EBS LX2NB Assembly instructions

LX2NB Manual v.1.9 Page 1 / 60
GPRS TRANSMITTER
LX2NB
Installation and
programming manual
Version of the manual: v1.9
Date of issue: 2018.06.04
Firmware version: LX2NB-2.5.0
GPRS transmitter configurator version: 1.4.83.1

LX2NB Manual v.1.9 Page 2 / 60
DECLARATION OF COMPLIANCE
We, EBS Sp. z o.o., declare with full responsibility that the present
product meets all requirements provided for in the Directive
1999/5/EC of European Parliament and Council dated 9 March 1999
The copy of the “Declaration of Compliance” can be found at
http://www.ebs.pl/en/certificates/ .
IMPORTANT INFORMATION
Crossed symbol of a trash bin means that at the territory of European
Union, the product, after finishing its useful life, shall be disposed of
in a separate, specially dedicated collection point. It refers to the
equipment itself and its accessories marked with that symbol. The
products shall not be disposed of together with non-sortable
municipal waste.
The content of the document is presented “as is”. The present
document shall not be deemed to be providing any warranties, either express or
implicit, including but not limited to, any implied warranties of merchantability or
fitness for a particular purpose, unless it is required by relevant law. The
manufacturer reserves the right to amend the present document or withdraw it any
time, without notice.
The manufacturer of the equipment promotes the sustainable development policy. It
reserves the right to modify and improve any functions of the product described in
the present document without previous notice.
The availability of particular functionalities will depend on the software version of
the equipment. Details can be found at the nearest dealer of the equipment.
In no event, the Manufacturer shall be held liable for any loss of data or loss of
profits or any specific, incidental, consequential or indirect damages caused in any
way.
MANUFACTURER
EBS Sp. z o. o.
59 Bronislawa Czecha St.
04-555 Warsaw, POLAND
E-mail : [email protected]
Technical support: [email protected]
Webpage : www.ebs.pl

LX2NB Manual v.1.9 Page 3 / 60
TABLE OF CONTENTS
1. INTRODUCTION............................................................................................... 6
2. FUNCTIONAL AND TECHNICAL PARAMETERS ....................................................... 7
3. ASSEMBLY AND WIRING................................................................................... 8
3.1. LX2NB TRANSMITTER................................................................................ 8
3.1.1. Wireless module antenna connector ..................................................... 9
3.2. INPUT CONFIGURATION .......................................................................... 11
3.3. REMOTE CONTROL CONFIGURATION (ONLY LX2NB-5R VERSION) ................ 12
3.4. LX-ZAS POWER SUPPLY........................................................................... 12
4. QUICK START PROCEDURE ............................................................................. 14
5. OPERATION .................................................................................................. 15
6. CONFIGURATION PROGRAM ............................................................................ 17
6.1. INITIAL REMARKS .................................................................................. 17
6.2. COMPUTER –REQUIREMENTS .................................................................. 17
6.2.1. File->New ....................................................................................... 18
6.2.2. File->Open...................................................................................... 18
6.2.3. File->Save ...................................................................................... 18
6.2.4. File->Language ............................................................................... 19
6.2.5. File->Connections ............................................................................ 19
6.2.5.1. Local connection........................................................................... 19
6.2.5.2. Remote connection ....................................................................... 20
6.2.6. File->Automatic device settings backup .............................................. 22
6.2.7. File->Exit........................................................................................ 22
6.2.8. Operations->Read ........................................................................... 22
6.2.9. Operations->Send ........................................................................... 22
6.2.10. Operations->Restore default settings ................................................. 23
6.2.11. Operations->System events history ................................................... 23
6.2.12. Operations->Device monitor ............................................................. 23
6.2.13. Help->About program ...................................................................... 23
7. PROGRAMMABLE PARAMETERS........................................................................ 24
7.1. ACCESS................................................................................................. 24
7.1.1. Parameters ..................................................................................... 24
7.1.1.1. Device mode................................................................................ 24
7.1.1.2. GPRS test time............................................................................. 25
7.1.1.3. SMS mode after unsuccessful attempts ........................................... 25
7.1.1.4. SMS test time .............................................................................. 25
7.1.1.5. Server phone number ................................................................... 25
7.1.1.6. Send events via SMS immediately .................................................. 25
7.1.2. APN Parameters............................................................................... 25
7.1.2.1. APN ............................................................................................ 25
7.1.2.2. User ID ....................................................................................... 25
7.1.2.3. User password ............................................................................. 26
7.1.2.4. DNS1 and DNS2 ........................................................................... 26
7.1.3. Main Server Parameters.................................................................... 26
7.1.3.1. Server IP Address......................................................................... 26
7.1.3.2. Server port .................................................................................. 26
7.1.3.3. Interval between subsequent connection attempts............................ 26
7.1.3.4. Number of connection attempts...................................................... 26
7.1.3.5. Order of connection to servers ....................................................... 26
7.1.4. Backup server parameters ................................................................ 27
7.1.4.1. IP server address ......................................................................... 27
7.1.4.2. Server port .................................................................................. 27
7.1.4.3. Interval between subsequent connection ......................................... 27
7.1.4.4. Number of connection attempts...................................................... 27
7.1.4.5. Disconnect after time limit ............................................................. 27
7.1.5. Access ............................................................................................ 27
7.1.5.1. Service code ................................................................................ 27
7.1.5.2. Installer code ............................................................................... 28

