HMi Series Instruction Leaflet
Instruction Leaflet IL04802001E Effective May 2010
Contents
Description Page
Preface....................................................... 1
Safety Information................................... 1
General Description................................. 2
Accessories (sold Separately) ............. 3
Unpack and Inspect.................................. 3
Hardware Features.................................. 4
Dimensions and Cut-Outs....................... 9
Serial Port Pinout ..................................... 11
Accessing the Setup Screens .............. 14
Apply Power .............................................. 14
Specifications ........................................... 15

HMi Series Instruction Leaflet
Safety Information
Preface
This instruction leaflet will be helpful in
the installation, wiring and inspection of
the Eaton HMiseries of operator
interface products. Before using the
product, please read the entire
document and understand all safety
precautions before proceeding with
installation, wiring and operation.
Carefully note and observe the
following safety precautions when
receiving, inspecting, installing, operating,
maintaining and troubleshooting. The
following words, WARNING AND
CAUTION, are used to mark safety
precautions when using the Eaton
product. Failure to observe these
precautions may void the warranty!
Please observe the following
precautions: Installation
Install the product in a clean and
dry location free from corrosive
and flammable gases or liquids.
Ensure that all installation, wiring,
operation, communication,
grounding, maintenance, and
inspection warnings and guidelines
are followed.
For information on HMisoftware
installation and operation, please
refer to the HMisoft user manual.
WARNING
Comply with instructions for
installation. Otherwise it may cause
equipment damage.
Do not install the product in a
location that is outside the stated
specification for the device.
Failure to observe this caution may
result in electric shock, fire or
personal injury.
Operation
For technical support, please contact
the EatonCare at 877-ETN CARE
(386-2273) or visit the Eaton website at
http://www.eaton.com/electrical.
WARNING
HMiusers must use HMisoft to
create and edit applications.
Do not modify wiring during
operation or it may result in electric
shock or personal injury.
Never use a hard or pointed object
to hit or strike the screen because
doing so may cause damage and
void the warranty.
Wiring
WARNING
Connect the ground terminals to a
class-3 ground (ground resistance
should not exceed 100Ω). Improper
grounding may result in electric
shock or fire.
EATON CORPORATION www.eaton.com 1

HMi Series Instruction Leaflet
Wiring Method General Description
WARNING
Remove the terminal block from the
HMi before wiring.
Insert only one wire into each
terminal on the terminal block.
Never use force to remove the
terminals or wires as this may cause
damage and void the warranty.
Positioned between the ELC graphics
panels and the XV series of operator
interfaces, HMiis the work horse of the
industry. The units feature touchscreen
and function keys to suit all
environments and applications. They
range in screen size and color to fit
available space and application needs.
All units offer RS-232, RS-485 and
RS-422 communications. The 6", 8" and
10" units also offer Ethernet
communication options.
Communication Wiring
WARNING
Comply with communication wiring
and grounding specifications for the
network being used.
• Analog Touchscreen
• Auto-scale application from 10" to 4"
• Screen Saver
Maintenance and Inspection
• Pop-up Screens
WARNING
Do not touch any internal or
exposed electrical parts of the
device or electrical shock may
result.
Do not remove the operator
interface while power is applied or
electrical shock may result.
Wait at least 10 seconds after
power has been removed before
touching terminals, wiring and/or
inspecting because an electrical
charge with hazardous voltages
may remain in the unit after power
has been removed.
Turn the power off before changing
the backup battery and check
system settings after installing
the new battery. All system settings
will be return to the default settings.
Be sure the ventilation holes are not
obstructed during operation or the
operator interface may overheat
and malfunction.
• Animated Graphics
• Clock Synchronization
• Data Archiving
• Multi-Language
• 8 Levels of Security
• Embedded Logic for use with Local I/O
• Ethernet Modbus TCP Communication
Drivers
• Ethernet, COMM port and USB Upload /
Download
• USB Ports for Data Storage
• 3 Serial Ports
• Up to 4 Simultaneous Protocols
• Math and Logic Functions
• Recipes
• Macro Capability
• Alarm/Event Recording and Viewing
• Real-time and Historical Trending
• On and Off-line Simulation
EATON CORPORATION www.eaton.com 2

