EcoFlow RIVER 600 PRO Extra Battery User manual

User Guide
Contact us:
[e-mail]
www.ecoflow.com
WARNING
1. Keep RIVER 600 PRO and the accessories dry and do not
exposethem to high heat.
2. Never disassemble, puncture, shock, crash, or incinerate the
product.
3. Recycle and dispose of RIVER 600 PRO in accordance with
thelocal regulations.
4. Pay attention to safety when handling the RIVER 600 PRO.
5. People with disabilities or children should use the machine
under the protection of the supervisor.

The following terms are used in this document to indicate various levels of potential harm that may be caused
by improper operation.
Read the ENTIRE user manual to be familiar with the features of this product before operating. Failure
to operate the product correctly may result in damage to the product or personal property and cause
serious injury. EcoFlow will not assume any legal responsibility. DO NOT use the product with
incompatible components or alter the product in any way without following the instructions provided by
EcoFlow. Otherwise, you cannot get after-sales service from EcoFlow under warranty condition. These
Safety Guidelines include instructions for safety, operation and maintenance. It is important to read and
follow all the instructions and warnings in the user manual before assembly, setup or use the product.
Product Use:
Product Safety Guidelines
Glossary
NOTICE
CAUTION
WARNING
WARNING
WARNING
1. DO NOT expose the product to any liquids. Do not immerse the product in water. DO NOT leave the batteries
out in the rain or near a source of moisture. Moisture in the device could cause short circuits, component failure,
fires or even an explosion.
2. Never use NON- EcoFlow parts. Go to http://www.EcoFlow.com to purchase new parts. EcoFlow takes no
responsibility for any damage caused by the use of non-EcoFlow parts.
3. Never install or remove other modules from the RIVER 600 PRO when it is turned on. Do Not plug or unplug
other modules when the power of the product is turned on, otherwise the power interface may be damaged.
4. The product should be used in temperatures between -4ºF and 140ºF(-20℃and 60℃). The use of product in
environments above 140 ºF (60℃) may cause fire or explosion. Using product below -4ºF (-20℃) will severely affect
the performance of the product. Allow the product to return to a normal operating temperature before use it.
5. DO NOT use the batteries in strong electrostatic or electromagnetic environments. Otherwise, the battery
control board may malfunction and cause a serious accident during use.
6. Never disassemble or pierce the product in any way. Otherwise, it may leak, catch on fire, or explode.
7. DO NOT use the product if it was involved in a crash or a heavy bump.
8. If the product falls into the water during use, take the product out immediately and put it in a safe and open
area. Keep a safe distance from it until it is completely dry. Never use it again and dispose it properly as
described in the Battery Disposal section below. If the product catches fire, it is recommended to use fire
extinguishing equipment in the following order: water or water mist, sand, fire blanket, dry powder, carbon
dioxide fire extinguisher.
9. DO NOT put the machine in a microwave oven or in a pressurized container.
The instructions, if not properly followed, may result in property damage and minor physical damage.
The instructions, if not properly followed, may result in property damage and serious physical damage.
The instructions, if not properly followed, may result in property damage, major accident and serious injury.
Improper use may result in fire, property damage or personal injury. Make sure to use the product
according to the following safety rules and guidelines.

