Eagle Access Control Systems X9S Operating instructions

AVI Slide Rev - C
Swing Gate Operators
X9S & X9L
X9S & X9L
TM
ACCESS CONTROL SYSTEMS, INC.
BY EAGLEACCESS CONTROL SYSTEMS, INC.
X9L - Long Arm
X9S - Short Arm
Gate Capacity 10 ft - 700 lbs.
Gate Capacity 16 ft - 800 lbs.
Installation & Owners Manual

2X9 Swing Rev - H

1
X9 Slide Rev - H
X9L - Long Arm
Control Box
X9S - Short Arm
Control Box Power 115 VAC @ 60 Hz - 4 amps per Arm
Motor Power 24 VDC @ 180 Watts per Arm
Thrust 1900
Normal Gate Cycles Intensive
Traveling Distance (Drive Screw) X9S: 13 3/4” X9L: 19 5/8”
Max Gate Length X9S: 10 ft per Gate X9L: 16 ft Per Gate
Max Gate Weight X9S: 700 lbs per Gate X9L: 800 lbs per Gate
Opening Time 90° X9S: 20 sec X9L: 25 sec
Entrapment Protection:
Built-In ERD adjustable reversing sensor
Input for non-contact sensor
Input for contact sensor
© 2018 Eagle Access Control Systems, Inc.
All rights reserved. No part of this manual may be reproduced in any means: graphics, electronics or mechanical. Including photocopying
with
ou
t th
e
e
x
p
r
essed
writt
e
n
pe
rmi
ss
i
o
n
o
f th
e
pub
li
s
h
e
r. M
a
t
e
ri
a
l
s
co
m
po
n
e
nt
s
a
n
d
spec
ifi
ca
ti
o
n
s
a
r
e
subjec
t t
o
c
h
a
n
ge
with
ou
t n
o
ti
ce
.
41”
35”
5”
5 1/2”
TABLE OF CONTENTS
SAFETY
UL 325 Listings
UL 325 Model Classifications
Swing Gate Recommendations
Important Safety Information
General Safety Information
2
3
4
5
5
2
PROGRAMMING & ADJUSTMENTS
Program Travel Distance and Pause Time to Close Gate(s)
SINGLE Gate Programming
Bi-Parting Gates Programming
Modify Programmed Pause Time
LEARN Remote Button
Adjust Reverse Sensor
Power Fail Operation
Control Box Wiring Diagram
24
24
25
26
26
27
27
28
24
X9 SWING GATE OPERATOR SPECIFICATIONS
INSTALLATION
Sample Single Gate Installation Setups
Sample Dual Gates Installation Setups
Disassemble Operator
Mount Arm
Mount Control Box
Open INSIDE Mounting Dimensions
Open OUTSIDE Mounting Dimensions
Adjusting Physical Limits
120 VAC Input Power Connection
Photo Eye Installation
Open INSIDE - Single Operator & Photo Eye Wiring
Open OUTSIDE - Single Operator & Photo Eye Wiring
Open INSIDE - Dual Operators & Photo Eye Wiring
Open OUTSIDE - Dual Operators & Photo Eye Wiring
Wiring Accessories
Advanced Accessory Connection
Loop Detectors
DIP-Switch Descriptions
6
7
8
9
10
11
12
13
13
14
15
16
17
18
19
20
21
22-23
6
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
11”
4 5/8” 8 3/4”

