Earlex SPRAY STATION 2900 Instruction Manual

OPERATING INSTRUCTION
MANUAL
MODE D’EMPLOI
MANUAL DE INSTRUCCIONES
MANUALE DI ISTRUZIONI
OPERATIVE
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUÇÕES DE
UTILIZAÇÃO
INSTRUKCJA OBSŁUGI
EARLEX SPRAY STATION 2900/3900
RU
PL
UA
GR
DK
NL
TR
SE
НСТРУКЦ Я ПО
ЭКСПЛУАТАЦ
ІНСТРУКЦІЇ З ЕКСПЛУАТАЦІЇ
ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ
ΛΕΙΤΟΥΡΓΙΑΣ
BETJENINGSVEJLEDNING
GEBRUIKSHANDLEIDING
KULLANIM TALİMATI
KILAVUZU
BRUKSANVISNING
hv2900 06-09 A4:Layout 1 18/8/09 14:23 Page 1

Thank you for purchasing the Earlex Spray Station.
BEFORE USE – PLEASE READ THE MANUAL AND SAFETY INSTRUCTIONS.
Please retain for future reference.
Merci d’avoir acheté cette station de peinture EARLEX.
AVANT UTILISATION MERCI DE BIEN LIRE CE MANUEL AINSI QUE LES CONSIGNES DE SECURITE.
Merci de concerver ce manuel pour toute consultation future.
Gracias por adquirir la Earlex Spray Station,el sistema innovador de pulverización HVLP.
ANTES DE SU USO – LEA ESTE MANUALY LAS INSTRUCCIONES DE SEGURIDAD.
Guárdelo para futuras consultas.
Obrigado por ter adquirido uma Estação de Pulverização Earlex.
ANTES DE UTILIZAR – POR FAVOR LEIA ESTE MANUAL E AS INSTRUÇÕES DE SEGURANÇA.
Guarde estas instruções para futuras consultas.
Grazie di avere comprato questa stazione di vernice Earlex.
PRIMA DELL’UTILIZZO GRAZIE DI BENE LEGGERE QUESTO MANUELE E LE CONSEGNE DI SICUREZZA.
Garzie di conservare questo manuale per ogni consultazione futura.
Herzlichen Dank für den Erwerb einer Earlex Spray Station.
BITTE LESEN SIEVOR INBETRIEBNAHME DES GERÄTES DIE BEDIENUNGSANLEITUNG SORFÄLTIG
DURCH UND BEFOLGEN SIE DIE SICHERHEITSHINWEISE.
Bewahren Sie die Bedienungsanleitung für späteres Nachlesen und evtl.Rückfragen gut auf.
Б агодарим вас за приобретение системы разбрызгивания Earlex.
ПРОЧИТАЙТЕ ДАННОЕ РУКОВОДСТВО И ПРАВИЛА ТЕХНИКИ БЕЗОПАСНОСТИ
ДО НАЧАЛА ЭКСПЛУАТАЦИИ СИСТЕМЫ.
Сохраните этот документ д я да ьнейших справок.
Dziękujemy za zakup aparatu natryskowego Earlex.
PRZED UŻYCIEM APARATU PROSIMY O PRZECZYTANIE TEJ INSTRUKCJI ORAZ
ZASAD BEZPIECZEŃSTWA.
Instrukcję należy zachować do wykorzystania w przyszłości.
Дякуємо за придбання системи розприскування Earlex. ПЕРЕД
ВИКОРИСТАННЯМ ОЗНАЙОМТЕСЬ ІЗ ПОСІБНИКОМ ТА ІНСТРУКЦІЯМИ
З ТЕХНІКИ БЕЗПЕКИ. Збережіть їх д я пода ьшого використання.
Σας ευχαριστούμε που αγοράσατε το σύστημα Spray Station της Earlex.
ΠΡΙΝ ΑΠΟ ΤΗ ΧΡΗΣΗ – ΔΙΑΒΑΣΤΕ ΤΟ ΕΓΧΕΙΡΙΔΙΟ ΚΑΙ ΤΙΣ ΟΔΗΓΙΕΣ ΑΣΦΑΛΕΙΑΣ.
Κρατήστε το για μελλοντική αναφορά.
Tillykke med din nye Earlex Spraystation.
FØR BRUG BØR DU LÆSE BETJENINGS- OG SIKKERHEDSVEJLEDNINGERNE IGENNEM.
Gem vejledningerne til senere brug.
Wij danken u voor de aankoop van het Earlex Spray Station. VOOR HET GEBRUIK
DIENT U DE HANDLEIDING EN DE VEILIGHEIDSINSTRUCTIES TE LEZEN!
Bewaar deze handleiding goed, zodat u deze later nog kunt raadplegen.
Earlex Sprey Paketini satın aldığınız için teşekkür ederiz.
KULLANMADAN ÖNCE – LÜTFEN KILAVUZU VE GÜVENLİK TALİMATLARINI OKUYUN
Lütfen referans için tutunuz
Tack för att ni köpt en Earlex sprutstation.
Innan ni börjar användning – var god läs bruksanvisning och
säkerhetsinstruktionerna. Spara denna bruksanvisning för framtida användnin
RU
PL
UA
GR
DK
NL
TR
SE
2
hv2900 06-09 A4:Layout 1 18/8/09 14:23 Page 2

