Eaton TRIPP LITE U442-DOCK11-S User manual

1
Owner’s Manual
Español 13
Français 24
Deutsch 35
Italiano 46
Purchased product
may differ from image.
Model:
U442-DOCK11-S
USB 3.2 Gen 1 USB-C Aluminum
Docking Station
PD Charging

2
Package Contents
Optional Accessories
• U442-DOCK11-S
• Owner’s Manual
• N201-Series Cat6 Gigabit Snagless Patch
Cables
• P566-Series HDMI to DVI Adapter Cables
• P569-XXX-CERT* Series High Speed HDMI
Cables
• U322-Series USB A/B Device Cables
• U326-Series USB Micro-B Device Cables
• U420-003-G2-5A USB 3.2 Gen 2 (10 Gbps)
USB-C M/M Cable with 5A rating, 3 ft.
• U428-003 USB 3.2 Gen 1 (5 Gbps) Cable,
USB-C to USB-A M/M, 3 ft.
*XXX represents length, in feet (e.g. 003 for 3 ft., 006 for
6 ft., etc.).

3
System Requirements
• Computer with USB-C®port that supports USB
DisplayPort Alternate Mode
• DVI* or HDMI monitor
• Ethernet network with speeds up to
10/100/1000 Mbps
*Requires an adapter. See Optional Accessories for
more information.
USB Type-C®and USB-C®are registered trademarks of
USB Implementers Forum

4
Product Features
• Supports USB DisplayPort Alternate Mode for
connecting an HDMI monitor
• Supports connection of a DVI monitor
(HDMI to DVI adapter required, sold separately)
• HDMI port supports 4K UHD video resolutions
up to 3840 x 2160 @ 30 Hz
• Ethernet port supports true 10/100/1000
Mbps network speeds
• USB-A hub ports support data transfer rates
up to 5 Gbps
• Micro SD and SD/MMC memory card slots
provide external memory access
• USB-C port supports USB 3.2 Gen1 data
transfer rates up to 5Gbps, and power input
up to 20V 3A (60W)
• Automatically resumes operation from
hibernation and suspend modes
• Complies with IEEE 802.3az
(Energy Ecient Ethernet)

5
Product Features
• Supports full- and half-duplex operations
• Supports IPv4 and IPv6 pack Checksum Ooad
Engine (COE) to reduce CPU loading
• Supports Wake-on-LAN
• Plug and play—no software, drivers or external
power supply required

6
Product Overview
1USB-C Connector
with Built-In Cable
2USB-A Ports
3Micro SD Memory
Card Slot
4SD/MMC Memory
Card Slot
5RJ45 Ethernet
Network Port
64K HDMI Port
7USB-C Data/Charging
Port
8(Optional) 5V DC
Power Jack
1
1
7
7
8
8
5
5
6
6
2
2
2
2
3
3
4
4

7
Installation
Notes:
• Both memory card slots can be used at the same time.
• When connected to an AC power source by way of the
USB-C charging port, 5W is dedicated to the docking
station and connected USB peripherals. The remaining
power is used to charge the connected USB-C device.
• See Optional Accessories section for suggested cables.
• When the unit is connected to the USB-C port on your
computer and to a network via Cat5e/6 cabling, a
network connection will automatically be established.
If no connection is made, one can be established
manually by going to your computer’s network settings
page. For example, when using a Mac, navigate to the
Network section found in System Preferences, click the
‘Assist Me’ button to get to the Network Setup Assistant,
then follow the prompts to establish a connection.
• If additional power is required for your installation, the
U442-DOCK11-S is compatible with user-supplied 5V DC
power jacks equipped with a 3.5 x 1.35 x 9.5 mm output
plug with a positive tip and negative sleeve.

8
Installation
1. Connect the built-in USB-C cable to USB-C
port on your laptop, tablet or other device.
2. Use an HDMI cable to connect a monitor or
display to the unit’s HDMI port.
3. Connect USB peripherals to the unit’s USB-A
hub ports.
4. For an Ethernet connection, use Cat5e/6 UTP
cable to connect to the unit’s RJ45 port.
5. Insert Micro SD or SD/MMC cards into their
corresponding slots to access external
memory.
6. Charge a device by connecting a USB-C
charger to the unit’s USB-C port. The USB-C
port can also be used to connect a USB-C
peripheral device.

