CLASSIC INFRARED ZONE HEATER
OWNER’S MANUAL
Model No. A5893
IMPORTANT
SAVE THESE
INSTRUCTIONS
To ensure you get the best results, please read this manual first
and keep it for future reference. For additional information,
please contact your place of purchase or call 1-800-225-6595.
Thank you for choosing EdenPURE®

2
Thank you for choosing the EdenPURE®Classic Infrared Heater. This owner’s manual will
provide you with valuable information necessary for the proper care and maintenance of your
new product. Please take a few moments to thoroughly read the instructions and familiarize
yourself with all the operational aspects of your new heater.
IMPORTANT INSTRUCTIONS
WARNING
IMPROPER USE OF THIS HEATER COULD RESULT IN RISK OF FIRE, ELECTRIC SHOCK,
AND INJURY TO PERSONS
WARNING
ANY REQUIRED SERVICE SHOULD ONLY BE
PERFORMED BY AN AUTHORIZED SERVICE REPRESENTATIVE AND ANY
OTHER REPAIRS ATTEMPTED BY ANYONE OTHER THAN AN AUTHORIZED
SERVICE REPRESENTATIVE WILL VOID THE WARRANTY.
FOR AUTHORIZED SERVICE, CALL 1-800-225-6595 OR VISIT WWW.EDENPURESUPPORT.COM
WARNING
RISK OF ELECTRICAL SHOCK. DO NOT OPEN.
NO USER-SERVICEABLE PARTS INSIDE.
1. Read ALL instructions before using the EdenPURE®Classic Infrared Heater.
2. CAUTION: Risk of Electric Shock. DO NOT open or try to repair the heater yourself.
3. This heater may get hot when in use. To avoid burns, DO NOT let bare skin touch hot
surfaces. If provided, use handles when moving this heater.
4. Keep combustible materials, such as furniture, pillows, bedding, paper, clothes, and
curtains at least 3 ft. from the front of the heater and keep them away from the sides, top,
and rear. DO NOT place towels or other objects on the heater.
5. Extreme caution is necessary when any heater is used by or near children or the disabled,
or when the heater is left operating and unattended.
6. DO NOT operate any heater with a damaged cord or if the heater malfunctions, has been
dropped or damaged in any manner. Return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
7. This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations. NEVER locate heater where it may fall into a bathtub or other water container.
To protect against electrical hazards, DO NOT immerse in water or other liquids.
8. DO NOT touch the control panel or plug with a wet hand.
9. DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or
similar coverings. Arrange cord away from traffic area and where it will not be tripped
over.
10. DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as
this may cause an electric shock or fire, or damage the heater.
11. To prevent a possible fire, DO NOT block the air intakes or exhaust in any manner. DO
NOT use on soft surfaces, like a bed, where openings may become blocked.

3
12. A heater has hot and arcing or sparking parts inside. DO NOT use in areas where
gasoline, paint, explosive and/or flammable liquids are used or stored. Keep unit away
from heated surfaces and open flames.
13. Do not plug the unit into any other cord-connected device such as a power strip, surge
protector, multiple outlet adapter, grounding adapter or outlet-type air fresheners. Plug
into a 3-prong 110v 15amp or higher grounded circuit receptacle only. Do not plug the
heater into a loose-fitting or broken receptacle. The heater is for use on 110 volt outlets.
The cord has a plug as shown on Page 4.
14. To avoid fire or shock hazard, plug the unit directly into a 120V AC electrical outlet.
15. To disconnect heater, turn controls to OFF, wait for fan to stop running then remove
plug from outlet. Pull firmly on the plug, DO NOT unplug by pulling on the cord.
16. Always unplug the unit before moving or cleaning, or whenever the heater is not in use.
17. Use only for intended household use as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury to persons.
The use of attachments not recommended or sold by unauthorized dealers may cause
hazards.
18. Always use on a dry, level surface. Use on floor only.
19. DO NOT use outdoors or on construction sites.
20. WARNING: To reduce the risk of fire or electric shock, DO NOT use this unit with any
solid-state speed control device.
21. DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit.
Doing so will void your warranty. The inside of the unit contains no user serviceable
parts. Qualified personnel should perform all servicing only.
22. Connect to properly grounded outlets only.
23. Some EdenPURE®units contain a button battery for the remote. If swallowed, it could
cause severe injury or death in just two hours. Seek medical attention immediately.
24. Save these instructions.
SPECIFICATIONS
Voltage Rating
120V (60Hz)
Power Consumption
1500W
Unit Size
11.4 in. (W) x 14.5 in. (D) x 14.9 in. (H)
Unit Weight
12.7 lbs.

4
SAFETY FEATURES
Tip-Over Safety Feature
This heater is equipped with a tip-over safety feature. Once the heater is tipped over, an internal
switch will automatically shut the heater off. Once the heater is restored an upright position, the
heater will reset. To continue operation, turn on the heater using the supplied remote control or
the control panel on the heater.
Overheat Safety Feature
This heater is equipped with an overheat safety feature. When the heaters internal components
reach a certain temperature that could cause it to overheat and a possible fire, the heater will
automatically shut off.
WARNING: This heater has a voltage
rating of 120 volts. The cord has a plug as
shown in A. An adapter as shown in C is
available for connecting three-blade grounding-
type plugs to two-slot receptacles. The
grounding lug extending from the adapter must
be connected to a permanent ground such as a
properly grounded outlet box. The adapter
should not be used if a three-slot grounded
receptacle is available.
DO NOT DEFEAT THE SAFETY PURPOSE
OF THE GROUNDED PLUG.
WARNING: It is normal for the power cord to feel warm to the touch; however, a loose fit
between the outlet and the plug may cause overheating of the plug. If this occurs, try inserting
the plug into a different outlet. Contact a qualified electrician to inspect the original outlet for
damage.
IN THE BOX
·EDENPURE®CLASSIC HEATER
·REMOTE CONTROL
·REMOTE CONTROL BATTERY
·OWNER’S MANUAL
·QUICK START GUIDE

