Eaton Powerware 9155 User manual

p/n: 164201592
Revision E0
8–15 kVA
User’s Guide
Eaton®® 9155 Parallel UPS

Eaton reserves t e rig t to c ange specifications wit out prior notice. Modbus is a registered trademark of Sc neider Automation, Inc.
MOXA is a registered trademark and MGate is a trademark of MOXA, Inc. Spiralock is a registered trademark of Spiralock Corporation.
KIRK is a registered trademark of Kirk Key Interlock company, LLC, a subsidiary of Halma plc. National Electrical Code and NEC are
registered trademarks of National Fire Protection Association, Inc. ERIFLEX and FLEXIBAR are registered trademark of Erico International
Corporation. All ot er trademarks are property of t eir respective companies.
©Copyrig t 2004-2019 Eaton, Raleig , NC, USA. All rig ts reserved. No part of t is document may be reproduced in any way wit out t e
express written approval of Eaton.
Class A EMC Statements
FCC Part 15
NOTE This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. peration of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
ICES-003
This Class A Interference Causing Equipment meets all requirements of the Canadian Interference
Causing Equipment Regulations ICES 003.
Cet appareil numérique de la classe A respect et outes les exigences du Reglement sur le matériel
brouilleur du Canada.
IEC 62040-2
Some configurations are classified under IEC 62040-2 as “C2 UPS for Unrestricted Sales
Distribution.”
VCCI Notice

Special Sym ols
The following are examples of symbols used on the product to alert you to important information:
Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of
electric shock symbol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead‐acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates.
Phillips and Pozidriv are registered trademarks of Phillips Screw Company.
ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be
reproduced in any way without the express written approval of Eaton Corporation.
RISK OF ELECTRIC SHOCK - Observe t e warning associated wit t e risk of
electric s ock symbol.
Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of
electric shock symbol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead‐acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates.
Phillips and Pozidriv are registered trademarks of Phillips Screw Company.
ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be
reproduced in any way without the express written approval of Eaton Corporation.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual
for additional information, suc as important operating and maintenance instructions.
Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of
electric shock symbol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead‐acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates.
Phillips and Pozidriv are registered trademarks of Phillips Screw Company.
ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be
reproduced in any way without the express written approval of Eaton Corporation.
T is symbol indicates t at you s ould not discard t e product in t e tras . T is
product must be disposed of properly. For more information, contact your local
recycling/reuse or azardous waste center.
Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of
electric shock symbol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead‐acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates.
Phillips and Pozidriv are registered trademarks of Phillips Screw Company.
ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be
reproduced in any way without the express written approval of Eaton Corporation.
T is symbol indicates t at you s ould not discard waste electrical or electronic
equipment (WEEE) in t e tras . For proper disposal, contact your local recycling/reuse
or azardous waste center.
Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric
shock symbol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead-acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
ON - Indicates that the switch is in the ON position.
OFF - Indicates that the switch is in the OFF position.
PHASE - The word “phase.”
ON - Indicates t at t e switc is in t e ON position.
Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric
shock symbol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead-acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
ON - Indicates that the switch is in the ON position.
OFF - Indicates that the switch is in the OFF position.
PHASE - The word “phase.”
OFF - Indicates t at t e switc is in t e OFF position.
Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric
shock symbol.
CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead-acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.
ON - Indicates that the switch is in the ON position.
OFF - Indicates that the switch is in the OFF position.
PHASE - The word “phase.”
PHASE - T e word “p ase.”
!
IMPORTANT
To ensure you have the most up-to-date content and information for this product, please review the
latest manual revision on our website, www.eaton.com/9155.

Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0 v
TTaabbllee ooff CCoonntteennttss
11 IInnttrroodduuccttiioonn....................................................................................................................................................................................................................................................................................................11
1.1 ptions and Accessories..............................................................................................................................2
1.1.1 Parallel Tie Cabinet................................................................................................................................2
1.1.2 Maintenance Bypass Module (MBM) ........................................................................................................2
1.1.3 Power Distribution Module (PDM) ............................................................................................................2
1.1.4 Bypass Power Module...........................................................................................................................2
1.1.5 Input Isolation Transformer .....................................................................................................................2
1.1.6 Seismic Kit ..........................................................................................................................................2
1.2 Using This Manual ......................................................................................................................................3
1.3 Conventions Used in This Manual ..................................................................................................................3
1.4 For More Information ..................................................................................................................................3
1.5 Getting Help..............................................................................................................................................4
1.6 Equipment Registration ...............................................................................................................................4
22 SSaaffeettyy WWaarrnniinnggss........................................................................................................................................................................................................................................................................................55
2.1 Consignes de Sécurité.................................................................................................................................6
2.1.1 C NSIGNES DE SÉCURITÉ IMP RTANTES C NSERVER CES INSTRUCTI NS ...............................................6
2.2 Advertencias de Seguridad ...........................................................................................................................7
2.2.1 INSTRUCCI NES DE SEGURIDAD IMP RTANTES GUARDE ESTAS INSTRUCCI NES .....................................7
33 UUPPSS IInnssttaallllaattiioonn PPllaann aanndd UUnnppaacckkiinngg ............................................................................................................................................................................................................................99
3.1 Creating an Installation Plan ..........................................................................................................................9
3.2 Preparing the Site .......................................................................................................................................9
3.2.1 Environmental and Installation Considerations ............................................................................................9
3.3 UPS System Power Wiring Preparation ......................................................................................................... 11
3.4 Inspecting and Unpacking the Equipment ...................................................................................................... 13
PPaarraalllleell UUPPSS SSyysstteemm IInnssttaallllaattiioonn...................................................................................................................................................................................................................................... 1155
4.1 Preliminary Installation Information............................................................................................................... 15
4.2 Unloading the UPS Cabinet from the Pallet..................................................................................................... 15
4.3 Parallel Installation .................................................................................................................................... 18
4.4 Installing ptions...................................................................................................................................... 28
4.4.1 Powerware Hot Sync CAN Bridge Card ................................................................................................... 29
4.5 Stabilizing the Cabinet ............................................................................................................................... 35
4.6 Extended Battery Module Installation............................................................................................................ 39
55 UUPPSS OOppeerraattiinngg IInnssttrruuccttiioonnss.................................................................................................................................................................................................................................................... 33
5.1 Control Panel Functions ............................................................................................................................. 43
5.1.1 Changing the Language........................................................................................................................ 44
5.1.2 Display Functions ............................................................................................................................... 44
5.1.3 User Settings..................................................................................................................................... 45
5.2 Parallel UPS Startup .................................................................................................................................. 47

vi Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0
5.3 Configuring the UPS for EBMs .................................................................................................................... 48
5.4 Parallel System Shutdown.......................................................................................................................... 49
5.5 Individual UPS Shutdown ........................................................................................................................... 49
5.6 Restarting the Parallel System .................................................................................................................... 50
5.7 Parallel UPS Bypass peration .................................................................................................................... 50
66 TTrroouubblleesshhoooottiinngg .................................................................................................................................................................................................................................................................................... 5533
6.1 Typical Alarms and Conditions ..................................................................................................................... 53
6.2 Silencing the Alarm ................................................................................................................................... 54
6.3 Service and Support .................................................................................................................................. 54
77 WWaarrrraannttyy ........................................................................................................................................................................................................................................................................................................ 5577
Table of Contents

Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0 vii
LLiisstt ooff FFiigguurreess
Figure 1. The Eaton 9155 UPS and EBM (2-High Cabinets Shown) ........................................................................1
Figure 2. Removing the Stabilizing Bracket Bolts ............................................................................................. 16
Figure 3. Removing the Brackets and Shipping Pad.......................................................................................... 17
Figure 4. Unloading the Cabinet................................................................................................................... 18
Figure 5. Removing the Pallet...................................................................................................................... 18
Figure 6. Parallel Tie Cabinet Front Cover....................................................................................................... 20
Figure 7. Internal Cover.............................................................................................................................. 21
Figure 8. Parallel Bypass Breaker ................................................................................................................. 22
Figure 9. UPS Rear View (2-High Shown) ....................................................................................................... 23
Figure 10. UPS Terminal Block ..................................................................................................................... 24
Figure 11. UPS to Parallel Tie Cabinet Wiring.................................................................................................... 25
Figure 12. Load Connections ........................................................................................................................ 26
Figure 13. Parallel AC Input Wiring ................................................................................................................. 27
Figure 14. Parallel Wiring Diagram ................................................................................................................. 28
Figure 15. Communication ptions and Control Terminals .................................................................................. 29
Figure 16. Powerware Hot Sync CAN Bridge Card............................................................................................. 30
Figure 17. Removing the Front Covers............................................................................................................ 30
Figure 18. Setting the CAN Bridge Card Jumper J7 (Side View) ............................................................................ 31
Figure 19. CAN Bridge Card Wiring ................................................................................................................ 33
Figure 20. Removing Knockout Tabs .............................................................................................................. 34
Figure 21. Reinstalling the Front Covers .......................................................................................................... 35
Figure 22. Lowering the Leveling Feet ............................................................................................................ 36
Figure 23. Stabilizing Bracket with ne Cabinet ................................................................................................ 37
Figure 24. Stabilizing Bracket with Two Cabinets .............................................................................................. 38
Figure 25. Stabilizing Bracket with Three Cabinets............................................................................................. 39
Figure 26. Typical EBM Installation (2-High Cabinets Shown) ............................................................................... 40
Figure 27. Front Ground Strap Installation (2-High Cabinets Shown) ...................................................................... 41
Figure 28. Eaton UPS Control Panel................................................................................................................ 43

viii Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0
List of Figures

Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0 ix
LLiisstt ooff TTaabblleess
Table 1. Air Conditioning or Ventilation Requirements During Full Load peration................................................... 10
Table 2. UPS Cabinet Weights..................................................................................................................... 11
Table 3. UPS Cabinet Clearances ................................................................................................................. 11
Table 4. UPS Terminal Block (TB1) Wiring ...................................................................................................... 12
Table 5. Input Isolation Transformer Terminal Block Wiring ................................................................................ 12
Table 6. MBM/PDM Terminal Block (TB10) Wiring ........................................................................................... 13
Table 7. Circuit Breaker Ratings ................................................................................................................... 19
Table 8. Recommended Terminal Block Wiring ............................................................................................... 23
Table 9. Menu Map for Display Functions ...................................................................................................... 44
Table 10. User Settings................................................................................................................................ 45

x Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0
List of Tables

Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0 1
CChhaapptteerr 11 IInnttrroodduuccttiioonn
A parallel system with up to three uninterruptible power supplies (UPSs) can be installed to provide a parallel
capacity and/or redundant system. This load sharing system provides more capacity than a single UPS and can
provide backup, depending on the load and configuration. In addition, when one UPS is taken out of service for
maintenance or is not operating properly, a redundant UPS continues to supply uninterrupted power to the
critical load. A parallel Eaton®Powerware Hot Sync®Controller Area Network (CAN) Bridge Card provides
connectivity for system metering and operational mode control. The parallel system consists of two or three
UPSs, each with a CAN Bridge Card and a parallel tie cabinet.
Figure 1 shows the Eaton 9155 UPS and an optional Extended Battery Module (EBM).
Figure 1. The Eaton 9155 UPS and EBM (2-High Ca inets Shown)
Eaton 9155 EBM
UPS
Providing outstanding performance and reliability, the Eaton 9155's unique benefits including the following:
• nline UPS design with pure sine wave output. The UPS filters and regulates incoming AC power and
provides consistent power to your equipment without draining the battery.
• More wattage in less space with a 0.9 power factor—protecting more equipment and leaving more room
for expansion.
• Support for Powerware Hot Sync®paralleling of multiple modules for redundancy or extra capacity.
• Input current total harmonic distortion (THD) of less than five percent, using active input power factor
correction.
• ABM®technology that uses advanced battery management to increase battery service life, optimize
recharge time, and provide a warning before the end of useful battery life.
• Start-on-battery capability for powering up the UPS even if utility power is not available.
• Up to four hours of extended runtime with added EBMs.

