Dukane Camera 335 User manual

#401-335-00
Camera 335
Document Camera
User’s Guide

0
Table of Contents
CHAPTER 1 PRECAUTIONS ................................................................................ 2
zSafety Precautions ................................................................................... 3
zFCC Warning............................................................................................ 3
zEN55022 (CE Radiation) Warning............................................................ 3
CHAPTER 2 PACKAGE CONTENT ...................................................................... 4
CHAPTER 3 PRODUCT OVERVIEW .................................................................... 5
3.1 PRODUCT INTRODUCTION............................................................................ 5
3.2 I/O CONNECTION ........................................................................................ 6
3.3 DIP SWITCH SETTING ................................................................................. 6
REMOTE CONTROL ............................................................................................ 7
CHAPTER 4 HOW TO USE IT ............................................................................... 8
4.1 GETTING STARTED...................................................................................... 8
4.1.1 TURN ON THE DOCUMENT CAMERA.......................................................... 8
4.1.2 AUTOMATIC IMAGE ADJUSTMENT ............................................................. 8
4.2 MAJOR FUNCTIONS..................................................................................... 9
4.2.1 SELECT INPUT SOURCE........................................................................... 9
4.2.2 『PHOTO/TEXT』MODES ........................................................................ 9
4.2.3 ZOOM IN /OUT....................................................................................... 10
AUTO FOCUS ................................................................................................... 10
BRIGHTNESS ADJUSTMENT .............................................................................. 10
4.2.6 DISPLAY THE COMPLETE CONTROL MENU (OSD) ON SCREEN DISPLAY.... 11
MENU NAVIGATION AND SELECTION ................................................................... 11
4.3 ADVANCED FUNCTIONS ............................................................................. 12
4.3.1 CAPTURE OF IMAGES ............................................................................ 12
4.3.2 PLAY BACK CAPTURED IMAGES.............................................................. 12

1
4.3.3 DELETE CAPTURED IMAGES .................................................................. 12
4.3.4 PRESET CONTROLS ............................................................................... 13
4.3.5 AUTO ERASE ........................................................................................ 13
CHAPTER 5 CONTROL MENU (OSD MENU) INTRODUCTION (ON SCREEN
DISPLAY).............................................................................................................. 15
5.1 OPERATION .............................................................................................. 15
5.2 CONTROL MENU (OSD MENU) .................................................................. 15
CHAPTER 6 USER SOFTWARE INSTRUCTIONS - USB335 ............................ 18
6.1 INSTALLATION........................................................................................... 18
6.2 FUNCTIONS (USB335 SOFTWARE) ........................................................... 22
Top window tool bar Functions ...................................................................... 24
6.2.1 FILE (FOLDER ICON) ............................................................................ 24
INITIAL WINDOW (BEFORE CAMERA IMAGE IS PRESENT) ............................... 24
REAL TIME (LIVE CAMERA IMAGE) ................................................................. 25
6.2.3 EDIT MODE............................................................................................ 25
6.2.4 FREEZE ................................................................................................ 25
6.2.5 CAPTURE.............................................................................................. 25
6.2.6 PAINT TOOL (ANNOTATION)................................................................ 26
6.2.7 FULL SCREEN ....................................................................................... 26
6.2.8 IMAGE ADJUST (FOR THE LIVE IMAGE) ................................................... 26
6.2.9 IMAGE PREVIEW VIEW TOOL BAR ........................................................... 27
6.3 OPERATION INFORMATION ......................................................................... 29
6.3.1 DISPLAY IMAGE：................................................................................. 29
6.3.2 EDIT IMAGE：ANNOTATION ................................................................... 30
6.3.3 USB335 SOFTWARE MENUS................................................................. 30
CHAPTER 7 TROUBLESHOOTING.................................................................... 32

2
Chapter 1 Precautions
Always follow these safety instructions when setting up and using the Document Camera:
1. Please do not tilt the machine while using.
2. Do not place the Document Camera on an unstable trolley, stand or table.
3. Do not use the Document Camera near water or source of heat.
4. Use attachments only as recommended.
5. Use the type of power source indicated on the Document Camera. If you are not sure
of the type of power available, consult your dealer or local electricity company for
advice.
6. Place the Document Camera where it can be easily unplugged.
7. Always take the following precautions when handling the plug. Failure to do so may
result in sparks or fire.
Ensure the plug is free of dust before inserting it into a socket.
Ensure that the plug is inserted into the socket securely.
8. Do not overload wall sockets, extensions leads or multi-way plug boards as this may
cause fire or electric shock.
9. Do not place the Document Camera where the cord can be stepped on as this may
result in fraying or damage to the lead or the plug.
10. Unplug the projector form the wall socket before cleaning. Use a damp cloth for
cleaning. Do not use liquid or aerosol cleaners.
11. Do not block the slots and openings in the case. They provide ventilation and prevent
the Document Camera from overheating. Do not place the Document Camera on a
sofa, rug or other soft surface or in a built-in installation unless proper ventilation is
provided.
12. Never push objects of any kind through cabinet slots. Never allow liquid of any kind to
spill into the Document Camera.
13. Except as specifically instructed in this User’s Manual, do not attempt to operate this
product by yourself. Opening or removing covers may expose you to dangerous
voltages and other hazards. Refer all servicing to licensed service personnel.
14. Unplug the Document Camera during thunderstorms or if it is not going to be used for
an extended period, do not place the Document Camera or remote control on top of
beat-emitting equipment or heated objects such as a car and etc.
15. In the following situations, unplug the Document Camera from the wall outlet and
refer servicing to licensed service personnel:
If the power cable or plug becomes damaged or frayed.