LX2NB Manual v.1.9 Page 4 / 60
7.1.5.3. PIN of SIM card ............................................................................ 28
7.2. TRANSMISSION...................................................................................... 28
7.3. INPUTS/OUTPUTS ................................................................................... 28
7.3.1. Inputs configuration ......................................................................... 29
7.3.1.1. NO/NC/EOL-NO/EOL-NC/DEOL-NO/DEOL-NC ................................... 29
7.3.1.2. Delay [ms] .................................................................................. 29
7.3.1.3. Lock............................................................................................ 29
7.3.2. Partitions ........................................................................................ 31
7.3.2.1. Partition arming input ................................................................... 31
7.3.2.2. Inputs assigned to partitions .......................................................... 31
7.3.2.3. Delayed inputs ............................................................................. 32
7.3.2.4. Exit time ..................................................................................... 32
7.3.2.5. Entry time ................................................................................... 32
7.3.3. Output configuration ........................................................................ 32
7.3.3.1. Activation mode and timing ........................................................... 32
7.3.3.2. Conditions ................................................................................... 33
7.3.3.3. Additional conditions ..................................................................... 33
7.3.4. Advanced outputs control.................................................................. 33
7.3.4.1. Output 1 ..................................................................................... 34
7.3.4.2. Time of output activation............................................................... 34
7.3.4.3. Event: CLIP ................................................................................. 35
7.3.4.4. Event: Input 5 (RC) and Input 6 (RC) ............................................. 35
7.4. MONITORING ......................................................................................... 35
7.4.1. GPRS On / GPRS Off......................................................................... 35
7.4.2. SMS On / SMS Off............................................................................ 36
7.4.3. Skip initial state............................................................................... 36
7.4.4. Power loss ...................................................................................... 36
7.4.5. Low DC power voltage ...................................................................... 37
7.4.6. Event: CLIP..................................................................................... 37
7.4.7. Event: Input 5 (RC) and Input 6 (RC)................................................. 37
7.5. RESTRICTIONS ...................................................................................... 37
7.5.1. SMS Authorized phones .................................................................... 37
7.5.2. GSM modems authorized phones ....................................................... 38
7.5.3. Validity period of outgoing SMS messages .......................................... 39
7.5.4. SMS limits....................................................................................... 39
7.6. SMS NOTIFICATIONS .............................................................................. 39
7.6.1. Phone numbers ............................................................................... 39
7.6.2. Events ............................................................................................ 40
7.6.3. SMS user tests ................................................................................ 41
7.6.4. Status ............................................................................................ 42
7.6.5. SMS Forward................................................................................... 43
7.7. LINK CONTROL....................................................................................... 44
7.7.1. GSM............................................................................................... 44
7.7.2. GPRS.............................................................................................. 45
7.8. PHONE LINE........................................................................................... 45
7.8.1. Phone line....................................................................................... 46
7.8.1.1. Report off-hook condition .............................................................. 46
7.8.1.2. Report “intervals too long”............................................................. 46
7.8.1.3. Generate dial tone ........................................................................ 46
7.8.1.4. Detect off-hook after..................................................................... 47
7.8.2. First and Second phone number ........................................................ 47
7.8.2.1. DTMF phone number..................................................................... 47
7.8.2.2. Handshake delay .......................................................................... 47
7.8.2.3. Protocol....................................................................................... 47
7.9. FIRMWARE ............................................................................................ 48
7.10. DEVICE MONITOR ............................................................................... 50
7.11. EVENTS HISTORY................................................................................ 50
8. DEVICE PROGRAMMING.................................................................................. 53
8.1. LOCAL PROGRAMING .............................................................................. 53