2X9 Swing Rev - H
UL 325 Listings
SAFETY
1. Install the gate operator only when:
a) The operator is appropriate for the construction of the gate and the usage class of the gate.
b) All openings of a horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 6 feet (1.83 m) above the
ground to prevent a 2-1/4 inch (57.2 mm) diameter sphere from passing through the openings anywhere in the gate, and in that portion
of the adjacent fence that the gate covers in the open position.
c) All exposed pinch points are eliminated or guarded, and
d) Guarding is supplied for exposed rollers.
2. The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a separate access opening. The
pedestrian access opening shall be designed to promote pedestrian usage. Locate the pedestrian gate such that persons will not come in
contact with the vehicular gate during the entire path of travel of the vehicular gate.
3. The gate must be installed in a location so that enough clearance is supplied between the gate and adjacent structures when opening and
closing to reduce the risk of entrapment. Swinging gates shall not open into public access areas.
4. The gate must be properly installed and work freely in both directions prior to the installation of the gate operator. Do not over-tighten the
operator clutch or pressure relief valve to compensate for a damaged gate.
5. For gate operators utilizing Type D protection:
a) The gate operator controls must be placed so that the user has full view of the gate area when the gate is not moving.
b) The placard provided marked in letters at least 1/4 in. (6.4-mm) high with the word “WARNING” and the following statement or the
equivalent: “Moving Gate Has the Potential of Inflicting Injury or Death – Do Not Start Gate Unless Path is Clear” shall be placed adjacent
to the controls,
c) An automatic closing device (such as a timer, loop sensor, or similar device) shall not be employed, and
d) No other activation device shall be connected.
6. Controls intended for user activation must be located at least six feet (6’) away from any moving part of the gate and where the user is
prevented from reaching over, under, around or through the gate to operate the controls. Outdoor or easily accessible controls shall have a
security feature to prevent unauthorized use.
7. The Stop and /or Reset button must be located in the line-of-sight of the gate. Activation of the reset control shall not cause the operator to
start.
8. A minimum of two (2) WARNING SIGNS shall be installed, one on each side of the gate where easily visible.
9. For gate operators utilizing a non-contact sensor in accordance with Usage Class:
a) See instructions on the placement of non-contact sensors for each type of application,
b) Care shall be exercised to reduce the risk of nuisance tripping, such as when a vehicle trips the sensor while the gate is still moving,
and
c) One or more non-contact sensors shall be located where the risk of entrapment or obstruction exists, such as the perimeter reachable
by a moving gate or barrier.
10. For gate operators utilizing a contact sensor in accordance with Usage Class:
a) One or more contact sensors shall be located where the risk of entrapment or obstruction exists, such as at the leading edge, trailing
edge, and post-mounted both inside and outside of a vehicular horizontal slide gate.
b) One or more contact sensors shall be located at the bottom edge of a vehicular vertical lift gate.
c) One or more contact sensors shall be located at the pinch point of a vehicular vertical pivot gate.
d) A hardwired contact sensor shall be located and its wiring arranged so that the communication between the sensor and the gate
operator is not subjected to mechanical damage.
e) A wireless contact sensor such as one that transmits radio frequency (RF) signals to the gate operator for entrapment protection
functions shall be located where the transmission of the signals are not obstructed or impeded by building structures, natural
landscaping or similar obstruction. A wireless contact sensor shall function under the intended end-use conditions.
f) One or more contact sensors shall be located on the inside and outside leading edge of a swing gate.
Additionally, if the bottom edge of a swing gate is greater than 6 inches (152 mm) above the ground at any point in its arc of travel, one
or more contact sensors shall be located on the bottom edge.
g) One or more contact sensors shall be located at the bottom edge of a vertical barrier (arm).
UL 325 Listings

3
X9 Slide Rev - H
UL 325 Classifications
UL 325 Model Classifications
UL 325 Entrapment Protection
CLASS I
Residential Vehicular Gate Operator - A vehicular gate
operator (opener or system) intended for use in a home
of one to four single family dwellings, or a garage or
parking area associated therewith.
CLASS II
Commercial/General Access Vehicular Gate Operator - A
vehicular gate operator (opener or system) intended for
use in a commercial location or building such as a
multi-family housing unit (five or more single family
units) hotel, garages, retail store or other building
servicing the general public.
CLASS III
Industrial/Limited Access Vehicular Gate Operator - A
vehicular gate operator (opener or system) intended for
use in a industrial location, loading dock area or other
location not intended to service the general public.
CLASS IV
Restricted Access Vehicular Gate Operator - A vehicular
gate operator (opener or system) intended for use in a
guarded industrial location or buildings such as airport
security area or other restricted access locations not
servicing the general public, in which unauthorized
access is prevented via supervision by security
personnel.
Entrapment Protection Requirements for Each Type of Operator.
Proper installation must satisfy the entrapment protection chart as shown.
A- Inherent (built into the gate operator) entrapment protection.
B1 - Non-contact sensor such as photo-eye or equivalent.
B2 - Contact sensor such as edge sensor or equivalent.
C- Inherent adjustable clutch or pressure relief device.
D- Actuating device requiring continuous pressure to
maintain gate motion.
CLASS I
CLASS II
CLASS III
CLASS IV
*UL 325 requires that B1 and B2 means of entrapment protection must be MONITORED.
A, B1*, B2* or D
A, B1*, B2* C or D
Gate Type
Horizontal Slide
Vertical Lift
Vertical Pivot Gate
Swing Gate or
Vertical Barrier (arm)
Entrapment Protection

