Edesa ISM-35 User manual

1
USER'S MANUAL
ISM-35 INDUCTION HOB

2
USE AND CARE INSTRUCTIONS – IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE OPERATION
1. Use an individual 220V electrical socket.
2. DO NOT block the air-intake panel, blocking may overheat the unit.
3. Use pans 14cm (5 1/2”) or larger in diameter. We recommend pans be less than 26cm
(10.25”) in diameter. Please refer to the next page for a list of suitable and unsuitable pans.
4. DO NOT touch the hot surface of the ceramic plate. NOTE: The induction range itself does
not produce any heat during cooking, however, the heat from the pan will leave the surface
of the ceramic hot!
5. DO NOT cook empty pots or pans. Heating an empty pan will automatically activate the
overheating protection device and the unit will shut off.
6. Place the induction range on a horizontal surface and at least 10cm (4”) away from the wall
and other objects for proper ventilation.
7. DO NOT place any objects or tools in the air-intake panel. Doing so may cause electrical
shock.
8. To protect against electrical shock, DO NOT immerse the unit, the cord or the plug in or near
water or other liquids.
9. Close supervision is necessary when the induction range is used or near children.
10. DO NOT operate the induction range if it has been damaged in any manner or if the unit
malfunctions. Return the unit to the nearest authorized service facility for examination or
repair.
11. The use of any accessories not recommended by the manufacturer may cause injuries.
12. Keep the power cord away from heat.
13. DO NOT place the induction range in, on or near open flames, electric burners, heated ovens
or other high temperature surroundings.
14. DO NOT heat any sealed cans on the induction range. A heated can may explode.
15. DO NOT move the induction range while cooking or when the pan is hot.
16. After the induction range has cooled down, unplug the cord and clean as follows,
VITRO CERAMIC PLATE: wipe with damp cloth or use a mild, non-abrasive cleaning solution.
BODY: wipe the control panel with soft cloth or use a mild cleaner.
17. DO NOT use induction range for other than intended use.
18. Unplug when not in use.
19. When storing, DO NOT place any objects on top of the induction range.
20. When using an induction range (smooth top range) for cooking, keep your pacemaker 2
feet (approx. 60cm) from the heating areas.
21. Clean Air-Filter (underneath) periodically, make sure to have fresh air in-
coming smoothly.
SAVE THESE INSTRUCTIONS!!!

3
SUITABLE COOK UTENSILS- FOR INDUCTION HEATING PLATES,
SUITABLE POTS,
1. Iron
2. Cast iron
3. Stainless steel
4. Enamelware
All pots and pans must have a magnetic bottom.
All pots and pans must have a flat bottom.
All pots and pans should have a diameter between 12cm (4.75”) and 26cm (10.25”).
UNSUITABLE POTS,
1. Pot with diameter below 5cm (2”).
2. Stainless steel pans with aluminum bottom
3. Pottery
4. Glass pans
5. Aluminum pans
6. Bronze pans
7. Copper pots
8. Pans with feet
SAFETY DEVICE
Two switches to turn on power
For comply with CE safety regulation, the user need to make two action to turn on the
induction cooking range. First, push power on/off key, and consequently push “+” switch
or turn the “rotary” power regulator within 5 seconds.
Automatic Safety Shut-Off,
If the induction range is left on for more than 60 seconds without a pan or with an
incompatible pan, the unit will automatically shut off.
Material Compatibility Detector
If the pan’s material or it’s dimensions are not suitable for this induction range, the pan
indicator will not light.
Small Object Detector
The induction range will not recognize any objects or utensils smaller than 5cm in
diameter. For best results, use pans that are between 14cm and 26cm in diameter.
Overheating Protection Device,
If the pan’s temperature becomes too high, and the temperature remains too high for 60
seconds, the unit will shut off automatically. And there will be a short warning sound
after unit shut off automatically.
IC Auto Reset Device
Main control micro processor equipped with watch dog device , the IC will auto reset
when the software program goes wrong.

