DVIGear DVI-7171c User manual

User Guide
Single-Link DVI Active Cable Extender™
DVI-7171c

TABLE OF CONTENTS
SECTION PAGE
PRODUCT SAFETY ....................................1
PRODUCT LIABILITY...................................1
1.0 INTRODUCTION ...................................2
2.0 SPECIFICATIONS ..................................3
3.0 PACKAGE CONTENTS ..............................4
4.0 CONNECTING THE HARDWARE......................4
5.0 OPERATING THE UNIT..............................5
6.0 TROUBLESHOOTING ...............................6
7.0 LIMITED WARRANTY ...............................7
8.0 REGULATORY COMPLIANCE ........................7

-1-
WARNING – Product Safety
1. Do not dismantle the product housing or modify the printed circuit board
module as this may result in electrical shock or burn.
2. Do not attempt to service this product yourself as opening or removing the
product housing may expose you to dangerous voltages or other hazards.
Refer all servicing to qualied service personnel.
3. Keep this product away from liquids. Spills into the product housing may
result in re, electrical shock, or equipment damage. If liquid spills into the
housing, unplug the product immediately. Have the product checked by a
qualied service engineer before using it again.
4. Place the product in an even and stable location. If the product falls or is
dropped, it may cause an injury and/or malfunction.
5. Avoid exposing the product to extreme temperatures or to high humidity
levels as this may result in damage to the product.
6. Only use the supplied External AC Power Adapter. The use of other power
adapters may cause this product to fail or may cause a re.
7. Do not twist or exert excessive force on the ends of the connected cables
as this can cause them to malfunction. Take precaution to ensure that all
connected cables are not forced to bend beyond their minimum bend radius.
Product Liability
Every effort has been made to ensure that this product is free of defects.
DVIGear cannot be held liable for the use of this product or for any direct or
indirect consequential damages arising from its use. It is the responsibility of
the users of this product to check that it is suitable for their requirements and
that it is installed correctly.
All rights are reserved. No parts of this manual may be reproduced or
transmitted by any form or means, electronic or mechanical, including
photocopying, recording or by any information storage or retrieval system,
without the written consent of DVIGear.
DVIGear reserves the right to revise any of its hardware and software, following
its policy to modify and/or improve its products where necessary or desirable.
This statement does not affect the legal rights of the user in any way. All
third-party trademarks and copyrights are recognized. The DVIGear logo is a
registered trademark of DVIGear, Inc. All other trademarks are the property of
their respective holders.

-2-
1.0 INTRODUCTION
Thank you for purchasing this Single-Link DVI Active Cable Extender™ (ACE™)
unit from DVIGear. This product is an adaptive cable equalizer capable of
mitigating insertion losses on copper Single-Link DVI cables with lengths up to
200 ft. (~ 60 meters).
Although this product will work with almost any DVI cable, its performance
cannot be guaranteed in all cases due to the wide variations in the quality of
conventional DVI cables. For best results, always use DVIGear’s Super High
Resolution™ (SHR™) cables.
Our professional digital distribution products have been serving the industry
for over ten years. DVIGear offers a full line of high quality Digital Matrix
Routing Switchers, Splitters, Video Scalers, Up/Down/Cross Converters,
Format Converters, Analog-Digital Converters, as well as a wide range of long-
reach Digital Cables, Extenders, and Optical Transmission systems.
1.1 Features
The Single-Link DVI Active Cable Extender™ (ACE™) unit has many unique
features and benets:
• Supports all HDTV resolutions up to 1080p (8-bit and 12-bit color)
• Supports PC resolutions up to 1920x1200 and 2048x1080
• Supports digital bit rates up to 2.25 Gbps.
• Supports HDCP (pass-through)
• Maximum distance from source to ACE™: 200 ft. (~ 60 meters)
• Maximum distance from ACE™ to display: 15 ft. (~ 5 meters)
• Automatic or precise Manual Adjustment of cable equalization
• Locking connector for AC Power Adapter for added security
• Rugged, ultra-compact metal enclosure
• LEDs indicate presence of sufcient power and active DVI signal