5
1
2
4
5
3
7
9
6
8
10
PRODUCT DIAGRAM
1. Indicating light of highest temp: Light’s on when set at the maximum temp.
2. Indicating light of lowest temp: Light’s on when set at the minimum temp.
3. Temp down button: For setting temp downward.
4. Signal-receiving window: For receiving remote control signal.
5. Temp up button: For setting temp upward.
6. Indicating light of high heat-up mode: Light’s on when you select all-power heat-up mode.
7. Mode button: Used for selecting heat-up mode.
8. Indicating light of auto heat-up mode: Light’s on when you select auto heat-up mode.
Control Panel
Cabinet
Air Outlet
Front Panel
Control Panel
Wheel
Remote Control
Air Intake
Cord Clamp
Heat Sensor
Power Switch

6
9. Power switch button: For power-on or off.
10. Power indicator light: Indicates that the heater is receiving power from outlet. Will flash
when powered “ON”.
PREPARATION
Unpackage unit. We recommend keeping the packaging for storage and any transporting needs.
Place the heater on a firm, level surface and plug into a grounded 120V 60Hz power outlet, and
turn on the power switch in the rear of the unit. Only operate heater in upright position with
caster wheels attached.
When using remote control, please pull out the insulating film as the following steps.
Mode button: Used for mode selection
ON/OFF button: Used for power-on or power-off
Temp up button: to make set temperature rise
Temp down button: to make set temperature decline
PULL
Remote control
Insulating film
Battery cover
Remote Control

7
OPERATING INSTRUCTIONS
1. Start and select working mode
Or
Turn the heater on by pressing the Power button on the
control panel or by pressing the Power button on the supplied
remote control.
Once power is off, heating element will stop working at first.
The fan will continue to run for approximately three minutes
to emit residual heat inside of the unit.
Or
Select a heat setting.
Press the Mode button to alternate between the two heat
settings.
Under Auto heat-up mode, when the value difference
between set temp and room temp exceeds 5°F or so, the unit
will run at full 1500W, otherwise run at 750W; Under High
heat-up mode, the unit runs at a stable 1500W, when room
temp exceeds 86°F, heat-up stops.
2. Setting room temperature
Caution! Only in Auto heat-up mode can setting temperature be performed.
Or Or
Or
Adjust the thermostat by pressing the arrows on the control
panel or remote control.
Set temperature indication varies from 59°F to 86°F. The
bottom lighting corresponds to the set temperature of 59°F.
The topmost light corresponds to the set temperature of
86°F, totalling 10 lights. Once you have chosen the desired
temperature, the heater will remain on until the room
temperature increases to the temperature on the digital
display. The heater will cycle on and off to maintain the
desired room temperature.

8
3. Setting electro lock
Function of electro lock can avoid misoperation from children. Locking can be set in both
power-on and power-off modes.
And
Press Temp Up and Temp Down buttons once for 3
seconds. Locking is fulfilled when you hear one beep.
When locked, control panel and remote control failed to
function.
And
When release is needed, please re-press Temp Up and
Temp Down buttons once for 3 seconds. Release is fulfilled
when you hear one beep. Lock indication disappears.
Control panel and remote control return to function.
MAINTENANCE
1. Turn off the power switch in the rear of the unit.
2. Unplug the unit and let it cool completely.
3. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth. You
may use a mild detergent if necessary. After cleaning, dry the unit with a soft cloth.
CAUTION: DO NOT let liquid enter the heater.
4. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes to
clean the heater. This may cause damage or deterioration to the surface of the heater.
5. DO NOT immerse the heater in water.
6. Wait until the unit is completely dry before use.
7. Air filter needs to be cleaned often. Please take off the filter with the 2 steps in the
drawing below. Flush and clean the filter with water, then dry it out and
re-assemble. If used weekly, check and clean on a weekly basis if dust accumulates on
the filter.
2) Remove Air filter
1) Remove bracket hand screws (4X)
The unit

9
8. If not using the unit for a long time, please take out the battery in remote control
according to the following steps.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-up, use the
original packaging to repack the unit.
TROUBLESHOOTING
If the heater will not operate, please check the following before seeking repair of service:
1. Check if the power cord is plugged into an electrical outlet, if not, plug in.
2. Make sure the outlet is getting the proper electrical current to it.
3. Check if the battery in remote control is in good use, and if the insulating film is pulled
out. Check to make sure the master power switch is in the “I” position on the back of the
heater.
NOTE: For the heater to function properly, the desired temperature on the heater must be set a
few degrees higher than the temperature in the room. If the seems to not be heating, increase the
desired temperature on the heater to engage the heat elements.
SERVICE
For repairs of service, please visit your place of purchase, call 1-800-225-6595 or visit
www.edenpuresupport.com.
WARNING:Any required service other than filter maintenance should only be performed by an
Authorized Service representative.
Follow us/Like us
facebook.com/Edenpure instagram.com/ twitter.com/ pinterest.com/
edenpureproducts edenpure_Edenpure
PULL
PUSH
Battery cover
Battery
©2018 EdenPURE® I-5551 BR11782R-1