EXPLODED PARTS VIEW
DIAGRAMS
HORIZONTAL VERTICALROUND
Fig.2
Fig.3
Expert Control Technology
Fig.4
Fig.5 Fig.6
3
14
13
12
11
10
9
8
7
6
5
4
3
2
1
AB
Fig.1
hv2900 06-09 A4:Layout 1 18/8/09 14:23 Page 3

SAFETY OPERATING INSTRUCTIONS
PLEASE READ BEFORE USE
PARTS LIST
No.Description Part Code
1. Needle and Fluid Tip Tool V0018
2. Air Cap Ring V0001
3. Air Cap V0002
4. Spray Direction Plate V0003
5. Fluid Tip 2.0mm V0004
6. Fluid Tip O-Ring V0005
7. Fluid Needle 2.0mm V0006
No.Description Part Code
8. Lip Seal - Fluid Needle V0007
9. Paint Flow Adjuster V0011
10. Paint Container Seal L0682
11. Pick-up Tube V0012
12. Paint Container V0014
13. Hose L0896
14. Filter L0290
Fig.1
• Never under any circumstances aim the Spray un at another person or animal. In the event of injury occurring seek expert medical advice
immediately.
• The Spray un must only be used with paints and solvents that have a flash point suitable for spraying. If in doubt, consult the paint or solvent
manufacturer’s data.
• Always ensure there is adequate ventilation when spraying.
• NEVER spray near a naked flame, including appliance pilot light.
• NEVER smoke whilst spraying.
• NEVER allow children to operate or play with the Spray un.
• Always read the solvent manufacturer’s instructions before use.
• Always disconnect unit from mains supply when filling the paint container.
• Always wear a suitable protective mask when spraying. We would also recommend the use of gloves, goggles and overalls.
• After each use, thoroughly clean the Spray un.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Use only genuine manufacturer replacement parts.
• Always disconnect the Spray Station from the mains supply before cleaning the appliance.
•Warning: The use of any accessory or attachment, other than those recommended in this instruction manual, may present a risk of personal
injury.
• Use the Spray un for the job it was designed for only. Mis-use of the Spray un will invalidate the guarantee.
• Wear ear protection.
WARNING: The substances used with this Spray Gun (paints, solvents, etc.) may contain dangerous, harmful, explosive or corrosive
materials. ALWAYS C MPLY WITH THE SAFETY INSTRUCTI NS ISSUED WITH THIS PR DUCT AND THE MATERIAL BEING USED.
INTRODUCTION
The concept
A motor feeds out a high volume of air (HV) and enables products to be sprayed at a low pressure (LP). The Hose feeds the air produced by the
motor to the Spray un. The solution is released from the Fluid Tip of the Spray un at a very low pressure (0.14 bar) and is enclosed in a high
volume of air.
The powerful motor can spray a wide range of solutions with or without dilution. However, there will always be some which will not be suitable for
the Spray un. ood quality paint contains a high percentage of solids which make the dilution easier. The users must keep in mind that low
temperatures make the paint thicker, that’s why we recommend spraying with the Spray un at a 15°C minimum temperature.
4
TECHNICAL SPECIFICATI N: HV2900 HV3900
Wattage: 500 Watts 550 Watts
Container capacity: 1litre 1litre
Voltage: 230 V230 V
Air hose length: 4m 4m
Dynamic air pressure: 0,14 bar 0,14 bar
Sound pressure level: 85 dB (A) 85 dB (A)
Maximum viscosity: 160DIN/s 180DIN/s
hv2900 06-09 A4:Layout 1 18/8/09 14:23 Page 4