LX2NB Manual v.1.9 Page 5 / 60
8.2. REMOTE PROGRAMMING ......................................................................... 53
8.2.1. The first programming of device ........................................................ 54
8.2.2. Reprogramming of device ................................................................. 54
9. RECEIVING OF SMS MESSAGE......................................................................... 55
9.1. LX PROTOCOL ........................................................................................ 55
10. LED DIODES INDICATION ............................................................................ 57
10.1. LOGGING TO GSM NETWORK................................................................ 57
10.2. GSM RANGE ....................................................................................... 57
10.3. DATA TRANSMISSION.......................................................................... 57
10.4. PROGRAMMING................................................................................... 58
10.5. FIRMWARE UPDATING ......................................................................... 58
10.6. SIM CARD ERROR................................................................................ 58
10.7. SYSTEM ERROR .................................................................................. 59
11. REVISION HISTORY .................................................................................... 60

LX2NB Manual v.1.9 Page 6 / 60
1. INTRODUCTION
Transmitter GPRS type LX2NBis an advanced microprocessor device, made with
surface moulding technology and designed according to the latest trends. This
transmitter is purposed for data transmitting from electronic security systems of
facilities and other technical devices with the use of GSM mobile phone network.
Data transmission follows via GPRS or SMS.
Due to many settings a transmitter may be applied with many systems of various
requirements. The device is basically purposed for data transmission from security
systems installed in detached houses and in small business facilities. It also have
input for connection of an alarm control panel’s phone communicator. This provides
for a cheap system of data transmission.
Communication with a monitoring station follows by GPRS/SMS mode. This device
provides an opportunity to send text messages to private mobile phones.
An advanced encoding methods like a 256 bytes encoding key and AES (Advanced
Encryption Standard) provides for security of data transmission. As a result
reception of this transmission is possible with OSM.Server monitoring receiver
system.
Programming of receiver is possible:
oLocally on computer and with recommended “GPRS transmitter
configurator” software
oRemotely - via GPRS connection
- via SMS commands
- via transmission on CSD canal

LX2NB Manual v.1.9 Page 7 / 60
2. FUNCTIONAL AND TECHNICAL PARAMETERS
Inputs:
(programmable)
4 signal inputs (NO, NC, EOL-NO, EOL-NC, DEOL-NO,
DEOL-NC),
1 DTMF
Outputs:
(programmable)
1
Operation modes:
GPRS transmission only
SMS transmission only
GPRS and SMS transmission
Messages:
Sending of text messages for defined mobile phones
Configuration:
Remote –via GPRS link
Remote- SMS
Remote –CSD
Locally –from PC with the use of software and GD-PROG
cable with RS-232 link
Security:
SMS/GPRS transmission –AES encoding
Loading of OUT1 output
50 mA
Working temperature
-10ºC ~ +55 ºC
Operating humidity
5% - 93%
In dependence from user's decision "Transmitter LX” can be delivered in different
versions. Therefore also the parameters as type of the power supply voltage,
current consumption as well as the dimensions were introduced for following options
separately:
Option 1 –Transmitter LX2NB + power supply LX-ZAS in metal/plastic box
Option 2 –PCB of transmitter LX2NB
Option 1
Option 2
Voltage
typ. 230 V AC
(190 –250 V AC)
50 –60 Hz
typ. 13.8 V DC
(12 –14 V DC)
Current/Power
consumption
(average/max)
3 W / 20 W
@230 V AC
60 mA /340 mA
@13.8 V DC
75 mA / 340 mA
@13.8 VDC (with radio receiver
433.92MHz)
Dimensions
255 x 255 x 90 mm
(metal/plastic box)
102 x 73 x 35 mm

LX2NB Manual v.1.9 Page 8 / 60
3. ASSEMBLY AND WIRING
Transmitter is delivered along with a power supply (See below). The manufacturer
provides necessary wiring linking a power supply with the transmitter, and
described procedures relate to wiring of a transmitter printed circuit board.
Switch power off to perform any connection.
3.1. LX2NB TRANSMITTER
Figure 1. LX2NB Transmitter with LX-ZAS
a) Connections of wires shall be made with due care to prevent any faults or dead
shorts. Places of connections shall be protected against weather conditions.
a) According to the above figure terminals of transmitter shall be connected to:
Terminal
Connection description
T1 –R1
Connection to alarm control panel phone communicator
GND
Device ground, common for other input and output

