Eagle Access Control Systems EAGLE Open User manual

Welcome to the smart world!
Congratulationsfor choosing EAGLE
Open, the mostinnovative gate opener
device.
The EAGLE Open device is awireless electronic
accessory to be used with smartphonesto control
electronicdoors, gates,and barriers.
Please read this User Guide carefully before
installing and using the product.
OPEN
This devise can be used for Residential or
Commercial applications.
•Residential: Up to 15 guest per devise FREE
of charge.
•Commercial: Up to 15 guest per devise
FREE of charge.
•For additional guests, a monthly subscription
will be needed.
How to use OPEN

Thisbox contains
Quick start guide
Screws(optional)
6.
3.
Should any of these be missing from the package, please
immediately contact the distributor by using any of the contact
details that are outlined on the website of the product.
You will also need
4. Smallscrewdriver
5. Cables
1. EAGLE Open device
2. Connector
2.
1.
4. 5. 6.
45
3.

6 7
1OVERVIEW
Power off your existing automatic gate opener system
either usingthe masterswitchor at the circuitbreakerbox.
Reviewall the instructions beforeyou startto avoidany
surprises duringinstallation.
HARDWAREINFO
EAGLE Open features dual output that can be used either controlling two separate
electronic gates/garage doors or controlling two functions of one electronic gate/garage
door. These outputs are connected to the control input of the central electronics of the
door / gate moverequipment(s).
There are two inputs on the device associated with each output. These can be used to sense
the state of the correspondinggate/door.
Low-voltage power supply is provided for the device from an external source, preferably
from the power supply output installed for this purpose on the connected control panel.
In the absence thereof, an external power supply unit must be provided for operating
the device, whose output voltage is within the operational voltage range indicated in the
technicalspecifications.The EAGLE Open power supplyinput is polarity-independent.
INSTALLATION INSTRUCTIONS
The installation section of the guide has been producedfor trained personnel,so it is advised
to have the installation work performed by a specialist recommended by the manufacturer
and the distributor, or by the specialist who puts into operation your electronic door, gate
or barrier.
Installation works must be completed and electric connections must be established by
appropriate working methods and due diligence.
The manufacturer and distributor of Nold Open are not liable for any damage arising from
incorrect,improperor unprofessionalinstallation (puttinginto operation).

RESET STATUS
OUT1 OUT2
IN1 IN2
NC PW
R
OUT1
First output of the device.Shouldbe connectedto
the appropriate inputof the mainunitof the gate
system (type: drycontact)
OUT2
Secondoutput of the device.Shouldbe connectedto
the appropriate input of the main unit of the gate
system (type: drycontact)
IN1
First inputof the devicefor detecting closed position of the
controlled gate in associationwith OUT1 (type: dry contact)
The usage of the inputis optional,can be enabled/disabled
in the application.
IN2
Secondinput of the devicefor detectingclosed position of
the controlled gate in association with OUT2 (type: dry
contact) The usage of the inputis optional,can be
enabled/disabled in the application.
NC Not connected. Reserved for future use.
PWR
Power supply input of the device (polarity independent, for
more informationplease see the electrical specificationof
the deviceat the endof thisdocument)
8 9

2WIRE IT UP
Beforeinstalling EAGLEOpen,pleasestudy the user guide
of your main access control unit, with particular regard
to the chapteron accessory connections, andcompareit
with this User Guide andthe connection drawing therein.
IN1 IN2
POWERSUPPLY
OUT1 OUT2
GATE2
GATE1
OPTION1-TWO DIFFERENT GATES
MAINCONTROL UNITMAINCONTROL UNIT
IN1 IN2 POWERSUPPLY OUT1 OUT2
PARTIALOPEN
MODE
FULLOPEN
MODE
OPTION2-TWO DIFFERENT MODES
MAIN CONTROL UNIT
*Theusage of the inputis optional,can be enabled/disabled in the application.
10 11

GARAGE
MOTOR
1.
12 13
2.
1. Putthewiresof thegateopener intotheirplaces(connector)
The outputs of the device are dry contact relay outputs. The inputs can only be driven by
dry contactoutputs.
Each output and input reserves 2 pins in the connector of the device.Regarding the pinout
of device please check the wiringdiagramon pages 10-11.
The operation mode of the relay outputs can be configured in the application.Momentary
pulsemode with adjustable pulselengthor static on/off mode can be chosen.
NOTE: Most of the garage door/gate openers are compatible with the pulse mode only
therefore it mightbe harmful for these devices to be used with on/off mode. Avoidswitching
to static on/offmode unlessyou knowwhat you are doing.
2. PlugtheconnectorintotheNoldOpendevice
The Nold Open must be connected to the appropriate points according to the connection
drawing,with the control panel de-energized.
3.Fastenthewires withascrewdriver
4. MountNoldOpenon thewallwith2screws.
The device should be installed as close as possible to the entry zone and as far as possible
from metallic elements as they negatively affect the transmission distance of Bluetooth®
signals. The device can be used both indoors and outdoors. In case of outdoor use, the
device must be fitted below a weatherproof protective cover. The device should be installed
at aheightof at least 1.5 metres above ground level.
For further information please visit
nold.io/help

