Dynamic Projection MH29 User manual

0 A
Copyright © 2014 - 2022 by Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.
Mirror Head Quick Installation
Guide
For MH29 / MH30
1. Surface coated mirror
2. Mirror Head control unit
3. Mirror Head base plate
3
3
1 1
2 2
MH29 MH30
QIG - Version 2.6
Mirror Head Quick Installation Guide
For the full manual please visit http://dynamicprojection.com/mirror-head-assembly
1 E
Copyright © 2014 - 2022 Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.

2
Copyright © 2014 - 2022 Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.
Introduction
Thank you for having chosen a Mirror Head unit. If you follow the instructions given in this Quick Installation Guide, we are sure you will enjoy this device for
a long period of time.
For your own safety, please read this document carefully before you initially start-up.
Every person involved with the installation, operation and maintenance of this device has to:
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latest version of the user manual from our website
Warning and Safety Information
NOTE: Damages caused by the disregard of this user manual are not subject to warranty.The dealer will not accept liability for any resulting defects or problems.
Never look directly into the light source of an attached projector!
Keep away children!
There are no user serviceable parts (fuse) inside this unit.
The Mirror Head is is a projector add-on device for creating decorative effects. This product is only allowed to be operated with:
- the voltage labeled on the device
- the projector that the product is specified for
- the original accessories and add-on parts
The device is designed for indoor use only. This device is designed for professional use only.
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original
factory box and packing with all safety clamps mounted.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net. This secondary safety attachment must be
constructed in a way that no part of the installation can fall down if the main attachment fails.
WARNING: OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to) calculating working load limits, installation material
being used, and periodic safety inspection of all installation material and the device. If you lack these qualifications, do not attempt the installation yourself, but
instead use a professional structural rigger. Improper installation can result in bodily injury and or damage to property.
CAUTION: Never project directly onto people or animals - the light of the projector can cause blindness.
Before starting to mount the Mirror Head make sure:
- the installation-spot is suited for the Mirror Head.
- the mirror can move freely.
- there are no vibrations by ventilation systems of any kind.
- all screws are secured.
WARNING: The Mirror Head and the projector can be very heavy – use a second person for help
NOTE: This device is only allowed for an installation via the original mounting brackets, clamps or stands.
NOTE: The manufacturer cannot be made liable for damages caused by incorrect installations, unauthorized parts or insufficient safety precautions!
In case you have questions about our product or need support during assembly and installation please contact our support!
Dynamic Projection Institute, Herstellungs und Vertriebs GmbH
Herzgasse 9 / 5, A-1100 Vienna
Email: offi[email protected], Web: www.dynamicprojection.com, Phone: [phone] (Mon. – Fri. 9:00 – 18:00h)
Commercial Register: FN400806x
QIG - Version 2.6
Mirror Head Quick Installation Guide
For the full manual please visit http://dynamicprojection.com/mirror-head-assembly

3 E
Copyright © 2014 - 2022 Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.
Technical specications
- High resolution 16bit Pan/Tilt mirror movement
- DMX-512 control over 14 DMX channels
- DMX-IN and DMX-OUT/Through port (5-pin male and female XLR connectors)
- 14 DMX channels are required to control the unit
- Art-Net™ connection (RJ45) (Art-Net™ designed by and Copyright Artistic License Holdings Ltd.) - OEM code 0x1140
- High resolution micro step motors with maintenance free direct drive
- Self calibrating mirror position for high accuracy
- Absolute reposition accuracy smaller than 0.03°
- Movement accuracy: Pan and Tilt from the same direction to the programmed point within approximately 0.01°
- RS232 remote control connection for projector (D-sub 9 male) - cable included
- Flash-able firmware (Mini USB OTG)
- High resolution LED-Display for easy configuration
- LED-Display back-light auto turn off for energy saving
- LED-Display Flip / Flop mode for easy reading in difficult positions
- Coated mirror for optimum reflection ~98% refraction factor
- Optimized mirror optics for the specific projector
- Ambient Light LED with high power RGB LEDs (17,9 Watt total) - see compatibility list if available for your model (MH08-MH13)
- Mounting plate optimized for specific projector mounting
- Easy to adjust mounting system
- Passive cooled system (excluding projector)
- Environmental tolerances: Ambient operating temperature range: 5°–35°C, Humidity: 20%–80% (non-condensing)
- A/C power input; 100V / 2A / 60Hz – 240V / 1A / 50Hz, 10A max. 3-prong C14 male socket - 3W Standby - max. 30W
(see type plate on device for details)
QIG - Version 2.6
Mirror Head Quick Installation Guide
For the full manual please visit http://dynamicprojection.com/mirror-head-assembly
~90°
Default Mode
Examples of positioning the Mirror Head
The illustrations show the approximate usable angular range of the projection
cone depending on the operation modes.The shown ranges may differ depending
on the lens-shift and blocking parts of the projector or mounting constructions.
The modes can be set in the firmware of the Mirror Head using the „Mirror
angle“ menu.
Default Mode („90 Degrees“), this is the „90° Tilt“ mode available on all Mirror
Head models.
~180°
Default Mode

