User Manual
Eaton RE Series Server Enclosure

RE SERIES_ RevA 3/5/2022
v
1
Eaton RE Series Rack Enclosures
Important Safety Instructions .................................................................................................................................. 2
Overview.................................................................................................................................................................... 3
Available RE Series Enclosures ........................................................................................................................ 3
Feature Identification ............................................................................................................................................... 4
Package in Flat packing............................................................................................................................................. 5
Main Components .............................................................................................................................................. 5
Accessories ..................................................................................................................................................... 6
Enclosure Installation---For Flat packing cabinet..................................................................................................... 7
Step 1:Triangle reinforcing plate fixed ........................................................................................................... 7
Step 2: Horizontal beams fixed to the rear door frame................................................................................... 7
Step 3: Horizontal beams fixed to the front door frame ................................................................................ 8
Step 4: Fixed the triangle reinforcing plate to the both front and rear door frame ....................................... 8
Step 5: Fixed 2pcs cable management rails to the horizontal beams ............................................................. 9
Step 6: Fixed 4pcs vertical rails to the horizontal beams.............................................................................. 10
Step 7: Fixed the top cover............................................................................................................................ 11
Step 8: Side panel installation .................................................................................................................11-12
Enclosure Installation--For Build up packing cabinet ............................................................................................. 13
Preparation .................................................................................................................................................... 13
Unpacking .................................................................................................................................................13-14
Placement ...................................................................................................................................................... 14
Leveling.......................................................................................................................................................... 15
Ground Connection ........................................................................................................................................ 15
Enclosure Configuration .......................................................................................................................................... 16
Adding or Removing Front and Rear Doors ................................................................................................... 16
Reversing Front Door................................................................................................................................16-17
Adding or Removing Roof Panel .................................................................................................................... 18
Adding or Removing Side Panels ...............................................................................................................18-19
Adjusting Mounting Rails and Cable Management Rails................................................................................. 19
Combining (Baying) Enclosures ....................................................................................................................... 20
Equipment Installation............................................................................................................................................ 20
Installing or Removing Cage Nuts ................................................................................................................... 21
Storage and Service................................................................................................................................................. 22
Warranty ................................................................................................................................................................. 22

RE SERIES_ RevA 3/5/2022
v
2
I
• Keep the enclosure in a controlled indoor environment, away from moisture, temperature extremes, flammable liquids and gasses, conductive
contaminants, dust and direct sunlight.
• Leave adequate space at the front and rear of the enclosure for proper ventilation. Do not block, cover or insert objects into the external ventilation
openings of the enclosure.
• The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install it unassisted. Use a mechanical
device such as a forklift or pallet jack to move the enclosure in the shipping container.
• Do not place any object on the enclosure, especially containers of liquid, and do not attempt to stack the enclosures.
• Inspect the shipping container and the enclosure for shipping damage. Do not use the enclosure if it is damaged.
• Leave the enclosure in the shipping container until it has been moved as close to the final installation location as possible. The casters are designed for
minor position adjustments within the final installation area only. The casters are not designed for moving the enclosure over longer distances.
• The casters are not designed to provide long-term support for the enclosure after final installation. Use the levelers to provide long-term support.
• Install the enclosure in a structurally sound area with a level floor that is able to bear the weight of the enclosure, all equipment that will be installed in
the enclosure and any other enclosures and/or equipment that will be installed nearby.
• Install the cabinet securely to the building structure, using the shipping brackets as illustrated in the Enclosure Installation section of this manual.
• Do not push the enclosure from the side panels to move it. Pushing from the side panels will cause a tipping hazard.
• When rolling the enclosure on its casters, always push it from behind, never pull it toward you.
• A rolling enclosure can cause personal injury and property damage if not properly supervised. If rolling the enclosure down a ramp is required, use
extreme caution. Do not attempt to use ramps that have a slope steeper than 1:12.
• Use caution when cutting packing materials. The enclosure could be scratched, causing damage not covered by the warranty.
• Save all packing materials for later use. Repacking and shipping the enclosure without the original packing materials may cause product damage that will
void the warranty.
• Do not re-ship the enclosure with additional equipment . The combined weight of the enclosure and installed equipment must not exceed the load capacity of the
pallet. Eaton is not responsible for any damage that occurs during re-shipment.
• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support
equipment or to significantly affect its safety or effectiveness is not recommended.
All sections of this manual contain instructions and warnings that should be followed during the installation and use of the Eaton RE Enclosures
in this
manual. Failure to comply will create a risk of personal injury and property damage and may invalidate the warranty.