4X9 Swing Rev - H
Swing Gate Requirements
The operator is intended for installation ONLY on gates used for vehicles. Pedestrians should be supplied with a separate
access opening. The pedestrian access opening should be designed to promote pedestrian usage. Locate the gate such that
persons will not come in contact with the vehicular gate during the entire path of travel of the vehicular gate.
Gates Closed
Separate
Pedestrian
Access
Opening
Gates should have smooth bottom edges, with vertical bottom edged protrusions not exceeding 0.50 inches.
If distance is greater than 4 inches,
entrapment protection for this area
is recommended.
If distance is less than 16 inches,
entrapment protection in this area
is recommended.
1
1
1
2
2
Gate Closed
With the hinge mounted on
the corner of the pilaster, the
entrapment area is
eliminated and protection is
NOT needed for this area.
Gate Closed
Gate Opened
Gate Opened
Swing Gate Recommendations

5
X9 Slide Rev - H
General Safety
Important Safety Information
General Safety Information
Install Warning Signs
1. Never let children operate or play with gate controls. Keep the remote control away from children.
2. Always keep people and objects away from gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE.
3. Test the operator monthly. The gate MUST reverse on contact with a rigid object or stop when an object activates the non-contact
sensors. After adjusting the force or the limit of travel, retest the gate operator. Failure to adjust and retest the gate operator properly can
increase the risk of injury or death.
4. Use the emergency release ONLY when the gate is not moving and verify that operator power has been turned OFF.
5. KEEP GATES PROPERLY MAINTAINED. Read the owner's manual. Have a qualified service person make repairs to gate hardware.
6. The entrance is for vehicles only. Pedestrians must use separate entrance.
7. SAVE THESE INSTRUCTIONS.
To reduce the risk of injury or death read and follow the instructions
WARNING
Be sure to read and follow all the Eagle Access Control Systems, Inc. and UL instructions before installing and
operating any Eagle Access Control System, Inc. products. Eagle Access Control Systems, Inc. is not responsible
for any improper installation procedures caused by failure to comply with local building codes.
Install warning signs on BOTH sides of the gate.
Be sure to mount ALL gate operating devices at least six
feet (6’) away from any moving part of the gate. They must
NOT be able to be operated reaching through the gate.
Injuries may be avoided if a mesh screen is installed on
the gate. Injuries resulting from hands and feet becoming
stuck in the gate or children riding on the gate while gate
is moving can be greatly reduced if this “screen” or
“mesh” is applied to the gate as a safety precaution.
CAUTION
Moving Gate Can Cause
Serious Injury or Death
KEEPCLEAR! Gatemay move at any time
withoutprior warning.
Donot let children operate the gate or play
inthe gate area.
Thisentrance is for vehicles only.
Pedestriansmust use separate entrance.
Moving Gate Can Cause
Serious Injury or Death
KEEP CLEAR! Gate may move at any time
without prior warning.
Do not let children operate the gate or play
in the gate area.
This entrance is for vehicles only.
Pedestrians must use separate entrance.
Moving Gate Can Cause
Serious Injury or Death
KEEPCLEAR! Gate may move at any time
withoutprior warning.
Donot let children operate the gate or play
inthe gate area.
Thisentrance is for vehicles only.
Pedestriansmust use separate entrance.
Installing Opening Devices
Ornamental Grill Styled Gates
Moving Gate Can Cause
Serious Injury or Death
KEEPCLEAR! Gate may move at any time
withoutprior warning.
Donot let children operate the gate or play
inthe gate area.
Thisentrance is for vehicles only.
Pedestriansmust use separate entrance.
BYEAGLEACCESS CONTROL SYSTEMS, INC.
BYEAGLEACCESS CONTROL SYSTEMS, INC.
BYEAGLEACCESS CONTROL SYSTEMS, INC.

6X9 Swing Rev - H
Single Gate Installation Setup
Phantom
Loop
(Shadow)
SAMPLE SINGLE GATE INSTALLATION SETUPS
An experienced installer should perform the installation. Improper installation may result in property damage, severe injury or death.
Read the entire manual before proceeding with the installation.
Eagle Access Control Systems, Inc. is not responsible for researching and complying with local building codes. Be sure to check all local
building codes before installation.
These drawings are typical and is supplied as working model
from which to choose the electronic components making up
the single gate installation. Dual gates setup is on the next
page. These drawings do not lay down any requirements
regarding the installation of the gate operator. Please see the
previous pages for safety and general gate recommendations.
Any external safety devices get wired to the control box in
conduit when possible.
Opening-Direction Photocell
(Inside Property)
Phantom Loop
(Shadow)
Safety Loop
Exit Loop
Safety Loop
Closing-Direction Photocell
(Outside of Property)
Closing-Direction Photocell
(Outside of Property)
Sensing Edge
BYEAGLEACCESSCONTROLSYSTEMS,INC.
Opening-Direction Photocell
(Outside Property)
Safety Loop
Exit Loop
Safety Loop
Sensing Edge
BYEAGLEACCESSCONTROLSYSTEMS,INC.
OPEN INSIDE
OPEN OUTSIDE