Travel Notice:
Product Maintenance:
Product Battery Disposal:
Product Storage and Transportation:
Product Charging:
You now own the best quality Portable Battery Generator in the world. This brief pamphlet is meant to help
you. Please take some time to read it before using the product. Read it through to fully understand how to
use the Lithium Generator!
RIVER 600 PRO Use Care and Safety Guide
CONGRATULATIONS!
NOTICE
10. Do Not allow pins, wires or other metal pieces to insert to the device case, outlets or controls. Metal pieces
may short circuit the product.
11.Avoid collision. DO NOT place heavy objects on the machine.
12. If there is dirt on any plug or outlet surface, use a dry cloth to clean it. Otherwise, it will cause abrasion and
result in energy loss or inability to charge.
1. Always use EcoFlow approved charging cables. EcoFlow does not response to any damage caused by using
non-EcoFlow charging cable.
2. When charging, please place the product on the ground with no flammable or combustible materials around.
To prevent accidents, never leave the machine unattended during charging.
3. DO NOT charge a product immediately after a long heavy load, because the product’s temperature may be
too high. DO NOT charge a product until it cools down to room temperature. The product may be unable to
charge out of the temperature range 32ºF to 104ºF (0 to 40℃). The ideal charging temperature range is 71ºF to
82ºF(22℃to 28℃).
It is forbidden to carry lithium batteries and equipment with a capacity greater than 160Wh on airplane due to
the regulation; Do Not bring this product on flights.
1. Dispose the product in specific recycling boxes only after a complete discharge. Batteries are hazardous
chemicals. Please strictly follow your local regulations regarding the battery disposal and recycle.
2. Dispose of the product immediately if it cannot be powered on after over-discharging.
1. Never store the product in environments below -4ºF (-20℃)or above 140ºF (60℃).
2. If the product is not used for a long time, the battery life may be reduced.
3. Fully charge and discharge the battery at least once every 3 months to keep the battery healthy.
1. Keep the product out of the reach of children. If any children accidentally swallow parts, please go to a doctor
immediately.
2. If a low-battery warning appears, charge the battery before store it. Otherwise, long-term storage may cause
damage to the battery in the product. Batteries in the product will enter hibernation mode if it is depleted and
stored for a long time. Recharge the product can bring the battery out of hibernation.
3. DO NOT place the product near a heat source, such as a car in direct sunlight, a fire source, or a heating stove.
4. Store the product in dry environments. Please keep the machine away from water.
5. Make sure no small metal objects can fall on or around the product while in storage.
6. Never ship a product with a battery power level higher than 30%.
To turn RIVER 600 PRO on or off, you need to PRESS and HOLD the ON/OFF system Power Button. To turn
on the AC power outlet, you need to PRESS and HOLD the AC Button after turning on RIVER 600 PRO. We
set the AC power button for users to turn off AC power when they don’t need it to save power usage. Please
follow this introduction step-by-step to be familiar with each of RIVER 600 PRO’s ports, buttons, display
screens and more. Please fully charge (100%) your RIVER 600 PRO before use it.

FCC Statement:
FCC Radiation Exposure Statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
WARNING
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
1. Orient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
NOTICE

EcoFlow App User Guide 1
4
6
10
1 1
12
15
16
16
Features of the RIVER 600 PRO
User Interface Introduction
Solar Panel Connection
Entry-Level UPS
AC X-Boost Mode
RIVER 600 PRO and RIVER 600 PRO Extra Battery Connection
Technical Specifications
How to Recharge RIVER 600 PRO
FAQs
What’s in the Box
CONTENTS
13
14

1Power A Free Life
1 2 3
2. App Login and Registration Guide
1. Open your App, click on "Sign up" to register. (If you already have an account, please click on "Login").
2. Fill your information and click on "Submit" to receive the activate email.
3. Open your activation email and click the link to activate your account. Go back to the EcoFlow app to
log in.
Search “EcoFlow” in the Google Play Store or App Store to
download the App.
You may also use your mobile phone to scan this QR code
or enter the download link in your browser:
https://ecoflow.com/pages/RIVER600-app-download
1. EcoFlow App Download Guide
EcoFlow App User Guide

2
Power A Free Life
3. Device Connection Guide
Outdoor Mode: Connect to the nearby RIVER 600 PRO hotspot. Make sure the mobile phone is within the
hotspot range).
1 2 3
1.
• Open your App, click on the "+" on the top right corner.
• Press and hold the "IOT RESET" button for more than 3 seconds on EF product. After a beep sound, your
device is ready to be connected.
2.
• Go to your phone Settings > Wi-Fi, turn on Wi-Fi and find the new device in the network list:
Ecoflow_XXXX. Tap it to make a connection.
3.
• Return to EcoFlow App, click on "Nearby" and wait for the device to appear. If it doesn't, please scroll down
to refresh the list.