3
If liquid is spilled into it or the Document Camera has been exposed to rain or
water.
zSafety Precautions
Warning: To reduce the risk of fire or electric shock, do not expose this
appliance to rain or moisture.
This Document Camera has a 2 wire AC line Plug. This is a safety feature to ensure that the
plug will fit into the power outlet. Do not try to defeat this safety feature.
If the Document Camera will not be used for an extended time, unplug it from the power
outlet.
Caution: To reduce the risk of electric shock. Do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to licensed service Personnel.
This symbol indicates that
dangerous voltage
constituting a risk of electric
shock is present within this
unit.
This symbol indicates that
there are important operating
and maintenance instructions
in this User’s Manual with this
unit.
zFCC Warning
This Document Camera has been certified to comply with the limits for a Class A computing
device, pursuant to Subpart J of Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against a harmful interference when the equipment is operated in a
commercial environment.
zEN55022 (CE Radiation) Warning
This product is intended for use in a commercial, industrial, or educational environment. It is
not intended for residential use.
This is a Class A product. In a domestic environment it may cause radio interference, in
which case the user may be required to take adequate measures. The typical use is in a
conference room, meeting room or auditorium.
CAUTION
RISK OF ELECTRIC SHOCK

4
Chapter 2 Package Content
Please make sure the package comes with the following items when you unpack:
(Total 9 items)：
Main Unit User’s Guide CD
Remote Warranty Card Power Cable
VGA Cable C-Video Cable USB Cable
DVI Adapter (Optional)

5
Chapter 3 Product Overview
3.1 Product Introduction
8. DIP Switch
7. Infrared receiver area
9. Auxiliary Stand
5. I/O Connection
3. Gooseneck
4. Lamp
2. Lens
1. Auto Focus Button
6. Power／Control keypad

6
3.2 I/O Connection
3.3 DIP Switch Setting
Factory default settings are as the following:
ved
ON
OFF
PAL C-Video SVGA Reserved
NTSC RGB XGA Reserved
(Reserved is OFF all the time)
1234

7
3.4 Remote Control
* Only use CR2025 as replacement battery. Please properly dispose of any used
batteries.
1. Power:
Power on or off.
2. Source:
Switch between different signal
sources.
3. BRT+/-:
Make the image brighter or darker
4. Menu:
Show the Control Menu (OSD, On
Screen Display, Menu)
5. Capture:
Capture the image
Play／Del:
Recall／Delete the saved images in the
flash memory of your Document
Camera.
6. ghij / Enter:
ghij:Select function
Enter: Enable the selected function
7. Zoom +/-:
Make the image larger & smaller
8. Focus +/- :
Manual Focus for fine adjustment
9. AF:
Auto Focus
10. Lamp:
Turn on/ off Lamp
11. AWB:
Auto white balance.
12. Flip:
Rotate the image by 180 degrees
13. Auto Adjust:
Auto-adjust for the optimum image
14. Freeze:
Freeze the image
15. Preset:
Save/load your setting parameters
(like brightness, lamp and focus)
16. Photo/ Text:
Select the text or photo mode
1
2
3
7
6
8
5
15
9
16
10
12
11
4
14
13

8
Chapter 4 How to use it
4.1 Getting Started
4.1.1 Turn on the Document Camera
When the power cord is plugged in, the LED indicator will be "Red".
When turned on, the LED indicator will be "Blue".
4.1.2 Automatic Image Adjustment
Auto-adjust to obtain the optimum image. It may require a few seconds
for this process.
Keypad Remote

9
4.2 Major Functions
4.2.1 Select Input Source
The default input source is set as the "Document Camera", press 『Source』to switch.
4.2.2 『Photo/Text』Modes
The default setting is "Photo". Users can switch mode by pressing "Photo/Text" button.
Keypad Remote
Remote
Monitor
Projector
PC
Notebook

10
4.2.3 Zoom in / out
4.2.4 Auto Focus
4.2.5 Brightness Adjustment
Goose-head Remote

11
4.2.6 Display the complete control menu (OSD) On Screen Display
4.2.7 Menu navigation and selection
1. Press『^ v< >』navigate menu.
2. Press『Enter』to select.
Keypad Remote
Keypad
Remote