PREPARATION
• Carefully cover areas which are not to be painted with a plastic cover and protective tape.
• Wear a suitable mask when spraying products (and make sure there is adequate ventilation in the room when working indoors).
• Clean the surface you are going to paint. As well as being clean, it must also be dry and smooth.
• Practice first on some old wooden planks to make sure you are holding the Spray un correctly.
• We recommend you wear protective clothing.
• Stir the paint well using a mixer where possible.
• Make sure there are no solid particles in the paint.
• Many products can be sprayed without being thinned. However, if the application is not good, thin the product progressively in stages of 5%.
• Most paints can be sprayed by being thinned just a little, e.g. by 5% or 10%.
• Some thick paints such as outer wall paints and certain undercoats will need to be thinned by 20% or 25%.
• Use water to thin a water-based product.
• Use appropriate thinner to thin solvent-based products.
• Certain manufacturers will indicate on the can whether a specific thinner is to be used.
• Certain paint manufacturers have specific paints available for HVLP application.
Your Spray Station, is a powerful and versatile solution, and comes with two sizes of Needle and Fluid Tip:
• The smaller Needle and Fluid Tip is the most commonly used size for decorative paints.
• The larger Needle and Fluid Tip, which can be easily assembled to the Spray un (with the Needle and Fluid Tip Tool (1)), is for thick paints such
as undercoats and smooth masonry paints.
There are other optional Needle and Fluid Tip sizes available to purchase for more specific applications.
SET UP
• Fill the Paint Container (12) with the product to be sprayed. Stir well (as mentioned previously) and strain to remove any bits which will interfere
with a smooth consistent spray.
• Make sure the Paint Container Seal (10) and Pick-up Tube (11) are firmly fitted into the base of the Spray un.
• Screw the Paint Container (12) to the base of the Spray un and tighten accordingly.
• Start with the Paint Flow Adjuster (9) at its minimum setting so the Trigger can not be pulled. Do not forget that the Paint Flow Adjuster controls the
quantity of paint sprayed (Fig.4).
• Uncoil the air Hose and attach it to the back of the Spray un and the other end to the Spray Station.
• Uncoil the power cable and attach the plug to the mains supply.
• Switch the Spray Station on. This will immediately cause some air to be produced, which is quite NORMAL. However, none of the product will be
sprayed until the Spray un Trigger is pulled.
•Very important: when spraying for the first time, we recommend that you always leave the motor unit to run for 1 to 2 minutes before applying the
product. Do not forget that the Paint Flow Adjuster controls the quantity of paint sprayed (Fig.4).
ALWAYS MAKE SURE THAT THE M T R UNIT IS N A RIGID SURFACE AND FREE FR M DUST.
3 spray patterns
Horizontal and Vertical Spray with varying widths Round Spray
Vertical and Horizontal for normal sized jobs Round for small and precise jobs
The most commonly used technique for painting a large surface is the ‘crisscross’ technique, i.e. you apply the product in a horizontal strips and
then cross over these strips by applying the product in a vertical strips (Fig. 3).
1) To achieve a horizontal strip adjust the Spray Direction Plate to the vertical position then pull the Trigger and move your arm across
to the right.
2) When you get to the end of the line, release the Trigger for a moment and then apply the product in the opposite direction
just beneath the line you have sprayed.
3) Next, to achieve a vertical strip adjust the Spray Direction Plate to the horizontal position then pull the Trigger and move your arm
up and down over the horizontal strips you just have sprayed.
Through gradual movement of the Spray Direction Plate (4) between Horizontal, Vertical and Round spray pattern you can vary the width of the
pattern (Fig.3)
HINT: To obtain the best results always keep your Spray un level and at an equal distance from the object you are spraying, ideally 25-30cm
(10“-12”) (Fig.5/6). Let your arm control the movement rather than your wrist (Fig.5/6). This will help give you an even paint distribution.
HINT: HVLP technology produces warm air through the Air Cap allowing the paint to dry quicker which can enhance the final effect.
HINT: For ceilings and floors make sure the Pick-up Tube is properly oriented towards the handle of the Spray un.
(Fig.2)
(Fig.2)
5
hv2900 06-09 A4:Layout 1 18/8/09 14:23 Page 5

