recuerde cambiar el cartucho
DuPont cada dos meses para obtener agua refrescante
de estupendo sabor.
Temp del agua < 85°F/29°C
No filt e agua caliente
19
WFPT200 / WFPT100 / WFPT075
7
Paso
Instalación
V4.6
