Easy@Home VC9389 User manual

User Manual
CARPET CLEANER
ID: #05007
m
y
h
a
n
s
e
c
o
n
t
r
o
l
.
c
o
m
M
A
N
U
A
L
D
E
V
E
L
O
P
E
D
I
N
G
E
R
M
A
N
Y
User-friendly
Manual

Dok./Rev.-Nr. 196834_20180921
Overview ............................................................................. 3
Use........................................................................................4
Package contents/device parts..........................................5
General information............................................................6
Reading and storing the user manual ................................. 6
Explanation of symbols .......................................................... 6
Safety ................................................................................... 7
Proper use..................................................................................7
Safety instructions....................................................................7
First use.............................................................................. 10
Checking the carpet cleaner and package contents........10
Carpet cleaner assembly .......................................................10
Carpet preparation ............................................................11
Using the carpet cleaner....................................................11
Filling the water solution tank...............................................11
Cleaning a carpet.................................................................... 13
Tips for carpet cleaning ......................................................... 13
Emptying the dirty water tank ............................................. 14
Cleaning............................................................................. 15
Cleaning the filters ................................................................. 15
Cleaning the carpet cleaner..................................................16
Storage .............................................................................. 16
Troubleshooting.................................................................17
Technical data ....................................................................17
Declaration of conformity..................................................17
Disposal.............................................................................. 18
Disposing of the packaging ..................................................18
Disposing of the carpet cleaner............................................18
Contents

3
A
1
2
3
5
6
7
8
10
9
4

4
B
11
12
13
16
17
14
15

Package contents/device parts
5
Package contents/device parts
1Handle
2On/off switch
3Water solution tank cap
4Water solution tank
5Dirty water tank handle
6Exhaust filter housing
7Dirty water tank
8Dirty water tank locking latch
9Water solution tank handle
10 Carrying handle
11 Solution release trigger
12 Mains cord hook, 2×
13 Handle release pedal
14 Crosshead screw, 2×
15 Cleaning solution
16 Mains cord
17 Mains cord clip

General information
6
General information
Reading and storing the user manual
This user manual accompanies this carpet cleaner and contains
important information on setup and use.
Before using the carpet cleaner, read the user manual carefully. This
particularly applies to the safety instructions. Failure to do so may result
in personal injury or damage to the carpet cleaner.
The user manual is based on the standards and rules in force in the European Union.
When abroad, you must also observe country-specific guidelines and laws.
Store the user manual for further use. Make sure to include this user manual when
passing the carpet cleaner on to third parties.
Explanation of symbols
The following symbols and signal words are used in this user manual, on the carpet
cleaner or on the packaging.
WARNING!
This signal symbol/word designates a hazard
with moderate risk, which may result in death or
severe injury if not avoided.
CAUTION!
This signal symbol/word designates a hazard
with low risk, which may result in minor or
moderate injury if not avoided.
NOTICE! This signal word warns of possible damage to
property.
This symbol provides you with useful additional information on
handling and use.
Declaration of Conformity (see chapter “Declaration of Conformity”):
Products labelled with this symbol meet all applicable provisions of
the European Economic Area.
This carpet cleaner is double insulated: protection class II.

Safety
7
Safety
Proper use
The carpet cleaner is exclusively designed for cleaning carpets. It is only intended for
private use and not suitable for commercial purposes.
Only use the carpet cleaner as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury incurred
through improper or incorrect use.
Safety instructions
WARNING!
Risk of electric shock!
A faulty electrical installation, excessive line voltage, or incorrect
operation may result in an electric shock.
− Only connect the carpet cleaner if the line voltage of the socket
corresponds to the data on the rating plate.
− Only connect the carpet cleaner to an easily accessible socket
so that you can quickly disconnect it from the power supply in
the event of a problem.
− Do not use the carpet cleaner if it is damaged or if the mains
cord or plug is defective.
− If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarly qualified persons
in order to avoid a hazard.
− Do not open the housing; instead, have a qualified
professional perform repairs. Contact a qualified workshop
for this. Liability and warranty claims are waived in the event
of repairs performed by the user, improper connection, or
incorrect operation.
− Only parts that comply with the original device data may be
used for repairs. This device contains electrical and mechanical
parts which are essential for providing protection against
sources of danger.