RE SERIES_ RevA 3/5/2022
v
3
This document outlines the recommended practices for assembling and installing the RE Series server enclosure. The standard server
enclosure is a high-quality design for storage of industry standard (EIA/ECA-310), 19” rack-mount hardware, which includes servers,
voice, data, networking, power protection equipment, KVM, etc., which are used in the data center rooms. 19" Standing Server Rack
is the ultimate solution designed and engineered for demanding data center environments. To achieve optimum versatility within the
server rack, users can set multiple depths throughout the rack by adjustable 19” mounting rails mounted on heavy duty side
supports. Horizontally divided side panels provide ease of access and convenient post-installation maintenance. Over 78%
perforations on front and rear door enable optimum airflow within the rack. Flat-pack option enables savings up to 60% in the
transport cost and warehouse space. Please follow the installation instructions closely; assembly should be performed using the
recommended tools.
Available RE Series Enclosures
Server Enclosure
Height[RMU]
Height[H]
Width[W]
Depth[D]
Premier
Essential
REV276100PB
REV276100EB
27
1325
600
1000
REV426100PB
REV426100EB
42
1992
600
1000
REV426110PB
REV426110EB
42
1992
600
1100
REV426120PB
REV426120EB
42
1992
600
1200
REV426127PB
REV426127EB
42
1992
600
1270
REV428100PB
REV428100EB
42
1992
800
1000
REV428110PB
REV428110EB
42
1992
800
1100
REV428120PB
REV428120EB
42
1992
800
1200
REV428127PB
REV428127EB
42
1992
800
1270
REV456100PB
REV456100EB
45
2125
600
1000
REV456110PB
REV456110EB
45
2125
600
1100
REV456120PB
REV456120EB
45
2125
600
1200
REV456127PB
REV456127EB
45
2125
600
1270
REV458100PB
REV458100EB
45
2125
800
1000
REV458110PB
REV458110EB
45
2125
800
1100
REV458120PB
REV458120EB
45
2125
800
1200
REV458127PB
REV458127EB
45
2125
800
1270
Note: ● Above products can be shipped fully assembled or Flat packed
● Customized dimension also optional
Caution:
Before installing this product, please note the following safety information:
1. Always lower the leveling feet of the enclosure.
2. Always install equipment starting from the bottom of the enclosure to the top.
3. Always install the heaviest equipment in the bottom of the enclosure.
4. Always have at least two persons during assembling of the enclosure.
Attention:
Avant d’installer ce produit, veuillez noter les informations de sécurité suivantes :
1. Abaissez toujours les pieds de nivellement de l’enceinte.
2. Installez toujours l’équipement à partir du bas de l’enceinte vers le haut.
3. Installez toujours l’équipement le plus lourd au fond de l’enceinte.
4. Avoir toujours au moins deux personnes lors de l’assemblage de l’enceinte.
Overview

RE SERIES_ RevA 3/5/2022
v
4
Premier Model(Model REV426100PB is shown)
Essential Model(Model REV426100EB is shown)
Component
Quantity
1
Front vented door with lock
1
2
Rear door
2
3
Top cover
1
4
Side panel
2(with lock)
2(without lock)
5
Vertical rails
4
6
Horizontal beam
4
7
Cable management rail
2
8
Door frame
2
9
Leveling feet
4
10
2" heavy duty castor
4
Note:Other models has similar features
Bottom plate option
Not Shown: Mounting hardware, documentation, shipping brackets and other shipping materials.
Component
Quantity
1
Front vented door with lock
1
2
Rear door
2
3
Top cover
1
4
Side panel with lock
4
5
Vertical rails
4
6
Horizontal beam
6
7
Cable management rail
2
8
Door frame
2
9
Leveling feet
4
10
2" heavy duty castor
4