Type of paint Cleaning
Water based paint Clean with water
Oiled based paint Clean with appropriate thinner e.g. White Spirit
CLEANING INSTRUCTIONS
SPRAY GUN
HINT: Before removing or re-inserting the Needle and Fluid Tip ensure the Spray un has been flushed through with water or the appropriate
thinner so the inner tube is clean.
HINT: When done immediately the cleaning operation can take you less than 5 minutes. If taking a break, leave the Spray un in a plastic bag to
prevent the paint from drying.
• Remove the Paint Container (12).
• Pour any leftover paint into its container so that it can be used for the future. Pull the Trigger to allow paint to run out of the Pick-up Tube (11).
• Pour a quantity of the respective thinner into container, shake the Spray un lightly, reassemble the Spray un, then spray this liquid though the
Spray un. Repeat this until the thinner being sprayed is coming through with no traces of paint.
• Clean any traces of paint off the outside of the Spray un.
• Clean the Paint Container Seal (10).
FLUID TIP AND NEEDLE
• Unscrew Air Cap Ring (2).
• Remove the Air Cap (3).
• Remove the Spray Direction Plate (4).
• It is recommended that you push the Trigger forward to help release the Fluid Tip (5).
• Using the Needle and Fluid Tip Tool - pincer end A (1) remove the Fluid Tip (5).
• Insert the Needle and Fluid Tip end B (1) into the inner tube and unscrew the Needle anticlockwise, then pull to release the Needle.
• Place all of these items into a container and clean, then using a brush and the respective thinners.
• Clean the inside of the body of the Spray un.
• Thoroughly dry all parts before reassembling.
• Reassemble parts in reverse order.
• Ensure the Air Cap Ring (2) is fully tightened and the Fluid Tip is pushed into place so that the Spray un Needle will shut off. NB: Ensure the
Spray Direction Plate is free to move. If necessary loosen the Air Cap Ring (2) slightly.
• NEVER DISPOSE OF PAINTS OR SOLVENTS DOWN THE DRAIN. ALWAYS USE YOUR LOCAL WASTE COLLECTION SITE.
• The motor unit itself does not require any specific maintenance apart from checking that the filter is not clogged up (the filter can be removed and
washed). The filter can be found in the base of the motor unit.
Important: Each Fluid Needle is manufactured to fit the size of the corresponding Fluid Tip. Do not try to fit a 2.0 mm Fluid Needle to a 3.0 mm
Fluid Tip.
CAUSE ACTI N REQUIRED
Paint too diluted Add undiluted paint
Paint output too high Reduce the paint output by adjusting the Paint Flow Adjuster (9)
Moving too slowly Increase speed of application
Spray Trigger held for too long Release Trigger sooner
Spray un too close Increase the distance between the Spray un and the work
surface
Paint too diluted Add undiluted paint
Paint output too low Increase the paint output by adjusting the Paint Flow Adjuster (9)
Moving too fast Reduce speed of application
Spray un clogged Clean the Spray un
Spray un too far away Move the Spray un closer to the work surface
Paint too thick Add thinner
Fluid Tip clogged Clean the Fluid Tip (5)
Pick-up Tube clogged Clean Pick-up Tube (11)
Air Hose split Replace air Hose (13)
rainy paint Filter the paint
Paint Container almost empty Refill Paint Container (12)
Spray un at an angle Check that the Pick-up Tube (11) is pointing towards the paint
Air inlet blocked Check the condition of the Filter (14) and clean if necessary
You move your wrist Move your fore arm instead
Either too much or not enough paint Use the Paint Flow Adjuster (9) to control the flow
PR BLEM
The paint drips onto item being
painted
Paint is too thin or irregular
No paint being released
Too much paint in an area
Application
TROUBLESHOOTING
SPRAY GUN
6
hv2900 06-09 A4:Layout 1 18/8/09 14:23 Page 6

