Dyson V7 Trigger User manual

click
User manual
Assembly
H H11
Wash filters
Wash filters with cold water at
least once every month.
Ensure that the filters are
completely dry before refitting.
2 easy ways to register
your free 2 year warranty
Powerful suction Max mode

2
Dyson customer care
Thank you for choosing to buy a Dyson machine
After registering your 2year warranty, your Dyson machine will be covered for parts and
labour for 2years from the date of purchase, subject to the terms of the warranty. If you
have any queries regarding your Dyson machine, call the Dyson Helpline with your serial
number and details of where and when you bought the machine. Most questions can be
solved over the phone by one of our trained Dyson Helpline staff.
Visit www.dyson.in/support for online help, support videos, general tips and useful
information about Dyson.
This illustration is for example purposes only.
Dyson contact details
www.dyson.in
1800 258 6688 (Toll Free)
[email protected]
Dyson Technology India Pvt. Ltd.
WeWork , DLF Forum, Cyber City,
Phase-III, Sector-24,
Gurugram, Haryana,
India-122002
IMPORTANT SAFETY
INSTRUCTIONS
BEFORE USING THIS APPLIANCE READ
ALL INSTRUCTIONS AND CAUTIONARY
MARKINGS IN YOUR USER MANUAL
AND ON THE APPLIANCE.
When using an electrical appliance, basic
precautions should always be followed,
including the following:
WARNING
These warnings apply to the appliance,
and also where applicable, to all tools,
accessories, chargers or mains adaptors.
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
1. Use only Dyson chargers for charging this
Dyson appliance. Use only Dyson batteries:
other types of batteries may burst, causing
injury to persons and damage.
2. The battery used in this device may present
a risk of fire or chemical burn if mistreated.
Do not short contacts, heat above
60°C(140°F), or incinerate. Keep away from
children. Do not disassemble and do not
dispose of in fire.
3. FIRE WARNING – Do not place this product
on or near a cooker or any other hot surface
and do not incinerate this appliance even if it
is severely damaged. The battery might catch
fire or explode.
4. Do not install, charge or use this appliance
outdoors, in a bathroom or within 3 metres
(10 feet) of a pool. Do not use on wet
surfaces and do not expose to moisture,
rain or snow.
5. The battery is a sealed unit and under
normal circumstances poses no safety
concerns. In the unlikely event that liquid
leaks from the battery, do not touch the liquid
and observe the following precautions:
Skin contact – can cause irritation.
Wash with soap and water.
Inhalation – can cause respiratory irritation.
Expose to fresh air and seek medical advice.
Eye contact – can cause irritation.
Immediately flush eyes thoroughly with water
for at least 15minutes.
Seek medical attention.
Disposal – wear gloves to handle the battery
and dispose of immediately, following local
Note your serial number for future reference.
Your serial number can be found on your rating plate which is on the
base of the machine.