RE SERIES_ RevA 3/5/2022
v
5
⚫Main Components
The flat-pack concept allows shipped enclosures to reduce space which
can save container and transportation costs.
Note: Carton B and Carton C put in Carton A
⚫Accessories

RE SERIES_ RevA 3/5/2022
v
6
Accessories for installation
PART NO
QTY
UNI
T
SPECIFICATIONS
REMARK
PB Flat
Packing
PB
Build
up
EB Flat
Packing
EB
Build
up
M6 floating nut combination
50
50
50
50
PCS
Black zinc plating
M6 Cage Nuts (1)
Phillips-head Mounting Screws
(M6-12 - ZB) (1)
M6 Nylon Cup Washers (1)
Equipment
installation in EIA
rails
Triangle reinforcing plate-Left
2
0
2
0
PCS
T=2.0
Triangle reinforcing plate-Right
2
0
2
0
PCS
T=2.0
Cross pan head self-drilling
screw
16
0
16
0
PCS
GB/T6560-M5-10-ZI
Triangle reinforcing
plate intallation
S1
Allen flat round head screw
24
0
16
0
PCS
GB/T70.2-M6-12-SUS
Horizontal beams
intallation
S2
Cross pan head self-drilling
screw
36
0
24
0
PCS
GB/T6560-M4-8-ZB（Full
thread）
Vertical rails and
cable tray intallation
S3
External serrated lock washer
36
0
24
0
PCS
GB/T862.2-#4-ZI
Vertical rails and
cable tray
intallation(Optional)
S4
Side Panel lock
4
4
2
2
PCS
Side panel bracket-Left
0
0
2
0
PCS
Bottom side panel
fixing for EB series
Side panel bracket-Left
0
0
2
0
PCS
Bottom side panel
fixing for EB series
Cross pan head screw
0
0
8
0
PCS
GB/T818-M6-12-ZB
Side panel bracket
installation
S5
Other accessories
RE series Manual
1
0
1
0
PCS
Allen wrench
1
1
1
1
PCS
Tool
PE bag
1
0
1
0
PCS
L bracket
2
0
2
0
PCS
Fixed on the pallet
External serrated lock washer
4
0
4
0
PCS
GB/T862.2-#8-ZI
Fixed on the pallet
Hexagon head bolts
4
0
4
0
PCS
GB/T5783-M8-55-ZI
Fixed on the pallet
Hexagonal nut
4
0
4
0
PCS
GB/T6170-M8-ZI
Fixed on the pallet
The big washer
8
0
8
0
PCS
GB/T96.1-#8-ZI
Fixed on the pallet
Spring washer
4
0
4
0
PCS
GB/T93-#8-ZI
Fixed on the pallet
Hexagon head bolts
4
0
4
0
PCS
GB/T5783-M8-25-ZI
Fixed on the pallet
Key
1
1
1
1
SET
Fixed on the pallet

RE SERIES_ RevA 3/5/2022
v
7
⚫Step 1:Triangle reinforcing plate fixed
Connect triangle reinforcing plate to the bottom horizontal beams by 8pcs GB/T6560-M5-10-ZI (Cross pan head self-drilling screw)【S1 in
accessories】.
⚫Step 2: Horizontal beams fixed to the rear door frame
Fixed the each horizontal beam to the rear door frame with 2pcs GB/T70.2-M6-12-SUS(Allen flat round head screw)【S2 in accessories】NOTE: 4pcs
horizontal beams for EB series cabinet and 6pcs horizontal beams for PB series
Triangle reinforcing plate-Right 2pcs
Triangle reinforcing plate-Left 2pcs
Horizontal beams 2pcs
Rear door and rear door farme 1pcs
Top/middle horizontal beams ( 4pcs for PB series and 2pcs fpr EB series)
Bottom horizontal beams 2pcs for both PB and EB series