2 Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0
• Emergency shutdown control through the remote emergency power-off (REP ) port.
• Standard communication options with a DB-9 serial port, relay output contacts, and programmable signal
inputs.
• ptional X-Slot®cards with enhanced communication capabilities for increased power protection and
control.
• Advanced power management with the Software Suite CD for graceful shutdowns and power monitoring.
• Backed by worldwide agency approvals.
11..11 OOppttiioonnss aanndd AAcccceessssoorriieess
The following options for the Eaton 9155 are available:
11..11..11 PPaarraalllleell TTiiee CCaabbiinneett
The parallel tie cabinet is used to connect up to three UPSs providing parallel capacity and/or redundant system.
This load sharing system provides more capacity than a single UPS and can provide backup, depending on the
load and configuration. In addition, when one UPS is taken out of service for maintenance or is not operating
properly, a redundant UPS continues to supply uninterrupted power to the critical load. A parallel Powerware
Hot Sync Controller Area Network (CAN) Bridge Card provides connectivity for system metering and
operational mode control. The parallel system consists of two to three UPSs, each with a parallel CAN Bridge
Card, and a parallel tie cabinet.
11..11..22 MMaaiinntteennaannccee BByyppaassss MMoodduullee ((MMBBMM))
The optional MBM is installed on the UPS rear panel and is used to bypass the UPS during maintenance or
servicing. The maintenance bypass switch on the MBM provides a Make-Before-Break (MBB) wrap-around
bypass for UPS service without shutting down the load.
11..11..33 PPoowweerr DDiissttrriibbuuttiioonn MMoodduullee ((PPDDMM))
The optional PDM provides the same functionality as the MBM and also comes equipped with several different
types of output receptacles.
11..11.. BByyppaassss PPoowweerr MMoodduullee
The Eaton Bypass Power Module (BPM) is designed to be a maintenance bypass switch that also contains
flexible output power distribution and mounting options.
The BPM provides added reliability to Eaton uninterruptable power supply (UPS) systems by ensuring
seamless, uninterrupted, no-break transfer as well as a lock-out/tag-out (L T ) feature to ensure the greatest
safety for UPS technicians and electricians. The BPM also offers output distribution in order to simplify wiring in
a rackmount IT environment, potentially removing the need for a panelboard, breakers, and conduit for
distribution.
11..11..55 IInnppuutt IIssoollaattiioonn TTrraannssffoorrmmeerr
The optional input isolation transformer is located at the bottom of a 3-high UPS model. The input isolation
transformer provides a neutral from a 208V or 240V input source with 240V output and can be wired to the UPS
or to an MBM/PDM.
11..11..66 SSeeiissmmiicc KKiitt
The optional seismic kit secures the UPS and optional EBMs for Zone 4 seismic installations.
Introduction

Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0 3
11..22 UUssiinngg TThhiiss MMaannuuaall
This manual describes how to install and operate the Eaton 9155 UPS. Read and understand the procedures
described in this manual to ensure trouble-free installation and operation. In particular, be thoroughly familiar
with the REP procedure or the L AD FF procedure, see Chapter 5 UPS Operating Instructions.
The information in this manual is divided into sections and chapters. The system, options, and accessories
being installed dictate which parts of this manual should be read. At a minimum, Chapter 1 Introduction
through Chapter 4 Parallel UPS System Installation and Chapter 5 UPS Operating Instructions should be
examined.
Read through each procedure before beginning the work. Perform only those procedures that apply to the UPS
system being installed or operated.
11..33 CCoonnvveennttiioonnss UUsseedd iinn TThhiiss MMaannuuaall
This manual uses these type conventions:
•Bold type highlights important concepts in discussions, key terms in procedures, and menu options, or
represents a command or option that you type or enter at a prompt.
• Italic type highlights notes and new terms where they are defined.
•Screen type represents information that appears on the screen or LCD.
Icon Descr pt on
Note Information notes call attention to important features or instructions.
[Keys] Brackets are used w en referring to a specific key, suc as [Enter] or [Ctrl].
In this manual, the term UPS refers only to the UPS cabinet and its internal elements. The term UPS system
refers to the entire power protection system – the UPS cabinet, an external battery system, and options or
accessories installed.
The term line-up-and-match refers to accessory cabinets that are physically located adjacent to the UPS. The
term standalone refers to accessory cabinets that are located separate from the UPS.
Left and right side notations are referenced standing in front of the cabinet.
11.. FFoorr MMoorree IInnffoorrmmaattiioonn
Refer to the Eaton 9155 UPS 8-15 kVA User’s uide for the following additional information:
• Installation instructions, including site preparation, planning for installation, wiring and safety information,
and detailed illustrations of cabinets with dimensional and connection point drawings
• peration, including breakers, standard features and optional accessories, procedures for using the bypass
functions, and information about maintenance
Refer to the Eaton Bypass Power Module (BPM) User’s uide for the following additional information:
• Installation instructions, wiring and safety information, and detailed illustrations with dimensional and
connection point drawings
• peration, standard features and information about maintenance
Refer to the Eaton Remote Monitoring Device (RMD) Installation and Operation Manual for additional
installation and operating instructions.
• Visit www.eaton.com/powerquality or contact an Eaton service representative for information on how to
obtain copies of these manuals.
Introduction