4 E
Copyright © 2014 - 2022 by Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.
Mounting of the projector
For further help on assembly please watch our assembly videos: http://www.dynamicprojection.com/mirror-head-assembly/
1
2
3
5
6
4
7. Mount the base-plate and the provided accessories to the projector.
WARNING: Secure the projector at any time so it cannot fall out or down. Use a second person to help.
8. Lock-in the Mirror Head into the base-plate and secure the two screws at the front and the two screws at the bottom.
NOTE: This step of the installation can be reversed.
9. Connect the RS232 and AC power-cord to the projector and control unit.
MH29
7.
8.
MH30
7.
8.
1
2
3
5
6
4
Flat side
1. Prepare the setscrew on the hex key.
2. Turn the setscrew into the drive arm
by two turns.
3. Slip over the end-stop (brass part)
over the pan drive shaft.
4. Take the whole drive arm end slip it
over the pan drive shaft until it
reaches the end-stop.
5. Secure the setscrew with the hex key.
Make sure that the screw is tightened
on the at side of the D-cut shaft.
6. Connect the motor signal cable and
mount the glue strip on the motor.
QIG - Version 2.6
Mirror Head Quick Installation Guide
For the full manual please visit http://dynamicprojection.com/mirror-head-assembly

5 BCDEFGH
Copyright © 2014 - 2022 by Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.
Use the lens shift of your projector to adjust the position of the
projected image on the mirror as shown in the illustration.
(Mirror position for adjustment = power on position)
Adjust lens shift
Tilt-Motor
Axis
1. Surface coated mirror
2. Mirror Head control unit
3. Mirror Head base plate
4. Tilt motor
5. Reference magnets
6. Motor-drive-arm
7. Reference screws
8. Pan drive shaft
27
1
4
8
6
Mirror Head control unit / MHE01
Backside view Top view
Elektronik Frontansicht komplett
all rights reserved by
www.dynamicprojection.com
25.08.14
Neumann
GEWICHT:
A3
BLATT 1 VON 1 MASSSTAB 1:1
ZEICHNUNGSNR.
BENENNUNG:
ÄNDERUNG
ZEICHNUNG NICHT SKALIEREN
WERKSTOFF:
DATUM
SIGNATUR
NAME
ENTGRATEN
UND SCHARFE
KANTEN
BRECHEN
OBERFLÄCHENGÜTE:
WENN NICHT ANDERS DEFINIERT:
BEMASSUNGEN SIND IN MILLIMETER
OBERFLÄCHENBESCHAFFENHEIT:
TOLERANZEN:
LINEAR:
WINKEL:
QUALITÄT
PRODUKTION
GENEHMIGT
GEPRÜFT
GEZEICHNET
DMX OUT DMX IN ARTNET / LAN
RS 232
MENUENTER
AC OUT AC IN
Mirror Head
Model: MHE01
34567
10
8
2
1
10
9
1. DMX-OUT / Through Socket - 5 Pins XLR
2. DMX-IN Socket - 5 Pins XLR
3. Art-Net™ network - 10Mb/s, 100Mb/s
4. Mini USB OTG - for firmware update
5. RS232 connector - male
6. A/C power output; loop trough, 3-prong C13 female socket
7. A/C power input; 100V / 2A / 60Hz - 240V / 1A / 50Hz, 10A max. 3-prong C14 male socket
8. Control buttons for menu navigation
9. LCD display
10. Control unit
QIG - Version 2.6
Mirror Head Quick Installation Guide
For the full manual please visit http://dynamicprojection.com/mirror-head-assembly