3Power A Free Life
4. For more information about the App, please follow the instruction on the App or
our official website www.ecoflow.com.
Indoor Mode: Connet to the home router (support remote control).
1 2
3
1.
• Open your App, click on the "+" on the top right corner.
• Press and hold the "IOT RESET" button for more than 3 seconds on EF product, after a beep sound, your
device is ready to be connected.
• Go to your phone Settings > Wi-Fi, turn on Wi-Fi and find the new device in the network list:
Ecoflow_XXXX. Tap it to make a connection.
• Return to EcoFlow App.
• Confirm the operation, and tap "Next" to continue.
2.
• Choose a Wi-Fi for your EF product. Your EF product can only connect to 2.4 GHz Wi-Fi networks.
• Enter a Name for your EF product.
• Tap "Next" to finish adding your EF product.
3.
Please confirm:
EF product
√Connection successful
√Device info setup successful
√Network setup successful
√Server connection successful
√Device registration successful
If it fails to connect, move the EF product closer to the router, confirm whether it is a 2.4GHz network, and
repeat the operations of the first step.

4
Power A Free Life
AC ON/OFF
Displays various conditions of the product.
Charge a wide array of devices such as your iPhone, tablet, GoPro, speakers, or anything else that could be
charged through USB Port. The USB Output Indicator Light will automatically light up when a USB port is
in use.
1. LCD Display
220-240V region*Dedicated AC Output
2. USB-A Output Ports
Features of the RIVER 600 PRO
*EcoFlow has designed different AC output sockets
following the local regulations of different countries.
7
9
8
11
10
15
141312
16
1
2
3
65
4
1. LCD Display
2. USB-A Output Ports
3. ON/OFF Button of LED Light
4. IOT Reset Button
(PRESS & HOLD 3s to reset WiFi)
5. USB-C 100W Output Port
6. Power Button & LCD Display Screen
7. DC Output ON/OFF Button (Car
Outlet, 2 DC 5521 Output Ports) & DC
Output Indicator
8. Fast Charge USB-A Output Port
9. AC Power Button (PRESS for ON/
OFF) AC Output Indicator
10. 3 AC Output Sockets (100-120V)
2 AC Output Sockets (220-240V)
12. X-STREAM Charging Input Port
13. Overload Protection Switch
14. Solar Charge/Car Charge Input Port
15. Power Earth Screw
16. Expansion Power Port
11. Ventilation Fan
Expansion Power Port

5Power A Free Life
3. ON/OFF Button of LED Light
4. IOT Reset Button (PRESS & HOLD 3s to reset WiFi)
5. USB-C 100W Output Port
6. System Power Button & LCD Display Screen ON/OFF Power Indicator
7. DC Output Port (Car Outlet, 2 DC 5521 Output Ports) DC Output Indicator
8. Fast Charge USB-A Output Port
9. AC Power Button AC Output Indicator
10. 3 AC Output Sockets (100-120V) / 2 AC Output Sockets (220-240V)
11. Ventilation Fan
There’re three types of LED light: low light, strong light, and SOS rescue signal flash. Press it once to turn on
the low light; press it twice to turn on the strong light; press it one more time to turn on the SOS rescue signal
flash; then press it again to turn off the LED light. Long press can turn off the LED directly.
When you first use IOT function or you are changing the network environment, you need to press and hold IOT
Reset button for 3 seconds to reset the WiFi. It can connect with the mobile phone, then reconfigure the
wireless network through the APP. When using the IOT mode, make sure the power station has sufficient
amount of power or is connected to a power source to keep IOT standby.
Devices that charge through a USB-C port, such as a MacBook Pro, Android phone, or other devices can be
charged by the RIVER 600 PRO USB-C port. The USB-C Output icon will appear on LCD Display when a USB
port is in use.
The USB-A Output Indicator Light will automatically light up when a USB-A port is in use. Fast charge-enabled
devices can be charged at a maximum speed of 28W. If your device does not support fast charging, the device
will charge in a normal speed.
The AC power button controls the AC output of the RIVER 600 PRO. The AC power needs to be turned on man-
ually. To enable AC power, press the AC power button. When AC power is not in use to charge a device, press
the AC power button to turn off the AC power. Make sure to unplug the power cord from the AC port. When the
AC power of the RIVER 600 PRO is enabled, the AC indicator will light up. If the AC power is not used for more
than 12 hours, the product will turn off automatically (You can set up the system standby time via APP).
Charging devices that require a 230V (220-240V region)/100-120V (220-240V region) wall charger such as
laptops, TVs, mini-refrigerators, vacuums, etc. The X-Boost function supports an additional 600W-1,200W of
power reduction. This function does not support all electrical devices with higher power rating, please test to
confirm before use.
Press DC ON/OFF to turn on or off RIVER 600 PRO DC power. The 13.6V DC power button controls the RIVER
600 PRO's car charger output and two direct currents (DC 5521) outputs. The car charger output supports an
output up to 10A, which is sufficient to power most electrical appliances use in vehicles (such as mini-refrigera-
tor). It can also be used to fully charge a 12V lead-acid car battery (must be used under the guidance of profes-
sionals).
Press and hold the system power button to turn RIVER 600 PRO on or off. When RIVER 600 PRO is turned on,
the power indicator is in breathing mode, and the display is on; to turn on or off the LCD and keep RIVER 600
PRO running, short press the power button; when RIVER 600 PRO senses that any output port is in use, the
display will automatically light up. Also, if no output port is in use, the RIVER 600 PRO screen will enter into the
sleep mode after being idle for more than 5 minutes, but the battery is still running; two hours after the idle
mode, the RIVER 600 PRO will automatically shut down (You can set up the system standby time via APP).
The fan prevents RIVER 600 from overheating. Please make sure nothing blocks the vents at both ends of the
RIVER 600 PRO.