7
X9 Slide Rev - H
Dual Gate Installation Setup
Phantom Loop
(Shadow)
These drawings are typical and is supplied as working model from
which to choose the electronic components making up the dual
gates installation. These drawings do not lay down any requirements
regarding the installation of the gate operators. Please see the pages
2-5 for safety and general gate recommendations.
Any external safety devices get wired to the control box in conduit
when possible.
BYEAGLEACCESSCONTROLSYSTEMS,INC.
Opening-Direction Photocell
Opening-Direction Photocell
(Inside Property)
Phantom Loop
(Shadow)
Master / Slave Connection
Safety Loop
OPEN INSIDE
OPEN OUTSIDE
Exit Loop
Exit Loop
Safety Loop
Closing-Direction Photocell
(Outside of Property)
Closing-Direction Photocell
(Outside of Property)
Sensing Edges
Opening-Direction
Photocell
Opening-Direction Photocell
(Outside Property)
Master / Slave Connection
Safety Loop
Safety Loop
Sensing Edges
SAMPLE DUAL GATES INSTALLATION SETUPS
BYEAGLEACCESSCONTROLSYSTEMS,INC.

8X9 Swing Rev - H
Disassemble Operator
Step 2 - Remove Cover to Access Limit Assembly
1. Remove two 5mm allen screws
2. Slide cover off.
Cover
Step 1 - Release Stroke Pin
1. Unlock with Key and open door.
2. Flip orange handle forward.
3. Stroke pin can now be moved.
4. To Lock Stroke Pin again: Flip orange
handle back to original position.
5. Close and lock door.
NOTE: The stroke pin can REMAIN
UNLOCKED by simply removing
the orange handle in the released
position.
The stroke pin must be released before
installation.
Released Position (Unlocked)
Stroke Pin
Door
Key
DISASSEMBLE OPERATOR

9
X9 Slide Rev - H
Mount Arm
Not Level
Arm MUST be Installed LEVEL!
Not Level
Not Level
Upside Down
Cut Bracket to Fit
Weld Bracket at an Angle
Option
Rear Bracket Front Bracket
Min Stroke
Stroke Pin
Min Max
X9L-Long Arm
X9S-Short Arm
Max Stroke
4” Minimum Above Ground
2”
2” Offset Between Brackets
18 3/4” 19 5/8”
18 3/4”
38 1/2”
32 1/2”
4”
13 3/4”
3 3/4”
Rear
Front
NOTE: Weld COMPLETELY around bracket.
See pages 11 and 12 for
dimensional layouts.
NOTE: Release the stroke pin before installation,
see “Release Stroke Pin” on previous page.
Option
COMMON MISTAKES
TO BE AWARE OF:
MOUNT ARM

10 X9 Swing Rev - H
Mount Control Box
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
BY EAGLE ACCESS CONTROL SYSTEMS, INC.
2”
11”
8 5/8”
6”
8 3/4”4 5/8”
Area for Conduit Holes
Conduit 1. Motor 1
Conduit 2. Motor 2
Conduit 3. Accessories
Conduit 4. Power
Conduit Runs
Mount control box using
4 existing mounting holes
with appropriate hardware
not included.
Mounting Hole
7 1/2”
Mounting Hole
Mount the control box as near as possible to
the actuator arm. Keep the box high enough
above the ground to avoid landscape sprinklers
and such. Avoid drilling holes in the side or top
of the box. Seal any holes made in box to keep
out moisture. The antenna reception for the
radio receiver gets better the higher the box is
above the ground.
Never run low voltage wires
in the same conduit as high
voltage wire.
MOUNT CONTROL BOX

11
X9 Slide Rev - H
Open INSIDE Dimensions
B” C”A”(°)
90
90
90
110
110
110
6 3/4
7 1/4
8
6 3/4
5 1/2
6
7
7
5 1/4
6 3/4
6
6
4 3/4
4 3/4
4 3/4
4 3/4
4 3/4
4 3/4
Closed
Opened
90°-110°
Max Stroke
X9L = 38 1/2”
X9S = 32 1/2”
Min Stroke
18 3/4”
A
B
C
The position of the brackets establishes the maximum opening angle and the length
of the actuator's linear stroke.
The longer the stroke, the greater the torque and smoother movements of the gate.
The shorter the stroke, the less the torque and more abrupt movements of the gate.
Install gate overlap on M1 gate.
M1 opens first and closes last.
Install maglock accordingly.
Bi-Parting Gates
M1 M2
M1 M2
X9L-LONG Arm: MAX 16 ft per Gate
X9S-SHORT Arm: MAX 10 ft per Gate
OPEN INSIDE MOUNTING DIMENSIONS