3GET THEAPPLICATION
To be able to operateyour EAGLE Open device,
download the Nold appto your smartphone from the
Apple App Store or Google Play Store.
The appwill guide you through creating your account,
connecting and setting up your device.
NOTE: The product can only be operated by the Nold application. The manufacturer and
distributor of Nold Open are not liable for any errors or damage by operation otherwise or
by the useof anyharmfulcode.
The Nold Open device is compatible with all mobile phones using iOS™ 9.0 (or newer),
Android™ OS 5.0(ornewer)operatingsystemsandhavingBluetooth®4.0wirelesstechnology. Scan the QR code or visit nold.io/app
14 15

4POWER ON THEDEVICE
Make sure that the EAGLE Open device is powered
on. (Thegreenlight is on.)
The EAGLE Open power supply input
is polarity-independent.
LEDnotifications
Pulsating greenlight
The device is powered up,
ready touse
Solidgreenlight
The device is connected
to asmartphone
Redlightinterrupts thesolid
greenlight
The device received command
from asmartphone
16 17

5BLUETOOTHON
Turnon Bluetoothon your phone.
Start the App and follow the instructions.
The two control outputs of EAGLE Open with all of its associated functionalities are
mapped into virtual keys in the application. So the device can be controlled through these
virtualkeys. Virtualkeyscan be shared with other users.
NOTE: Please do not share the virtual key with unauthorized persons. The manufacturer
and distributor of Nold Open are not held liable for damage by shares to unauthorized
persons.
18 19

6USENOLDCLOUD
To manage your devices and guests
more easily, use your Nold account
to login to cloud.nold.io
20 21

TECHNICAL PARAMETERS
22 23
Supplyvoltage:8-32V DC, 6-24V AC
Operatingtemperature range:-40°C –+85°C
Max. current consumption(@24V):75 mA
Numberof switchedoutput(s):2
Output type: unfused relay contact(NO)
Max.loadcurrent on output(s):1A@24V DC,0.5A@125V AC
Max.switchedvoltage:125V AC, 60V DC
Numberof opendetection inputs:2
Inputvoltageshortcircuit protection:fuse(0.2A)
Size:40x80x20 mm
Wirelesscommunication protocol:Bluetooth4.0LE
RF carrier frequency:2.4GHz
RF TX power: +4dBm

Security
Communication between the Nold smartphone application and the device is
encrypted. Strength of encryption is 128 bits.
iBeacon compatibility
Nold Open supports the Apple®iBeacon™ standard. When approaching the Nold
Open device, notification of the application on the iOSTM operating system
automatically appears on the display of your phone. To enable this function, go to
Settingsand choose automaticnotifications of virtual keys.
Operational radius
Depending on the location and line of sight of the device, the operational distance of
the integrated Bluetooth®radio can vary between 5 and 50 metres.
Areas of use of Nold Open
Nold Open can be preferably used together with the following access control solutions:
•Garage door and gate opener automatics control
•Industrial gate control
•Remotecontrol of barrier and parking systems
•Automatic door control
•Electromagnetic lock systems control
•Accessory for admission systems
•Other: Nold Open can alsobe used for other connectiontaskswhere power
supply and operating conditions fit in the ranges indicated in the specifications.
General information
The Nold Open complies with applicable standards and normative documents and is
equipped with the conformity marking. The full conformity declaration is available at
the following website: nold.io/help
The sign (crossed dustbin) means that within the European Union, the product
must be thrown into a separate collector bin at the end of its life cycle. Please do
not dispose of the product as household waste. The manufacturer undertakes to make
available for buyers information on chemicals in the devices as required for regulatory
compliance. This information is available at the following website: nold.io/help
Alltrademarks and markingsindicated in this User Guide are exclusivelyowned by
their proprietors.
The descriptions and illustrations in this User Guide are subject to change.
The manufacturer reserves the right to effect any modifications deemed to be
required for the technical, manufacturing and commercial development of the
product, while keeping the basic product features, and is allowed to do so at any time
wi tho ut modi fying this documentatio n.
Pleasealwaysuse Nold Open withcaution and keepsafetyin mind.
Nold Open is not qualified as a security device and cannot protect your property,
therefore the manufacturer and distributor of Nold Open are not responsible for any
violation of protection of your personal assets.
24 25

The manufacturer and distributor of Nold Open are not held liable for any defects
caused by use or operation other than specified in this User Guide, improper use,
unprofessional installation, operation repair and transformation, unauthorized
modifications or alterations, inadequate storage, external impacts, (e.g. overvoltage,
lightning), environmental effects (chemical impacts, e.g. acid rain, scale, etc.),
irregular environmental conditions (e.g. discoloration due to freezing or harmful
solar radiation), disaster or otherwise not listed as above after purchase, and for any
damage arising therefrom.
Unauthorized use of the Product or software can impair the Product‘s performance
and may invalidate this Limited Warranty.
Sendus an e-mail
info@eagleoperators .com
Orcall usat:1-800-708-8848