HMi Series Instruction Leaflet
EATON CORPORATION www.eaton.com 3
Accessories (sold
Separately)
• ELC-CBPCELC1 — 1 meter cable to
connect between the HMiand Eaton Logic
Controller (ELC)
• HMIEC0806 — 8 DC In, 6 Relay Outputs
expansion module for local logic
• HMIEC1612 — 16 DC In, 12 Relay Outputs
expansion module for local logic
• HMIECENT — Ethernet expansion card
for Modbus TCP communications and
application upload/download
• ELC-PS01 — 1 amp 24V DC power
supply
• ELC-PS02 — 2 amp 24V DC power
supply
• HMI-SPKIT — Spare Parts Kit for HMi
Operator Interface
• HMI04-GASKET — 2 Spare Gaskets
for 4" HMiunits
• HMI06-GASKET — 2 Spare Gaskets
for 6" HMiunits
• HMI08-GASKET — 2 Spare Gaskets
for 8" HMiunits
• HMI10-GASKET — 2 Spare Gaskets
for 10" HMiunits
Unpack and Inspect
Included with the HMiare:
• Panel Mounting clips (number of clips
varies depending on the size of the unit).
• DB9 gender changer for easy connection
to the Eaton Logic Controller (ELC).
• 3-pin 24V DC power connector.

HMi Series Instruction Leaflet
Hardware Features
4” HMi(HMI04BU/HMI04CU)
A Power Input Terminal
B COM2
C COM1(Note)
D USB
E Startup Switch
UP position - Run Mode
DOWN position - Boot Menu
NOTE
For simultaneous communications, wire one DB9 connector for COM1 and COM3
according to the pinout diagram in this document.
EATON CORPORATION www.eaton.com 4

HMi Series Instruction Leaflet
6” HMi(HMI06CU)
A Power Input Terminal
B COM2(Note)
C COM1
D Battery Cover
E USB Host
F USB Client
G System Key
NOTE
For simultaneous communications, wire one DB9 connector for COM2 and COM3
according to the pinout diagram in this document.
EATON CORPORATION www.eaton.com 5

HMi Series Instruction Leaflet
6” HMi(HMI06BE/HMI06GE/HMI06CE)
A Power Input Terminal
B Expansion Slot
C Smart Memory Card Slot
D COM2(Note)
E COM1
F USB
NOTE
For simultaneous communications, wire one DB9 connector for COM2 and COM3
according to the pinout diagram in this document.
EATON CORPORATION www.eaton.com 6

HMi Series Instruction Leaflet
8” HMi(HMI08CE)
A Power Input Terminal
B Expansion Slot
C Smart Memory Card Slot
D COM2(Note)
E COM 1
F USB
G Battery Cover
NOTE
For simultaneous communications, wire one DB9 connector for COM2 and COM3
according to the pinout diagram in this document.
EATON CORPORATION www.eaton.com 7

HMi Series Instruction Leaflet
10” HMi(HMI10CE)
A Power Input Terminal
B Expansion Slot
C Smart Memory Card Slot
D COM2(Note)
E COM 1
F USB
G Battery Cover
NOTE
For simultaneous communications, wire one DB9 connector for COM2 and COM3
according to the pinout diagram in this document.
EATON CORPORATION www.eaton.com 8

HMi Series Instruction Leaflet
Dimensions and Cut-Outs
4” HMi(HMI04BU/HMI04CU)
6” HMi(HMI06BE/HMI06GE/HMI06CE/HMI06CU)
EATON CORPORATION www.eaton.com 9

HMi Series Instruction Leaflet
8” HMi(HMI08CE)
10” HMi(HMI10CE)
EATON CORPORATION www.eaton.com 10

HMi Series Instruction Leaflet
Serial Port Pinout
For 4” (HMI04BU/HMI04CU)
COM1 and COM3 are RS-232 only COM2
DB 9 Pinout for COM1 and COM3 RS-232
COM3 Not Used COM3 Used
PIN COM1 COM3 COM1 COM3
1
2 RX RX
3 TX TX
4
5 GND GND GND
6
7 RTS TX
8 CTS RX
9
Not Used
Note: Blank=No connection.
COM2 Pinout for
RS-422 & RS-485
PIN RS-422 RS-485
G GND GND
T+ TX+ TX+
T- TX- TX-
R+ RX+ RX+
R- RX- RX-
Note: Blank=No connection.
Note: For RS-485 Connect TX+ to RX+ and
TX- to RX-.
EATON CORPORATION www.eaton.com 11

