Eaton CurrentWatch EDC Series Manual

CurrentWatch™ EDC Series Current Sensors,
DC Current Sensor, Solid Core Housing with
Analog Output
WARNING
IN ORDER TO AVOID ELECTRIC SHOCK OR OTHER POSSIBLE INJURY:
• DO NOT USE THIS PRODUCT FOR HUMAN SAFETY APPLICATIONS. IT
WAS NOT DESIGNED, TESTED, OR RECOMMENDED FOR THIS USE.
• DO NOT USE THIS PRODUCT IN HAZARDOUS LOCATIONS (E.G.
EXPLOSIVE ATMOSPHERES). IT WAS NOT DESIGNED, TESTED, OR
RECOMMENDED FOR THIS USE.
• ENSURE THE PRODUCT IS PROPERLY WIRED TO THE CORRECT POWER
SUPPLY FOR THE APPLICATION. REFER TO THE SPECIFICATIONS AND
WIRING DIAGRAMS IN THIS PUBLICATION.
Models Covered In This Publication
Catalog Number Description
EDC1420SC Solid Core, 24 VAC/DC, 4-20 mA Output, 5/10/20 A Range
Introduction
The CurrentWatch™ EDC Series combines a
hall effect sensor and a signal conditioner
into a single, compact package for use in
DC current applications. The EDC Series
has jumper selected current input ranges
and an industry standard 4-20 mA output.
ote:N Note that this manual only covers
solid-core versions of the EDC Series.
For the split-core manual, use publication
P51927.
Eaton’s current sensor family encom-
passes a broad range of products for cost-effective monitoring,
status, and predictive maintenance. Downtime and costly repairs
can be avoided by utilizing Eaton’s products and technologies in
your control systems.
Instructions Publication P51926 Effective July 2017
Supersedes March 2014
Instruction Leaflet
Montageanweisung
Notice d’installation
Instrucciones de montaje
Istruzioni per il montaggio
安装说明
Инструкция по монтажу
Montagehandleiding
Montagevejledning
Οδηγίες εγκατάστασης
Instruções de montagem
Monteringsanvisning
Asennusohje
Návod k montáži
Paigaldusjuhend
Szerelési utasítás
Montāžas instrukcija
Montavimo instrukcija
Instrukcja montażu
Navodila za montažo
Návod na montáž
Монтажни инструкции
Instrucţiuni de montaj
Upute za montažu
Electric current! Danger to life!
Only skilled or instructed persons may
carry out the following operations.
Lebensgefahr durch elektrischen Strom!
Nur Elektrofachkräfte und elektrotechnisch
unterwiesene Personen dürfen die im Folgenden
beschriebenen Arbeiten ausführen.
Tension électrique dangereuse !
Seules les personnes qualifiées et averties doivent
exécuter les travaux ci-après.
¡Corriente eléctrica! ¡Peligro de muerte!
El trabajo a continuación descrito debe ser realizado
por personas cualificadas y advertidas.
Tensione elettrica: Pericolo di morte!
Solo personeabilitate e qualificate possono eseguire
le operazioni di seguito riportate.
触电危险！
只允许专业人员和受过专业训练的人员进行下列工作。
Электрический ток! Опасно для жизни!
Только специалисты или проинструктированные
лица могут выполнять следующие операции.
Levensgevaar door elektrische stroom!
Uitsluitend deskundigen in elektriciteit en
elektrotechnisch geïnstrueerde personen is het
toegestaan, de navolgend beschreven
werkzaamheden uit te voeren.
Livsfare på grund af elektrisk strøm!
Kun uddannede el-installatører og personer der
e instruerede i elektrotekniske arbejdsopgaver,
må udføre de nedenfor anførte arbejder.
en
de
fr
es
it
zh
ru
nl
da
Προσοχή, κίνδυνος ηλεκτροπληξίας!
Οι εργασίες που αναφέρονται στη συνέχεια θα
πρέπει να εκτελούνται μόνο από ηλεκτρολόγους
και ηλεκτροτεχνίτες.
Perigo de vida devido a corrente eléctrica!
Apenas electricistas e pessoas com formação
electrotécnica podem executar os trabalhos
que a seguir se descrevem.
Livsfara genom elektrisk ström!
Endast utbildade elektriker och personer som
undervisats i elektroteknik får utföra de arbeten
som beskrivs nedan.
