Early Childhood Resources ELR-0627 User manual

Large Hex Screw(26)
TIP！
DO NOT FULLY
TIGHTEN SCREWS
UNTIL ALL SCREWS
HAVE BEEN LOOSELY
POSITIONED。
!
WARNING:
Adult Assembly Required. Two
adults recommended.
- Contains small parts, sharp points
and edges.
- Do not stand, sit, kneel, climb, lean
or pull on unit for support.
- Never leave children unattended.
- Do not place unit near high heat or
moisture.
-Adult Supervision Recommended.
BEFORE ASSEMBLING,
MAKE SURE THERE
ARE NO
MISSING PARTS.
1
Attach the Dividers to the
Bottom and Center Shelves
Caster Screw(16)
2
Attach the Center Bottom Shelf
3
Assemble the Top Section
4
Attach the Top and Bottom Sections
Model#: ELR-0627
High Storage Cabinet
(8-Compartment)
Mount Laurel,NJ 08054 USA
www.ecr4kids.com
1A.Insert4Cams(M)intolargeholeson
theinsideofa2Dividers(G).Makesure
arrowsonCams(M)pointtowardholesin
theclosestedge.
1B.Attachthe2Dividers(G)totheBottom
Shelf(E)using4LargeHexScrews(I).
TightenwiththeAllen Wrench(J) .
1C. Insert 4 Metal Dowels(H) into the
plastic plugs located underneath the
Center Bottom Shelf(D). Tighten with
a Phillips Screwdriver. Attach the
Divider(G) to the Center Bottom
Shelf(D) using 2 Large Hex Screws(I).
Tighten with theAllen Wrench(J) .
2B. Position Center Bottom Shelf(D) so the attached Metal Dowels(H)
enter the holes in the top edges of the 2 lower Dividers(G) as shown.
Turn Cams(M) with a Phillips Head Screwdriver until locked onto the
Metal Dowels(H).
4A. Two Adults Suggested: On a cartpet or protected surface, carefully
lay the assembled components on their backs, facing upward.
4B. Insert 2 Metal Dowels(H) into the plastic plugs located under the
Center Top Shelf(C). Tighten with the Phillips Head Screwdriver.
4C. Insert 2 Cams(M) into
the last Divider(G). Make
sure arrows on Cams(M)
point toward the holes in
the closest edge.
4D. Position the Top
Divider Section(B,G,C)
so the attached Metal
Dowels(H) enter holes
in the top edge of the
Divider(G) that is
attached to the Bottom
Divider Section(G,D,E)
as shown.
I
X4
M
X4
I
X2 X4
H
I
X2 X4
H
M
X2
2A. Insert 2 Cams (M) into the Divider(G). Make sure arrows on
Cams (M) point toward holes in the closest edge.
I
X4X4
M
X4
Version: ELR-0627.D.2010.01.03
NOTE:
A Phillips Head Screwdriver
will be needed for
assembly (not included)
3A.Attach the 2 Dividers(G) to
the Center Top Shelf(C) using
4 Large Hex Screws(I). Tighten
with theAllen Wrench(J).
3B. Insert 4 Metal Dowels(H) into
the plastic plugs located under
Top Shelf(B). Tighten with the
Phillips Head Screwdriver.
3C. Insert 4 Cams(M)
into the 2 Dividers(G).
Make sure the arrows
on Cams(M) point
toward the holes in
the closest edge.
3D. Position Top
Shelf(B) so the
attached Metal
Dowels(H) enter
the holes in the top
edge of the Dividers(G) as shown. Turn the Cams(M) with a Phillips Head
Screwdriver until locked onto the Metal Dowels(H).
3A
X2
H
X2
3B
3C,3D
M
GG

6
Attach the Wheel Casters*
*Optional
5
Attach the Left Side and Backs
underneath Bottom Shelf(E) with 16 Caster Screws(L),
4 in each. Tighten using a Phillips Head Screwdriver.
Tighten all Screws - You’re done!
8
!
CAUTION:
- Do not allow children to climb on shelves.
- Do not use as a ladder, seat or cart.
7
Attach the Right Side
“Early Childhood Resources® guarantees the quality
of all of our products. You can trust the quality and
safety of our furniture and materials, along with the
peace of mind that our products are made to last. If
for any reason, you are not satisfied with the quality
and workmanship of our products, we will replace the
item or refund the sale.”
We appreciate your purchase of the 8-Compartment
Storage Cabinet. Early Childhood Resources® has made
every effort to supply a quality product, that with proper use
and care, will bring you many years of trouble free use!
Clean wood with a damp cloth or sponge using warm water
and mild soap. Wipe dry.
Do not place near heat, moisture or vaporizer which may
cause wood to warp and peel.
Check for loose or worn parts periodically and tighten or
replace as necessary.
Care and Cleaning
I
X8
L
Ｘ１６ K
Ｘ４
Purchase Order Number:
Record the Purchase Order Number here. Information is
located on a label enclosed, and on the shipping carton.
Place label and this sheet in an accessible place.
Model Number: ELR-0627
Version: ELR-0627.D.2010.01.03
I
X8