12 X9 Swing Rev - H
Open OUTSIDE Dimensions
NOTE: Rear bracket
MUST be fabricated.
Supplied Rear Bracket
Closed
Opened
Fabricated
Bracket
90°-105°
7 1/2”
6”
4 3/4”
Max Stroke = 38”
Only to be used with the X9L – Long Arm
The position of the brackets establishes the maximum opening angle and the length
of the actuator's linear stroke.
The longer the stroke, the greater the torque and smoother movements of the gate.
The shorter the stroke, the less the torque and more abrupt movements of the gate.
Install gate overlap on M1 gate.
M1 opens first and closes last.
Install maglock accordingly.
Bi-Parting Gates
M1 M2
Fabricated
Bracket
M1 M2
OPEN OUTSIDE MOUNTING DIMENSIONS

13
X9 Slide Rev - H
Input Power Connection
Adjust Physical Limits
+
+
-
+
-
+
-
NO
D
ENCODER
D
M1
M1
POWER
NC C
F16A F3A
US1
SEC
FUSE
FUSE
FUSE
FUSE
M2
M2
POWER
L
T4A 120V
120V 50/60Hz N
21321
54321
54321
1 2 5 6 8 9 12 137 10 113414
COM24 COM
+++
24VDCMAG LOCK
MOTOR
2 LIMITS
MOTOR
1 LIMITS
OPEN
EXIT
MOTOR
COM
REVERSE
LOOP
54321 10 119876 1312
WARNING: Eagle Access Control Systems, Inc. is not
responsible for researching and complying with local
building codes. Be sure to check all local building codes
before installation.
Be sure that the circuit breaker for the input power is
turned OFF before connecting the input power to the
operator.
All operators MUST be properly grounded.
Installing surge protection is recommended.
IMPORTANT: DO NOT cycle the operator before physically setting
the limit switches (see above) AND programming has been
completed (see pages 23-24). Damage or injury could occur.
Wire Color Description
Black - 120 VAC input power
White - Neutral input
Green - Ground input
(from an approved grounding method)
CAUTION
400 ft
14 AWG
600 ft
12 AWG
1200 ft
10 AWG
2000 ft
8 AWG
300 ft 500 ft 1000 ft 1700 ft
Single Arm
Dual Arms
120 VAC
120 VAC
Input Power Wire
120 VAC Input Power Wire Runs Maximums
SEC
L
T4A 120V
120V 50/60Hz N
4 Amp Fuse
Black
Green
White
Pulling the 4 Amp fuse
will shut-off power.
4A
Never run low voltage wires
in the same conduit as high
voltage wire.
ON / OFF
Operator Must be in released position (Unlocked).
Cover MUST be removed.
Manually move gate to CLOSED position.
Slide CLOSE limit switch until it activates (clicks).
Spin mechanical stop until it touches limit switch and
tighten it down.
Manually move gate to OPEN position.
Slide OPEN limit switch until it activates (clicks).
Spin mechanical stop until it touches limit switch and
tighten it down.
Re-lock operator and reinstall cover.
Repeat process with second operator if installed.
Released Position
(Unlocked)
Stroke Pin
Assembly
Mechanical
Stop
Mechanical
Stop
Mechanical
Stop
Limit
Switch
Limit
Switch
Limit SwitchLimit Switch
1/8” min gap for mechanical stop
NOTE: To REMOVE limit switches,
slide to center of limit plate.
Limit switches and mechanical stops MUST be
CORRECTLY positioned and secured with the
set screw BEFORE programming.
120 VAC INPUT POWER CONNECTION
ADJUST PHYSICAL LIMITS