6
Power A Free Life
Plug in an AC cable with a universal three-pin plug (one that can withstand an effective current of 15A) into
the port and connect the cable to an AC power source. The U.S. and Japanese version supports 100Vac-
120Vac (50Hz/60Hz)/international version supports 220Vac-240Vac (50Hz/60Hz) charging. RIVER 600 PRO's
X-STREAM system supports an entry-level UPS function, and user can use the RIVER 600 PRO AC socket while
the device is connected to a wall socket with AC power supply (the AC power comes from the grid, not the
battery). When the grid loses power suddenly, the device can automatically switch to RIVER 600 PRO battery
power mode in <30ms to ensure your work is uninterrupted. This is an entry-level grade UPS function that does
not support 0ms switching. Do not connect devices with high uninterrupted power supply requirements, and
perform multiple tests to confirm compatibility before connecting such devices as data servers and workstations
with RIVER 600 PRO. EcoFlow will not be responsible for any loss of data or equipment damage caused by
customers’ failure in following the instruction.
When the input current continuously exceeds 10A during a charge, the AC charging port will trigger the
overload protection (the Overload Protection Switch button will automatically pop out). When the device is
confirmed to be normal, press the overload protection switch button to continue charging.
This port is used to connect the RIVER 600 PRO Extra Battery through the Expansion Power Cable to expand
the battery capacity to 1440Wh.
i
j
12. X-STREAM Charging Input Port
13. Overload Protection Switch
14. Solar Charge/Car Charge Input Port
16. Expansion Power Port
User Interface Introduction
Support a maximum of two 110W solar panels to be connected in parallel. RIVER 600 PRO has a limit input of
200W which supports 12V/24V car charge up to 10A (remember to start the engine, otherwise, the car battery
may be drained).
15. Power Earth Screw
For safety concern, some eletrical appliances need to be grounded. The power earth screw provides an option
to get your RIVER 600 PRO grounded using a grounding cable.
The number indicates the remaining charge/discharge time (in minutes) for RIVER 600 PRO.
a. Remaining Charge/Discharge Time

7Power A Free Life
d. High Temperature Indicator
e. Low Temperature Indicator
f. Fan Indicator
g. Current Input
h. Current Output
i. Overload Warning
j. Port Usage Indicators
Protection Information Instruction
The RIVER 600 PRO fan speed is intelligently controlled by the RIVER 600 PRO, and the displayed speed is
related to the fan speed.
Shows the current input power of RIVER 600 PRO in watts.
Shows the current output power of RIVER 600 PRO in watts.
Indicates the usage status of each port.
The overload icon and corresponding icon indicate the corresponding overload module.
Shows the percentage of the power. If it displays 0%, please charge RIVER 600 PRO immediately.
b. Battery Level Indicator
c. Battery Level Percentage
Shows the remaining power. The icon rotates while charging.
When the temperature of the RIVER 600 PRO is too high, a high-temperature warning icon appears on the
screen to warn that the temperature of the product is too high. Please cool down the product.
When the temperature of the RIVER 600 PRO is too low, a low-temperature warning icon appears on the
screen to warn that the temperature of the product is too low. Please warm up the product properly before
use.
The RIVER 600 PRO display screen uses different icons and combined icons to indicate the reason for device
protection.