LX2NB Manual v.1.9 Page 9 / 60
IN1 - IN4
Signal inputs. Possible connection of detectors contacts or
alarm control panel outputs. GND terminal is common for
all inputs.
OUT1
Type OC output.. It may control external device. Provides
ground during activation.
V+
Connect to the positive pole (+13,8V) of the EBS power
supply.
GND
Connect to the negative pole of the power supply.
After careful connections examination a battery may be connected (to +/- AKU
terminals of LX-ZAS power supply) and then power may be switched on for
transformer and programming procedure of transmitter may begin (see Chapter 6).
Manufacturer reserves the right to amend appearance of printed circuit
with no effect on functionality of device.
3.1.1. Wireless module antenna connector
LX2NB-5R included one internal antenna. It is also possible to connect an external
dipole type.
433MHz internal antenna
Internal antenna can be used wherever required compact size and antenna provides
appropriate coverage level detectors. Ending of the internal antenna without
isolation should be mounted in hot pole of the socket described as ANT (the right
side)
NOTE: If the device is housed in a metal box, you should not use the internal
antenna.
Figure 2. 433MHz internal antenna
433MHz external antenna dipol type

LX2NB Manual v.1.9 Page 10 / 60
In order to improve the signal coverage in harsh environments, you can use an
external antenna dipol type. Antenna should be connected to GND and ANT
connector regardings to the color on the endings of the wires. Before screw the
antenna, remove plastic element from GND socket. Correct install position for dipol
antenna in the attached photo below.
Figure 3. 433MHz external antenna dipole tipe and correct install position

LX2NB Manual v.1.9 Page 11 / 60
3.2. INPUT CONFIGURATION
Inputs IN1 - IN4 might work as normally closed (NC) or normally open (NO).
Additionally inputs might be configured as end of line (EOL-NO or EOL-NC) with
resistors 2,2kΩor as double end of line (DEOL-NO or DEOL-NC) with resistor 1,1kΩ.
Figure 4. Configuration of input lines

LX2NB Manual v.1.9 Page 12 / 60
3.3. REMOTE CONTROL CONFIGURATION (ONLY LX2NB-5R
VERSION)
The device in version LX2NB-5R provides 2 additional virtual inputs that can be
triggered by radio transmitters. The way of functioning should be configured by
GPRS configurator software.
Remote control programming procedure
Press PROG (B) and hold. After a moment, the red LED STATUS flash. If the button
is held longer, the red LED STATUS will flash second time and a third and then stop
blinking which would mean the exit from the programming process.
If the button will be released:
•After the first STATUS LED flash, the transmitter will enter the programming
mode the channel is responsible for virtual input # 5. Status LED on. Pressing the
remote control button program in the transmitter memory. LED turns off to exit the
programming mode.
•After the second STATUS LED flash, the transmitter will enter the
programming mode the channel is responsible for virtual input # 6. Status LED on.
Pressing the remote control button program in the transmitter memory. LED turns
off to exit the programming mode.
•After the third STATUS LED flash, the transmitter will enter the erasing mode.
Press the PROG button again and wait to LED STATUS off. Release the button.
Erasing of pre-programmed remotes will be confirmed by lighting up STATUS LED
and OK.
3.4. LX-ZAS POWER SUPPLY
The dedicated power supply LX-ZAS (product of EBS) possesses the following
parameters:
Parameter
Value
Served batteries
Acid-leaded 12V
Maximum voltage of charging battery
13.8V
Charging current
0.2A or 1A (switched by jumper)
Voltage of signaling of low level
11 V
Voltage of switch-off battery
9.5V
as well as it characterizes with following proprieties:
 protection against opposite connecting battery.
 protection against excessive unloading battery:
The battery protects before damage in case of long-lasting fading the AC. In
case of lack the AC and unloading below voltage 9.5 V the battery becomes
separated from device automatically.
quick charging of the battery:

LX2NB Manual v.1.9 Page 13 / 60
The jumper showed on drawing place causes settlement of maximum
current of charging on 1A. We recommended jumper be taken off and the
current of charging battery carries out 0.2 A.
Figure 5. Choice of current of charging the battery
Note: the applying the quick charging can bring to damage of battery.
Jumper ON => charging current 1A
Jumper OFF => charging current 0,2A