14 X9 Swing Rev - H
PHOTO EYE INSTALLATION
SW1
OFF
ON
OFF
OFF
OFF
ON
Monitoring Method
POWER ALIGN
Min. Max.
R.T:
Resistive
termination
Non-Polarity
Power NO NCCOM (HB+) (HB-)
Switch Setting
Light ON
Dark ON
2 Frequency (HB)
3 Frequency (HB)
R. T. (NC)
R. T. (NO)
SW5
OFF
OFF
OFF
OFF
OFF
ON
SW2
OFF
OFF
OFF
ON
OFF
OFF
SW3
OFF
OFF
ON
ON
OFF
OFF
SW4
OFF
OFF
OFF
OFF
ON
OFF
ON
1 2 3 4 5
Pull Out
Lift Up
Remove Hood
Remove cover
with 4 screws
Cover
Pull Out
Closing
Opening
Open
Top View
5”
or less
Gate Frame
21”
Typical
MAX
27.5”
Disassembly
DIP-Switches
Beam Adjustment Typical Vehicular Gate Locations
Mount with appropriate hardware
Wrap Around
Mounting Bracket
for Reflector
Wrap Around
Mounting Bracket
Max Sensing Range:
49 ft (15m) / Outdoors
Beam is aligned with reflector when yellow ALIGN LED turns ON.
Sensing Range Adjustment
Turning Clockwise: Range becomes longer.
Turning Counter-Clockwise: Range becomes shorter.
SW1
OFF
ON
OFF
OFF
OFF
ON
Monitoring Method
POWER ALIGN
Min. Max.
R.T:
Resistive
termination
Non-Polarity
Power NO NCCOM (HB+) (HB-)
Switch Setting
Light ON
Dark ON
2 Frequency (HB)
3 Frequency (HB)
R. T. (NC)
R. T. (NO)
SW5
OFF
OFF
OFF
OFF
OFF
ON
SW2
OFF
OFF
OFF
ON
OFF
OFF
SW3
OFF
OFF
ON
ON
OFF
OFF
SW4
OFF
OFF
OFF
OFF
ON
OFF
ON
1 2 3 4 5
Side View
Hood
Cover
2 3/4”
4”
7 3/4”
1 2 5 6 8 9 12 137 10 113414
COM24 COM
+++
24VDCMAG LOCK
MOTOR
2 LIMITS
MOTOR
1 LIMITS
OPEN
EXIT
MOTOR
COM
REVERSE
LOOP
54321 10 119876 141312
SW 1 = OFF
SW 2 = OFF
SW 3 = OFF
SW 4 = ON
SW 5 = OFF
Red
Blue
Black
White
Red -
Blue -
Black -
White -
9
11
12
14
Photo Eye Installation

15
X9 Slide Rev - H
Open INSIDE - Single Operator Wiring
1 2 5 6 8 9 12 137 10 113414
COM24 COM
+++
24VDCMAG LOCK
MOTOR
2 LIMITS
MOTOR
1 LIMITS
OPEN
EXIT
MOTOR
COM
REVERSE
LOOP
54321 10 119876 141312
1
ON
23456789 10 11 12
1
ON
234567
+-
24V
FT
+-
LAMP.
+-
EL. LOCK
+-
+
-
+
-
+
-
+
-
NO
D
ENCODER
D
M1
M1
POWER
NC C +-
24V
SPIA
24V
SPIA 2
F16A F3A
PRG-LINK
PROG
OC2 RECEIVER
P2 P1
STOP
Reset
TAST3F
P3
US1
P/P
P/P
J
BSCC
SECTR
BSA FT1 J1 J2 PC PA PED STP P/P C
TR1
LD1
FT2
Prel.
Rich
US1
C.Sg
Rall.
C.Ch
2 M.
Fot.R
BSC BSA FT1 FT2 J1 J2 STP
FUSE
FUSE
FUSE
FUSE
+-
24V
ANTENNA
M2
M2
POWER
121110987654321
12 131110987654321
321
54321
54321
Operator MUST OPEN after initial power up. If operator begins
to close, shut-off power and reverse Red and Black wires.
Supplied Photo Eye should be installed in closing direction
as shown, see page 17 for installation requirements.
DIP Switch Settings
1
ON
2345678910 11 12
P/P
J
Prel.
Rich
US1
C.Sg
Rall.
C.Ch
2 M.
Fot.R
SW 1 = OFF
SW 2 = OFF
SW 3 = ON (limits for motor 1 only)
SW 4 = OFF
SW 5 = OFF
SW 6 = ON (automatic closure is active)
SW 7 = OFF
SW 8 = OFF
SW 9 = ON (slow down near endpoints)
SW 10 = OFF
SW 11 = OFF (1 motor configuration)
SW 12 = OFF
1
ON
234567
BSC BSA FT1 FT2 J1 J2 STP
SW 1 = ON
SW 2 = ON
SW 3 = OFF (Photo Eye FT1)
SW 4 = ON
SW 5 = OFF
SW 6 = OFF
SW 7 = ON
Closed Gate
M1 Power
M1 Limits
Closing-Direction Photo Eye
Open
INSIDE
M1
Green -
Gray -
Blue -
Red - M1-1
Black - M1-2
MOTOR 1
Inputs
1
2
3
OPEN INSIDE - SINGLE OPERATOR & PHOTO EYE WIRING
Red -
Blue -
Black -
White -
Photo Eye
9
11
12
14
ON DIP
1 2 3 4 5
SW 4 = ON
Red
Green
Gray
Blue Blue
Black
White