-3-
2.0 SPECIFICATIONS
Performance
Compliance DVI v1.0, HDMI, HDCP
Maximum Pixel Clock Frequency Up to 225 MHz
Maximum Bit Rate Up to 2.25 Gbps
Supported HDTV Resolutions 480p, 720p, 1080i, 1080p, (8-bit and 12-bit color)
Supported PC Resolutions Up to 1920x1200 and 2048x1080
Input Signal Equalization Adaptive equalization, provides up to +40 dB correction @ 825 MHz
Cable Equalization Modes Auto EQ Mode - for cable lengths up to 30 meters
Manual EQ Mode - for cable lengths longer than 30 meters
Connections
Input / Output 2x DVI 29-pin female connectors
Power Input 1x 5.5 / 2.5 mm locking connector
Cable Length
Maximum Input Cable Length 200 ft. (~ 60 meters) 1,2
Maximum Output Cable Length 15 ft. (~ 5 meters) 1
DDC Support
EDID / HDCP Support Yes, pass-through
Mechanical
Construction Rugged steel enclosure with durable black nish
Dimensions (H-W-D) 1.1” x 2.1” x 2.6”(29.2 mm x 53.7 mm x 67.1 mm)
Weight 4.7 oz (132 g)
Environmental
Operating Temperature +32° to +122° F (0° to +50° C)
Storage Temperature -4° to +158° F (-20° to +70° C)
Humidity (storage / operating) 10% to 90% (non-condensing)
Power Requirements
External AC Power Adapter Input: 100~240VAC / 50-60Hz Output: 5VDC, 3.0A
Power Consumption (typical) 1.5 watts
Regulatory Approvals
ACE™ Unit FCC, CE, and RoHS
External AC Power Adapter FCC, CE, UL, C-UL, CEC, GS, PSE, RoHS
Warranty
Limited Warranty 3YearsParts and Labor
Model Number
DVI-7171c DVI Single-Link Active Cable Extender
Accessories
Included 1x External AC Power Adapter, 1x User Guide
Optional International AC Power Adapter (USA, Euro, UK, Australia)
Note 1: Maximum cable lengths using DVIGear’s 22AWG Super High Resolution (SHR™) cables.
Note 2: The maximum cable length with 1080p / 60Hz 8-bit color (1.5 Gbps.) input signal is
200 ft. (~ 60 meters). The maximum cable length with 1080p / 60Hz 12-bit color (2.25 Gbps.)
input signal is 131 ft. (~ 40 meters).

3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain
the following items are contained in the shipping carton:
• 1x DVI-7171c Single-Link DVI Active Cable Extender™ (ACE™) unit
• 1x External AC Power Adapter
• 1x User Guide
Note: Please retain the original packing material in case you need to return the unit. If you
nd any items are missing, contact your reseller or DVIGear immediately. Please have the
Model Number, Serial Number, and Invoice Number available for reference when you call.
4.0 CONNECTING THE HARDWARE
Please study the images below and become familiar with the signal input,
output, and power input. See Section 5, “Operating the Unit,” for additional
information.
-4-

-5-
5.0 OPERATING THE UNIT
1. Turn OFF the DVI source and the DVI display device.
2. Connect a high quality DVI (long) cable between the output of the DVI
source and the “INPUT” port of the ACE™ unit.
3. Connect a high quality DVI (short) cable between the DVI input on the
display device and the “OUTPUT” port of the ACE™ unit.
4. Connect the External AC Power Adapter to the ACE™ unit. Take care to
insert the locking plug into the DC power connector on the ACE™ unit and
rotate a quarter turn clockwise so that it locks securely into position.
5. Plug the AC Power Adapter into an active AC power socket. The red
POWER LED should be illuminated.
6. Turn ON the DVI source and DVI display device. The green ACTIVE LED
should be illuminated, and there should be a stable image on the DVI
display. There should be no artifacts (streaks, sparkles, etc.) visible in the
displayed image.
7. On the side of the ACE™ unit there is a cable equalization switch that
can be set for AUTO (automatic) or MANUAL adjustment. The AUTO
position is preferred and works well with most cables. For DVI cables
longer than 30 meters (100 ft.), the MANUAL EQ position can give better
results. When the switch is set to the MANUAL EQ position, a 25x turn
potentiometer is activated, allowing very precise control of the amount of
cable equalization. For best results, take care to rotate this potentiometer
adjustment slowly. Note that at the end of its range you will feel a slight
clicking in the adjustment even though it continues to rotate.
Source Device
(e.g. PC or Mac)
DVIGear ACE™ unit
(e.g. DVI-7171c)
Up to 60m DVIGear
SHR™ cable
0.5m DVIGear
SHR™ cable
Display Device
(e.g. Projector)
+5V Power Supply
for ACE™ unit
LEVEL EQ
AUTO
+40 dB
0 dB
MANUAL
OUTPUT
POWER
ACTIVE
DVI-7370
HDMI Active Cable Extender
+40 dB
LEVEL
0 dB
EQ MANUAL
AUTO
DVI-7370
HDMI Active Cable Extender
OUTPUT
POWER
ACTIVE
DVI-7171
Active Cable Extender
DVI Single-Link