9
Specications
Input Connectors
USB 1x USB-C (Male)
DC Port DC Power (Female)
Output Connectors
USB-A 2x USB-A (Female)
USB-C 1x USB-C (Female)
HDMI 1x HDMI (Female)
Memory Cards 1x Micro SD, 1x SD/MMC
Ethernet 1x RJ45
Environmental
Operating
Temperature
32° to 131°F (0° to 55°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature 14° to 158°F (-10° to 70°C)
Storage Humidity 5% to 90% RH, Non-Condensing
Power Requirements
USB-C Charging Port Supports up to 20V 3A (60W)
Input*
DC Port 5V 2A
*5W of power is dedicated to the unit; the remaining power goes
to the USB-C device the unit is connected to.

10
3-Year Limited Warranty
We warrant our products to be free from defects in materials and
workmanship for a period of three (3) years from the date of initial
purchase. Our obligation under this warranty is limited to repairing or
replacing (at its sole option) any such defective products. Visit Tripplite.
Eaton.com/support/product-returns before sending any equipment
back for repair. This warranty does not apply to equipment which has
been damaged by accident, negligence or misapplication or has been
altered or modied in any way.
EXCEPT AS PROVIDED HEREIN, WE MAKE NO WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. Some states do not permit limitation or
exclusion of implied warranties; therefore, the aforesaid limitation(s) or
exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL WE BE LIABLE
FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specically, we are not
liable for any costs, such as lost prots or revenue, loss of equipment,
loss of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
Warranty

11
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modications to this equipment not expressly approved
by Eaton could void the user’s authority to operate this equipment.
Warranty

12
WEEE Compliance Information for Customers and Recyclers
(European Union)
Under the Waste Electrical and Electronic Equipment (WEEE)
Directive and implementing regulations, when customers buy
new electrical and electronic equipment from Eaton, they are
entitled to:
• Send old equipment for recycling on a one-for-one, like-for-
like basis (this varies depending on the country)
• Send the new equipment back for recycling when this
ultimately becomes waste
Use of this equipment in life support applications where failure of this
equipment can reasonably be expected to cause the failure of the life
support equipment or to signicantly aect its safety or eectiveness is
not recommended.
Eaton has a policy of continuous improvement. Specications are
subject to change without notice.
Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
United States
Eaton.com
© 2023 Eaton
All Rights Reserved
Publication No.
23-08-335 /
93-37BC_RevD
September 2023
Eaton is a registered
trademark.
All trademarks are
property of their
respective owners.
Warranty

13
Manual del Propietario
English 1
Français 24
Deutsch 35
Italiano 46
El producto comprado
puede diferir de la imagen.
Modelo:
U442-DOCK11-S
Estación de Conexión USB 3.2
Gen 1 USB-C, Aluminio
Carga PD

14
Contenido del Empaque
Accesorios Opcionales
• U442-DOCK11-S
• Manual del Propietario
• Cables Patch Snagless Gigabit Cat6 Serie N201
• Cables Adaptadores de HDMI a DVI Serie P566
• Cables HDMI de Alta Velocidad Serie
P569-XXX-CERT*
• Cables para Dispositivo USB A/B Serie U322
• Cables para Dispositivo USB Micro-B Serie
U326
• U420-003-G2-5A – Cable USB 3.2 Gen 2 (10
Gbps) USB-C M/M con especicación de 5A,
91 cm [3 pies]
• U428-003 – Cable USB 3.2 Gen 1 (5 Gbps),
USB-C a USB-A M/M, 91 cm [3 pies]
*XXX representa la longitud, en pies (p.e. 003 para 3
pies, 006 para 6 pies, etc.).