3
ordinances or regulations.
6. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
7. Do not allow to be used as a toy.
Close attention is necessary when used by or
near children. Children should be supervised
to ensure that they do not play with
the appliance.
8. Use only as described in your Dyson User
manual. Do not carry out any maintenance
other than that shown in your User manual,
or advised by the Dyson Helpline.
9. Suitable for dry locations ONLY.
Do not use outdoors or on wet surfaces.
10. Do not handle any part of the plug or
appliance with wet hands.
11. Do not use with a damaged cable or plug.
If the supply cable is damaged it must be
replaced by Dyson, its service agent or
similarly qualified persons in order to avoid
a hazard.
12. If the appliance is not working as it should,
if it has received a sharp blow, if it has been
dropped, damaged, left outdoors, or
dropped into water, do not use and contact
the Dyson Helpline.
13. Contact the Dyson Helpline when a service
or repair is required. Do not disassemble the
appliance as incorrect reassembly may result
in an electric shock or fire.
14. Do not stretch the cable or place the cable
under strain. Keep the cable away from
heated surfaces. Do not close a door on the
cable, or pull the cable around sharp edges
or corners. Arrange the cable away from
traffic areas and where it will not be stepped
on or tripped over. Do not run over the cable.
15. Do not unplug by pulling on the cable.
To unplug, grasp the plug, not the cable.
The use of an extension cable is
not recommended.
16. Do not use to pick up water.
17. Do not use to pick up flammable or
combustible liquids, such as petrol, or use
in areas where they or their vapours may
be present.
18. Do not pick up anything that is burning
or smoking, such as cigarettes, matches,
or hot ashes.
19. Keep hair, loose clothing, fingers, and all
parts of the body away from openings and
moving parts, such as the brush bar. Do not
point the hose, wand or tools at your eyes or
ears or put them in your mouth.
20. Do not put any objects into openings. Do not
use with any openings blocked; keep free of
dust, lint, hair and anything that may
reduce airflow.
21. Use only Dyson recommended accessories
and replacement parts.
22. Do not use without the clear bin and (filters)
in place.
23. Unplug the charger when not in use for
extended periods.
24. Use extra care when cleaning on stairs.
25. Always turn ‘OFF’ the appliance before
connecting or disconnecting the motorised
brush bar.
READ AND SAVE THESE
INSTRUCTIONS
This Dyson appliance is intended
for household use only.
Do not use near
naked flames.
Do not store near
heat sources.
Do not pick up
water or liquids.
Do not pick up
burning objects.
Do not put hands
near the brush bar
when the machine
is in use.
Do not place on or
near the cooker.

4
1
2
3
click
click
1
click
2
1
2
Power mode and run-time
Lights during charging
20 minutes
Max mode
Up to 6
minutes
30 minutes
Solid blue:
Charging.
Lights off:
Charging complete.
Solid amber: Not charging,
temporary fault (e.g. too hot/cold).
Flashing red:
Fault (contact Dyson helpline).
Flashing blue: Not charging
– Refit charger or try another
socket. If warning light persists,
contact the Dyson Helpline.
Powerful suction
4

5
1
2
3
click
click
1
click
2
1
2
Lights during use
Emptying the clear bin
Solid blue: 'ON'.
Flashing amber:
No power, temporary fault
(e.g. too hot/cold).
Flashing red:
Fault (contact Dyson helpline).
Flashing blue:
No power, charge battery.
Solid amber:
Fault (contact Dyson Helpline).
Clearing mini motorised tool brush bar obstructions
5

6
2
click
click
1
2
1
3
2
1
B
A
Looking for blockages
Stubborn blockages – Disassembly Reassembly
6

7
2
click
click
1
2
1
3
2
1
B
A
7
Wash filters
Wash filters with cold water at least
once every month.
Ensure that the filters are completely dry
before refitting.
Important!

