Eagle Peak HTDH120-BLK User manual

Thank you for choosing Eagle Peak !
EAGLE PEAK 10 FT X 12 FT
Double Roof Hardtop Gazebo
INSTRUCTION MANUAL

LIMITED WARRANTY
Global Shade Corporation offers a limited warranty that this product is free from defects in materials
and workmanship for a period of one (1) year from the original date of purchase. At its discretion, Global
Shade Corporation may provide replacement parts for defective parts to original purchaser after its
own review and examination. Original receipt or proof of purchase as well as proof of defect is required.
Global Shade Corporation will not be responsible for shipping costs incurred outside the continental
USA. Warranty is valid for the original purchaser for 1 year from the date of purchase and is not
transferable. Regular maintenance of wood, aluminum, and steel components is required to assure the
integrity of your product and is a requirement of the warranty. This warranty does not cover any
inspection costs.
This Limited Warranty does not cover:
•Labor for replacement of any defective item(s);
•Incidental or consequential damages;
•Cosmetic defects which do not affect performance or integrity;
•Vandalism; improper use or improper installation; acts of nature, including but not limited to wind,
storms, hail, floods, excessive water exposure;
•Structural or component failure due to snow loading.
•Minor twisting, warping, checking, cracking, or any other natural occurring properties of wood that do
not affect performance or integrity.
Global Shade Corporation’s products have been designed for safety and quality. Any modifications
made to the original product could damage the structural integrity of the product leading to failure and
possible injury. Global Shade Corporation cannot assume any responsibility for modified products.
Furthermore, modification voids any and all warranties.
All replacement products or parts will assume the remaining warranty of the original product. This
warranty gives you specific legal rights. You may also have other rights, which vary from state to state.
This product is warranted for RESIDENTIAL USE ONLY. Global Shade Corporation disclaims all
other representations and warranties of any kind, express or implied.
Global Shade Corporation does not warrant against and under no circumstances shall Global
Shade Corporation be liable or responsible for any personal loss, injury, or direct or indirect
incidental or consequential damages resulting from the use of this product
This Warranty gives you specific legal rights. You may have other rights as well which vary from state to state
or province to province. This warranty excludes all consequential damages, do not allow the limitation or
exclusion of consequential damages, and therefore this limitation may not apply to you, however, some
states/provinces do not allow the limitation or exclusion of consequential damages, and therefore this
limitation may not apply to you.

1
To reduce the risk of serious injury, read the following safety instructions thoroughly
before assembling and using the gazebo.
•Check with your local governing authority/local municipal codes regarding installation and permitting
of such structures before assembly.
•Use of personal protective equipment including gloves, safety glasses, and closed toe footwear is
recommended during assembly.
•Requires two or more people to assemble and install safely and correctly.
•The product is required to be installed on level solid surface and is not intended for unsecured use. The
gazebo is to be anchored to the surface with appropriate bolts or anchors. These anchors need to be
purchased separately for the specific installation surface. Do not assemble the gazebo on soil, earth, or
bare ground.
•Ensure enough clearance around the product. Before assembling the product, find level ground no less
than 6' (1.8 m) away from any structures or obstructions, such as fences, buildings, or overhead
obstacles.
•Do not assemble or install the gazebo underneath electrical lines or above underground utilities.
•Check for underground utilities before digging or driving stakes into the ground.
•This gazebo is not to be regarded as part of a building/house structure.
•All assembly and maintenance of the product must be carried out by adults only.
•Use all power tools and hand tools in accordance with their respective safety manuals.
•Keep children and pets away while setting up the gazebo.
•Do not hang heavy weights from the roof frame.
•Do not climb onto the roof of the gazebo for any reason.
•Check all nuts and bolts monthly to ensure bolts/nuts are tightened.
•Check the metal hardware monthly to ensure there are no exposed sharp edges or rust. Sand sharp
edges or rust with sandpaper and apply touch up paint. Always use lead free paint that conforms to 16
CRF Part 1303.
WARNING:
Needed for assembly: (The following tools are not included)
Pistol Drill Tape Measure Hammer Screwdriver Ladder
Level Framing Square
Two or more people

Part List
2
Post
A 4
Base Cover
B 4
Base
C4
Top Roof Fastening
Piece
D 1
Long Top Tube of Big
Roof
E8 2
Short Top Tube of Big
Roof
E9 2
Left Bevel Beam of
Top Roof
F1 2
Right Bevel Beam of
Top Roof
F2 2
Bevel Beam of Big
Roof
G1 4
4
Middle Beam of Big
Roof
H1
4
Connector for Bevel
Beam
I
4
Connector for Middle
Beam
J
4
Connector for Beam
J1
4
Left Beam of Long Side
K1 2
Description SketchLabel QTY
Connector for Beam
J2

