DVA Blue Electric 36128 User manual

MANUAL
Multi-hybrid Worklight - Article No. 36128 - 40W, 36135 - 80W

1. Advantage
1.1 Universal baery
1.2 Adapter
36142
19.2 V 6000mAh
115.2Wh
Rubber coating
shockproof
Hybrid system suitable for different scenarios.
Article no. 36159 (not included).
AC Supply Charging while LightingCharger
Baery, not included.
LiFeP04 baery

1.5 Waterproof
IP 65
Rotatable
1.4 Hook & Tripod
1.3 Tool baery power supply
PANASONIC
14.4V & 18V
HIKOKI
14.4V & 18V
MAKITA
14.4V & 18V
BOSCH
14.4V & 18V
DeWALT
14.4V & 18V
Milwaukee
14.4V & 18V
Metabo
14.4V & 18V
Adapter
Tool Baery
36180
36173

SWITCH: ON/OFFBRIGHT: 20%-40%-60%-80%-100%
3.1 Install baery
Handle
Bracket
Rubber Cover
Hook
Heat
Dissipation
LED
Switch
Unlock
Switch
Brightness
Control USB
Output
Baery
Indicator
2. Introduction
3. Instructions
Slide the baery into the slideguide.
Press the Switch to turn on the light.
Press the Brightness control buon to control
the Brightness.

3.2 Replace baery
3.3 Install adapter
3.4 Charging
Press the unlock switch,
the baery will eject automatically. Slide on the new baery.
Slide the AC adapter into the slideguide.
Slide the baery into the AC adapter.
Plug in.
Press the Switch to turn on the light.
Press the Brightness control buon to control
the Brightness.
Plug in.
Baery indicator lights will turn on one by one
during charging.When the green indicator is on,
the baery is fully charged.

3.5 Install adapter with tool baery
1.1 Pull up the “DE”.
1.2 Press the buons on both sides
to make sure “DE/MI” is up.
1.3 Slide the baery into the adapter.
1.1 Pull up the “MI”.
1.2 Press the buons on both sides
to make sure “DE/MI” is up.
1.3 Slide the baery into the adapter.
1.1 Pull up the “ME”.
1.2 Make sure “DE/MI” is down.
1.3 Slide the baery into the adapter.
DEWALT Baery(14.4V or 18V)
MILWAUKEE Baery(14.4V or 18V)
METABO Baery(14.4V or 18V)
36180
36173
3617336180
1.Pull up the “H”.
2.Slide the baery into the adapter.
1.Pull up the “M”.
2.Slide the baery into the adapter.
1. Pull up the “B”.
2. Slide the baery into the adapter.
1. Pull up the “P”.
2. Push the component “A” on both side.
3. Press the baery into the adapter.
HIKOKI Baery(14.4V-18V)
MAKITA Baery(14.4V-18V)
BOSCH Baery(14.4V-18V)
PANASONIC Baery(14.4V-18V)
A
3.5.1 Baery installation

Slide the adapter with baery into the slideguide.
Press the Switch to turn on the light.
Press the Brightness control buon to control
the Brightness.
Adapter has a memory for the baery voltage.
That means when switching to 14.4V, the default
voltage memory will be at 14.4V.
Red indicator is for 18V.
Green indicator is for 14.4V.
When the baery is inserted into the light, the red indicator will be on for 5 sec.
18V Baery
Press Voltage Switch.
Please make sure the voltage indicator is red.
14.4V Baery
Press Voltage Switch.
Please make sure the voltage indicator is green.
3.5.2 Choose the right baery voltage
Transform Adaptor
Voltage Switch
14,4V (Green)
18V (Red)
18V 14,4V
Transform Adaptor
14,4V (Green) 18V (Red)
Transform Adaptor
14,4V (Green) 18V (Red)
18V 14,4V
18V 14,4V
Voltage Switch Voltage Switch
3.5.3 Turn on the light

4. Instructions
5. Working Place
Model NO.
Power
36128
40W
36135
80W
LED Chip COB
CCT, kelvin 4000 K
Lumen of output 5000LM(MAX) 10000LM(MAX)
Baery 19.2V 6.0Ah LiFePO4 Baer(universal)
AC Pack/Charger 21.6V 4A output(universal)
Operating time with 36142
5,000LM-4H
2,500LM-8H
10,000LM-2H
5,000LM-4H
Operating Temp.(AC Supply) -20 C ~ 50C
Operating Temp.(DC Supply) -10 C ~ 45C
Storage Temp. 0 C ~ 40C
Beam angle 120degree
IP rateing IP 65
RA 80
Construction Site Indoor Illumination Automotive repair

6. Safety Instructions
6.1 General
• Ensure the worklight is correctly charged before initial use.
• DO NOT cover or block the lens during use
• DO NOT use the light directly towards the eyes of a person or an animal.
• DO NOT handle or move the worklight while it is being charged
• DO NOT use the work light if you suspect that the baery or the worklight casing is damaged
6.2 Baery safety
WARNING! To reduce the risk of burns or fire:
• DO NOT aempt to open,disassemble,modify or service the baery.
• The worklight charger is switched off and disconnected from the worklight before aempting
to open the lamp unit.
• DO NOT expose the worklight to temperatures above 40 ºC
• DO NOT crush, puncture, short external contacts or dispose of in fire or water.
• Replace only with the baeries designated for this product.
• Dispose of the old baeries in accordance with local authority baery regulations.
6.3 Electrical safety
• Check that cables are protected against short circuits and overloads.
• Check that the Volt indicated on the charger socket corresponds to the power supply used. Fully unroll the cable
between the charger and the work light.
• Do not use other types of chargers with this product.
• Use only the appropriate connectors.
• Do not aempt to disconnect the charger connector.
• Do not use the charger plug to charge or power other products.
6.4 Maintenance
• Do not clean the work light with detergents.
• Store the work light in a clean, dry place when not in use

7. Accessories
Article no. 36142 19.2V baery
Article no. 36159 230V adapter
Article no. 36173 Baery adapter: Panasonic - Hikoki- Makita - Bosch
Article no. 36180 Baery adapter: Dewalt - Milwaukee - Metabo
(Sold separately)
Designation: Blue Electric Hybrid worklight
Reference no.: 36128, 36135
European Directive European Standard No.
DECLARATION OF CONFORMITY
We, hereby declare that the following products described below, conforms to the technical
safety rules wich are applicable for the supply to the European Union market.
Import EU:
DVA A/S • Meterbuen 26, 2740 Skovlunde • [email protected] • [phone] • www.dva.dk
Above products is conformed to:
Ruben Jørgensen
HSEQ Responsible
7 July 2021