12
4.3 Advanced Functions
4.3.1 Capture of Images
Remote or Keypad：：Press『Capture』button from remote control.
4.3.2Play back captured Images
Remote or Keypad：
1. Press『Play』to show thumbnail images in memory.
2. Use『ef』to select thumbnail.
3. Press『Enter』to display as full screen.
4. Use『ef』to view next image.
5. Press『Play』to go back to thumbnail images.
6. Press『Menu』to Exit.
4.3.3 Delete Captured Images
Remote:
1. Press『Play』to show all thumbnail images in memory.
2. Use『ef』to select.
3. Press『Del』to delete.
4. Press『Menu』to Exit
Keypad:
1. Press『Play』to show all thumbnail images in memory.
2. Use『ef』select one.
3. Press『Enter』to display a full screen image.
4. Press『Menu』to invoke the on screen Control Menu (OSD Menu).
5. Use『ef』to select (Storage).
6. Use『dS』to select『Delete』or 『Delete All』

13
7. Press『Enter』to execute.
8. Press 『Menu』to Exit
4.3.4 Preset controls
Preset save: Save the customized user setting parameters (Ex. Zoom,
brightness, color, AE setting).
1. Press『Preset』to entry the Preset menu.
2. Use『d』to『save』
3. Use『f』to『Yes』
4. Press『Enter』to execute.
Preset Load：Invoke the customized user setting parameters (Ex. Zoom,
brightness, color, AE setting).
1. Press『Preset』to entry the Preset menu.
2. Use『d』to『Load』
3. Use『f』to 『Yes』
4. Press『Enter』to execute.
【NOTICE】You can store up to four presets in each of five image modes 1.
Normal 2.Gray 3.Slide 4.Microscope 5.Film.
4.3.5 Auto Erase
With Auto Erase function turned on, all captured images will be erased
automatically once the Document Camera is turned off.
1. Press『Menu』to invoke the full Control Menu (OSD Menu).
2. Use『f』to (Storage).
3. Use『S』to select『Auto Erase』.
4. Use『f』to『On』.

14
5. Use『d』to『Yes』.
6. Press『Enter』to execute.

15
Chapter 5 Control Menu (OSD Menu)
Introduction (On Screen Display)
5.1 Operation
A. Use『fe』to select main function.
B. Use『dS』to select sub-item.
C. The activated item with red line and yellow block. Use『dS』to select other
items.
D. 『fe』: For More functions, you can press『fe』to execute.
E. 『』:If Only one item is desired , you can press『Enter』to execute.
F. Press『Menu』to Exit.
5.2 Control Menu (OSD Menu)
zThere are Display, Storage, Setting and Advanced function pages in the
Control Menu (OSD Menu).
zThe menu will be automatically turned off when not being used for a
while.
OFF
OFF
OFF
100
c
dfe
Freeze
Flip
Digital Zoom
Focus
100
A
B
CD

16
¾VGA Mode (Computer Image output mode)
Layer 1 Layer 2 Layer 3 Description
Image Normal/Gray/Slide/
Microscope/Film
Select Normal/Gray/Slide/
Microscope/Film image mode
Freeze ON ／OFF Use Freeze to retain the image on
the screen.
Flip ON ／OFF Flip image by 180°
(Up→Down & Left→Right )
Gamma Photo / Text Select Photo or Text mode
Digital Zoom 100%~1600% Adjust Zoom 100% ~ 1600%
Display
Focus 0~Max Adjust image focus
Delete Execute Delete captured images
Delete All Yes／No Delete all captured images
Format Yes／No Format internal storage memory
Storage
Auto Erase ON／OFF Delete all captured images when
user turns off the power.
Lamp ON ／OFF Select Lamp On or Off.
AE ON ／OFF Auto Exposure
Night vision ON／OFF Select Night view function On or
Off.
Setting
Factory Reset Yes／No Restore unit back to factory
setting
Preset Load Yes／No Invoke the customized user
setting values
Advance
Preset Save Yes／No Save a set of customized user
setting values

17
¾C-Video Mode ( Composite Video output mode)
This is a low resolution output that requires the camera’s bottom
switch to be reset. THERE IS NO COMPOSITE VIDEO OUTPUT
WHEN THE “COMPUTER IMAGE” MODE IS USED.
Layer 1 Layer 2 Layer 3 Content
Focus -/+ 100~300
Gamma Photo／Text Select Photo／Text mode
Image Normal／Gray Select Normal／Gray mode
Freeze OFF／ON Use Freeze to retain the image on the
screen.
Display
Exit Exit the Menu
Lamp ON／OFF Turn on/off lamp
Advance
Full Range
ON/OFF
Night vision
ON/OFF
Exit
Adjust On or Off of Full screen &
Night view function
Factory Reset Enter / Exit Select a fitting output format.
Setting
Exit

18
Chapter 6 User software instructions
- USB335
Using the Camera USB with a Computer
6.1 Installation
1. Insert the software CD in your computer’s CD-ROM.
2. Connect the Camera and PC with USB Cable. Follow instructions for
driver download.
3. Before you install USB335, please be sure your system meets these
requirements.
zOperation System：Windows XP SP2, Windows 2000 SP4,
zCPU：Intel Pentium 4 2.0 G over and above
z256MB RAM
zMinimum 40MB HD space
zCD ROM、DVD ROM。（installation use）
zDisplay : 1024x768 above
zMicrosoft Office Power Point
4. The “Auto run” program will be shown automatically, if you would like to