Safety
8
− Do not use the carpet cleaner with an external timer or
separate remote control system.
− Do not immerse the carpet cleaner or mains cord in water or
other liquids.
− Never touch the mains plug with wet or damp hands.
− Do not pull the mains plug out of the socket by the cord;
instead, always pull it out by the plug itself.
− Never move, pull, or carry the carpet cleaner by its mains cord.
− Keep the carpet cleaner and mains cord away from open
flames and hot surfaces.
− Lay the mains cord so that it does not pose a tripping hazard.
− Do not kink the mains cord and do not lay it over sharp edges.
− Only use the carpet cleaner indoors. Do not use the carpet
cleaner in the rain.
− Never reach to retrieve an electrical device if it has fallen into
water. In such a case, immediately disconnect the mains plug.
− Never insert any objects into the housing.
− WARNING: the plug must be removed from the socket-outlet
before cleaning or maintaining the carpet cleaner.
WARNING!
Danger for children and persons with impaired physical, sen-
sory or mental capacities (e.g. partially disabled persons, older
persons with reduced physical and mental capacities), or lack
of experience and knowledge (e.g. older children).
− If they are supervised or have been instructed on how to
safely use the carpet cleaner and have understood the risks
associated with operating it, this carpet cleaner may be
used by persons with impaired physical, sensory or mental
capacities, or those lacking experience and knowledge.
Children may not play with the carpet cleaner. Cleaning and
user maintenance must not be performed by children.

Safety
9
− Keep children away from the carpet cleaner and mains cord.
− Do not leave the carpet cleaner unattended while in use.
− Make sure that children do not play with the plastic wrapping.
They may get caught in it when playing and suffocate.
NOTICE!
Risk of damage!
Improper handling of the carpet cleaner may damage it.
− Never expose the carpet cleaner to high temperatures
(heaters etc.) or to the effects of the weather (rain etc.).
− Stop using the carpet cleaner if any of the parts are cracked,
broken, or deformed. Only replace damaged parts with
corresponding original spare parts.
− Do not use the carpet cleaner to suck up any liquid other than
the cleaning solution dispensed from it.
− Do not use the carpet cleaner to suck up such wet or damp
materials as mud, tile grout, plaster filler, or caulking.
− Do not use the carpet cleaner without the tanks in place.
− Make sure all openings and outlets are free and clear of any
blockage that may reduce airflow.
− Keep hair, loose clothing, fingers and other body parts away
from the openings and moving parts.
− Do not use the carpet cleaner to suck up flammable or toxic
liquids such as gasoline, chlorine bleach or drain cleaner, or
use it in areas where they may be present.
− Do not suck up anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.

First use
10
First use
Checking the carpet cleaner and package contents
NOTICE!
Risk of damage!
If you are not cautious when opening the packaging with a sharp
knife or other pointed object, you may quickly damage the carpet
cleaner.
− For this reason, be very careful when opening it.
1. Take the carpet cleaner out of the packaging.
2. Check to make sure that all parts are included (see Fig. A and B).
3. Check whether the carpet cleaner or individual parts are damaged. If this is the
case, do not use the carpet cleaner. Contact the manufacturer via the service
address indicated on the warranty card.
Carpet cleaner assembly
CAUTION!
Risk of injury!
Improper handling of the carpet cleaner may cause injury.
− Do not plug the carpet cleaner in until it is fully assembled.
− Do not operate the carpet cleaner without the handle being
firmly screwed into place.
1. Set the carpet cleaner in an upright position.
2. Place the handle 1firmly onto the main body of the carpet cleaner.
3. Make sure that the mains cord clip 17 is on the same side as the mains cord
hooks 12 .
4. Drive one crosshead screw 14 into each side of the handle and fasten them
snugly.
Do not overtighten the screws, as this could strip the screw holes.

Carpet preparation
11
Carpet preparation
NOTICE!
Risk of damage!
Using the carpet cleaner as a dry vacuum will damage it.
− Only use the carpet cleaner with an appropriate carpet
cleaning solution.
1. Remove as much furniture from the room as possible.
2. Thoroughly vacuum the carpet to be cleaned.
3. Place a plastic or other protective covering under and around any furniture left in
the room.
− In a small area (corner or closet), test the carpet for colour fastness.
4. Dampen a white cloth with the included carpet cleaning solution 15 .
5. Rub the cloth gently over the small test area and check for any colour bleeding.
6. If the cloth remains clean, it should be safe to clean the carpet.
Using the carpet cleaner
Filling the water solution tank
CAUTION!
Risk of injury!
Improper handling of the carpet cleaner may cause injury.
− Always unplug the carpet cleaner before filling the water
solution tank.
− Avoid prolonged skin contact with cleaning solutions.
− Keep carpet cleaning solution out of the reach of children.
− In case of contact with eyes, rinse immediately with plenty of
water and seek medical advice.

