Eclipse INTU Beadfit User manual

A
B
C
D
rubber bead side profile bead depth measuring the window
E
best fit profile
Installation Survey Guide – INTU® Beadfit
See overleaf for additional notes on; Fitting Blinds to Timber Frames (TF)
Flush or Recessed Rubber Bead Proud Rubber Bead
Measure clear glass width
and drop
• min. width: 240mm
• max. width: 1400mm
• max. drop: 2000mm
• max. area: 1.5 sq m
Tape Measure Depth Gauge (TP487)For beads above 27mm use INTU® Screwfit
• bead depth 19 to 27mm: no endcap spacer
• bead depth 15 to 18mm: 1 endcap
spacer per side
• bead depth 11 to 14mm: 2 endcap
spacers per side
• min. bead depth: 11mm
Ensure windows have suitable rubber
bead that accepts fitting of bracket
Profile A Profile B Profile C Profile D
All profiles are shown at 2× actual size
Y
F
P
1mm max.
Rubber Bea
d
Glass
Plastic
Bead
clear glass size
bead depth:
min. 11mm
max. 27mm
Y
F
P
1mm max.
Rubber Bea
d
Glass
Plastic
Bead
clear glass size
bead depth:
min. 11mm
max. 27mm
Flush or Recessed Rubber Bead Proud Rubber Bead
Select side profile that:-
• gives best fit at Y,
• has max. 1mm gap
between point P and clear
glass size,
• keeps face F flat on glass
© Eclipse 2018 MSM4242
greater than
1mm
greater than
1mm
gap between profile
and plastic bead
less than
1mm
less than
1mm
good fit good fit
Where the gap is greater than 1mm, this size must be deducted from clear glass size (both sides)
gap between profile
and plastic bead
.
.
CHILD SAFE
PRODUCT
.
.

If you require further advice or more information on INTU®blinds
please call 0141 814 3508 or email [e-mail]
Eclipse Blind Systems Inchinnan Business Park Renfrew PA4 9RE Scotland UK
Phone: [phone] Fax: [phone]
Installation Survey Guide – INTU® Beadfit
F
G
H
operating rod air vents special headrail
J
important
I
bottomrail
THESE PRODUCTS ARE ALL CHILD SAFE BY DESIGN AND COMPLIANT WITH THE CHILD SAFETY REQUIREMENTS OF EN13120
70mm std.
50mm mod.
standard
reduced
35mm
25mm
Reduced Headrail — All Models
• insuicient clearance on window frame or
glazing bar will require modified headrails
• reduction will be 10mm per side
• note requirements on order form ‘Special
Instructions’ box
drop
max.
10mm
clear
glas
s
drop
air vent
Air Vents
When headrail may foul air vent or
other obstruction, a deduction of up
to 10mm can be made from the clear
glass drop to clear obstruction
See diagram opposite
Blind Out of Reach — All Models
• choose 30, 60 or 120cm rod as required
• the rod connector is placed inside the tilt
handle (Venetian only)
• bottom rail is slotted for raising/lowering
All blinds are supplied with bottomrail that has an
integrated handle. This moulded handle is simple
to use and maintains the stylish appearance of the
blind.
Bottomrail with integrated handle
Following the above instructions will ensure that the blind is correctly measured,
installed and fully functioning.
.
.