16 X9 Swing Rev - H
Open OUTSIDE - Single Operator Wiring
1 2 5 6 8 9 12 137 10 113414
COM24 COM
+++
24VDCMAG LOCK
MOTOR
2 LIMITS
MOTOR
1 LIMITS
OPEN
EXIT
MOTOR
COM
REVERSE
LOOP
54321 10 119876 141312
1
ON
23456789 10 11 12
1
ON
234567
+-
24V
FT
+-
LAMP.
+-
EL. LOCK
+-
+
-
+
-
+
-
+
-
NO
D
ENCODER
D
M1
M1
POWER
NC C +-
24V
SPIA
24V
SPIA 2
F16A F3A
PRG-LINK
PROG
OC2 RECEIVER
P2 P1
STOP
Reset
TAST3F
P3
US1
P/P
P/P
J
BSCC
SECTR
BSA FT1 J1 J2 PC PA PED STP P/P C
TR1
LD1
FT2
Prel.
Rich
US1
C.Sg
Rall.
C.Ch
2 M.
Fot.R
BSC BSA FT1 FT2 J1 J2 STP
FUSE
FUSE
FUSE
FUSE
+-
24V
ANTENNA
M2
M2
POWER
121110987654321
12 131110987654321
321
54321
54321
Closed Gate
Open
OUTSIDE
M1
Opened
Closing-Direction Photo Eye
M1 Power
M1 Limits
Green -
Gray -
Blue -
Black - M1-1
Red - M1-2
MOTOR 1
Inputs
1
2
3
OPEN OUTSIDE - SINGLE OPERATOR & PHOTO EYE WIRING
DIP Switch Settings
1
ON
2345678910 11 12
P/P
J
Prel.
Rich
US1
C.Sg
Rall.
C.Ch
2 M.
Fot.R
SW 1 = OFF
SW 2 = OFF
SW 3 = ON (limits for motor 1 only)
SW 4 = OFF
SW 5 = OFF
SW 6 = ON (automatic closure is active)
SW 7 = OFF
SW 8 = OFF
SW 9 = ON (slow down near endpoints)
SW 10 = OFF
SW 11 = OFF (1 motor configuration)
SW 12 = OFF
1
ON
234567
BSC BSA FT1 FT2 J1 J2 STP
SW 1 = ON
SW 2 = ON
SW 3 = OFF (Photo Eye FT1)
SW 4 = ON
SW 5 = OFF
SW 6 = OFF
SW 7 = ON
Operator MUST OPEN after initial power up. If operator begins
to close, shut-off power and reverse Red and Black wires.
Supplied Photo Eye should be installed in closing direction
as shown, see page 17 for installation requirements.
Red -
Blue -
Black -
White -
Photo Eye
9
11
12
14
ON DIP
1 2 3 4 5
SW 4 = ON
Only to be used with the X9L – Long Arm
Red
Green
Gray
Blue Blue
Black
White

17
X9 Slide Rev - H
Open INSIDE - Dual Operators Wiring
1 2 5 6 8 9 12 137 10 113414
COM24 COM
+++
24VDCMAG LOCK
MOTOR
2 LIMITS
MOTOR
1 LIMITS
OPEN
EXIT
MOTOR
COM
REVERSE
LOOP
54321 10 119876 141312
1
ON
23456789 10 11 12
1
ON
234567
+-
24V
FT
+-
LAMP.
+-
EL. LOCK
+-
+
-
+
-
+
-
+
-
NO
D
ENCODER
D
M1
M1
POWER
NC C +-
24V
SPIA
24V
SPIA 2
F16A F3A
PRG-LINK
PROG
OC2 RECEIVER
P2 P1
STOP
Reset
TAST3F
P3
US1
P/P
P/P
J
BSCC
SECTR
BSA FT1 J1 J2 PC PA PED STP P/P C
TR1
LD1
FT2
Prel.
Rich
US1
C.Sg
Rall.
C.Ch
2 M.
Fot.R
BSC BSA FT1 FT2 J1 J2 STP
FUSE
FUSE
FUSE
FUSE
+-
24V
ANTENNA
M2
M2
POWER
121110987654321
12 131110987654321
321
54321
54321
OPEN INSIDE - DUAL OPERATORS & PHOTO EYE WIRING
Closed Gates
M1 Power
M1 Limits
M2 Limits
M2 Power
Closing-Direction Photo Eye
Open
INSIDE
M1
Open
INSIDE
M2
Green -
Gray -
Blue -
Red - M1-1
Black - M1-2
MOTOR 1
Inputs
1
2
3
Green -
Gray -
Blue -
MOTOR 2
Inputs
1
5
4
Red - M2-1
Black - M2-2
DIP Switch Settings
1
ON
234567
BSC BSA FT1 FT2 J1 J2 STP
SW 1 = ON
SW 2 = ON
SW 3 = OFF (Photo Eye FT1)
SW 4 = ON
SW 5 = OFF
SW 6 = OFF
SW 7 = ON
1
ON
2345678910 11 12
P/P
J
Prel.
Rich
US1
C.Sg
Rall.
C.Ch
2 M.
Fot.R
SW 1 = OFF
SW 2 = OFF
SW 3 = ON
SW 4 = ON
SW 5 = OFF
SW 6 = ON (automatic closure is active)
SW 7 = OFF
SW 8 = OFF
SW 9 = ON (slow down near endpoints)
SW 10 = OFF
SW 11 = ON (2 motors configuration)
SW 12 = OFF
(motor 1 on J1-J2,
motor 2 on PA-PC)
Supplied Photo Eye should be installed
in closing direction as shown, see page
17 for installation requirements.
Operator MUST OPEN after
initial power up. If operator
begins to close, shut-off
power and reverse Red and
Black wires.
Red -
Blue -
Black -
White -
Photo Eye
9
11
12
14
ON DIP
1 2 3 4 5
SW 4 = ON
Red
Gray
Green
Gray
Blue Blue Blue
Black
White