6
Copyright © 2014 - 2022 by Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.
DMX OUT DMX IN ARTNET / LAN
RS 232
MENUENTER
AC OUT AC IN
Mirror Head
Model: MHE01
DMX OUT DMX IN ARTNET / LAN
RS 232
MENUENTER
AC OUT AC IN
Mirror Head
Model: MHE01
Art-Net™
Art-Net™
RS232 RS232
DMX
DMX Light Table
Power
Power Power
Power
Media Server
Mirror Head control unit Mirror Head control unit
Media Player
Projector
Projector
Video
Video
This setup shows the combination of the Mirror Head
and a Media Server (e.g. MDC-X) that is capable of
Art-Net control, video playback and optional geometry
effects. For more information about controlling the Mirror
Head see the „Using and operations“ section.
This setup shows how the Mirror Head can easily be
integrated into DMX-Light Management (DMX512-XLR or
Art-Net DMX512) and Media-playback. For more informa-
tion about controlling the Mirror Head see the „Using and
operations“ section.
Media Server with Art-Net™ control and
video playback
Media Player and DMX Light Table
optional optional
Using and operations (DMX512 / Art-Net™)
To use the Mirror Head as intended, a DMX512/Art-Net™ controller is needed with at least 14 channels. In order to control the Mirror Head
at least a 14 channel DMX Master is required.
DMX-512 controlled operation
1. Make sure the unit is turned off.
2. Connect the DMX XLR cable to the DMX-IN socket.
3. Connect the power-cord so the unit turns on.
4. Check the DMX settings in the control unit.
5. Start sending DMX commands and check if the system reacts.
Art-Net™controlled operation
1. Make sure the unit is turned off.
2. Connect the power-cord so the unit turns on.
3. Check the DMX settings in the control unit.
4. Check the IP address settings in the control unit.
5. Connect the CAT cable to the control board.
6. Start sending Art-Net™ DMX commands and check if the system reacts.
RS232 projector control
The Mirror Head control unit offers the possibility to send some basic remote control commands to the projector using the RS232 interface.
1. Make sure the projector is turned on and accepts RS232 commands corresponding to the RS232 compatibility list in the appendix.
2. The commands are sent to the projector whenever a specific DMX value is sent on the specific DMX channel – see DMX fixture chart.
NOTE: It is maybe necessary to insert a
DMX / XLR termination plug (with 120
Ohm) in the last unit in the link in order to
ensure proper transmission on the DMX
data link – please ask your DMX operator.
NOTE: If you change the IP address of the
unit you have to replug the CAT cable in
order to avoid ARP / IP caching of some
intermediate switching equipment
QIG - Version 2.6
Mirror Head Quick Installation Guide
For the full manual please visit http://dynamicprojection.com/mirror-head-assembly

7
Copyright © 2014 - 2022 by Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.
Mirror Head control unit operations
The control unit of the Mirror Head offers the possibility to adjust the system to the projector and the control environment.
Main screen
The Main-Screen shows the company logo. The back-light of the screen is turned off on default after 30 seconds of inactivity if the system is on
this screen. To turn it on again press any of the Mirror Head buttons. On this screen you can change the screen orientation for better handling by
pressing special keystroke combinations:
Main menu
This is the top level menu to access all settings of the Mirror Head. You can return to this screen anytime by pressing the (MENU) button.
To select an item in the list use the (UP) or (DOWN) buttons and press (ENTER) to access the sub-menu. Inside this menu you can start a
mirror-reset (calibration) by pressing the following buttons for 3 seconds.
Version
The version menu shows the firmware version of the Mirror Head.The firmware of all Mirror Head products can be upgraded if needed using the
USB OTG connector. In this menu you can override the factory default center of the calibration function. Under standard conditions you should
never use this function.
Function (ENTER) (UP) ▲(DOWN) ▼(MENU)
Display FLIP X X - -
Display FLOP X - X -
Function (ENTER) (UP) ▲(DOWN) ▼(MENU)
SET
Zero Position X X - -
RESET
Zero Position X - X -
Function (ENTER) (UP) ▲(DOWN) ▼(MENU)
Mirror reset - X X -
Network
The network interface of the Mirror Head is for Art-Net™ DMX512
communication. Please note that the Mirror Head supports static IP addresses
only (DHCP is not supported) and comes with a factory set IP address set to
2.0.0.3, netmask 255.0.0.0. To change the IP-address use the (UP), (DOWN)
and (ENTER) buttons. After you changed the IP address press (ENTER) over
and over again until you see “DONE” on the top of the screen. Changes will
then apply immediately to the network interface of the Mirror Head. To force
an ARP update disconnect the network cable for at least 5sec.
NOTE: Depending on the network infrastructure it is maybe necessary to
reset the switches and / or network interfaces of other devices if the IP-
address of the Mirror Head changes.
NOTE: Every device in an IP network must have its own IP address.
NOTE: You cannot use Art-Net™ DMX512 and analog DMX at the same time.
Changing this physical layer requires a power off-on cycle of the Mirror Head.
Projector
The Mirror Head offers the possibility for a remote control of the projector over
DMX via the RS232 interface. This menu allows you to select the connected
projector brand (see Appendix for compatibility and function list) to be used
with the Mirror Head. The projector must be connected with the Mirror Head
using a RS232 cable and the remote control function must be enabled and set
correctly on the projector.
Mirror angle
This option offers you the possibility to change the tilt-axis between Mode-90°
and Mode-162° for specific versions of the Mirror Head. Switching between
Mode-90° and Mode-162° does not require a restart of the Mirror Head. If you
switch the mode the center position on the tilt-axis of the Mirror Head changes.
WARNING: Use the 162° only if your Mirror Head is compatible with this
setting – Check the 162° compatibility list in the appendix.
DMX
By default the DMX-Address of the unit starts at 001. Here you can set the
offset if you need to change the DMX-Address of this unit. The DMX fixture
for the Mirror Head is in the appendix.
NOTE: The Mirror Head unit is always a slave device.
LEDs (MH08–MH13 only)
By default the RGB LEDs of the Mirror Head (if available for your model - see
appendix) are controlled over Art-Net™/DMX by selecting the specific RGB
and intensity channel values. If the LEDs should be on no matter if there is a
DMX signal or not, the fixed values can be set here.
QIG - Version 2.6
Mirror Head Quick Installation Guide
For the full manual please visit http://dynamicprojection.com/mirror-head-assembly