HMi Series Instruction Leaflet
For 6” (HMI06CU)
COM1 is RS-232 only COM2 and COM3
DB 9 Pinout for COM1 RS-232
PIN COM1
1
2 RX
3 TX
4
5 GND
6
7 RTS
8 CTS
9
Note: Blank=No connection.
Note: HMI06CU supports RS-232 flow control.
DB 9 Pinout for COM2 and COM3
RS-232 RS-232 RS-485
COM3 Not Used COM3 Used
PIN
COM2 COM3 COM2 COM3
1
2 RX RX
3 TX TX
4 D+
5 GND GND GND
6
7
8
9
Not Used
D-
COM2 and COM3
DB 9 Pinout for COM2 and COM3
RS-485
COM3 Not Used COM3 Used
PIN
COM2 COM3 COM2 COM3
1 D+ D+
2
3
4 D+
5 GND GND GND
6 D- D-
7
8
9
Not Used
D-
DB 9 Pinout for COM2 and COM3
RS-232 RS-23
2
RS-42
2
COM3 Not Used COM3 Used
PIN
COM2 COM3 COM2 COM3
1 TX+
2 RX RX
3 TX TX
4 RX+
5 GND GND GND
6 TX-
7
8
9
Not Used
RX-
Note: Blank=No connection.
Note: HMI06CU does not support RS-422 flow control.
EATON CORPORATION www.eaton.com 12

HMi Series Instruction Leaflet
EATON CORPORATION www.eaton.com 13
For 6" (HMI06BE, HMI06GE, HMI06CE), 8" (HMI08CE), and 10" (HMI10CE)
COM1 is RS-232 only COM2 and COM3
DB 9 Pinout for COM1 RS-232
PIN COM1
1
2 RX
3 TX
4
5 GND
6
7 RTS
8 CTS
9
Note: Blank=No connection.
DB 9 Pinout for COM2 and COM3
RS-232
COM3 Not Used COM3 Used
PIN
COM2 COM3 COM2 COM3
1
2 RX RX
3 TX TX
4
5 GND GND GND
6
7 RTS TX
8 CTS RX
9
Not Used
COM2 and COM3
DB 9 Pinout for COM2 and COM3
RS-485
COM3 Not Used COM3 Used
PIN
COM2 COM3 COM2 COM3
1 RX- RX-
2 RX+ RX+
3 TX+ TX+
4 TX- TX-
5 GND GND GND
6 TX-
7 TX+
8 RX+
9
Not Used
RX-
DB 9 Pinout for COM2 and COM3
RS-422
COM3 Not Used COM3 Used
PIN
COM2 COM3 COM2 COM3
1 RX- RX-
2 RX+ RX+
3 TX+ TX+
4 TX- TX-
5 GND GND GND
6 RTS- TX-
7 RTS+ TX+
8 CTS+ RX+
9 CTS-
Not Used
RX-
Note: Blank=No connection.
Note: For RS-485 Connect TX+ to RX+ and TX- to RX-.

HMi Series Instruction Leaflet
Accessing the
Setup Screens Apply Power
For 4” (HMI04BU/HMI04CU),
To bring up the System menu, press and
hold the SYS key for several seconds
located on the front for those models
with function buttons and on the back of
the unit for all other models. The
following may be changed from the
System menu:
6” (HMI06BE/HMI06GE/HMI06CE),
8” (HMI08CE), 10” (HMI10CE)
Recommended wiring:
Type
Wire
Gauge
(AWG)
Stripped
length Torque
Solid 28 ~ 12 7 ~ 8 mm 4.5 lb-in
Stranded 28 ~ 12 7 ~ 8 mm 4.5 lb-in
• Date & Time
• Touchscreen settings and calibration
• Adjust backlight settings
• Select the download method For 6” (HMI06CU)
• COMM port settings Recommended wiring:
Type
Wire
Gauge
(AWG)
Stripped
length Torque
Solid 28 ~ 12 7 ~ 8 mm 4.3 lb-in
Stranded 30 ~ 12 7 ~ 8 mm 4.3 lb-in
• Security
EATON CORPORATION www.eaton.com 14