4 Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0
11..55 GGeettttiinngg HHeellpp
If help is needed with any of the following:
• Scheduling initial startup
• Regional locations and telephone numbers
• A question about any of the information in this manual
• A question this manual does not answer
Please call the Customer Reliability Center at:
United States: 1-800-843-9433
Canada: 1-800-461-9166 ext 260
All ot er countries: Call your local serv ce representat ve
Please have the following information ready when you call for service:
• Model number
• Serial number
• Firmware version number
• Date of failure or problem
• Symptoms of failure or problem
• Customer return address and contact information
Please use the following e-mail address for manual comments, suggestions, or to report an error in this
manual:
[email protected]
11..66 EEqquuiippmmeenntt RReeggiissttrraattiioonn
Please visit www.eaton.com/pq/register to register your new Eaton UPS / Eaton UPS Accessory.
Model Num er:
Serial Num er:
Introduction

Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0 5
CChhaapptteerr 22 SSaaffeettyy WWaarrnniinnggss
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS
This manual contains important instructions that you should follow during installation and maintenance of the
UPS and batteries. Please read all instructions before operating the equipment and save this manual for future
reference.
DANGER
This UPS contains LETHAL V LTAGES. All repairs and service should be performed by AUTH RIZED SERVICE
PERS NNEL NLY. There are N USER SERVICEABLE PARTS inside the UPS.
WARNING
• This UPS contains its own energy source (batteries). The UPS output may carry live voltage even when the
UPS is not connected to an AC supply.
• To reduce the risk of fire or electric shock, install this UPS in a temperature and humidity controlled, indoor
environment, free of conductive contaminants. Ambient temperature must not exceed 40°C (104°F). Do
not operate near water or excessive humidity (95% maximum).
• To reduce the risk of fire, connect only to a circuit provided with 100 amperes maximum branch circuit
overcurrent protection in accordance with the National Electrical Code®(NEC®), ANSI/NFPA 70.
• utput overcurrent protection and disconnect switch must be provided by others.
CAUTION
• Batteries can present a risk of electrical shock or burn from high short circuit current. bserve proper
precautions. Servicing should be performed by qualified service personnel knowledgeable of batteries and
required precautions. Keep unauthorized personnel away from batteries.
• Proper disposal of batteries is required. Refer to your local codes for disposal requirements.
• Never dispose of batteries in a fire. Batteries may explode when exposed to flame.

