Dunlop EJF1 ERIC JOHNSON SIGNATURE FUZZ FACE User manual

ERIC JOHNSON SIGNATURE FUZZ FACE
92503011324REVB

“I FIRST HEARD THE FUZZ FACE WHILE
LISTENING TO JIMI HENDRIX WHEN I
WAS ABOUT TWELVE. I PICKED ONE
UP AS SOON AS I COULD, AND I LOVED
PLAYING THROUGH IT. NO OTHER PEDAL
GETS THIS TYPE OF SOUND—IT’S THE
PINNACLE OF PSYCHEDELIC FUZZ. ”

EJF1 ERIC JOHNSON SIGNATURE FUZZ FACE
POWER REQUIREMENTS
The EJF1 Eric Johnson Fuzz Face
requires one 9 volt battery. Unscrew
the bottom of the pedal to access the
battery clip. Remove the instrument
cable from the input jack when not in
use to extend battery life.
SPECIFICATIONS
Input Impedance 10 k
Output Impedance @ 1 kHz 16 kΩ
Maximum Gain 55 dB
Current Draw 500 uA @ 9 VDC
Bypass True Hardwire Bypass
*All specications are measured at 1 kHz
DIRECTIONS
• Run a cable from your guitar to
the Fuzz Face’s Input jack and run
another cable from the Fuzz Face’s
Output jack to your amplier.
• Set the Fuzz Face’s controls to their
12 o’clock position.
• Turn the eect on by depressing
the footswitch.
• Dial in the amount of desired fuzz by
adjusting the FUZZ knob.
• Use the LEVEL knob to set the
desired volume level of the eect.
• Try rolling back your guitar’s volume
knob to clean up the Fuzz Face.
CONTROLS
• Footswitch toggles eect on/ bypass
• Volume knob controls total
output level
• Fuzz knob controls intensity of the
fuzz tone

ALSO AVAILABLE FROM DUNLOP:
THE ERIC JOHNSON CLASSIC JAZZ III.
FOR MORE INFO, VISIT JIMDUNLOP.COM