Right Beam of Long
Side
K2 2
Left Beam of Short
Side
K3 2
Right Beam of Short
Side
K4 2
Short Beam of Top
Roof
L11 2
Upper Short Beam of
Big Roof Long Side
L12 4
Middle Short Beam of
Big Roof Long Side
L13 4
Upper Short Beam of
Big Roof Short Side
L14 4
Middle Short Beam of
Big Roof Short Side
L15 4
Lower Short Beam
of Big Roof Long Side
L23 4
Lower Short Beam of
Big Roof Short Side
L25 4
4
4
Hook
P 1
Metal Panel of Top
Roof Short Side
P7 2
Metal Panel of Top
Roof Long Side
P8 2
Description SketchLabel QTY
Part List
3
Long Tube for
Mosquito Netting
M6
Short Tube for
Mosquito Netting
M7

Part List
4
Upper Metal Panel of
Big Roof Short Side
Q1 2
Left Middle Metal Panel
of Big Roof Short Side
Q2 2
Middle Right Metal Panel
of Big Roof Short Side
Q3 2
Lower Left Metal Panel
of Big Roof Short Side
Q4 2
Lower Right Metal Panel
of Big Roof Short Side
Q5 2
Upper Left Metal Panel
of Big Roof Long Side
Q6 2
Upper Right Metal Panel
of Big Roof Long Side
Q7 2
Middle Left Metal Panel
of Big Roof Long Side
Q8 2
Middle Right Metal Panel
of Big Roof Long Side
Q9 2
Lower Left Metal Panel
of Big Roof Long Side
Q10 2
Lower Right Metal Panel
of Big Roof Long Side
Q11 2
Bevel Beam Cover
Plate of Top Roof
R8 4
Middle Cover Plate
of Top Roof
R7 1
Middle Beam of
Big Roof
R2 4
Bevel Beam Cover
Plate of Big Roof
R1 4
Description SketchLabel QTY

Part List
5
Curved Supporting
Tube
T 8
Mosquito Netting
U 1
Sidewall
V 1
Description SketchLabel QTY

Hardware List
BB
DD
PP
QQ
Z1
LL
FF
HH
KK
GG
36
36
8
56
2
2
180
104
16
12
Washer
M6
Hex Nut
M6
Stake
Ø8 x 180
Cross Outer Hexagon
Bolt
M6 x 40
Wrench
M6
Cross Outer Hexagon
Bolt
M6 x 60
Cross Outer Hexagon
Bolt
M6 x 20
Q Ring
Cross Outer Hexagon
Bolt
M6 x 90
JJ 20
Cross Outer Hexagon
Bolt
M6 x 55
Cross Outer Hexagon
Bolt
M6 x 15
6
0 1 2 3 4 5 6 7 8

STEP1
STEP2 STE P3
Step 1
7
28X
M6x20
4X
A
4X
B
FF
4X
C
4X
I

2X
K1
2X
K2
2X
K3
2X
K4
Step 2
8
8X
M6x90
KK
8X
M6
BB
8X
M6
DD
4X
J
4X
J1
4X
J2
STEP1 STEP2

4X
M6
4X
M7
Step 3
9
8X
M6x90
KK
8X
M6
BB
8X
M6
DD 8X
M6x20
FF
STEP1 STEP2

K3 K4
A
2X
4X
4X
T
Step 4
10
16X
M6x40
QQ
12X
M6x20
FF
STEP2
STEP1
Rt=90º
Use the framing square to ensure each Post
remains at a 90 degree angle to the Short Beam
and Long Beam. Secure each Arch Support to the
Posts using 4pcs Screw (QQ) at each location.

2X
Step 5
11
12X
M6x20
FF
K2
K1
Attention: This step requires at least 5 people.

4X
T
Step 6
12
16X
M6x40
QQ
124.8 in
100.4 in
160.2 in
160.2 in
Site Dimensions
Use the framing square to ensure each Post
remains at a 90 degree angle to the Short Beam
and Long Beam. Secure each Arch Support to the
Posts using 4pcs Screw (QQ) at each location.
Rt=90º

2X
2X
Step 7
13
8X
M6x15
GG
E
E8
STEP1
STEP2

4X
G1
Step 8
14
8X
M6
BB
8X
M6
DD 8X
M6x20
FF 8X
M6x55
JJ
STEP1
STEP2

4X
H1
Step 9
15
8X
M6
BB
8X
M6
DD 8X
M6x20
FF 8X
M6x55
JJ
STEP1
STEP2

4X
M6x15
GG
1X
D
2X
F1
2X
F2
Step 10
16
4X
M6
BB
4X
M6
DD 4X
M6x55
JJ
STEP1
STEP2

2X
L11
Step 11
17
4X
M6x20
FF

2X
P7
2X
P8
Step 12
18
8X
M6x20
FF
Attention :
Please don’t collide the panels to avoid damage.