6 Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0
22..11 CCoonnssiiggnneess ddee SSééccuurriittéé
22..11..11 CCOONNSSIIGGNNEESS DDEE SSÉÉCCUURRIITTÉÉ IIMMPPOORRTTAANNTTEESS CCOONNSSEERRVVEERR CCEESS IINNSSTTRRUUCCTTIIOONNSS
!
IMPORTANT
Ce manuel comporte des instructions importantes que vous êtes invité à suivre lors de toute procédure
d'installation et de maintenance des batteries et de l'onduleur. Veuillez consulter entièrement ces instructions
avant de faire fonctionner l'équipement et conserver ce manuel afin de pouvoir vous y reporter ultérieurement.
DANGER!
Cet onduleur contient des TENSI NS M RTELLES. Toute opération d'entretien et de réparation doit être
EXCLUSIVEMENT C NFIÉE A UN PERS NNEL QUALIFIÉ AGRÉÉ. AUCUNE PIÈCE RÉPARABLE PAR
L'UTILISATEUR ne se trouve dans l'onduleur.
AVERTISSEMENT!
• Cet onduleur renferme sa propre source d'énergie (batteries). Les prises de sortie peuvent être sous
tension même lorsque l'onduleur n'est pas branché sur le secteur.
• Pour réduire les risques d'incendie et de décharge électrique, installer l'onduleur uniquement à l'intérieur,
dans un lieu dépourvu de matériaux conducteurs, où la température et l'humidité ambiantes sont
contrôlées. La température ambiante ne doit pas dépasser 40 °C. Ne pas utiliser à proximité d'eau ou dans
une atmosphère excessivement humide (95 % maximum).
• La protection contre une surintensité pour le(s) circuit(s) de sortie de courant alternatif doit être fournie par
un autre fournisseur.
• Les interrupteurs de déconnexion convenables pour le(s) circuit(s) de sortie de courant alternatif doivent
être fournie par un autre fournisseur.
ATTENTION!
• Les batteries peuvent présenter un risque de décharge électrique ou de brûlure par des courts-circuits de
haute intensité. Prendre les précautions nécessaires.
• Une mise au rebut réglementaire des batteries est obligatoire. Consulter les règlements en vigueur dans
votre localité.
• Ne jamais jeter les batteries au feu. L'exposition aux flammes risque de les faire exploser.
Safety Warnings

Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0 7
22..22 AAddvveerrtteenncciiaass ddee SSeegguurriiddaadd
22..22..11 IINNSSTTRRUUCCCCIIOONNEESS DDEE SSEEGGUURRIIDDAADD IIMMPPOORRTTAANNTTEESS GGUUAARRDDEE EESSTTAASS IINNSSTTRRUUCCCCIIOONNEESS
!
IMPORTANT
Este manual contiene instrucciones importantes que debe seguir durante la instalación y el mantenimiento del
SIE y de las baterías. Por favor, lea todas las instrucciones antes de poner en funcionamiento el equipo y
guarde este manual para referencia en el futuro.
PELIGRO
Este SIE contiene V LTAJES M RTALES. Todas las reparaciones y el servicio técnico deben ser efectuados
S LAMENTE P R PERS NAL DE SERVICI TÉCNIC AUT RIZAD . No hay NINGUNA PARTE QUE EL
USUARI PUEDA REPARAR dentro del SIE.
WARNING
• Este SIE contiene su propia fuente de energía (las baterías). Los receptáculos de salida pueden transmitir
corriente eléctrica aun cuando el SIE no esté conectado a un suministro de corriente alterna (c.a.).
• Para reducir el riesgo de incendio o de choque eléctrico, instale este SIE en un lugar cubierto, con
temperatura y humedad controladas, libre de contaminantes conductores. La temperatura ambiente no
debe exceder los 40°C. No trabaje cerca del agua o con humedad excesiva (95% máximo).
• La protección contra exceso de corriente para el/los circuito(s) de CA de salida será suministrada por
terceros.
• Los interruptores de desconexión debidamente clasificados para el/los circuito(s) de CA de salida serán
suministrados por terceros.
PRECAUCIÓN
• Las baterías pueden presentar un riesgo de descargas eléctricas o de quemaduras debido a la alta
corriente de cortocircuito. Preste atención a las instrucciones correspondientes.
• Es necesario desechar las baterías de un modo adecuado. Consulte las normas locales para conocer los
requisitos pertinentes.
• Nunca deseche las baterías en el fuego. Las baterías pueden explotar si se las expone a la llama.
Safety Warnings