8
Using your Dyson machine
Please read the ‘Important Safety Instructions’ in your Dyson User manual
before proceeding.
Operation
• Do not use outdoors or on wet surfaces or to vacuum water or other liquids – electric
shock could occur.
• Ensure the machine remains upright in use and in storage. Dirt and debris may be
released if it is turned upside down.
• Do not operate while checking for blockages.
• For domestic indoor and car use only. Do not use whilst the car is in motion or
while driving.
• To operate the Max mode, locate the switch on the top of the machine. Slide the switch
to the Max mode position.
• To switch off Max mode, slide the switch back to the Powerful suction mode position.
• This machine has carbon fibre brushes. Take care if coming into contact with them,
as they may cause minor skin irritation. Wash your hands after handling the brushes.
Carpets or hard floors
• Before vacuuming your flooring, rugs and carpets, check the manufacturer’s
recommended cleaning instructions.
• The brush bar on the machine can damage certain carpet types and floors.
Some carpets will fuzz if a rotating brush bar is used when vacuuming. If this happens,
we recommend vacuuming without the motorised floor tool and consulting with your
flooring manufacturer.
• Before vacuuming highly polished floors, such as wood or lino, first check that the
underside of the floor tool and its brushes are free from foreign objects that could
cause marking.
Looking after your Dyson machine
• Do not carry out any maintenance or repair work other than that shown in your Dyson
User manual, or advised by the Dyson Helpline.
• Only use parts recommended by Dyson. If you do not, this could invalidate
your warranty.
• Store the machine indoors. Do not use or store it below 3°C (37.4°F).
Ensure the machine is at room temperature before operating.
• Clean the machine with a dry cloth only. Do not use any lubricants, cleaning agents,
polishes or air fresheners on any part of the machine.
• Check the brush bar regularly and clear away any debris (such as hair).
Debris left on the brush bar may cause damage to flooring when vacuuming.
Vacuuming
• Do not use without the clear bin and filter(s) in place.
• Fine dirt such as flour should only be vacuumed in very small amounts.
• Do not use the machine to pick up sharp hard objects, small toys, pins, paper clips,
glass or oils etc. They may damage the machine.
• When vacuuming, certain carpets may generate small static charges in the clear bin.
These are harmless and are not associated with the mains electricity supply.
To minimise any effect from this, do not put your hand or insert any object into the clear
bin unless you have first emptied it. Clean the clear bin with a damp cloth only.
(See ‘Cleaning the clear bin’.)
• Use extra care when cleaning on stairs.
• Do not rest the machine on chairs, tables, etc.
• Do not press down on the nozzle with excessive force when using the machine as this
may cause damage.
• Do not leave the cleaner head in one place on delicate floors.
• On waxed floors the movement of the cleaner head may create an uneven lustre.
If this happens, wipe with a damp cloth, polish the area with wax, and wait for it to dry.
Emptying the clear bin
• Empty as soon as the dirt reaches the level of the MAX mark – do not overfill.
• Ensure the machine is disconnected from the charger before emptying the clear bin.
Be careful not to pull the 'ON' trigger.
• To make emptying the clear bin easier, it is advisable to remove the wand and floor tool.
• To minimise dust/allergen contact when emptying, encase the clear bin tightly in a dust
proof bag and empty.
• To release the dirt, hold the machine by the handle, pull the red lever back and lift
upwards to release the cyclone. Continue until the bin base automatically opens and
releases the dirt.
• Remove the clear bin carefully from the bag.
• Seal the bag tightly, dispose as normal.
• To close, push the cyclone downwards until it is in the normal position and manually
close the base of the bin – the base will click when it is securely in place.
Cleaning the clear bin
• Ensure the machine is disconnected from the charger before removing the clear bin.
Be careful not to pull the ‘ON’ trigger.
• Remove the floor tool.
• To remove the cyclone, hold the machine by the handle, pull the red lever towards you
and lift upwards until the bin opens, then push in the red button located behind the
cyclone and lift the cyclone out.
• To detach the clear bin from the machine, pull back on the red catch located at the
base, slide the clear bin down and carefully remove forwards from the main body.
• Clean the clear bin with a damp cloth only.
• Do not use detergents, polishes or air fresheners to clean the clear bin.
• Do not put the clear bin in a dishwasher.
• Ensure the clear bin is completely dry before replacing.