Channel Function Value Destination Description
001 Pan high 0 - 255 Mirror motors Pan High Byte
002 Pan low 0 - 255 Mirror motors Pan Low Byte
003 Tilt high 0 - 255 Mirror motors Tilt High Byte
004 Tilt low 0 - 255 Mirror motors Tilt Low Byte
005 Reset 255 Mirror motors Starts mirror recalibration
006 Picture mute off 0 - 10 RS232 / projector Disables picture mute
006 Picture mute on 20 - 30 RS232 / projector Enables picture mute
006 Shutter off 40 - 50 RS232 / projector Disables the mechanical shutter
006 Shutter on 60 - 70 RS232 / projector Enables the mechanical shutter
006 Picture freeze off 10 0 - 110 RS232 / projector Disables picture freeze
006 Picture freeze on 120 - 130 RS232 / projector Enables picture freeze
007 Image orientation 1 10 - 63 RS232 / projector Image orientation mode 1
007 Image orientation 2 64 - 127 RS232 / projector Image orientation mode 2
007 Image orientation 3 128 - 192 RS232 / projector Image orientation mode 3
007 Image orientation 4 192 - 255 RS232 / projector Image orientation mode 4
008 reserved - - -
009 Motor and LED drivers on 28 - 38 Mirror motors & LED Turns the drivers on
009 Motor and LED drivers off 50 - 58 Mirror motors & LED Turns the drivers off
009 Lamp mode 1 130 - 138 RS232 / projector Lamp power mode 1
009 Lamp mode 2 150 - 158 RS232 / projector Lamp power mode 2
009 Lamp mode 3 170 - 178 RS232 / projector Lamp power mode 3
009 Lamp on 230 - 238 RS232 / projector Lamp lamp on
009 Lamp off 250 - 255 RS232 / projector Lamp lamp off
010 LED intensity 0 - 255 LED Main intensity of the combined RGB LEDs
011 LED red 0 - 255 LED Red LED intensity
012 LED green 0 - 255 LED Green LED intensity
013 LED blue 0 - 255 LED Blue LED intensity
014 reserved - - -
Valid for firmware version 1.3.26
8
Copyright © 2014 - 2022‚ by Dynamic Projection Institute GmbH. All rights reserved. http://www.dynamicprojection.com
Weights and dimensions shown are approximate. Specications and appearance are subject to change without notice.
DMX xture denition
In order to control the Mirror Head at least a 14 channel DMX Master is required no matter what kind of Mirror Head and/or function of the
fixture you use (see section „Using and operations“ for details).
available for
MH08 – MH13 only
QIG - Version 2.6
Mirror Head Quick Installation Guide
For the full manual please visit http://dynamicprojection.com/mirror-head-assembly