8 Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0
Safety Warnings

Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0 9
CChhaapptteerr 33 UUPPSS IInnssttaallllaattiioonn PPllaann aanndd UUnnppaacckkiinngg
Use the following asic sequence of steps to install the UPS:
1. Create an installation plan for the UPS system.
2. Prepare your site for the UPS system.
3. Inspect and unpack the UPS cabinet.
4. Unload and install the UPS cabinet, and wire the system.
5. Complete the Installation Checklist.
6. Have authorized service personnel perform preliminary operational checks and start up the system.
The instructions are intended for the chief operator/system supervisor, electrical consultants, and installation
electricians. Local regulations and electrical code must be followed during the UPS installation.
33..11 CCrreeaattiinngg aann IInnssttaallllaattiioonn PPllaann
Before installing the UPS system, read and understand how this manual applies to the system being installed.
Use this chapter’s procedures and illustrations and those in Chapter 4 UPS System Installation to create a
logical plan for installing the system.
33..22 PPrreeppaarriinngg tthhee SSiittee
For the UPS system to operate at peak efficiency, the installation site should meet the environmental
parameters outlined in this manual. The operating environment must meet the weight, clearance, and
environmental requirements specified.
33..22..11 EEnnvviirroonnmmeennttaall aanndd IInnssttaallllaattiioonn CCoonnssiiddeerraattiioonnss
The UPS system installation must meet the following guidelines:
• The system must be installed on a level floor suitable for computer or electronic equipment.
• The system must be operated at an altitude no higher than 1500m (5000 ft) without derating. For additional
assistance with high altitude operation, contact an Eaton service representative (see paragraph
1.5 Getting Help).
• The system must be installed in a temperature and humidity controlled indoor area free of conductive
contaminants.
CAUTION
Do not expose the UPS to overly aggressive environments, like salt mist or corrosive gases. High relative
humidity accelerates the effects of contaminants. The UPS should be installed in a G1 environment (based on
ANSI/ISA S-71.04 classifications). If the UPS is used in a more aggressive environment, it can cause reduced
product life and possibly early failure. If the installation location does not meet the recommended environment,
contact Eaton service representative for further information (see paragraph 1.5 Getting Help).
• The environmental requirements specified below are for the air at the intake ports of the 9155 UPS, and
are the maximum, not to exceed, ratings.
–There shall be at least a 1.8°F (1.0°C) difference between the dry bulb temperature and the wet bulb
temperature, at all times, to maintain a non-condensing environment.
–The maximum rate of temperature change shall be limited to 3°F over 5 minutes (36°F/hour), based on
the ASHRAE Standard 90.1-2013.

10 Eaton 9155 Parallel UPS (8–15 kVA) User’s Guide 164201592—Rev E0
• The newer, more energy efficient data center cooling methods (such as air side economization) can create
much wider ranges of temperature and Relative Humidity (RH) in the UPS room and/or data center. There
are two aspects of this increased operating environment that can, if ignored, create issues.
–ne is the creation of microclimates, which are persistent variations of temperature and/or RH within
a single room. For example one side of the room is always cooler than the other side, no matter the
actual temperature.
–The other aspect is the rate of change of temperature and/or RH, which can occur during transitions
within the cooling system. Examples: changing the mixture ratio of inside versus outside air, or
external changes in the outside air when going from night to day, and back to night.
–When ignored, either one of these aspects can create an undesirable microclimate at the UPS
location. If the environment created by this microclimate exceeds the UPS operating specification, the
UPS reliability, over time, will be reduced. These same environmental extremes will also create
reliability concerns for any servers that are exposed to them.
Failure to follow guidelines may void your warranty.
The basic environmental requirements for operation of the UPS are:
• Ambient Temperature Range: 5–40°C (41–104°F)
• Recommended perating Range: 5–40°C (41–104°F)
• Maximum Relative Humidity: 5–95%, noncondensing
CAUTION
If battery systems are located in the same room as the UPS, the battery manufacturer's environmental
requirements should be followed if they are more stringent than the UPS requirements. perating
temperatures above the recommended range will result in decreased battery life and performance, and may
reduce or void the battery warranty.
The UPS ventilation requirements are shown in Table 1. To allow for future power upgrades, Eaton
recommends using air conditioning or ventilation sized for the fully rated UPS kVA installed instead of the
derated kVA ordered. Sizing the site cooling infrastructure to be capable of cooling the maximum kVA size will
allow a full power rating upgrade without having to modify the infrastructure.
Table 1. A r Cond t on ng or Vent lat on Requ rements Dur ng Full Load Operat on
Model UPS Rating Minimum Required Cooling Air Flow
Eaton 9155 UPS 8–15 kVA 129 liter/sec (274 cfm)
The UPS equipment operating environment must meet the weight requirements shown in Table 2\ and the size
requirements shown in Table 3.
When planning the installation, consider the UPS weight for floor loading. The strength of the installation
surface must be adequate for point and distributed loadings. The approximate weights are shown in the
following table.
UPS Installation Plan and Unpacking