8
Power A Free Life
USB-A Overload
Protection
USB-A and OVERLOAD icons flash together.
Disconnect all electrical appliances and wait 10
seconds before adding each appliance back.
USB-C High Temperature
Protection
High Temperature
Recharge-protection
High Temperature
Discharge-protection
Low Temperature
Recharging-protection
Low Temperature
Discharge-protection
Overload
Recharging-protection
Overload
Discharging-protection
Communication Failure
between Main Board and
BMS
USB-C and High-Temperature icons flash together.
Let RIVER 600 PRO cool before adding each appli-
ance back.
Recharging Time, Exclamation and High-Temperture
icons flash together. This will happen especially
when you charge your device immediately after a
heavy battery use. Let RIVER 600 PRO cool down
before Recharging.
Exclamation and High-temperature icons flash
together. The power supply can be resumed after the
battery is cooled down.
RECHARGING TIME, Exclamation and Low-Temperature
icons flash together. Place RIVER 600 PRO in warmer
place before recharging.
Exclamation and Overload icons flash together.
Disconnect all appliances, restart RIVER 600 PRO, and
add each appliance back in turn. Please note that elec-
trical appliances must be operated within rated power.
Light stays on
USB-C Overload Protection
The USB-C icon and the OVERLOAD icon flash
together. After unplugging the appliance, it will
automatically resume operation after 10 seconds.
Exclamation and Low-Temperature icons flash
together. Place RIVER 600 PRO in warmer place
before turning Power back on.
RECHARGING TIME, Exclamation and OVERLOAD
icons flash together.
Unplug Charging cables, restart RIVER 600 PRO and
plug back in, If light keeps flashing contact
[e-mail]
Only the Exclamation icon is flashing. Restart RIVER
600 PRO. If the light keeps flashing, contact
[e-mail]
The Exclamation icon is on. Restart the device. If the
light stays on, contact [e-mail].

9Power A Free Life
Communication Failure
between Main Board and
AC
Inverter Output Overload
Inverter High Temperature
Protection
Inverter Low Temperture
Protection
Fan Blockage
Car Charger Overload
Car Charger High
Temparature Protection
AC icon Flashes. Restart RIVER 600 PRO. If icon
keeps flashing, contact [e-mail]
AC and Overload icons flash together.
Wait 10 seconds, turn AC Power ON/OFF. Please
note that electrical appliances must be operated
within rated power. (For more information about
X-Boost function, go to P12 to see the power limit
for appliance use in X-Boost mode. )
AC and High-temperature icons flash together.
Let RIVER 600 PRO cool down. Then turn AC Power
On/OFF the interface will automatically resume
operation.
The AC and Low-Temperature icons flash together.
Move RIVER 600 PRO to a warmer place and wait
for the inverter to warm up. Press AC Power ON/
OFF button again. It will automatically recover. If it
doesn’t, contact [e-mail]
Fan icon flashes. Turn Off RIVER 600 PRO and
carefully clean and vacuum around vents on both
ends . Turn System Power On. If icon keeps flashing
contact [e-mail]
Car and OVERLOAD icons flash together.
Restart RIVER 600 PRO, and make sure that electrical
appliances must be operated within rated power.
Car and High-Temperature icons flash together.
Wait for RIVER 600 PRO to cool down and it will
automatically recover.

10
Power A Free Life
Solar Panel Connection
How to recharge the RIVER 600 PRO using solar panels?
e.g.1
RIVER 600 PRO Charging Port
RIVER 600 PRO Charging Port
XT60 Connector
XT60 Connector
RIVER 600 PRO
SOLAR PANEL-21.6V X2
MC4 Connector
SOLAR PANEL-21.6V
Solar MC4 parallel connection cable
* Users need to buy the solar panels and related
parallel connection
accessories on their own.
RIVER 600 PRO
1. Recommend Charging Method
e.g.2(Only supports parallel connection, NOT serial connection)
If you need to know more about the connection of solar panel, please refer to the Solar Panel User Guide.
Here we focus on demonstrate how one or two solar panel in parallel. The RIVER 600 PRO can support a 10-
25V DC input. When the input exceeds 25V, the RIVER 600 PRO's overvoltage protection will be triggered. Over
voltage may damage the product. Users should follow these instructions. EcoFlow do not provide free repair
services for any product damage caused by connecting many solar panels to the product or incorrect connec-
tion, even during the warranty period.
Users can connect a solar panel (do not connect more than one in series) as shown in Example 1. Connect
to EF MC4 to XT60 solar charge cable. Connect the XT60 connector to the RIVER 600 PRO’s XT60 input to
charge the device. Users can connect up to 2 sets of solar panels in parallel to the MC4 port as shown in Ex-
ample 2. If you want to connect 2 pieces of solar panels, connect them with our solar MC4 parallel connection
cable. Connect the XT60 connector to the RIVER 600 PRO’s XT60 input to charge the device. The parallel con-
nection cable is an optional accessory that is purchased separately.