Hengenvaarallinen jännite!
Vain pätevät sähköasentajat ja opastusta saaneet
henkilöt saavat suorittaa seuraavat työt.
Nebezpečí úrazu elektrickým proudem!
Níže uvedené práce smějí provádět pouze
osoby s elektrotechnickým vzděláním.
Eluohtlik! Elektrilöögioht!
Järgnevalt kirjeldatud töid tohib teostada ainult
elektriala spetsialist vői elektrotehnilise
instrueerimise läbinud personal.
Életveszély az elektromos áram révén!
Csak elektromos szakemberek és elektrotechnikában
képzett személyek végezhetik el a következőkben leírt
munkákat.
Elektriskāstrāva apdraud dzīvību!
Tālāk aprakstītos darbus drīkst veikt tikai
elektrospeciālisti un darbam ar elektrotehniskām
iekārtām instruētās personas!
el
pt
sv
fi
cs
et
hu
lv
Pavojus gyvybei dėl elektros srovės!
Tik elektrikai ir elektrotechnikos specialistai gali
atlikti žemiau aprašytus darbus.
Porażenie prądem elektrycznym stanowi
zagrożenie dla życia!
Opisane poniżej prace mogąprzeprowadzaćtylko
wykwalifikowani elektrycy oraz osoby odpowiednio
poinstruowane w zakresie elektrotechniki.
Življenjska nevarnost zaradi
električnega toka!
Spodaj opisana dela smejo izvajati samo
elektrostrokovnjaki in elektrotehnično poučene osebe.
Nebezpečenstvo ohrozenia života
elektrickým prúdom!
Práce, ktoré sú nižšie opísané, smú vykonávat’
iba elektroodborníci a osoby s elektrotechnickým
vzdelaním.
Опасност за живота от електрически ток!
Операциите, описани вследващите раздели,
могат да се извършват само от
специалисти-електротехници иинструктиран
електротехнически персонал.
Atenţie! Pericol electric!
Toate lucrările descrise trebuie efectuate numai
de personal de specialitate calificat şi de persoane
cu cunoştiinţe profunde în electrotehnică.
Opasnost po život uslijed električne struje!
Radove opisane u nastavku smiju obavljati samo
stručni električari i osobe koje su prošle
elektrotehničku obuku.
lt
pl
sl
sk
bg
ro
hr
292004228

Quick Install Guide
The below steps can be followed to quickly install a CurrentWatch
EDC Series sensor.
1. Run the wire to be monitored through the aperture, being sure
monitored current flow matches arrows on the sensor or as
noted on the figure to the right on this page.
2. Mount the sensor to a surface, if needed.
3. Connect output wiring:
a. Use up to 14 AWG (2.5 mm2) copper wires, tightening termi-
nals to 5.3 in.-lbs / 0.60 N·m of torque.
b. For current output models, make sure output load is no more
than 500 ohms.
4. Connect power using the appropriate power supply.
5. Select the correct range by positioning the Range Jumper.
Installation
Considerations for all EDC Series models…
• Run wire to be monitored through the aperture (opening) of the
sensor.
• Care should be taken to ensure current flow is in accordance with
any directional arrows on the sensor and as noted in the figure on
the right of this page.
• These sensors can be located in the same environment as
motors, contactors, heaters, pull-boxes, and other electrical enclo-
sures.
• Mounting can be done in any position or hung directly on a wire
with a wire tie.
• For optimal performance, ensure the unit has been energized for a
period of 20 minutes prior to sensing operation.
Range Selection
The CurrentWatch EDC Series sensors feature field selectable rang-
es. The ranges are factory calibrated, eliminating time consuming
and inaccurate field setting of zero or span.
Setting Range
1. Determine the normal operating amperage of your monitored
current.
2. Select the range this is equal to or slightly higher than the nor-
mal operating amperage.
3. Place the Range Jumper in the appropriate position.
Wiring and Mounting Information
Connect control or monitoring wires to the sensor. Use up to 14
AWG copper wire and tighten terminals to 5.3 in.-lbs / 0.60 N·m
maximum torque.
3 . 375 in.
(85 .7 3 mm
EDC1420SC
DC C urrent Sensor
MID HIGH
J UM PER RA NG E
M ID 10A
HIGH 20A
PO WER
+-
4-20mA
Output
1 2 3 4
Current Directio
n
Unipolar
Bipolar
(+)
(-)
Connection Notes:
• The current loop is powered by the sensor. Maximum loop
impedance is 800 ohms.
