Dual MMC36BT Installation instructions

INSTALLATION/OWNER'S MANUAL
Marine Receiver with Speaker Zone Control
MMC36BT
Inputs
Weather
Band
Tunner

2
MMC36BT
Please read entire manual before installation.
Installation
Mounting the Controller
1. Choose a mounting location in the dash board or instrument panel that will
allow room behind to run the cables to the black box. Consider how you
will use the AUX IN, LINE OUTPUTS and USB connector and route the appropriate
extension and RCA cables to an accessible area for installation.
3. Once you have determined a mounting location, you will need to cut a rectangular
shaped hole in the panel (4.84” X 3.15” / 123mm X 80mm).
IMPORTANT! Do not mount the commander or black box where they are submerged in water.
4. After the hole is cut slide the commander and wiring into the hole.
5. Slide the included spring washers (B) over the screw posts (A) and attach the screw
posts to the back of the commander.
6. Place the “U” bracket (C) over the screw posts and secure the radio to the dash using the
included hex nuts (D). If necessary, cut the score marks (E) on either side of the mounting
bracket to custom fit the bracket length for your application.
NOTE: Before final installation, test the wiring connections to make sure the unit
is connected properly and the system works.
7. When the black box installation, use the 4 rubber mounting stoppers (included in package)
on the bottom of the black box. This provides clearance from surface moisture and provides
sufficient ventilation for the heat.
9. Plug in all wiring harnesses and cables.
C
D
E
A
B
BLACK BOX
RUBBER STOPPER (4EA)
CONTROLLER Cutout dimensions
123mm X 84mm
123.0
84.0
R5.0
2. The contorller should be mounted to a dry, clean and flat surface.
8. Connect the controller to the black box using the supplied 13-pin DIN cable.

3
MMC36BT
Wire Connection
Fuse:
When replacing the fuse, make
sure new fuse is the correct type
and amperage. Using an incorrect
fuse could damage the radio.
Tip:
When a suitable ground wire is
not present in the vehicle wiring
harness, connect the black ground
wire to the vehicle chassis.
ACC (+12V)
GROUND (-)
CAMERA (+)
AMP TURN-ON (+)
REVERSE (+)
(Brown)
(Gray)
(Black)
(Yellow)
(Blue)
(Blue)
(White)
(Red)
(White)
(Red)
(White)
(Red)
FRONT
CHANNEL AUX
SUBWOOFER REAR
CHANNEL
FUSE
(Red)
(Black)
(Brown)
(Blue)
(Orange)
(Yellow)
LINE OUT
LEFT
LINE OUT
RIGHT
LINE OUT
LEFT
LINE OUT
RIGHT
AUX IN
LEFT
AUX IN
RIGHT
Zone 1
SPEAKERS
Zone 2
SPEAKERS
Zone 3
SPEAKERS
(White)
(White/Black)
FRONT LEFT
FRONT RIGHT
REAR LEFT
REAR RIGHT
(Gray)
(Gray/Black)
(Green)
(Green/Black)
(Violet)
(Violet/Black)
(White)
(White/Black)
(Gray)
(Gray/Black)
(Green)
(Green/Black)
(Violet)
(Violet/Black)
DISPLAY
CONTROLLER
Male
Female
13-pin Din Cable
3m (10 feet)
SWI INPUT USB CAMERA INPUT
ANTENNA
(Black)
(Black)
LEFT
RIGHT
LEFT
RIGHT
(Black)
(Optional MWR17)
DISPLAY
CONTROLLER
20A
ZONE 1
ZONE 2 & 3

4
MMC36BT
Mode / Camera
Disp / Function
Screen / Play / Pause
Audio / Menu
Band / ESC
Power / Mute
Preset Up / Folder Up
Preset Down / Folder Down
Speaker Zone 1
Speaker Zone 2
Speaker Zone 3
Select
Tune / Track Up
Tune / Track Down
1
2
3
4
1
10
2
11
3
12
4
13
5
14
6
15
7
Volume Knob
8
9
13
10 6
5
11
12
14
15
Control Locations - Receiver
7
98