RE SERIES_ RevA 3/5/2022
v
8
⚫Step 3: Horizontal beams fixed to the front door frame
Fixed the each horizontal beam to the rear door frame with 2pcs GB/T70.2-M6-12-SUS(Allen flat round head screw)【S2 in accessories】NOTE: 4pcs
horizontal beams for EB series cabinet and 6pcs horizontal beams for PB series(Same way with step 2)
⚫Step 4: Fixed the triangle reinforcing plate to the both front and rear door frame
Connect triangle reinforcing plate to the bottom frame of the front door and rear door by 8pcs GB/T6560-M5-10-ZI (Cross pan head self-drilling
screw)【S1 in accessories】

RE SERIES_ RevA 3/5/2022
v
9
⚫Step 5: Fixed 2pcs cable management rails to the horizontal beams
Hang on the cable management rails to the horizontal beams by the back ring.Then fixed the cable tray by GB/T6560-M4-8-ZB（Full thread）
(Cross pan head self-drilling screw)【S3 in accessories】
Note: 12pcs screws for PB series and 8pcs screws for EB series
( Washer S4 in accessories optional)
Back ring
Hole for screws fixing

RE SERIES_ RevA 3/5/2022
v
10
⚫Step 6: Fixed 4pcs vertical rails to the horizontal beams
Hang on the vertical rails to the horizontal beams by the back ring.Then fixed the cable tray by GB/T6560-M4-8-ZB（Full thread）
(Cross pan head self-drilling screw)【S3 in accessories】
Back ring
Hole for screws fixing
Note: 24 pcs screws for PB series and 16pcs screws for EB series
( Washer S4 in accessories optional)

RE SERIES_ RevA 3/5/2022
v
11
⚫Step 7: Fixed the top cover
While holding the top cover,arrange the 2 pins near the rear of the top cover into the holes in the enclosure frame.Pull the roof panel downward until it’s
close to the enclosure frame.
⚫Step 8: Side panel installation
Option 1. For PB series
Installation the side panel latch on to the side panel.Open side panel latch by sliding it down and then install the side panels into the frame as below:

RE SERIES_ RevA 3/5/2022
v
12
Option 2. For EB series
1. Side panel bracket installation: Fix the side panel bracket to the frame by GB/T818-M6-12-ZB (Cross pan head screw) 【S5 in accessories】2pcs
screws for each bracket and 8pcs for each enclosure.
2. Put the side panel without latch at the bottom (slide from top of the side panel bracket and hang on the bracket).The fixed the top side panel same as that
for PB series.

RE SERIES_ RevA 3/5/2022
v
13
Preparation
The enclosure must be installed in a structurally sound area with a level floor that is able to bear the weight of the enclosure, all the equipment that will be
installed in the enclosure and any other enclosures and/or equipment that will be installed nearby. Before unpacking the enclosure, you should transport the
shipping container closer to the final installation location to minimize the distance you will need to move the unit after the protective packaging has been
removed. If you plan to store the enclosure for an extended period before installation, follow the instructions in the Storage and Service section.
You need several tools (user-supplied):
• 13 mm Open-end Wrench
• 18 mm Open-end Wrench
• Utility Blade
• Carpenter's Level
• Phillips-head Screwdriver
• 5/32" Allen Wrench
• Ground wire 8AWG(( D=3.2
mm )with proper length, M6 Ring
terminal and another end with
proper terminal to connect your
facility's earth ground
Unpacking
You also need the following hardware (included):
• (50) Phillips-head Mounting Screws (M6 x 5/8")
• (50) Cage Nuts (M6)
• (50) Nylon Cup Washers
【S1 in accessories】
1 Confirm that the shipping container is upright and stable, then use a utility blade to cut the shrink-
wrap securing the corner protectors. Apply the utility blade directly over the corner protectors to
prevent the utility blade from scratching the enclosure or cutting the heavy protective plastic bag
beneath the shrink-wrap. WARNING: Do not scratch the enclosure or cut the heavy plastic
bag beneath the shrink-wrap. Do not push or pull the enclosure while unpacking.
2 Remove the corner protectors. Save all packing materials (including the pallet) for later use unless
you are certain they will not be required. The packing materials are recyclable.
3
Remove the heavy plastic bag surrounding the enclosure. Examine the enclosure for any damage or
loose parts. Confirm that all parts are present. If anything is missing or damaged, contact Eaton for
assistance. Do not attempt to use the enclosure if it has been damaged.
1
2
3
WARNING: The rack enclosure is extremely heavy. Do not attempt to unpack, move or install the enclosure without assistance. Until it has
been properly installed and stabilized, the enclosure is prone to tipping and could cause property damage and/or personal injury. Use
extreme caution when handling the enclosure and be sure to follow all handling and installation instructions. Do not attempt to install
equipment without first stabilizing the enclosure.