18X9 Swing Rev - H
Open OUTSIDE - Dual Operators Wiring
Closed Gates
Open
OUTSIDE
M1
Open
OUTSIDE
M2
Opened
Closing-Direction Photo Eye
1
ON
23456789 10 11 12
1
ON
234567
+-
24V
FT
+-
LAMP.
+-
EL. LOCK
+-
+
-
+
-
+
-
+
-
NO
D
ENCODER
D
M1
M1
POWER
NC C +-
24V
SPIA
24V
SPIA 2
F16A F3A
PRG-LINK
PROG
OC2 RECEIVER
P2 P1
STOP
Reset
TAST3F
P3
US1
P/P
P/P
J
BSCC
SECTR
BSA FT1 J1 J2 PC PA PED STP P/P C
TR1
LD1
FT2
Prel.
Rich
US1
C.Sg
Rall.
C.Ch
2 M.
Fot.R
BSC BSA FT1 FT2 J1 J2 STP
FUSE
FUSE
FUSE
FUSE
+-
24V
ANTENNA
M2
M2
POWER
121110987654321
12 131110987654321
321
54321
54321
1 2 5 6 8 9 12 137 10 113414
COM24 COM
+++
24VDCMAG LOCK
MOTOR
2 LIMITS
MOTOR
1 LIMITS
OPEN
EXIT
MOTOR
COM
REVERSE
LOOP
54321 10 119876 141312
M1 Power
M1 Limits
M2 Limits
M2 Power
Red
Gray
Green
Gray
Blue Blue Blue
Black
White
Green -
Gray -
Blue -
Black - M1-1
Red - M1-2
MOTOR 1
Inputs
1
2
3
Green -
Gray -
Blue -
MOTOR 2
Inputs
1
5
4
Black - M2-1
Red - M2-2
OPEN OUTSIDE - DUAL OPERATORS & PHOTO EYE WIRING
1
ON
234567
BSC BSA FT1 FT2 J1 J2 STP
DIP Switch Settings
1
ON
2345678910 11 12
P/P
J
Prel.
Rich
US1
C.Sg
Rall.
C.Ch
2 M.
Fot.R
SW 1 = OFF
SW 2 = OFF
SW 3 = ON
SW 4 = ON
SW 5 = OFF
SW 6 = ON (automatic closure is active)
SW 7 = OFF
SW 8 = OFF
SW 9 = ON (slow down near endpoints)
SW 10 = OFF
SW 11 = ON (2 motors configuration)
SW 12 = OFF
SW 1 = ON
SW 2 = ON
SW 3 = OFF (Photo Eye FT1)
SW 4 = ON
SW 5 = OFF
SW 6 = OFF
SW 7 = ON
(motor 1 on J1-J2,
motor 2 on PA-PC)
Operator MUST OPEN after initial power up. If operator begins
to close, shut-off power and reverse Red and Black wires.
Supplied Photo Eye should be installed
in closing direction as shown, see
page 17 for installation requirements.
Red -
Blue -
Black -
White -
Photo Eye
9
11
12
14
ON DIP
1 2 3 4 5
SW 4 = ON
Only to be used with the X9L – Long Arm
