JHW4 | AUTHENTIC HENDRIX™'69 PSYCH SERIES BAND OF GYPSYS® FUZZ 2
Get the unique and bitingly aggressive
Band of Gypsys™fuzz sound in an MXR
mini housing with a Tone control
for sonic ne-tuning. This pedal
comes emblazoned with the trippy,
kaleidoscopic designs of award-winning
UK-based design crüe ILOVEDUST.

JHW4 | AUTHENTIC HENDRIX™'69 PSYCH SERIES BAND OF GYPSYS® FUZZ 3
1OUTPUT knob controls overall volume of effect
2TONE knob shapes EQ of effect
3FUZZ knob controls intensity of fuzz effect
4FOOTSWITCH toggles effect on/bypass (blue LED indicates on)
13
2
4
External Controls

JHW4 | AUTHENTIC HENDRIX™'69 PSYCH SERIES BAND OF GYPSYS® FUZZ 4
Basic Operation
1 Run a cable from your guitar to JHW4’s INPUT jack and another
cable from JHW4’s OUTPUT jack to your amplifier.
2Start with OUTPUT, TONE, and FUZZ controls at 12 o’clock.
3 Turn effect on by depressing the footswitch.
4Rotate VOLUME knob clockwise to increase overall volume
or counterclockwise to decrease it.
5Rotate TONE knob clockwise to for a brighter sound or
counterclockwise for a warmer sound.
6Rotate FUZZ knob clockwise to increase the amount of fuzz
or counterclockwise to decrease it.
Authentic Hendrix™’69 Psych Series Band of Gypsys®
Fuzz is powered by the Dunlop ECB003 9-volt adapter
or the DC Brick™, Iso-Brick™, and Mini Iso-Brick™power
supplies. This pedal cannot be powered by a battery.
Power
Directions

JHW4 | AUTHENTIC HENDRIX™'69 PSYCH SERIES BAND OF GYPSYS® FUZZ 5
Input Impedance 30 kΩ
Output Impedance
Max Volume 33 kΩ
Mid Volume 80 kΩ
Noise Floor* -83 dBV
Bypass True Hardwire
Current Draw 4.3 mA
Power Supply 9 volts DC
