1. General Introduction
1.1 Brief Introduction
E72-2G4M20S1E is a multi-protocol 2.4GHz SMD wireless system-on-chip
module independently developed by TI based on CC2652P produced by TI. The
transmit power is 20dBm. It integrates an ARM microcontroller and
high-performance wireless transceiver. It uses industrial-grade 48MHz
high-precision low-temperature. Floating crystal oscillator.
The module leads all the IO ports of the single-chip microcomputer. The chip
comes with a powerful 48 MHz Arm ® Cortex ® -M4F processor, an internal
integrated power amplifier, powerful peripherals and up to 26 GPIOs, which can be developed in multiple directions.
CC2652P is a wireless microcontroller with great potential to become the future smart furniture, Internet of Things
transformation, and industrial automation.。
Because this module is a pure hardware SoC module, users need to program it before use.
1.2 Features
Built-in high-performance low-power Arm ® Cortex ® -M4F processor, clock speed up to 48MHz;
Rich resources,352KB FLASH，80KB RAM;
Support 1.9 ~ 3.8V power supply, power supply greater than 3.3V can ensure the best performance;
Transmitting power 20dBm;
Under ideal conditions, the communication distance can reach 700m;
The module contains 48M high-speed crystal/32.768k low-speed crystal;
Industry standard design, support long-term use at -40～+85℃;
2 pin cJTAG and JTAG debugging
Support wireless upgrade (OTA)
Wireless protocol:Thread, Zigbee ® , Bluetooth ® 5 Low Energy,
IEEE 802.15.4g, IPv6-enabled smart objects
(6LoWPAN), Wi-SUN ® , proprietary systems,
SimpleLink™ TI 15.4-Stack (2.4 GHz),
Dynamic Multiprotocol Manager (DMM) driver.
Receive sensitivity:–100 dBm for 802.15.4 (2.4 GHz),–105 dBm for Bluetooth 125-kbps (LE Coded PHY)
1.3 Application
Building automation
-Building security system-Motion detector, electronic intelligent door lock, door and window sensor, garage
door system, gateway
-HVAC-thermostat, wireless environment, sensors, HVAC system controller, gateway
-Fire safety system-Smoke and temperature detector, fire alarm control panel (FACP)

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
-Video surveillance- IP network camera
-Elevator and escalator-Elevator main, control panel of elevator and escalator;
Grid infrastructure
-Smart electric meters-Water meters, gas meters, electric meters and heat cost apportioners
-Grid communication-Wireless communication. Remote sensor application
-Other Alternative Energy-Energy Collection
Industrial Transportation-Asset Tracking
Factory automation and control
Medicine
Electronic Point of Sale (EPOS)-Electronic Shelf
Label (ESL)

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
2. Specification and Parameter
2.1 limit parameter
Main parameter
Performance
Remark
Min
Max
Power supply （V）
0
3.8
Voltage over 3.8V will cause permanent damage to module
Blocking power（dBm）
-
10
Chances of burn is slim when modules are used in short
distance
Operating temperature（℃）
-40
+85
Industrial grade
2.2 Operating parameter
Main parameter
Performance
Remark
Min
Type
Max
Operating voltage（V）
1.9
3.3
3.8
≥3.3 V ensures output power
Communication level （V）
-
3.3
-
For 5V TTL, it may be at risk of burning down
Operating temperature （℃）
-40
-
+85
Industrial grade
Operating frequency（MHz）
2400
-
2480
-
Power
Consum-ptio
n
TX current（mA）
-
106
-
Instantaneous power consumption @20dBm
RX current（mA）
-
7.3
-
-
Max TX power（dBm）
19
19.5
20
-
Receiving sensitivity（dBm）
-
-105
-
Bluetooth 125-kbps (LE Coded PHY)
Main parameter
Description
Remark
Reference distance
700m
Test condition：clear and open area, antenna gain:
5dBi，antenna height: 2 m，air data rate: 150 kbps
Crystal frequency
48MHz/32.768k
High speed 48MHz/low speed 32.768k
Protocol
Bluetooth 5 Low Energy
Zigbee
Thread
-
Package
SMD
-
Interface
1.27mm
Stamp hole
IC
CC2652P1FRGZ
-
FLASH
352KB
-
RAM
80KB
-
Core
Arm ® Cortex ® -M4F
-
Size
28.7*17.5mm
-
Antenna
PCB on-board antenna
50 ohm impedance
Weight
1.9±0.1g
-