-6-
6.0 TROUBLESHOOTING
If the DVI ACE™ unit does not appear to be working properly, please check the
following:
1. Verify that the External AC Power Adapter is plugged in and delivering power
to the DVI ACE™ unit. In this case the red POWER LED should be brightly lit.
If the red POWER LED is dim, ickering or off altogether, then check the AC
power source and/or replace the power adapter.
2. Verify that the cables connected to the Input and Output ports of the DVI
ACE™ unit are premium grade cables (such as DVIGear’s Super High
Resolution™ cables) and do not exceed the recommended cable lengths
specied in Section 2 of this User Guide.
3. Inspect the DVI connectors on both the cables and on the DVI ACE™ unit for
damage, bent pins, loose connections, etc.
4. Turn ON the DVI source and verify that the green ACTIVE LED is illuminated.
If it is not, double-check the source to ensure that it is outputting an active
DVI signal.
5. As a nal check, bypass the DVI ACE™ unit and connect the DVI source
directly to the DVI display device using a high quality DVI cable with a length
of 3 meters (10 ft.) or less. If the image is visible on the display, then follow
the procedure below in step 6.
6. Turn OFF all system components, as well as the DVI ACE™ unit. Restart
the DVI display, then the DVI ACE™ unit, and nally the DVI source device.
Recheck steps 1-4 above.
If the problem persists after trying the above suggestions, please contact your
dealer for additional assistance. If the dealer’s technical personnel are unable
to assist you, please contact DVIGear via telephone at 1.888.463.9927 (toll-free
for United States and Canada) or 1.770.421.6699. You may contact DVIGear by
e-mail at [e-mail].

-7-
7.0 LIMITED WARRANTY
LIMITED WARRANTY – Subject to the limitations stated below, DVIGear warrants
that this product will be free from defects in materials and workmanship for a
period of three (3) yearsfrom the date of purchase.
Should the product, in DVIGear’s opinion, prove defective within the warranty
period, DVIGear, at its option, will repair or replace this product without charge.
Any defective parts replaced become the property of DVIGear. This warranty does
not apply to products that have been damaged due to accident, unauthorized
alterations, improper repair, modications, inadequate maintenance and care, or
use in any manner for which the product was not intended.
If repairs are necessary under this warranty policy, the original purchaser must
obtain a Return Authorization Number from DVIGear and return the product freight
prepaid to a location designated by DVIGear. After repairs are complete, the
product will be returned, freight prepaid.
The foregoing warranty is the sole and exclusive warranty given by DVIGear,
express or implied, and DVIGear disclaims all implied warranties, including but not
limited to implied warranties of merchantability or tness for a particular use.
LIMITATIONS - The liability of DVIGear with respect to any defective products
will be limited to the repair or replacement of such products. In no event shall
DVIGear be responsible or liable for any damage arising from the use of such
defective products, including but not limited to loss of use, revenue or prot,
whether such damages are direct, indirect, consequential or otherwise and
whether such damages are incurred by the reseller, end-user, or any third-party.
8.0 REGULATORY COMPLIANCE
This product is compliant with appropriate FCC, CE and RoHS rules and
regulations. The supplied AC Power Adapter is compliant with FCC, CE, UL,
C-UL, CEC, GS, PSE and RoHS rules and regulations.

www.dvigear.com
Your Digital Connectivity Experts
Toll Free 888.463.9927
Phone [phone]
Fax [phone]
DVIGear, Inc.
1059 Triad Court, Suite 8
Marietta, Georgia 30062-2258
DVI-7171c-UG-03 / November.2013
