ECO Charge FS3 User manual

WARNINGS
2. Warnings
Keep open flames
away from batteries
on charge.
Risk of battery
explosion.
Be aware of
battery fumes
and electrolyte.
Do not dispose
of batteries in
the garbage.
Electrical hazard
exists inside the
charger, do not
remove the
side cover.
Always recycle lead
acid batteries.
Battery electrolyte is
highly corrosive.
Wear eye protection
when working near
batteries.

Contents .3
Contents
Warnings ....................................................................................................................................... 2
Contents ........................................................................................................................................ 3
Location ......................................................................................................................................... 4
Mounting Bracket Options ................................................................................................... 5
Installation ..................................................................................................................................... 6
FS3 Block Diagram .................................................................................................................. 9
Operating Instructions ..........................................................................................................10
Front Panel (Set Equalize Charge) .................................................................................12
Charger Configuration Settings .......................................................................................14
Charger Alarms ........................................................................................................................15
Battery Alarms ..........................................................................................................................17
Troubleshooting ......................................................................................................................20
Exploded View .........................................................................................................................22
Spare Parts ................................................................................................................................23
Maintenance ..............................................................................................................................25
Service & Warranty ................................................................................................................26
Specifications ...........................................................................................................................27
Charger Serial Number
Charger Part Number
Date Supplied
Vehicle Model
Purchaser
Purchase Invoice Number
Fleet Number

4. Location
Location
The preferred installation is where the charger(s) can be located on a shelf,
protected against accidental contact with the lift truck or its forks.
With the charger on a shelf the risk
of damage to the charger or battery
cables is greatly reduced.
Avoid just placing the charger on
the floor next to the lift truck.

Mounting Bracket Options .5
Mounting Bracket Options
Rear Mount
1. Fix the mounting bracket to the wall using a type
of fastener that suits the wall material.
2. Slide the rear of the FS3 onto the mounting bracket.
3. With 2x M5x8 hex bolts (included with the mounting
bracket)secure the front of the mounting bracket to
the FS3.
4. When fitting the battery cable ensure the locking
screw is installed.
Base Mount
1. Fix the mounting bracket to a bench using a type
of fastener that suits the bench material.
2. Remove the 2x front case feet.
3. Slide the base of the FS3 onto the mounting bracket.
4. With 2x M5x8 hex bolts (included with the mounting
bracket) secure the front of the mounting bracket to
the FS3.
5. When fitting the battery cable ensure the locking
screw is installed.
Side Mount
1. Fix the mounting bracket to the wall using a type
of fastener that suits the wall material.
2. Slide the side of the FS3 onto the mounting bracket.
3. With 2x M5x8 hex bolts (included with the mounting
bracket)secure the front of the mounting bracket to
the FS3.
4. When fitting the battery cable ensure the locking
screw is installed.