11 Power A Free Life
2. RIVER 600 PRO supports the use of third party solar panels (DIY solution)
SOLAR CABLE
SOLAR PANEL
-
+ +
-
RIVER 600 PRO Entry-level UPS and Parallel Connection Use Reminder
Entry-Level UPS User Guide
Users can buy universal solar panels of MC4 connection standard on their own to power RIVER 600 PRO, as
long as the voltage and current (10-25V DC, 12A Max) comply with the specifications of RIVER 600 PRO, the
panels will be able to recharge RIVER 600 PRO through the MC4 to XT60 conversion cable. However, EcoFlow
do not provide free repair services for any damage to the product caused by the quality issue or improper oper-
ation of the third-party solar panels, even in the warranty period.
Users can connect the AC charging cable of RIVER 600 PRO to the power grid and connect a device to RIV-
ER 600 PRO and turn on the AC switch to automatically enter the entry-level UPS mode. When the external
power is cut off, power will be supplied from the battery of RIVER 600 PRO immediately to protect your
device (as shown below).
Entry-Level UPS
Entry-level UPS function. RIVER 600 PRO's X-STREAM system supports an entry-level UPS function. You can use
the RIVER 600 PRO AC socket while the device is connected to a wall socket with AC power supply (the AC pow-
er comes from the grid, not the battery). When the grid loses power suddenly, the device can automatically switch
to RIVER 600 RRO battery power mode in <30ms to ensure your work is uninterrupted. This is an entry-level grade
UPS function that does not support 0ms switching. Do not connect devices with high uninterrupted power supply
requirements. Perform multiple tests to confirm compatibility before connecting such devices as data servers and
workstations with RIVER 600 PRO. EcoFlow will not be responsible for any loss of data or equipment damage
caused by users’ failure in following the instructions. For example, data server and workstation, otherwise it will
affect your user experience.The parallel mode uses Parallel Cables to connect the Parallel Outlets of two prod-
ucts to provide almost doubled power of a single product. Since the UL2743 standard socket cannot be grounded
effectively, please connect the grounded wire to the grounding screw port of the input end according to your own
needs, to ensure the safety using of the electrical appliances.
* UPS is only applicable to electrical appliances below 600W. Please do not use other equipment at the same
time to avoid OVERLOAD. EcoFlow is not responsible for any abnormal operation or data loss caused by
careless use. Only one RIVER 600 PRO can conduct the UPS function. To connect, follow the instructions
below. More than one RIVER 600 PRO connected CANNOT conduct the UPS function.

12
Power A Free Life
AC X-Boost Mode
EcoFlow AC X-Boost allows you to use 600W-1200W appliances with the RIVER 600 PRO AC inverter without
the
disruption caused by overload protection. As a result, there is no need to buy different electrical devices in
order to use it on the product. Traditional inverters will overload when one electrical appliance with a higher
rated power is connected. Those inverters cannot be used to power such appliances. EcoFlow AC X-Boost
enables the powering of 600W-1200W electrical appliances. Please take note of the following when using this
mode:
1. The X-Boost mode is enabled by default. You can use the App to turn on or off this function. Please do not
connect AC output to the home grid under X-Boost mode, otherwise, the low voltage protection will trip
during use.
2. The X-Boost mode is not available in the following situations: in the parallel connection state, the charging
state, X-Boost mode off state.
3. When using appliances with a rated power of 600W-1200W, please only connect to one appliance. When
more than one electrical devices are connected, the change of voltage may affect the usage of other electrical
devices.
* The X-Boost mode is not applicable for all electrical devices. Some devices with a rated power of
600W-1200W that have strict voltage requirements are still not compatible. Please conduct a full test to
confirm before usage, so it will not to affect your work. It is recommended to use electrical equipment with
heating elements and with a rated power between 600-1200W, such as hair dryers, electric kettles, coffee
machines.