5
MMC36BT
General Operation
Power On/Off
Changing Modes
Volume
Mute
Auxiliary Inputs
Display
Audio/Menu
Reset
Press the button to turn the unit on. Press and hold
to turn unit off.
Press MODE to select between Radio, Weatherband Tuner, AUX,
Bluetooth, USB, iPod. Modes of operation are shown in the display.
Adjust volume using the volume knob.
Press to silence the audio. Press again to resume
listening at the previously selected volume.
Press DISP to toggle display between various displayed
information.
Press
options.
Audio/Menu to access the audio and setup menu
If abnormal operation occurs, press and hold Audio/Menu
and TUNE
nn
for 3 seconds to reset the unit to the
default factory settings.
Press the Zone 1 button to turn on/off the sound from this zone
.
Speaker Zone 1
Speaker Zone 2
Speaker Zone 3
Press the Zone 2 button to turn on/off the sound from this zone.
Press the Zone 3 button to turn on/off the sound from this zone.
The MMC36BT includes the IP35USB adapter which allows the
AUX and USB inputs on the black box to be mounted in the boats
console for easy access. Refer to the wiring diagram for connection
instructions. Press the Mode button to select the AUX input or USB
input depending on which input you have connected your device to.

6
MMC36BT
General Operation
Audio Setup Menu
Menu Function Options
EQ Presets Rotate the volume knob to cycle through the following EQ presets : Flat, Pop,
Jazz, Classic, Beat, Rock and User. Any manual adjustment to the Bass or
Treble settings are automatically saved as User.
Bass Level Rotate the volume knob to adjust the bass level setting
(-6 minimum / +6 maximum).
Bass Frequency Rotate the volume knob to select one of the following bass frequency settings:
60 Hz, 80 Hz, 100 Hz or 200 Hz.
Mid Level
Rotate the volume knob to adjust the middle level setting
(-6 minimum / +6 maximum).
Mid Frequency Rotate the volume knob to select one of the following middle frequency settings:
500 Hz, 1 kHz, 1.5 kHz or 2.5 kHz.
Treble Level Rotate the volume knob to adjust the treble level setting
(-6 minimum / +6 maximum).
Treble Frequency Rotate the volume knob to select one of the following treble frequency settings:
10 KHz, 12.5 KHz, 15 KHz or 17.5 KHz.
Balance Rotate the volume knob to adjust the balance setting.
(12-L to 12-R; 0 represents equal balance).
Fader Rotate the volume knob to adjust the fader setting.
(12-F to 12-R; 0 represents equal balance)
Subwoofer Rotate the volume knob to turn subwoofer output ON or OFF.
Subwoofer Level Rotate the volume knob to adjust subwoofer level between 0 and 12.
Subwoofer
Frequency
Rotate the volume knob to select one of the following subwoofer center
frequency settings: Off, 80 Hz, 120 Hz and 160 Hz. "Off" represents a full range
subwoofer output.
Press MENU to toggle through and select one of the
following setup menus: Audio, General, Gain and Radio.
1. Once the desired menu is displayed, rotate the volume
knob to scroll through the list of menu features.
2. Press SELECT to select a specific feature to adjust, then
rotate the volume knob left/right to adjust or activate
the desired feature.
3. Press SELECT to confirm and save the changes.
Setup Menu
LOUD Off : Disables the loudness function.
LOUD Low : Enables the loudness function. Activating this feature will enhance
the bass and treble frequencies when listening to music at low volumes.
LOUD High : Enables the loudness function. Activating this feature will enhance
the bass and treble frequencies when listening to music at low volumes.
Loudness
Rotate the
Off,High,Low
volume knob to cycle through the following Loundness curves:

Backlight
Rotate the volume knob to adjust the brightness settings of
the display screen from 1 to 7.
Demo
Rotate the volume knob to enable (ON) or disable (OFF)
the demonstration mode.
7
MMC36BT
General Operation
Menu Function Options Action
Scrolling
Option
Off Programs the unit to not scroll any information on the
display.
Once Programs the unit to only scroll information once.
15Sec Programs unit to scroll information once every 15 seconds
(default).
On
Programs unit to scroll information continuously.
Beep
Confirmation
Off
Disables the confirmation beep.
On Enables the confirmation beep.
Programmable
Turn On Volume
Variable
Value
Programs unit to always turn on at a specific volume
(default is Off). A volume level of 1-30 can be selected.
General Setup Menu
Low Battery
Battery Voltage drops(10.8V+/-0.03V)a Beep will sound.(default)
Battery Voltage drops(10.8V+/-0.03V)a Beep will not sound.
Variable
Value
Off
On