• To replace the clear bin, align the tabs on the clear bin with the grooves on the main
body and slide upwards into place until the catch clicks.
• Slide the cyclone into the grooves of the main body and push downwards until it is in its
normal position and manually close the base of the bin – the base will click when it is
securely in place.
Washable parts
Your machine has washable parts, which require regular cleaning. Follow the
instructions below.
Washing the filters
• Your machine has two washable filters; wash the filters at least once a month according
to the following instructions to maintain performance. More frequent washing may be
required where the user: vacuums fine dust, operates mainly in 'Powerful suction' mode,
or uses the machine intensively.
Washing filter A
• Ensure the machine is disconnected from the charger before removing the filter.
Be careful not to pull the ‘ON’ trigger.
• Check and wash the filter regularly according to instructions to maintain performance.
• The filter may require more frequent washing if vacuuming fine dust or if used mainly in
‘Powerful suction’ mode.
• To remove the filter, lift it out of the top of the machine.
• Wash the filter with cold water only. No hot water and no detergents.
• Run water over the outside of the filter until the water runs clear.
• Squeeze and twist with both hands to make sure the excess water is removed.
• Leave the filter to dry completely for a minimum of 24 hours.
• Do not put any part of your machine in a dishwasher, washing machine, tumble dryer,
oven, microwave or near a naked flame.
• To refit, place the dry filter back into the top of the machine. Make sure it is
seated properly.
Washing filter B
• To remove the filter, twist anticlockwise to the open position and pull away from
the machine.
• Wash the inside of the filter under cold running water, rotating the filter to ensure all
pleats are covered.
• Gently tap the filter against the side of the sink several times to remove any debris.
• Repeat this process 4-5 times until the filter is clean.
• Place the filter upright, with the top of the filter facing upwards, and leave to dry
completely for a minimum of 24 hours.
• To refit, return the filter to the open position and twist clockwise until it clicks into place.
Blockages – automatic cut-out
• This machine is fitted with an automatic cut-out.
• If any part becomes blocked, the machine may automatically cut out.
• This will happen after the motor pulses a number of times (i.e switches on and off in
quick succession).
• Leave to cool down before looking for blockages.
• Ensure the machine is disconnected from the charger before looking for blockages.
Failure to do so could result in personal injury.
• Clear any blockages before restarting.
• Refit all parts securely before using.
• Clearing blockages is not covered by your warranty.
Looking for blockages
The motor will pulse when there is a blockage. Please follow the instructions below to
locate the blockage:
• Ensure the machine is disconnected from the charger before looking for blockages.
Be careful not to pull the ‘ON’ trigger.
• Do not operate while checking for blockages. Doing so could result in personal injury.
• Beware of sharp objects when checking for blockages.
• To check for blockages in the main body of the machine, remove the clear bin and
cyclone as per the instructions in the 'Cleaning the clear bin' section and remove the
blockage. Please consult the 'Stubborn blockages' section of the illustrations for
further guidance.
• If you cannot clear an obstruction, you may need to remove the brush bar. Use a coin to
unlock the fastener, slide the brush bar out of the cleaner head and remove the
obstruction. Replace the brush bar and secure it by tightening the fastener. Ensure it is
fixed firmly before operating the machine.
• This machine has carbon fibre brushes. Take care if coming into contact with them,
as they may cause minor skin irritation. Wash your hands after handling the brushes.
• Refit all parts securely before using.
• Clearing blockages is not covered by your warranty.
Charging and storing
• This machine will switch ‘OFF’ if the battery temperature is below 3°C (37.4°F). This is
designed to protect the motor and battery. Do not charge the machine and then move it
to an area with a temperature below 3°C (37.4°F) for storage purposes.
• To help prolong battery life, avoid recharging immediately after a full discharge.
Allow to cool for a few minutes.
• Avoid using the machine with the battery flush to a surface. This will help it run cooler
and prolong battery run time and life.
Battery safety instructions
• If the battery needs replacing, please contact the Dyson Helpline.
• Use only Dyson chargers for charging this Dyson machine.
Online support
• For online help, general tips, videos and useful information about Dyson.
www.dyson.in/support