• Ensure the direction of the monitored current is the same as the
direction shown on the diagram. The unipolar output design will
not operate properly if the current is opposite the direction of the
arrow.
• Use 26-14 AWG copper wire.
• Screw thread is M3 and screw torque is 5.3 in.-lbs / 0.60 N·m.
• Remove jumper entirely for Low Range operation.
• Observe polarity.
Unipolar Versus Bipolar Output
Output Diagram
Unipolar Output
Bipolar Output
4
2
0
Output(m A)
F S0 Range
(S ensed C u rr e nt, A )
F S
- F S
Range(S ensed C u r rent, A )
4
2 0
1 2
Output(m A)
)
2EATON www.eaton.com
CurrentWatch™ EDC Series Current Sensors,
DC Current Sensor, Solid Core Housing with
Analog Output
Instructions Publication P51926
Effective July 2017

Troubleshooting
Problem
Solution for Current
Output Models
Sensor has no
output.
Monitored load is not DC or is not on. Check that the moni-
tored load is DC and that it is actually on.
Polarity is not properly matched. Check and correct wiring
polarity.
Output signal is
too low.
The jumper may be set in a range that is too high for current
being monitored. Move jumper to the correct range.
Power supply is inadequate. Check power supply. Make sure
it is of sufficient voltage with all loads at maximum. The cur-
rent draw of EDC Series sensors is 2.0 VA.
Output load is too high. Check output load, being sure it is no
more than 500 ohms.
Output signal is
always at maxi-
mum.
The jumper may be set in a range that is too low for current
being sensed. Change the jumper position.
Specications
Specification Value
Power Supply 24 VAC/DC (22-28 VAC/DC)
Power input and output signal are not isolated.
Caution: Do not connect Grounded AC Supply to the
Output Negative (-), as sensor damage may occur.
Power Consumption 2 VA
Current Ranges Jumper Selectable: 5, 10, or 20 A
Output Signal 4-20 mA
Response Time 160 ms (90% of Step Change)
Repeatability 1% FS
Frequency Range DC
Accuracy 1% FS
Linearity 0.75%
Isolation Voltage 3 kV (Monitored Line to Output)
Sensing Aperture 0.75 in. (19 mm) dia.
Housing UL94 V0 Flammability Rated
Environmental Operating Temperature: -4 to +122°F (-20 to +50°C)
Humidity: 0-95% RH, Non-Condensing
Approvals UL Listed, E117028
UL tested to Canadian safety standards
CE
RoHs Compliant
3
EATON www.eaton.com
Instructions Publication P51926
Effective July 2017
CurrentWatch™ EDC Series Current Sensors,
DC Current Sensor, Solid Core Housing with
Analog Output

Eaton Industries GmbH
Hein-Moeller-Straße 7-11,
53115 Bonn, Germany
Eaton Corporation
W126 N7250 Flint Drive
Menomonee Falls,
WI 53051, USA
Contact your regionalEaton oce for additionaltechnical support
Eatonis a registered trademark of
Eaton Corporation.
All other trademarks are property
of their respective owners.
Americas – Asia Pacic Europe – Middle East – Africa
Eaton Corporation
Electrical Sector – Sensors
+1.800.426.9184
www.eaton.com/sensors
Eaton Industries GmbH
Electrical Sector EMEA
[phone]
www.eaton.eu/sensors
© 2017 by Eaton
All Rights Reserved
Printed in USA
Publication No. P51926 / 003
July 2017
CurrentWatch™ EDC Series Current Sensors,
DC Current Sensor, Solid Core Housing with
Analog Output
Instructions Publication P51926
Effective July 2017
Eaton Industries GmbH
Hein-Moeller-Straße 7-11,
53115 Bonn, Germany
Eaton
W126 N7250 Flint Drive
Menomonee Falls,
WI 53051, USA
Eaton
Electrical Sector – Sensors
+1.800.426.9184
www.eaton.com/sensors
Eaton Industries GmbH
Electrical Sector EMEA
[phone]
www.eaton.eu/sensors
Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
Contact your regional Eaton office for additional technical support
Americas – Asia Pacific Europe – Middle East – Africa