HMi Series Instruction Leaflet
Specifications
MODEL HMI04BU HMI04CU HMI06BE HMI06GE
Display Type STN TFT LCD STN FSTN
Display Color 8 Blues 65536 Colors 8 Blues 16 Grays
Screen Pixels 320 x 240 pixels
LCD Module LED Back Light LED Back Light CCFL Back Light
Back-light Life
About 10,000
hours half-life at
25oC (Note 1)
About 30,000
hours half-life at
25oC (Note 1)
About 50,000 hours half-life at
25oC (Note 1)
Display Size 3.8” (78.8 x
59.6mm)
3.5” (70.08 x
52.56mm) 5.7” (118.2 x 89.4mm)
Operation System Real Time OS
MCU 32-bit RISC Micro-controller / 206.4MHz
Memory
Program
History
Recipe
Alarm
Data Register
Volatile
Non-volatile
1M
120K
64K(Note 2)
4K
64K
1K
3M
120K
64K(Note 2)
4K
64K
1K
3M
360K
128K
16K
64K
1K
3M
360K
128K
16K
64K
1K
Backup Memory
(Bytes) 128K 128K 512K
SM Card 
EXT.
Memory USB Disk 
Extension Interface 
USB Host / Client 1 Host (Note 3) Ver 1.1 / 1 Client Ver 1.1
COM1 RS-232
COM2 RS-422 / RS-485 RS-232 / RS-422 / RS-485
Serial
COM
Port COM3 RS-232 RS-232 / RS-422 / RS-485
Function Key User defined key x 4 + System key x 1
Perpetual Calendar
(RTC) Built-in
Cooling Method Natural air circulation
Safety Approval
(Waterproof for
front panel)
IP65 / NEMA 4X (indoor only)/ CE / UL / cUL / C-Tick
Operation Voltage DC +24V (-10% ~ +15%) (Please use isolated power supply) (Note 4)
EATON CORPORATION www.eaton.com 15

HMi Series Instruction Leaflet
MODEL HMI04BU HMI04CU HMI06BE HMI06GE
Power
Consumption (Note 5) 2.64W 3.36W 7.2W 7.2W
Voltage Endurance AC500V for 1 minute
(between charging (DC24 terminal) and FG terminals)
Operation Temp. 32°F ~ 122°F (0°C ~ 50°C)
Storage Temp. -4°F ~ 140°F (-20°C ~ +60°C)
Ambient Humidity 10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]
Pollution Degree 2
Shock 30G @ 11ms
Vibration Resistance
IEC 61131-2 Compliant
5Hz f≦＜9Hz = Continuous: 1.75mm / Occasional: 3.5mm
9Hz f 150Hz = Continuous: 0.5g / Occasional: 1.0g≦≦
X, Y, Z directions for 10 times
Backup Battery 3V lithium battery CR2032 x 1 / Battery life: 5 years
Backup Battery Life It depends on the temperature used and the conditions of usage, about
3 years or more at 25oC.
Buzzer Multi-Tone Frequency (2K ~ 4K Hz) / 85dB
Dimensions
(W) x (H) x (D) in Inches
(mm)
5.54 x 4.13 x 1.76
(140.8 x 104.8 x 44.8)
7.25 x 5.67 x 1.85
(184.1 x 144.1 x 47)
Panel Cutout
(W) x (H) in Inches (mm)
4.68 x 3.65
(118.8 x 92.8)
6.79 x 5.21
(172.4 x 132.4)
Weight in Lbs. (kg) .69 (.315) .62 (.310) 1.69 (.768)
NIT Rating 100 cd/m2300 cd/m2130 cd/m2
NOTE
1) The half-life of backlight is defined as original luminance being reduced by 50% when the maximum
driving current is supplied to HMi. The life of LED backlight shown is an estimated value under 25oC
normal temperature and humidity conditions.
2) Program memory is used for recipes.
3) USB Host port can provide up to 5V/ 500mA of power.
4) Please use isolated power supply (not applicable for HMI08CE and HMI10CE).
5) The value of the power consumption indicates the electrical power consumed by HMionly without
connecting to any peripheral devices. In order to ensure the normal operation, it is recommended to
use a power supply which the capacity is 1.5 ~2 times the value of the power consumption.
6) For further details, please visit the Eaton website www.eaton.com/electrical.
EATON CORPORATION www.eaton.com 16