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
3. Size and Pin Definition
Pin No.
Item
Direction
Description
1
GND
-
Ground, connecting to power source referential ground
2
DIO_7
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
3
DIO_8
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
4
DIO_9
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
5
DIO_10
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
6
DIO_11
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
details)
7
DIO_12
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
8
DIO_13
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
9
DIO_14
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
10
DIO_15
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
11
GND
-
Ground, connecting to power source referential ground
12
GND
-
Ground, connecting to power source referential ground
13
JTAG_TMSC
Input/Output
JTAG_TMSC
14
JTAG_TCKC
Input/Output
JTAG_TCKC
15
DIO_16
Input/Output
Configurable general-purpose IO port, JTAG_TDO (see CC2652P1FRGZ
manual for details)
16
DIO_17
Input/Output
Configurable general-purpose IO port, JTAG_TDI (see CC2652P1FRGZ
manual for details)
17
DIO_18
Input
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
18
DIO_19
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
19
GND
Input/Output
Ground, connecting to power source referential ground
20
VCC
-
Module power supply is positive reference voltage, voltage range 1.9 ~
3.8V
21
DIO_20
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
22
DIO_21
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
23
GND
Input/Output
Ground, connecting to power source referential ground
24
RESET_N
Input
Reset pin, low level effective.
25
DIO_22
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
26
DIO_23
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
27
DIO_24
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
28
DIO_25
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
29
DIO_26
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
30
DIO_27
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
31
DIO_28
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
details)
32
DIO_29
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
33
DIO_30
Input/Output
Configurable general-purpose IO port (see CC2652P1FRGZ manual for
details)
34
GND
Input/Output
Ground, connecting to power source referential ground

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
8
4. Development and use
No.
Key words
Remark
1
Burning
program
The module is an SOC module, with its own GPIO port, and the program download uses the
XDS100 special downloader.
2
Test board
Our company does not provide a supporting board now.
5. Basic operation
5.1 Hardware design
It is recommended to use a DC stabilized power supply. The power supply ripple factor is as small as possible and
the module needs to be reliably grounded.
Please pay attention to the correct connection of the positive and negative poles of the power supply, reverse
connection may cause permanent damage to the module.
Please check the power supply to ensure that between the recommended supply voltage, if exceeding the maximum,
the module will be permanently damaged;
Please check the stability of the power supply. Voltage can not fluctuate greatly and frequently;
When designing the power supply circuit for the module, it is often recommended to reserve more than 30% of the
margin, so the whole machine is beneficial for long-term stable operation;
The module should be as far away as possible from the power supply, transformers, high-frequency wiring and other
parts with large electromagnetic interference;
Bottom Layer High-frequency digital routing, high-frequency analog routing, and power routing must be avoided
under the module. If it is necessary to pass through the module, assume that the module is soldered to the Top Layer,
and the copper is spread on the Top Layer of the module contact part(well grounded), it must be close to the digital
part of the module and routed in the Bottom Layer;
Assuming the module is soldered or placed over the Top Layer, it is wrong to randomly route over the Bottom Layer
or other layers, which will affect the module's spurs and receiving sensitivity to varying degrees;
It is assumed that there are devices with large electromagnetic interference around the module that will greatly
affect the performance. It is recommended to keep them away from the module according to the strength of the
interference. If necessary, appropriate isolation and shielding can be done;
Assume that there are traces with large electromagnetic interference (high-frequency digital, high-frequency analog,
power traces) around the module that will greatly affect the performance of the module. It is recommended to stay
away from the module according to the strength of the interference.If necessary, appropriate isolation and shielding
can be done;
Try to stay away from some physical layers such as TTL protocol at 2.4GHz , for example: USB3.0;
The mounting structure of antenna has a great influence on the performance of the module. It is necessary to ensure
that the antenna is exposed, preferably vertically upward. When the module is mounted inside the case, use a good

