UXA4403 Quickstart Guide
Carton Contents
•Amplier unit • Output connector x 1 or 2
• Mains power cable • Adhesive rubber feet x 4
• Input connector x 2 • Document pack
• GPIO Socket Connector • Rack Mount Ears (tted) x2
Connection Sockets
Network
Control
Congurable
GPIO
S/PDIF Audio I/O Audio Inputs
Balanced: Euroblock
Unbalanced: RCA Phono.
Congurable
Speaker Outputs
Mains
Power Input
Wireless Network Control Connection Wired Network Control Connection
• The amplier must be switched on before use via its front panel
Standby button. Do not switch on until all required signal and control
connections are made.
• High or low impedance speaker connection options can be selected
independently for each output channel via the conguration web
app
• Analogue input sensitivity can be adjusted independently for each
channel via the conguration web app.
Installation Notes
• Audio I/O routing can be congured via the conguration web app.
• GPIO (General Purpose Input/Output) options can be congured via
the conguration web app.
• Ensure that rack or other conned installation does not restrict
the front to rear airow required for safe and reliable operation
of the amplier. It is important that the 40°C maximum operating
temperature for the amplier is not exceeded.
A mobile, laptop or desktop device with WiFi functionality and a web
browser is required. Follow the steps below.
1. Connect the [Amp Name] amplier to mains power using the
supplied mains cable and switch it on via the front panel Standby
switch. Wait for the front panel WiFi indicator to illuminate green.
2. Use a mobile, laptop or desktop device to search for available WiFi
networks. Connect to,‘[Amp Name] (product serial number)’using the
password,‘password’. The amplier serial number can be found on its
rear panel.
3. Open a mobile, laptop or desktop device web browser and enter
the following IP address: 192.168.4.1. The amplier conguration
web interface page will open in the browser app to enable amplier
conguration as required.
It is strongly recommended that the amplier WiFi password is
changed following initial wireless connection.
A laptop or desktop device with Ethernet functionality, a web browser
and a network scanning app is required. Follow the steps below.
1. Connect the [Amp Name] amplier Network Control socket directly
to a laptop or desktop device - or through a switch.
2. Connect the [Amp Name] amplier to mains power using the
supplied mains cable and and switch it on via the front panel Standby
switch. Wait for the front panel Network indicator to illuminate green
to indicate that the amplier has network connectivity.
3. The default LAN IP address of the amplier is 192.168.64.100.
Congure your laptop or desktop device to a xed IP address in the
same IP range, ex. 192.168.64.10, with Subnet mask 255.255.255.0 (or
prex 24) and set Gateway to 192.168.64.1.
4. Open a laptop or desktop device web browser and enter the
address http://192.168.64.100/ - The amplier conguration web page
interface will open to enable amplier conguration as required.

Tel [phone] | www.eaw.com
2
UXA4403 Quickstart Guide
This symbol is intended to
alert the user to the presence
of uninsulated“dangerous
voltage”within the product’s
enclosure that may be of
sucient magnitude to
constitute a risk
of electric shock to persons.
Ce symbole a pour but d’attirer l’attention de l’utilisateur sur la
présence, à l’intérieur du boîtier de l’appareil, d’une «tension
dangereuse» non isolée, qui pourrait être susamment puissante
pour représenter un risque d’électrocution pour les personnes.
This symbol is intended
to alert the user to the
presence of important
operating and
maintenance (servicing)
instructions in the
literature accompanying
the appliance.
Ce symbole a pour but d’attirer l’attention de l’utilisateur sur la
présence, dans la documentation qui accompagne l’appareil,
d’instructions importantes relatives à son utilisation et sa maintenance
(entretien).
Consignes de sécurité importantes
1. Veuillez lire ces instructions.
2. Conservez ces instructions.
3. Respectez tous les avertissements.
4. Suivez toutes les instructions.
5. N’utilisez pas cet appareil près de l’eau.
6. Nettoyez uniquement avec un chion sec.
7. N’obstruez pas les ouïes de ventilation. Installez l’appareil en
respectant les instructions du fabricant.
8. Éloignez l’appareil des sources de chaleur: radiateurs, bouches de
souage, fours et autres (y compris les amplicateurs).
9. Pour réduire le risque d’électrocution, le cordon d’alimentation
doit être connecté à une prise de courant avec une mise à la terre
de protection.
10. Respectez le dispositif de protection de mise à la terre de la prise
secteur. Une prise polarisée est équipée de deux ches, l’une plus
large que l’autre. Une prise avec borne de terre est équipée de
deux ches et d’une borne de terre. La che large, ou la borne
de terre, est garante de votre sécurité. Si la che secteur fournie
avec l’appareil ne correspond pas à la prise secteur de votre
installation, faites remplacer cette dernière par un électricien.
11. Disposez les câbles de sorte qu’ils ne puissent pas être piétinés,
coincés ou pincés; une attention toute particulière doit être
accordée au niveau des prises secteur et de l’embase secteur de
l’appareil.
12. Ne débranchez pas l’appareil en tirant sur le cordon. Utilisez la
che.
13. Débranchez cet appareil du secteur lors des orages ou des
longues périodes d’inutilisation.
14. Conez toute réparation à un technicien qualié. L’intervention
d’un technicien est nécessaire dans les cas suivants: le cordon
d’alimentation ou la prise secteur sont endommagés, des
corps étrangers ou du liquide se sont introduits dans l’appareil,
l’appareil a été exposé à la pluie ou à l’humidité, l’appareil montre
des signes de dysfonctionnement ou est tombé.
15. Le coupleur de l’appareil, ou la che secteur, est le dispositif de
déconnexion du secteur et doit rester facilement accessible après
l’installation.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation opening. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. To reduce the risk of electrical shock, the power cord shall be
connected to a mains socket outlet with a protective earthing
connection.
10. Do not defeat the safety purpose of the polarized or grounding
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete outlet.
11. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
12. Do not unplug the unit by pulling on the cord, use the plug.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
This equipment must be earthed.
AVIS
RISQUE DE CHOC
ELECTRIQUE.
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Class 2 Wiring
Exposed high voltage on the speaker terminals. Touching the
uninsulated terminals or wiring may result in an unpleasant
sensation
Class 2 Câblage
Haute tension exposeé sur les bornes des haut-parleurs. Toucher
les bornes ou le câblage non isolés peuvent entraîner une
sensation désagréable

Tel [phone] | www.eaw.com 3
UXA4403
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
