EcoQuest Fresh Air Spectrum UVX User manual

CAUTION! - Disconnect power cord before servicing.
WARNING! - UV Lamp operation. Do not operate unless the unit is completely
and correctly assembled. Failure to comply may result in serious eye damage.
RCI™ Cell Replacement
If the unit no longer produces light
or the light has become dim (after
approx. 25,000 hrs of operation), the
RCI™ Cell should be replaced.
Contact your EcoQuest Dealer for
more information on a replacement
RCI™ Cell.
Remove the two
screws located at the
back of the unit.
Tilt the bottom of the
RCI™ shield away
from the unit.
Lift the RCI™ shield
up about 1/4” to
release it from the
upper tab.
Lay the RCI™ shield
over and remove the
RCI™ cell from the
retaining clips.
Remove the RCI™
cell from the plug.
Replace with new
RCI™ cell.
Reverse steps 1 - 4 to reassemble.
Note: The AC transformer may feel warm to the touch.
Over time some discoloration of the clear panel may occur.
Hg - LAMP CONTAINS MERCURY.
Manage in accordance with local laws.
See www.lamprecycle.org.
SPECIFICATIONS
• 12VDC
• 11 watts power consumption
• Advanced Oxidation: 0.01 ppm
• Size: 6” x 12” x 3”
(15cm x 30cm x 7cm)
• Weight: 2 pounds (.9kg)
• Coverage: up to 500 ft2 (46m2)
• One Year limited warranty
- see warranty card for details
12
3 4 5
6
Operation
If your Fresh Air Spectrum UVX™ has been equipped
with an international AC adapter, you will need to
select and install the proper plug (see below) .
Plug the adapter into a working receptacle and into
the back of the unit. Set the unit upright on a stable,
fl at surface.
Fresh Air Spectrum UVX™ units with standard AC
adapters are controlled by a single on/off switch
located on the electrical cord. Units equipped with
international adapters do not have a switch.
ABOUT THE INTERNATIONAL PLUG ADAPTER:
When installing one of the interchangeable plugs, be sure to snap
and lock the plug into the adapter. When removing a plug, press
the raised tab to release, then slide the plug out the top.
PRESS HERE

310 T. Elmer Cox Drive
Greeneville, TN 37743
Copyright © 2004 EcoQuest International. All rights reserved
Please record the name and phone of your EcoQuest Dealer:
Name _______________________________________________
Phone _______________________________________________
Please record the serial number of your Fresh Air Spectrum
™
:
Serial # ______________________________________________
This product is of solid state construction and is warranted by
EcoQuest International
310 T. Elmer Cox Drive
Greeneville, TN 37743
to the original purchaser to be free from defect in materials and
workmanship for a limited time.
Length of warranty will vary depending on model.
See warranty card for specific details.
If you have any questions concerning your Fresh Air Spectrum
™
,
please see your local EcoQuest Dealer.
Did you forget to register your Fresh Air Spectrum
™
?
By registering, you’ll activate your warranty, and your
privacy is guaranteed. Just fill out your warranty card and
drop it in the mail.
65-00119-002
FA Spectrum OM 0904
This equipment has been tested and found to comply with the limits for
Industrial, Scientifi c and Medical Equipment (ISM), pursuant to Part 18 of
the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television, which can be
determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
FCC DECLARATION OF CONFORMITY
Name: EcoQuest Model: Fresh Air Spectrum
Manufacturer:
EcoQuest Manufacturing
This device complies with Part 18 of the FCC Rules.
RESPONSIBLE PARTY
EcoQuest International, 310 T. Elmer Cox Dr., Greeneville, TN 37743
Ph: [phone]
Signature: __________________________________
Printed Name: R. Paul Beam
Title: Engineering Manager Date: 7/12/04
Ph: [phone]
Signature: ___________
_________________
CE DECLARATION OF CONFORMITY
We, EcoQuest Manufacturing, Inc.
Of 310 T. Elmer Cox Drive
Greeneville, TN. 37743
U.S.A.
Declare under our sole responsibility, that the product including options or accessories
Product Type: Electronic Air Purifi cation Systems
Model: Fresh Air Spectrum UVX
starting with serial number 110,001
to which this declaration relates, conforms with the following standards:
EN55014-1, EN50014-2, EN61000-3-2, EN61000-3-3, EN61000-4-2, EN61000-4-3
EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11
EN60335-1:2002 Safety of household and similar Electrical appliances
EN60335-2-65:2003 Safety of household and similar electrical appliances
By conformance with the standards referenced, the product meets the provisions of the
Directives listed below:
Low Voltage Directive 73/23/EEC
EMC Directive 89/336/EEC
Authorized by:
Representative: R. Paul Beam
Title: Engineering Manager
Company: EcoQuest Manufacturing, Inc.
A1: 310 T. Elmer Cox Drive
A2: Greeneville, TN. 37743
Date: 09/21/04
[phone]
