Ecolink WST-211 User manual

WST-211 Wireless Contact with Local Bypass
Specifications
Frequency: 319.5MHz Operating Temperature: 32°-120°F (0°- 9°C)
Battery: 3V lithium CR2032 Operating Humidity: 5-95% RH non condensing
Battery life: 5-8 years Compatible with GE/Interlogix receivers
Magnet gap: 5/8th inch max Supervisory signal interval: 60min (approx.)
Enrolling
To enroll the sensor, set your panel into program mode, then go to the Learn Sensors menu. Refer
to your specific alarm panel manual for details on these menus. To activate the case tamper
simply slide the cover up and down, you will hear a click when the case latches are engaging and
disengaging. Continue until the panel responds to the sensor. Then select the appropriate sensor
group and number.
Bypass Enable/Disable
By default the bypass switch is disabled. To enable this feature, press and hold the bypass button
while installing the battery. The LED will flash twice to indicate bypass is enabled. To disable the
bypass, press and hold the button while installing the battery, the LED will flash once.
Bypass Operation
To bypass the sensor, the door or window being protected must be in the closed position. Press
and hold the bypass button until the LED starts to flash, then open the door or window. The LED
will flash once every 10 seconds to indicate that the sensor is in bypass mode. To remove the
bypass and restore normal operation, simply close the door or window.
ounting
Included with the contact is double sided tape for the contact and the magnet. For reliable
bonding ensure the surface is clean and dry. Apply the tape to the sensor and then to the desired
location. Apply firm pressure for several seconds. It is not recommended to mount the tape at
temperatures below 50°F, although after 2 hours the bond will hold at low temperatures.
One side of the sensor is marked with 3 lines; this indicates the location of the reed switch. The
magnet should be mounted facing this side of the sensor, and it must be no further than 5/8 of an
inch from the sensor.
Interchangeable covers
The contact comes from the factory assembled with a white cover, but included are option brown
covers. To change the cover simply slide the front cover to disengage it from the sensor then
remove. Replace with the brown cover ensuring the Top (as marked on the inside of the cover)
points away from the battery. You should hear a click when the cover engages and disengages
from the sensor. You do not need to replace the back plastic because once mounted the back is
not visible.
To replace the magnet cover you will need to gently pry the white cover off with a flat head screw
driver and snap the brown cover in place.

Replacing the Battery
When the battery is low a signal will be sent to the control panel. To replace the battery:
1. Slide the top cover to disengage it from the sensor, then remove to reveal the battery.
2. Replace with a CR2032 battery ensuring the + side of the battery faces towards you.
3. Re-attached the cover, ensure the Top (as marked on the inside of the cover) points away
from the battery. You should hear a click when the cover engages properly.
Note: Removing the cover will trigger a zone tamper signal to the control panel
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•Re-orient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment to an outlet on a different circuit from the receiver
•Consult the dealer or an experienced radio/TV contractor for help.
Warning: Changes or modifications not expressly approved by Ecolink Intelligent Technology Inc. could void the user’s
authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
FCC ID:XQC-WST211 IC: 9863B-WST211
Warranty
Ecolink Intelligent Technology Inc. warrants that for a period of 5 years from the date of purchase that this product is free
from defects in material and workmanship. This warranty does not apply to damage caused by shipping or handling, or
damage caused by accident, abuse, misuse, misapplication, ordinary wear, improper maintenance, failure to follow
instructions or as a result of any unauthorized modifications.
If there is a defect in materials and workmanship under normal use within the warranty period Ecolink Intelligent Technology
Inc. shall, at its option, repair or replace the defective equipment upon return of
the equipment to the original point of purchase.
The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties,
whether expressed or implied and of all other obligations or liabilities on the part of Ecolink Intelligent Technology Inc. neither
assumes responsibility for, nor authorizes any other person
purporting to act on its behalf to modify or to change this warranty, nor to assume for it any other warranty or liability
concerning this product.
The maximum liability for Ecolink Intelligent Technology Inc. under all circumstances for any warranty issue shall be limited to
a replacement of the defective product . It is recommended that the customer check their equipment on a regular basis for
proper operation.
© 2012 Ecolink Intelligent Technology Inc. PN WST211 R1.00
2055 Corte Del Nogal
Carlsbad, California 92011
1-855-632-65 6
www.discoverecolink.com