13 Power A Free Life
Expansion Power Cable
RIVER 600 PRO and RIVER 600 PRO Extra
Battery Connection
First prepare the RIVER 600 PRO, RIVER 600 PRO Extra Battery and Expansion Power Cable, then turn off the
power of the RIVER 600 PRO and RIVER 600 PRO Extra Battery to ensure the accurate operation. If it is operated
in the power-on state, it will not be able to connect successfully.
1. Open the soft plug under the AC port of the RIVER 600 PRO to expose the Expansion Power Port, connect with
the Expansion Power Cable, and tighten the screws on both sides of the interface to prevent it from accidentally
falling off.
2. Open the RIVER 600 PRO Extra Battery dust cover, find the Expansion Power Port interface, connect the
other end of the Expansion Power Cable, and tighten the screws on both sides of the interface to prevent it from
accidentally falling off.
3. Turn on the power switch of RIVER 600 PRO, or turn on the power switch of RIVER 600 PRO Extra Battery.
The power-on icon displayed on the screen of RIVER 600 PRO indicates that the connection is successful. It is
recommended to fully recharge the battery for the first time to ensure that the capacity of the two machines is
balanced and the maximum efficiency of the RIVER 600 PRO Extra Battery can be exerted.
* Not included in the package, this cable only
comes with RIVER 600 PRO Extra Battery
1
2
3

14
Power A Free Life
Technical Specifications
General Specs
Outputs
Input
Net Weight
Dimensions
Capacity
Testing and certification
AC Output (x3) /
(x2 International Version) Full Sine Wave
USB-A Output (x2)
USB-A Fast Charge (x1)
USB-C Output (x1)
Car Power Output (x1)
DC5521 Output (x2)
Solar Charge Input
Car Charger (Example 2)
AC Charge Input Power (Example 1)
AC Charge Input Voltage 100-120Vac (50Hz/60Hz)
International Version 220-240Vac (50Hz/60Hz)
200W 10-25V DC 12A max
12V/24V DC 10A max
X-STREAM Charge 660W Max
600W (Surge 1200W) total, 120Vac (50Hz/60Hz) /
230Vac (50Hz/60Hz)
5V DC, 2.4A, 12W Max, per port
5V DC, 9V DC, 12V DC, 2.4A, 28W Max
5V DC, 9V DC, 12V DC, 15V DC, 20V DC, 5A, 100W Max
136W, 13.6V DC, 10A Max
13.6V DC, 3A Max (per port)
* 15.9 lbs (7.2kg)
* 11.3 x 7.3 x 9.96in (28.8 x 18.5 x 25.3cm)
720Wh (28.8V)
UL Standard, CE, FCC, RoHS
Battery
Cell Chemistry
Discharge Temperature
Charge Temperature
Shelf Life
Cycle Life
Lithium-ion
-4 to 140°F +/-5°F (-20 to 60°C +/-3°C)
32 to 113°F +/-5°F (0 to 45°C +/-3°C)
1 Year (after fully charged)
500 Cycles (80%)
* Please Note: The above weight, size, etc. have certain measurement errors. Please refer to the actual
measurement.

15 Power A Free Life
AC Cable
XT60 Connector
Example 1:
Example 2:
How to Recharge RIVER 600 PRO
<2 hrs
<6.5 hrs
660W Max
X-STREAM charging
Car Charger
(120W Input)
How do I recharge my RIVER 600 PRO?
Can RIVER 600 PRO power my devices while it's charging?
RIVER 600 PRO has an AC charging port and an XT60 charging port located on the side of RIVER 600
PRO. The RIVER 600 PRO can be charged via AC power or 12V car charger. Besides, you can also use solar
panels and connect the solar charge cable to the XT60 solar charging port of RIVER 600 PRO for charging.
Yes, RIVER 600 PRO can output power while being charged.
0-80% charged in 1 hour
0-100% charged in 1.6 hour
0-100% charged less
than 6.5 hours
(AC charging cable included)
(Car charge cable
included)