PLEASE NOTE: We have done all we can to ensure that when used correctly and in accordance with these instructions the spray gun has a long
and fault-free life. We accept no responsibility for damage caused by the use of incorrect or unsuitable substances, paints or liquids which have
not been thinned correctly or which are not suitable for the surfaces to which they are applied, health hazards arising from a lack of ventilation
when working in confined spaces or equipment which is faulty due to inadequate cleaning of the components after use. If in doubt, test a small
inconspicuous area first. Always read the manufacturer’s instructions before use. Neither our guarantee nor the above statement affects your
statutory rights.
GUARANTEE and HELPLINE
This product is guaranteed for a period of 24 months against faulty manufacture or materials. It is not guaranteed for industrial or hire purposes.
This guarantee does not affect your statutory rights. For further information or any user advice, please phone our helpline between 9am to 12am
and 2pm to 5pm Mondays to Fridays (excluding Bank Holidays), or visit our website www.earlex.fr.
EARLEX LTD. WILL ACCEPT NO RESPONSIBILITY FOR THE USE OF THIS PRODUCT IF USED FOR ANY OTHER PURPOSES THAN THOSE
DETAILED HEREIN.
All rights reserved © 2009
Information on the disposal of waster electrical equipment know as Weee.
Please don not dispose of tools with your household waste collected by the council. It is your responsibility
to dispose of this type of waste by handing it over to a special designated collection point for recovery and
recycling.
This unit is a Class II appliance which means it is double insulated for your protection, no earthing wire is necessary. If the supply cord is
damaged, it must be replaced by Earlex Ltd or our appointed agents.
If you are using an extension lead it must be rated at a minimum of 6 amps and fully unwound. Do not operate with a lead rated at less
the 6 amps as this will cause premature failure of the motor which is not covered by the guarantee.
If the plug is cut off from the mains lead, it must be disposed of safely. NEVER under any circumstances insert a plug which is cut off
from the mains lead into socket.
MAINS CONNECTION
Design Registrations and Patents:
Spray Gun Design Registration
ECD 001096218-0001
CN 200930004457.X
Spray Gun Patent
B 0903275.6
HVLP Turbine Design Registration
B 3022947
FR 06/5463
EU 000608856
US D563,503
Earlex Sarl.
Earlex Sarl,Tel: [phone]
Email: [email protected] Website: www.earlex.fr
Earlex Ltd.
Earlex Ltd,Tel: [phone]
Email: [email protected] Website: www.earlex.co.uk
EC Declaration of Conformity
We declare that the unit: HV2900/3900 Conforms to LVD 2006/95/EC, EN60335-1, EMC 2004/108/EC, EN55014-1, EN55014-2, EN61000-3-2,
EN61000-3-3, EMF EN50366.
Tim Hopper Technical Director
7
hv2900 06-09 A4:Layout 1 18/8/09 14:23 Page 7

61
Notes
hv2900 06-09 A4:Layout 1 18/8/09 14:25 Page 61

V0039 08/09
www.earlex.fr
hv2900 06-09 A4:Layout 1 18/8/09 14:25 Page 62