15
Requisitos del Sistema
• Computadora con puerto USB-C®que soporte
USB DisplayPort Modo Alterno
• Monitor DVI* o HDMI
• Red Ethernet con velocidades hasta 10Mbps /
100Mbps / 1000Mbps
* Requiere un adaptador. Ver Accesorios Opcionales
para obtener información adicional.
USB Type-C®y USB-C®son marcas comerciales
registradas del USB Implementers Forum

16
Características del Producto
• Soporta USB DisplayPort de Modo Alterno para
conectar un monitor HDMI
• Soporta la conexión un monitor DVI (requiere
de un adaptador HDMI a DVI, vendido por
separado)
• El puerto HDMI soporta resoluciones de video
UHD 4K de hasta 3840 x 2160 @ 30 Hz
• El puerto Ethernet soporta velocidades reales
de red de 10Mbps / 100Mbps / 1000Mbps
• Los puertos del hub USB-A soportan tasas de
transferencia de datos hasta 5 Gbps
• Ranuras para tarjeta de memoria Micro SD y
SD / MMC proporcionan acceso a memoria
externa
• El puerto USB-C soporta tasas de transferencia
de datos USB 3.2 Gen1 de hasta 5 Gbps, y
alimentación hasta 20V 3A (60W)
• Restablece automáticamente la operación
desde los modos de hibernación y suspensión

17
Características del Producto
• Cumple con IEEE 802.3az (Consumo eciente
de energía en redes Ethernet)
• Soporta operaciones Dúplex y Semi-dúplex
• Soporta Checksum Ooad Engine (COE) de
módulo IPv4 e IPv6 para reducir la carga del
CPU
• Soporta Wake-on-LAN
• Conectar y Usar—No requiere fuente de
alimentación externa, controladores o software

18
Vista General del Producto
1Conector USB-C con
Cable Incorporado
2Puertos USB-A
3Ranura para
Tarjeta de Memoria
Micro SD
4Ranura para
Tarjeta de Memoria
SD / MMC
5Puerto de Red
Ethernet RJ45
6Puerto HDMI 4K
7Puerto de Carga /
Datos USB-C
8(Opcional) Enchufe
de Alimentación 5V
CD
1
1
7
7
8
8
5
5
6
6
2
2
2
2
3
3
4
4

19
Instalación
Notas:
• Ambas ranuras para tarjetas de memoria pueden usarse
simultáneamente.
• Cuando se conecta a una fuente de alimentación de CA
por medio del puerto de carga USB-C, 5W se dedican a
la estación de conexión y periféricos USB conectados. La
potencia restante se usa para cargar el dispositivo USB-C
conectado.
• Para consultar los cables sugeridos, vea la sección
Accesorios Opcionales.
• Cuando la unidad esté conectada al puerto USB-C en su
computadora y a una red mediante cableado Cat5e /
Cat6, se establecerá automáticamente una conexión de
red. Si no se realiza una conexión, puede establecerse una
manualmente accediendo a la página de conguración
de red de la computadora. Por ejemplo, cuando usa una
Mac, vaya a la sección de Red en Preferencias del Sistema,
haga click en el botón ‘Ayúdame’ para llegar al Asistente
de Conguración de Red, luego siga las instrucciones para
establecer una conexión.
• Si se requiere alimentación adicional para su instalación,
el U442-DOCK11-S es compatible con convertidores
de corriente de 5V CD suministrados por el usuario
equipado con una clavija de salida de 3.5 x 1.35 x 9.5
mm con una punta positiva y casquillo negativo.

20
Instalación
1. Conecte el cable USB-C incorporado al puerto
USB-C en su laptop, tableta u otro dispositivo.
2. Use un cable HDMI para conectar un monitor
o pantalla al puerto HDMI de la unidad.
3. Conecte periféricos USB a los puertos del hub
USB-A de la unidad.
4. Para una conexión Ethernet, utilice cable UTP
Cat5e / Cat6 para conectar al puerto RJ45 de
la unidad.
5. Inserte tarjetas Micro SD o SD / MMC en sus
ranuras correspondientes para acceder a la
memoria externa.
6. Cargue un dispositivo conectando un
cargador USB-C al puerto USB-C de la unidad.
El puerto USB-C puede usarse también para
conectar un dispositivo periférico USB-C.