9
Disposal information
• Dyson products are made from high grade recyclable materials. Recycle
where possible.
• The battery should be removed from the product before disposal.
• Dispose of or recycle the battery in accordance with local ordinances or regulations.
• Dispose of the exhausted filter in accordance with local ordinances or regulations.
Dyson customer care
Thank you for choosing to buy a Dyson machine
After registering your 2year warranty, your Dyson machine will be covered for parts
and labour for 2years from the date of purchase, subject to the terms of the warranty.
If you have any queries regarding your Dyson machine, visit www.dyson.in/support (IN)
for online help, general tips and useful information about Dyson.
Alternatively, you can call the Dyson Helpline with your serial number and details of
where and when you bought the machine.
If your Dyson machine needs a repair, call the Dyson Helpline so we can discuss the
available options. If your Dyson machine is under warranty, and the repair is covered,
it will be repaired at no cost.
Please register as a Dyson machine
owner
To help us ensure that you receive a prompt and efficient service, please register as a
Dyson machine owner. There are two ways to do this:
• Online at www.dyson.in/register.
• Call the Dyson Helpline on 1800 258 6688 (Toll Free)
This will confirm ownership of your Dyson machine in the event of an insurance loss,
and enable us to contact you if necessary.
Limited 2 year warranty
Terms and conditions of the Dyson 2 year limited warranty
What is covered
• The repair or replacement of your Dyson machine (at Dyson’s discretion) if it is found to
be defective due to faulty materials, workmanship or function within 2 years of
purchase or delivery (if any part is no longer available or out of manufacture,
Dyson will replace it with a functional replacement part).
• Where this machine is sold outside of the EU, this warranty will only be valid if the
machine is used in the country in which it was sold.
What is not covered
Dyson does not guarantee the repair or replacement of a product where a defect is the
result of:
• Accidental damage, faults caused by negligent use or care, misuse, neglect,
carelessness or operation or handling of the machine which is not in accordance with
the Dyson User manual.
• Use of the machine for anything other than normal domestic household purposes.
• Use of parts not assembled or installed in accordance with the instructions of Dyson.
• Use of parts and accessories which are not genuine Dyson components.
• Faulty installation (except where installed by Dyson).
• Repairs or alterations carried out by parties other than Dyson or its authorised agents.
• Blockages – please refer to the Dyson User manual for details on how to look for and
clear blockages.
• Normal wear and tear (e.g. fuse, brush bar etc.).
• Use of this machine on rubble, ash, plaster.
• Reduction in battery discharge time due to battery age or use (where applicable).
If you are in any doubt as to what is covered by your warranty, please contact the
Dyson Helpline.
Summary of cover
• The warranty becomes effective from the date of purchase (or the date of delivery if this
is later).
• You must provide proof of (both the original and any subsequent) delivery/purchase
before any work can be carried out on your Dyson machine. Without this proof, any
work carried out will be chargeable. Keep your receipt or delivery note.
• All work will be carried out by Dyson or its authorised agents.
• Any parts which are replaced by Dyson will become the property of Dyson.
• The repair or replacement of your Dyson machine under warranty will not extend the
period of warranty.
• The warranty provides benefits which are additional to and do not affect your statutory
rights as a consumer.
Important data protection
information
When registering your Dyson machine:
• You will need to provide us with basic contact information to register your machine and
enable us to support your warranty.
• When you register, you will have the opportunity to choose whether you would like to
receive communications from us. If you opt-in to communications from Dyson, we will
send you details of special offers and news of our latest innovations.
• We never sell your information to third parties and only use information that you share
with us as defined by our privacy policies which are available on our website:
privacy.dyson.com

10

11

www.dyson.in
JN.103296 PN.232540-75-03 05.07.19
Wash filters
Wash filters with cold water at least once every month.
Ensure that the filters are completely dry before refitting.
Dyson customer care
If you have a question about your Dyson machine, contact us via the
Dyson website or call the Dyson Helpline with your serial number and
details of where and when you bought the machine.
Dyson contact details
www.dyson.in
1800 258 6688 (Toll Free)
[email protected]
Dyson Technology India Pvt. Ltd.
WeWork , DLF Forum, Cyber City,
Phase-III, Sector-24,
Gurugram, Haryana,
India-122002
Important!