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
9
antenna extension cable to extend the antenna to the outside;
The antenna must not be installed inside the metal case, which will cause the transmission distance to be greatly
weakened.
5.2 Software writing
The core of this module is CC2652P, and users can operate according to the CC2652P chip manual.
Note: The chip used in the module is in DC/DC mode
The module comes with our radio frequency switch, please operate strictly according to the truth table.
Truth Table:
DIO_6
DIO_5
Transmit(TX)
Receive(RX)
Low
High
ON
OFF
High
Low
OFF
ON
Burning program: The module is an SOC module and comes with a GPIO port. The program download uses the
XDS100 special downloader.
Program download interface definition:
E72 Pin
XDS100
Interface
JATG_TMSC
TMS
JTAG_TCKC
TCK
RESET_N
SRSTN
GND
DGND
VCC
TVD

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
10
6. FAQ
6.1 Communication range is too short
The communication distance will be affected when obstacle exists;
Data lose rate will be affected by temperature, humidity and co-channel interference;
The ground will absorb and reflect wireless radio wave, so the performance will be poor when testing near ground;
Sea water has great ability in absorbing wireless radio wave, so performance will be poor when testing near the sea;
The signal will be affected when the antenna is near metal object or put in a metal case;
Power register was set incorrectly, air data rate is set as too high (the higher the air data rate, the shorter the
distance);
The power supply low voltage under room temperature is lower than recommended value, the lower the voltage, the
lower the transmitting power;
Due to antenna quality or poor matching between antenna and module.
6.2 Module is easy to damage
Please check the power supply source, ensure it is between the recommended supply voltage, voltage higher than
the maximum will damage the module.
Please check the stability of power source, the voltage cannot fluctuate too much.
Please make sure antistatic measure are taken when installing and using, high frequency devices have electrostatic
susceptibility.
Please ensure the humidity is within limited range, some parts are sensitive to humidity.
Please avoid using modules under too high or too low temperature.
6.3 BER(Bit Error Rate) is high
here are co-channel signal interference nearby, please be away from interference sources or modify frequency and
channel to avoid interference;
Poor power supply may cause messy code. Make sure that the power supply is reliable;
The extension line and feeder quality are poor or too long, so the bit error rate is high.

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
11
7. Welding operation guidance
7.1 Reflow soldering temperature
Profile Feature
Curve characteristics
Sn-Pb Assembly
Pb-Free Assembly
Solder Paste
Solder paste
Sn63/Pb37
Sn96.5/Ag3/Cu0.5
Preheat Temperature min (Tsmin)
Min preheating temp.
100℃
150℃
Preheat temperature max (Tsmax)
Max preheating temp.
150℃
200℃
Preheat Time (Tsmin to Tsmax)(ts)
Preheating time
60-120 sec
60-120 sec
Average ramp-up rate(Tsmax to Tp)
Average ramp-up rate
3℃/second max
3℃/second max
Liquidous Temperature (TL)
Liquid phase temp
183℃
217℃
Time(tL)Maintained Above(TL)
Time below liquid phase
line
60-90 sec
30-90 sec
Peak temperature(Tp)
Peak temp
220-235℃
230-250℃
Aveage ramp-down rate(Tp to Tsmax)
Average ramp-down rate
6℃/second max
6℃/second max
Time 25℃ to peak temperature
Time to peak
temperature for 25℃
6 minutes max
8 minutes max

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
12
7.2 Reflow soldering curve

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
13
8. Bulk packaging
Revision history
Version
Date
Description
Issued by
1.0
2017-10-16
Initial version
huaa

Chengdu Ebyte Electronic Technology Co., Ltd E72-2G4M20S1E User Manual
Copyright ©2012–2020，Chengdu Ebyte Electronic Technology Co., Ltd
14
About us
Technical support: [email protected]om
Documents and RF Setting download link:：www.ebyte.com
Thank you for using Ebyte products! Please contact us with any questions or suggestions: [e-mail]
-------------------------------------------------------------------------------------------------
Office hotline: [phone] ext. 821
Web: www.ebyte.com
Address: (office）Address : Building B5, Mould Industrial Park, 199# Xi-Qu Ave, West High-tech Zone, Chengdu,
611731, Sichuan, China
(Production + Q&A + Warehouse)Address : Building B2, Mould Industrial Park, 199# Xi-Qu Ave, West High-tech Zone,
Chengdu, 611731, Sichuan, China