RE SERIES_ RevA 3/5/2022
v
14
4 Open the enclosure's doors directly and locate the 2 shipping brackets A that attach theenclosure
to the shipping pallet. The brackets are located inside or outside the enclosure.
Note: The keys are in the accessories box.
5 Use a 13 mm open-end wrench to remove the shipping brackets. Be extremely careful, as the
enclosure could shift unexpectedly after bracket removal. Save the brackets and bracket hardware
for later use.
6 Position at least one person at the front of the enclosure and one person at the rear of the
enclosure. Slowly push the enclosure toward the back of the shipping pallet until all four casters go
over the edge of the pallet and touch the floor. WARNING: Use at least one assistant when
removing the enclosure from the pallet. Be extremely careful when moving the enclosure.
Placement
1 Use the casters to move the enclosure for a short distance over a level, smooth, stable surface by
pushing it from the front or rear (not the side panels). Do not attempt to roll the enclosure over
long distances. The enclosure should be moved close to its installation location inside its shipping
container before it is unpacked. (Use a forklift or pallet jack to move the shipping container.)
WARNING: Do not push or pull the enclosure at the side panels or pull the enclosure
toward you.
5
6
1
4

RE SERIES_ RevA 3/5/2022
v
15
Leveling
WARNING: Level the enclosure before attempting to install equipment. The casters are not designed to provide long-term support for the
enclosure. Use the levelers to provide long-term support. Install the enclosure in a structurally sound area with a level floor that is able to
bear the weight of the enclosure, all equipment that will be installed in the enclosure and any other enclosures and/or equipment that will be
installed nearby.
1 After the enclosure has been moved to the installation location, use a carpenter's level to check
the slope of the floor. If the floor slopes more than 1%, choose an alternate installation site.
2 Use an 18 mm open-end wrench to lower each leveler A until it reaches the floor. (There are 4
levelers, 2 at the front and 2 at the rear.) Make sure each leveler contacts the floor solidly.
Note: Lower a leveler by turning it clockwise; raise a leveler by turning it counter-clockwise.
3
After lowering each leveler, use the carpenter's level to confirm that the enclosure is level in all
directions. Adjust the levelers as required until the enclosure is level.
4 In order to secure the cabinet to the building structure for stability, attach the 2 shipping brackets
using the hardware that attached the enclosure to the shipping pallet. Use a 13 mm open-end
wrench to connect the brackets to the outer A or inner B bracket mounting points of the
enclosure. Attach the brackets to secure mounting points in the floor using user-supplied
hardware .
Ground Connection
All the parts of the enclosure are grounded to the frame of the enclosure. Use the enclosure's front or
rear threaded grounding point A and an M6 screw (included) to connect the frame of the enclosure
directly to your facility's earth ground connection with an 8 AWG ( D=3.2 mm ) wire(user-supplied).
Route the ground wire under the enclosure's frame to ensure unhindered door operation.
WARNING: Attach each enclosure to earth ground separately. Do not use the enclosure
without an earth ground connection.
3
FLOOR
1
2
B
A
4