HMi Series Instruction Leaflet
MODEL HMI06CE HMI06CU HMI08CE HMI10CE
Display Type STN TFT LCD TFT LCD TFT LCD
Display Color 256 C rsolo 65536 sColor 65536 sColor 65536 sColor
Screen Pixels 320 x 240 pixels 640 x 480 pixels
LCD Module CCFL Back Light LED Back ck Light 2CCFL Back
Lig
Light CCFL Ba ht
Back-light Life
About 50,000
hours half-life at
25oC (Note 1)
About 20,000
hours half-life at
25oC (Note 1)
About 50,000 hours half-life at
25oC (Note 1)
Display Size 5.7” (118.2 x
89.4mm)
5.6” (113.28 x
84.70mm)
8” (162.2 x 10.4” (215.2 x
121.7mm) 162.4mm)
Operation System Real Time OS
MCU
32-bit RISC
Micro-controller
/206.4MHz
32-bit RISC
Micro-controller
/266MHz
32-bit RISC Micro-controller
/206.4MHz
Memory
Program
History
Recipe
Alarm
Data Register
Volatile
Non-volatile
3M 7M 7M 7M
360K
128K
16K
64K
1K
125K
(Note 6)
128K
125K (Note 6)
64K
360K 360K
128K
16K
64K
128K
16K
64K
1K 1K 1K
Back ryup Memo
(Bytes) 128K 128K 512K
SM Card 
EXT.
Memory USB Disk   
Extension Interface 
USB Host / Client 1 Host (N ) Ver 1.1 / 1 Cli Ver 1.1
ote 3 ent
COM1 RS-232
COM2
RS-232 / RS-232 /
RS-422 /
RS-485 RS-485 RS-232 / RS-422 / RS-485
Serial
COM
Port RS-232 /
RS-422 /
RS-485
RS-422 / RS-232 / RS-422 / RS-485
COM3 RS-485
Function Key
Use eyr defined k
x 4 + System
key x 1
N/A
User defined key
x 6 + System
key x 1
User defined key
x 7 + System
key x 1
Perpetual Calendar Built-i
(RTC) n
Cooling Method Natura lationl air circu
EATON CORPORATION www.eaton.com 17

HMi Series Instruction Leaflet
EATON CORPORATION www.eaton.com 18
MODEL HMI06CE HMI06CU HMI08CE HMI10CE
Safety Approval
IP65 / NEMA 4X / CE / UL / cUL / C-Tick
(Waterproof for
front panel)
Operation Voltage DC 0% ~ + ase use i su+24V (-1 15%) (Ple solated power pply) (Note 4)
Power
Consumption (Note 5 3.0W 14W7.2W 15W
)
Voltage Endurance AC500V for 1 minute
(between charging (DC24 terminal) and FG terminals)
Operation Temp. 3 2°F (0°C ~ )2°F ~ 12 50°C
Storage Temp. -4°F )~ 140°F (-20°C ~ +60°C
Ambient Humidity 10% ~ 90% RH [0 ~ 40°C], 10% ~ 55% RH [41 ~ 50°C]
Pollution Degree 2
Shock 30G @ 11ms
Vibration Resistance
IEC 61131-2 Compliant
5Hz f≦＜9Hz = Co ccasional: 3.5mmntinuous: 1.75mm / O
9Hz f 150Hz = C / Occasional: 1.0g≦≦ ontinuous: 0.5g
X, esY, Z directions for 10 tim
Backup Battery 3V lithium battery CR2032 x 1 / Battery life: 5 years
It depen about
Backup Battery Life ds on the temperature used and the conditions of usage,
3 years or more at 25oC.
Buzzer Multi-Tone Frequency (2K ~ 4K Hz) / 85dB
Dimensions
(W) x (H) x (D) in Inches
(mm)
7.25 x 5.67 x 1.85
(184.1 x 144.1 x 47)
9.57 x 7.01 x
2.06
(243.1 x 178.1 x
52.4)
11.70 x 8.74 x
2.01
(297.1 x 222.1
x 51.1)
Panel Cutout
(W) x (H) in Inches (mm)
6.79 x 5.21
(172.4 x 132.4)
9.11 x 6.55
(231.4 x 166.4)
11.2 283 x 8.
(285.2 x 210.2)
Weight in Lbs. (kg) 1.69 (.768) 1.48 (.670) 2.5 7)2 (1.14 3. )79 (1.721
NIT Rating 100 cd/m2200 cd/m2400 cd/m2330 cd/m2
NOTE
1) The half-life of backlight is defined as original g redu hen th
driving current is supplied to HMi. The life of LED backlight shown is an estimated value under 25 C
normal temperature and humidity conditions.
2) Pro m memory is used for recipes.
cal power consumed by HMionly without
mal operation, it is recommended to
value of the power consumption.
luminance bein ced by 50% w e maximum
o
gra
3) USB Host port can provide up to 5V/ 500mA of power.
4) Please use isolated power supply (not applicable for HMI08CE and HMI10CE).
cates the electri5) The value of the power consumption indi
connecting to any peripheral devices. In order to ensure the nor
use a power supply which the capacity is 1.5 ~2 times the
6) A total of 125K Bytes of memory is shared for History and Alarms.
7) For further details, please visit the Eaton website www.eaton.com/electrical.

HMi Series Instruction Leaflet