Using the carpet cleaner
12
NOTICE!
Risk of damage!
Using the carpet cleaner without the water solution tank in place or
with a wrong solution may damage the carpet cleaner.
− Always make sure that the water solution tank is properly in
place before using the carpet cleaner.
− Do not use any solvents, cleaners with strong acidic or strong
alkali formulas, or any type of cleaning solution not specifically
for use in carpet cleaning machines.
Only use suitable (low-foaming) carpet cleaning solution. Using
incorrect solutions may cause excess foaming, which will prevent the
carpet cleaner from working effectively.
1. Unplug the carpet cleaner.
2. While holding on to the water solution tank 4, lift the water
solution tank handle 9upwards.
3. Tilt the water solution tank away from the carpet cleaner and
remove it.
4. Unscrew the water solution tank cap 3by turning it
counterclockwise.
5. Add cleaning solution 15 , making sure to follow the instructions
on the bottle.
6. Fill the remainder of the water solution tank with warm tap
water (max. 40 °C (104 °F)) and replace the water solution tank
cap.
Make sure to not exceed the max fill level.
7. Place the water solution tank back into position by pushing it down and into the
carpet cleaner.
8. Push the water solution tank handle down until it clicks, locking into place.
• A bottle of carpet cleaning solution is included. Once this has
been used, most commercially available low foaming carpet
cleaning solutions may be used. Always read the manufacturer’s
instructions before use.
• Carpet cleaning solution cannot be ordered from our customer
service department.

Using the carpet cleaner
13
Cleaning a carpet
• Before cleaning, determine where to start and stop, making sure
you will not walk over previously cleaned areas.
• Do not oversaturate the carpet.
• For heavily soiled areas, additional applications may be necessary.
1. Plug the mains cord 16 into an electrical outlet and turn it on
by using the on/off switch 2.
2. Step on the handle release pedal 13 to lower the carpet
cleaner into the cleaning position.
3. While pulling the solution release trigger 11 , pull the carpet
cleaner in a backwards direction towards you.
4. Release the solution release trigger and push the carpet cleaner
forward in the same path to agitate and remove dirty water and
solution from the carpet.
5. For heavily soiled areas, repeat as necessary.
Tips for carpet cleaning
• Use the carrying handle 10 to lift up the carpet cleaner and move it to the
desired cleaning location.
• Use a steady, moderate, forward and backward motion.
• Always work from back to front across a room to avoid stepping on wet carpet.
• Do not make the carpet too wet. Use no more than two sets of forward and
backward strokes while releasing solution. Always follow with dry strokes; the
more the better.
• Wipe any cleaning solution from woodwork and furniture to prevent any damage.
• Allow plenty of time for the carpet to dry and avoid walking on it until it is dry.
• Increased air circulation (open doors, fans, etc.) or the use of a dehumidifier will
help the carpet dry thoroughly and prevent the growth of mold or mildew.
• Vacuum the carpet thoroughly before cleaning it and after it has dried.

Using the carpet cleaner
14
Emptying the dirty water tank
CAUTION!
Risk of injury!
Improper handling of the carpet cleaner may cause injury.
− Always unplug the carpet cleaner before emptying the dirty
water tank.
An automatic shut-off device prevents the carpet cleaner from picking
up more dirty water than the dirty water tank can hold. You will know
the dirty water tank needs to be emptied when:
• the motor sound rises in pitch,
• you do not see dirty solution coming up through the dirty water
tank lid,
• or the float inside the dirty water tank has risen to the top of the
tank and is visible.
1. Unplug the carpet cleaner.
2. Unlock the dirty water tank 7by pressing the dirty water tank locking
latch 8and lifting up the dirty water tank handle 5at the same time
(see Step 1).
3. Remove the dirty water tank from the carpet cleaner.
4. Open the dirty water tank cap 18 by turning it counterclockwise, so the grip
points to the word “unlock” (see Step 2).
5. Empty the dirty water tank, replace the dirty water tank cap and turn it to the
“lock” position, and place the dirty water tank back into the carpet cleaner
(see Step 3).
6. Push the dirty water tank handle down until the dirty water tank locking latch
clicks into place.
Step 1
UNLOCK
LOCK
Step 2 Step 3
18