RE SERIES_ RevA 3/5/2022
v
16
Adding or Removing Front and Rear Doors
WARNING: Do not attempt to add or remove doors without assistance.
Removing Door
1 Disconnect the door's ground wire.
2 Open the door until it is perpendicular (90 degrees) to the front of the enclosure.
3 Lift the door from the hinges and remove it from the enclosure.
To Reinstall Door, Reverse Steps 1-3
(Optional) If the enclosure is joined to another enclosure, turn the door back toward the enclosure as
you lift it from the hinges.
Reversing Front Door
WARNING: Do not attempt to reverse the front door without assistance.
1 Remove the screw connecting the ground wire to the inside of the door.
2 Remove the 2 screws connecting the door handle to the door. Remove the door handle.
2
1
2
3
1

RE SERIES_ RevA 3/5/2022
v
17
Reversing Front Door (continued)
3 Remove the screw and washer from the rear of the door handle and remove the latching
mechanism. Rotate the latch washer counter-clockwise 90 degrees and reverse the latch so it
points in the opposite direction, then use the screw and washer to re-attach the latch to the rear
of the door handle.
4 Remove the door by following the steps in the previous section.
5 Remove the door hinges from the enclosure, rotate them 180 degrees and attach them on the
opposite side of the enclosure.
Note: The alternate door hinge attachment points have plastic plugs in the screw holes. Remove
the plugs and insert them in the original door hinge attachment points.
6 Unscrew the 2 hinge mechanisms from the hinge openings inside the door, then reattach each of
them using the set of screw holes immediately opposite their original position.
7 Rotate the door 180 degrees and reinstall it on the enclosure. Remember to connect the ground
wire to the inside of the door, using the attachment point nearest the hinge at the top of the door.
The attachment point is marked with the ground connection symbol: .
8 Reinstall the door handle.
6
4
8
3
5
7

RE SERIES_ RevA 3/5/2022
v
18
Adding or Removing Roof Panel
WARNING: Do not attempt to use the roof panel for weight-bearing purposes other than those explicitly described and approved by Eaton. Do
not attempt to add or remove the roof panel without assistance.
Removing Roof Panel
1 Pull the 2 pins near the rear of the roof panel. While holding the pins, push the roof panel upward.
2 Remove the roof panel tabs A from the roof panel attachment slots B in the enclosure frame.
3 Lift the roof panel from the enclosure.
To Reinstall Roof Panel, Reverse Steps 1-3
Adding or Removing Side Panels
Removing Side Panel
1 Open the latch by sliding it downward.
2 Tilt the top of the panel away from the enclosure.
A
2
1
2
1
3
2
1

RE SERIES_ RevA 3/5/2022
v
19
Adding or Removing Side Panels (continued)
3 Lift the panel away from the brace that supports it.
To Reinstall Side Panel, Reverse Steps 1-3
Adjusting Mounting Rails and Cable Management Rails
WARNING: Do not attempt to adjust rails without assistance. Do not attempt to adjust rails while equipment is installed in the enclosure. Do
not attempt to use rails without screws installed (6 per rail).
The 4 mounting rails are pre-installed to accommodate equipment with a mounting depth of 30 inches (762 mm). Do not adjust the mounting rails unless
your equipment requires a different mounting depth. The front and rear sets of rails can be adjusted independently in ¼-inch (6 mm) increments for
mounting depths between 4 inches (101.6 mm) and 42 inches (1066.8 mm).
1 Each rail is connected to the enclosure with 6 screws - 1 pair at the upper beam A , 1 pair at the
middle beam B and 1 pair at the lower beam C .
2 Remove the screws fastening each of the rear mounting rails to the enclosure. (If adjustment of
the front rails is required, you can also remove the screws from the front rails.)
3 Slide the mounting rails to the desired depth and reattach them using the screws you removed in
Step 2. The rail attachment points are numbered A to help you align each pair of rails at the
same depth.
The depth of the 2 cable management rails can be adjusted using the same method.
8
3
A
C
1
5
3