LX2NB Manual v.1.9 Page 14 / 60
4. QUICK START PROCEDURE
NOTE :
Do not insert SIM card before the first programming of transmitter as it
may block the card if PIN code is required for the card.
This chapter is purposed for users that possess experience regarding GPRS
data transmission systems and who work with OSM.Server receiver for
monitoring system. Other users shall skip this chapter and go to chapter 5
of this Manual.
As many users possess protected facilities spread at vast locations, local
programming of transmitter is not always available (with PC computer and
programming cable).
Two phases comprise programming in this option:
a) sending to transmitter of main parameters (with SMS) that enable connection
to receiver (OSM.Server system).
b) full configuration of device with remote programming (GPRS transmitter
configurator and OSM.Server).
Quick start procedure:
a) insert into device SIM card with PIN code 1111
b) connect power supply for module
c) send to SIM card number with SMS parameters related to connection of
device to receiver (OSM.Server)
d) waiting for moment, when device indicates connection to OSM.Server
e) complete, remote programming with GPRS transmitter configurator
Note: Connection to receiver is possible if the device was registered into it.
Registration procedure has been described in OSM.Server Operation Manual.
SMS text message shall provide the following information:
<transmitter’s service code>█SERVER=<server address>█PORT=<server port>█
APN=<access point name>█UN=<user ID number>█
PW=<user password>
Where:
█: space (every parameter shall be separated with space –blank character)
<transmitter’s service code>: factory settings -1111
<server address>: address of communication server purposed for collection of
transmitter signals e.g. 89.123.115.8. In case address is provided as domain e.g.
block.autostrada.com, SMS message shall include DNS1 parameter (address of main
DNS server)
<server port>: Number of port in server that receives messages from a device
<access point name>: defines access point name to GSM network.
If private network is used, SMS message shall provide the following parameters:
UN=<user ID number> and PW=<user password>.

LX2NB Manual v.1.9 Page 15 / 60
Exemplary SMS is as follows (if we use public network and provide server address
as IP):
1111█SERVER=89.123.115.8█PORT=6780█APN=general.t-mobile.uk█
UN=█PW=
Where:
█: space character
5. OPERATION
A device maintains communication via GSM-GPRS network. If any problem
follows a device automatically switch to SMS mode (if this mode has been
programmed before –See chapter 7). As a result the transmitter may be used only
at the territory covered with mobile phone operator network.
If status of inputs is the same as programmed one (NO, NC, EOL-NO, EOL-
NC, DEOL-NO, DEOL-NC) a device stays in a rest. Change of status on any input
results in immediate signal transmitting of this event by the device.
Note :
Each input (IN1 –IN4) may be individually defined as normally open (NO) or
normally closed (NC). It means that when input was defined as NO, input shorting
will be an active state and when input was defined as NC, input opening will be an
active state. EOL and DEOL (parametrized and double parametrized) are options
where you use 1 or 2 resistors to distinguish alarm from sabotage.
To avoid an excessive cost of use related in particular to false alarms a device
possesses a programmable analysis of inputs.
All inputs respond only to states change which means that transmitting will
follow only if an active state is on input and maintains during programmed minimum
time. Maintenance of active state longer than a minimum time will result in single
indicating. Another input activation (another transmitting) is possible only after
input reached based state.
Number of messages sent in SMS mode is limited (limit includes also text massages
or answers to orders sent by user).This function provides for cost reduction by
limiting messages e.g. in case of damage of sensor connected to any input. After
passage of programmed time new messages will be sent but only in a number
determined by the user.
Text message on events sent to private phone numbers may be edited.
LX2NB transmitter is equipped with input to connect telephone communicator
module of alarm control panel.
Configuration of transmitter for cooperation with an control panel’s phone
communicator requires entering into memory a phone number for which transmitter
is to answer.
Once a phone is picked up via an alarm control panel telephone
communicator , a telephone number is being dialled to make connection. After the
control panel dialled a number to which transmitter is to respond, a transmitter
generates confirmation signal and awaits for data from a control panel –next DTMF

LX2NB Manual v.1.9 Page 16 / 60
tones generated with communicator are treated as data. After transmitting
adequate number of DTMF signs (16 for ContactID) transmitter generates Kissoff
signal. Collection of data from control panel finishes at hanging up a phone of a
control panel by phone communicator module. After that transmitter comes back to
standard operation and awaits for dialling of new number.
If telephone number dialled with communicator is other than number GPRS
module answers, no operation follows and it waits until communicator hangs up a
phone and picks it up again –since picking up a telephone number dialled with a
communicator module is being checked.
All programmable parameters are saved in memory and in case of voltage
drop that are not lost. Supply of power starts the transmitter with saved settings.