8
MMC36BT
General Operation
Gain Setup Menu
Menu Function Options
Tuner Gain Rotate the volume knob to adjust the tuner gain.
(-6 minimum / +6 maximum)
Aux Gain Rotate the volume knob to adjust the gain for the front auxiliary input.
(-6 minimum / +6 maximum)
Bluetooth Rotate the volume knob to adjust the gain for the rear auxiliary input.
(-6 minimum / +6 maximum)
USB Gain Rotate the volume knob to adjust the gain for USB playback.
(-6 minimum / +6 maximum)
iPhone/iPod Gain Rotate the volume knob to adjust the gain for iPod playback.
(-6 minimum / +6 maximum)
Radio Setup Menu
Menu Function Options Action
Tunner
Frequency
Spacing
USA Programs the unit to USA tuner spacing.
(200kHz for FM and 10kHz for AM).
Auto Station
Store
S-America Programs the unit to South American tuner spacing.
(100kHz for FM and 10kHz for AM).
Europe
Local/Distance
Tuning
AUTO STORE Press SELECT to seek and save 6 strong stations in the
current band.
Activales distance tuning.OFF
On Activales local tuning for strong station reception only.
Programs the unit to European tuner spacing.
(50kHz for FM and 9kHz for AM).

9
MMC36BT
Manual Tuning
Seek Tuning
Band
Storing Station Presets
Recalling Station Presets
Press TUNE
nn
or TUNE
ll
momentarily to change
radio frequency up or down one step at a time. Press and
hold to advance quickly.
Press TUNE
nn
or TUNE
ll
for more than two seconds
(then release) to automatically seek and tune to the next
strong station.
Press BAND to select between FM1, FM2, FM3, WB, AM1 and
AM2 bands.
Select the desired band and station. Press the
(F)unction button, turn the volume knob until the desired
preset number is highlighted, then press SELECT to store
the preset.
Press the P+ or P- buttons to cycle through the 1-6 presets
in the current band.
AM/FM Tuner Operation
Manual Tuning
Band
Press TUNE
nn
or TUNE
ll
momentarily to seek the next
weather band station.
Press BAND to select Weatherband(WB)
Weather Band Tuner Operation
Recalling Station Presets Press the P+ or P- buttons to cycle through the 1-6 presets
in the current band.

10
MMC36BT
Playing MP3 Files
Displaying Information
Repeat
Random
Intro
To play MP3 files, connect a USB device containing
MP3 files. “Loading" will flash in the display.
Depending on the number of files and folders, this may take
several seconds.
Press DISP to cycle between track information and file/
folder information.
*Song title, artist name and album name will only be
displayed if included with the MP3 file.
When referring to MP3 playback, the following terms
are synonymous:
•File name and track name
•Folder name and directory name
Press (F)unction to enter the Function Menu, then rotate
the volume knob until Repeat is highlighted. Press SELECT,
then rotate the volume knob to select one of the following
repeat options.
•All - Plays all songs on device.
•Track - Continuously repeats selected song.
•Folder - Continuously repeats all songs in selected
folder.
Press (F)unction to enter the Function Menu, then rotate the
volume knob until Random is highlighted. Press SELECT,
then rotate the volume knob to select one of the following
options for random playback.
•Off - Cancels the Random function.
•All - Plays all songs in random order.
•Folder - Plays all songs in folder in random order.
Press (F)unction to enter the Function Menu, then rotate the
volume knob until Intro is highlighted. Press SELECT, then
rotate the volume knob to select one of the following options
for intro playback.
•Off - Cancels the Intro function.
•All - Plays first 10 seconds of each song.
•Folder - Plays first 10 seconds of each song in folder.
Note: Folder repeat, random and intro options only function
on devices recorded with more than one folder.
MP3 Operation