4
HOW DOES YOUR INDUCTION HOB WORK?
A high frequency (20-35KHz) induction coil underneath the surface ceramic top plate
heats the cooking utensil by magnetic friction. The heat is produced directly within the
pan. It's controlled by electronic circuit to offer superior performance and functions.
During cooking, no energy is lost between the hob and the food. When you switch off,
the cooking is stopped immediately.
PRECAUTION BEFORE USING YOUR INDUCTION HOB
1. The glass top is of strong, hard, and non-porous properties. But, in case of breakage,
even it's only slight cracking, disconnect the appliance from the mains immediately and
contact the after-sales service.
2. The appliances is equipped with 'small object detector'. But, it's recommended not to
place metal kitchen utensils, pan lids, knives, or other metal objects on the induction
heating zone. If an inductor is switched on, there is a risk of becoming hot.
3. When using your induction hob, don't place any magnetic objects on the glass top, such
as credit cards, cassettes, etc.
4. Scientific tests have shown that the induction hob presents no danger. Whatsoever, for
persons using pacemaker, please keep 60cm (2 feet) distance from the unit while the
induction hob is in using.
5. To prevent from overheating, do not place aluminum-foiled or iron plate on the top plate.
6. Put the appliance on a horizontal surface but keep away from wall or articles at least 5-
10cm.
7. Do not put any articles like iron wire or tools into the air entrance or outlet to prevent from
electric shock.
8. Immediate clean-up is recommended when water left on the top plate.
9. Clean Air-Filter (underneath) periodically, make sure to have fresh air in-coming
smoothly.

5
OPERATION INSTRUCTION
Turn on the power.
1. Plug power cord into 230V, 50Hz power socket.
2. Turn on power by two action: 1. Push power on/off key. 2. Push “+” key or rotary the
power control knob within 5 seconds, power level display led will light on.
Start cooking on induction range. (Heat Function)
1. Rotary power control knob clockwise, the power level led will display from step.1 to
step.19.
2. Put a suitable pan on central position of top plate, and rotate power control knob to desire
power level. Power at 1 position is the minimum, 19 position is the maximum.
3. Heating indicator light will indicates the pan is suitable or not. If the Heating indicator light
is on, then the pan is heating. If the Heating indicator light is off, It indicates no pan or no
suitable pan is on top plate position.
4. This unit is equipped with 'over heating protection device', which will stop power
temporally when top plate temperature reaches 250°c (+/- 20°c). The power will start
again automatically when the temperature of top plate reduced. If you put an empty pan
on it, and heat-up at max. Power, it will reach 250°c very soon. So, the safety device will
stop output power temporarily to prevent over-heating. Under this situation, the Heating
indicator light will flash to indicate the over heating protection function is on.
Keep food at certain temperature (Warm Function)(Holding Temperature)
1. Warm function (Temperature holding function): Push “Heat / Warm” function select
key, the temperature holding function will be activate. The Function indicate LED
(Warm) will start flashing. And the Status display window will display the temperature
you want to hold. For example, when the Status display window show 190, it’s mean
you want to hold the cooking pan’s temperature at 190 °C .
2. At the beginning of Warm Function activate, the “Warm” function indicate LED will
flashing, it’s mean the temperature of cooking pan is not yet reach the setting
temperature. After a while, the “Warm” function indicate LED light will stop flashing,
and it keep turn on, it’s mean the temperature are reached the setting temperature.
3. You can change the setting temperature by push “+” or “--“ keys. To increase the
setting temperature, push “+”. Or decrease the setting temperature by push “--“ key.
The temperature setting range is from 50°C - 240°C / 10°C per step.
4. You can change the WARM function to HEAT function by push “Heat / Warm”
Function key again.