Cleaning
15
Cleaning
CAUTION!
Risk of injury!
Improper handling of the carpet cleaner may cause injury.
− Always unplug the carpet cleaner when not in use, refilling the
tanks, cleaning it, or performing maintenance.
NOTICE!
Risk of damage!
Improper handling of the carpet cleaner may result in damage.
− Do not use any aggressive cleaners, brushes with metal or
nylon bristles, or sharp or metallic cleaning utensils such as
knives, hard scrapers and the like. They could damage the
surfaces.
− Never immerse the motor unit in water or any other liquid and
do not rinse it under the tap or with a hose.
Cleaning the filters
NOTICE!
Risk of damage!
Improper handling of the carpet cleaner may result in damage.
− Do not clean the filters with any chemicals as this will destroy
them.
1. Remove the dirty water tank 7as described in the chapter “Emptying the dirty
water tank.”
2. Remove the exhaust filter housing 6from the dirty water tank (see Step 1).
3. Pull out the filter 19 and rinse it with warm water (see Step 2).
Allow it to dry thoroughly when storing the carpet cleaner.
4. Replace the filter and put the exhaust filter housing back into the dirty water
tank.

Storage
16
5. With the dirty water tank still removed, pull out the motor filter 20 and rinse it
with warm water (see Step 3).
Allow it to dry thoroughly when storing the carpet cleaner.
6. Replace the filter and put the dirty water tank back into the carpet cleaner as
described in the chapter “Emptying the dirty water tank.”
Step 1 Step 2 Step 3
Cleaning the carpet cleaner
1. Unplug the carpet cleaner.
2. Make sure the water solution tank 4and the dirty water tank 7are empty
(see chapter “Emptying the dirty water tank”).
3. Use a soft damp cloth to wipe off the carpet cleaner and accessories. Then let all
parts dry completely.
Storage
NOTICE!
Risk of damage!
Mineral deposits and mildew can form when cleaning solution and/
or water is left in the tanks, affecting the performance of the carpet
cleaner.
− Do not store the carpet cleaner with cleaning solution left in
the water solution tank or dirty water left in the dirty water
tank.
All parts must be completely dry before being stored.
− Always store the carpet cleaner in a dry area.
− Protect the carpet cleaner from direct sunlight.
− Store the carpet cleaner so that it is not accessible to children.
19
20

Troubleshooting
17
Troubleshooting
Problem Solution
Carpet cleaner will not run. − Make sure the carpet cleaner is plugged in.
− Check the fuse or breaker.
Not enough suction during
floor cleaning.
− Empty the dirty water tank; it may be full and
the automatic shut-off engaged.
− Make sure the dirty water tank is properly
installed.
Cleaning solution will not
dispense.
− Make sure the water solution tank is fully
inserted and securely in place.
− Refill the water solution tank if it is empty.
Technical data
Model: VC9389
Power supply: 230 V ~ 50 Hz
Output: 600 W
Protection class: IPX4
Water solution tank capacity: 1.8 L – max. capacity 2.8 L
Dirty water tank capacity: 1.75 L – max. capacity 2.4 L
Product code: 10953
Declaration of conformity
The EU declaration of conformity can be requested from the address
specified on the enclosed warranty card.

Disposal
18
Disposal
Disposing of the packaging
TRAY
BOTTLE CAP
Sort the packaging before you dispose of it.
Dispose of paperboard and cardboard with
the recycled paper service and wrappings
with the appropriate collection service.
Disposing of the carpet cleaner
(Applicable in the European Union and other European countries with separate
collection systems of recyclable materials)
Old appliances may not be disposed of in the household waste!
Should the carpet cleaner no longer be capable of being used at some
point in time, dispose of it in accordance with the regulations in force in
your city or county. This ensures that old appliances are recycled in a
professional manner and also rules out negative consequences for the
environment. For this reason, electrical equipment is marked with the symbol shown
here.

YEAR
WARRANTY
3
PRODUCED IN CHINA FOR:
ALDI STORES LTD. PO BOX 26, ATHERSTONE
WARWICKSHIRE, CV9 2SH.
ALDI STORES (IRELAND) LTD.
PO BOX 726, NAAS, CO. KILDARE.
Visit us at www.aldi.com
GB IE
Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly.
In the event of product failure within its intended use over the course of the
first 3 years after date of purchase, we will remedy the problem as quickly
as possible once it has been brought to our attention. In the unlikely event
of such an occurrence, or if you require any information about the product,
please contact us via our helpline support services, details of which are to be
found both in this manual and on the product itself.
MODEL:
VC9389
ke[email protected]
01909 517672 012 475 437
AFTER SALES SUPPORT
IEGB
10953
03/2019