LX2NB Manual v.1.9 Page 17 / 60
6. CONFIGURATION PROGRAM
6.1. INITIAL REMARKS
GPRS transmitters configurator may be downloaded at www.ebs.pl (login: ebs,
password: ebs)
To install program an installation wizard shall be started that performs installation
in default place C:\Program Files\EBS\. During installation process shortcuts on
screen and Windows menu may be created.
If device is to be used for the first time it shall be programmed with the
above program and after this procedure the SIM card may be inserted into the
device. Otherwise SIM card may be blocked if wrong PIN code is entered.
Alternatively SIM card may be used along with switched off PIN code.
In case of remote programming it is necessary to insert SIM card prior to
sending configuration settings. In this situation SIM card with switched off PIN code
shall be used or before card inserting, PIN code shall be changed with mobile phone.
6.2. COMPUTER –REQUIREMENTS
Minimum requirements for computer system where configuration software
(Configurator from 1.3.69.022 version) is to be installed are the following:
Hardware:
Processor 1GHz or faster,
1 GB RAM,
4GB HDD,
Software:
Operating system: Windows 7 or newer,
.NET Framework 4,5 software
PROGRAM FUNCTIONS
After installation and program starting a main view shall be displayed on screen.
Thanks to this view an access to program or programmable parameters of device is
possible (See chapter 7)
Main window of program is divided into some fields.
Main menu: at upper part of window, contains control and configuration options.
Main menu contents:

LX2NB Manual v.1.9 Page 18 / 60
Main menu is available as icons on fast access bar:
6.2.1. File->New
Opens new set of parameters. Editing of configuration parameters is possible.
Select type of device (LX2NB).
6.2.2. File->Open
If file contains saved settings, they may be used to program next device. Firstly a
catalogue where file has been saved shall be chosen and then name of file shall be
provided. Obtained data collection may be modified by the user. Any amendments
are effective if send to device.
6.2.3. File->Save
During programming many devices in different configurations, it is not necessary to
have in mind each one as it may be saved on hard disc or floppy disk under any
name and it may be loaded later on. This function save on disc any information from
configuration wizard window. After activation of function a dialog window appears
with request to provide file name. Default data is saved with CMI extension
(Configuration Memory Image).

LX2NB Manual v.1.9 Page 19 / 60
6.2.4. File->Language
Allows for selection of any available languages (determined in attached exterior
language files).
6.2.5. File->Connections
Before programming of devices, a connection type shall be defined. It is possible to
do it with two methods:
- locally
- remotely.
6.2.5.1. Local connection
Local connection means that configuration software (namely computer on which is
installed) is directly connected to proper terminal of transmitter via special wire and
through RS-232 serial port (GD-PROG) or USB port or Bluetooth (MINI-PROG-BT,
SP-PROG-BT). All channel connection (also USB and Bluetooth) "open" virtual COM
serial ports used in communication control panel-Configurator.
To program device or make any other operations (e.g. reading of device settings,
firmware amendments, etc.) it is necessary firstly to define connection parameters.
For the above purpose you shall use the following window, available after activating
File option from the Main Menu and selecting Connection function or after clicking
icon on a taskbar and opening RS232 tab.
Define:
Name of connection e.g. Local
Choose serial port e.g. COM1
Click on [Add] button to confirm settings. Connections shall be saved (and inserted
in table). From this time on program shall enable wires connection with device and
reading, and saving of parameters in LX memory will be possible.
In the next tab "MINI-PROG" (the name derived from the programmer) you have to
also define the connection parameters.

LX2NB Manual v.1.9 Page 20 / 60
Operations are the same as with the "RS232" tab. Specify the name, the correct
COM port and add a connection.
Programmers MINI-PROG-BT and SP-PROG-BT have microUSB ports, through which
we can connect to the computer using the USB port, but also have built-in Bluetooth
interface.
6.2.5.2. Remote connection
As provided above the device and software makes for complete configuration with
GPRS link or CSD channel. This programming mode requires definition of linking
parameters.
GPRS link
Activate file in Main menu and select Connection function (or after clicking on
icon on fast access bar) and click on GPRS tab to carry out configuration of this
mode.
On screen the following window shall appear:
Define:
Name of connection e.g.: Remote
Select name of analyzer e.g.: Primary
Enter analyzer address e.g.: www.ebs.pl
Enter port on which analyzer operates e.g. 9000