6
5. The air filter is located in the front underneath of top cabinet, the air filter need to be
clean after certain period. Because it is made by washable (aluminum) material, so,
you can wash it and re-use it. To keep the air filter clean will help the cooling air go
through the electronic induction components, and will keep good performance of this
induction cooking range.
Remark,
Clean Air-Filter (underneath) periodically, make sure to have fresh air in-coming smoothly.
Control Panel:
1. Power On/ Off Key.
2. Rotary knob (power regulator)
3. Heat / Warm FUNCTION select key.
4. Power / Temp. adjust key. “+” for increase, “—“ for decrease.
5. Power / Temp. status display window.
6. “Heat” “Warm” function indicator LED.
7. “Heating” status indicate LED.
I/O +
_ Heat
Warm
Heat Heating
Warm (°C)
1. Powe
r
on / off key 2. Rotary knob
(Power regulator)
3. Heat / Warm
function select
key
4. Power /
Temp. adjust
key.
5. Power /
Temp. status
display
window 7. Heating status
indicate LED.
6. Heat / Warm
Function indicate LED

7
FEATURES & DESCRIPTION:
1. 3500watt Induction Heating Zone
2. Vitro Ceramic Top Plate
3. Bottom Chassis
4. Power on/ off key.
5. Rotary Control Knob. (Power regulator)
6. Induction Heating Indicator Light
7. Heat function indicator light.
8. Warm function Indicator Light
9. Heat / Warm function select key.
10. Power / Temp. adjust keys “+”, “—“.
11. Air-Intake (Air filter)
12. Air-Outlet
SPECIFICATION:
Model No. ISM-35 Induction Range
Voltage 230V ~ 50Hz
Vitro-Ceramic Plate Approx. 300mm X 300 mm x 6 mm Thickness
Max. Electrical Power
Consumption Max. 3,500watt, 15.2A
Power Adjust Range Approx. 350watt ~ 3,500watt
Functions yPower regulate: 19 steps, from 350w – 3500w
yTemperature holding: from 50 - 240°C, every 10°C
Safety Device yAutomatic Safety Shut-Off
yMaterial Compatibility Detector
ySmall Object Detector
yOverheating Protection Device
yIC Auto Reset.
Dimension 385mm(W) X 510mm(D) X 175mm(H)
Remark: The switching frequency is verified by different power setting,
it’s to be between 20 ~ 35 K Hz.
2
1
3
4
5
6
7
8
9
10
11
12

8
TROUBLE SHOOTING
1.If your induction range seems to be working improperly, it doesn't necessarily
mean it's a faulty. In all cases, check the following points.
2. If you fail to identify the problem contact the after-sales service without delay.
If ...... It might be caused ......
No indication light when
power "on" Cable/terminal block is loosed
Broken circuit of fuse; or automatic switch in your house
Power supply stopped.
Heating indicator does
not light-in, Unsuitable cooking utensil,
Appliance fails to heat up Utensil doesn't located at the center properly.
Utensil is small than 5cm.
Over-heating protection is activated.
Appliance suddenly stops
heating during High ambient temperature.
Operation Air entrance or outlet blocked.
Over-heating protection activated.
Trouble Shooting,
ERROR CODE, verified by BEEPER
If the machine turned-off itself, please check if you can hear BEEP as following descriptions,
If It might be caused,
Bi--------(1 long BEEP)
Bibibibi (4 short BEEP) Over-voltage protection,
Action:
Try again later till electricity supply is
stable
Turn-off immediately without any sound 1. Over-heating protection, or
Action:
Try again later after the machine is
cooling down
2. Surge protection
Action:
Try again immediately.
Bibibibibi… (short BEEP last for
60seconds)
Bi--------(1 long BEEP)
No pan on the cook-top
Bi----------(1 long BEEP)
Bibibibibibibibibi (9 short BEEP) Heating empty pan on the cook-top,
Action:
Remove the empty pan, or fill food/water
into the utensil as you want,
Bi----------(1 long BEEP)
Bibi (2 short BEEP) Temperature sensor failed (open or short),
Action:
Call your local distributor for service
information.
