Edge-Core ECW5211-L User manual

– 1 –
Mount the AP
a. Mounting on a Wall
1. Set two screws in the wall 128 mm (5.0 in.) apart.
2. Slide the AP’s wall mounting slots down onto the screws so that
the unit is secure.
b. Mounting on a Ceiling T-Bar
1. Use the included screws to attach two ceiling-mount T-bar clips
to the back of the AP.
2. Push the AP onto the ceiling T-bar until it clicks securely in place.
Connect Cables
a. Connect LAN Cables
1. Connect Category 5e or better cable to the Eth1/PoE
1000BASE-T RJ-45 port. When connected to a PoE source, the
Eth1/PoE port connection provides power to the unit.
2. (Optional) Connect a local LAN switch or computer to the Eth2
1000BASE-T RJ-45 port.
b. (Optional) Connect AC Power Adapter
1. Connect the AC power adapter to the DC power jack on the AP
and then plug the adapter into a nearby AC power source.
Check AP LEDs
1. Power LED — on amber for normal operation.
2. 2G-WiFi and 5G-WiFi LEDs — on green for radio enabled.
3. Eth1/PoE and Eth 2 LEDs — on green for a valid LAN link.
Warning: For indoor use only. The access point, AC power
adapter, and all connected cables are not for outdoor use.
Note: For safety and regulatory information, refer to the
Safety and Regulatory Information document included with
the AP.
Note: The ceiling mounting clips are for two different sizes
of ceiling T-bars. The narrow clips are for 15 mm bars. The
wider clips are for 24.5 mm bars.
1
1
2
1
2
2
2
1
1
3
1
3
2
E112018-CS-R02
150200001948A
www.edge-core.com
802.11ac Dual-Band Enterprise Access Point
ECW5211-L |ECW5211-L2 |ECW5211-O
1. ECW5211-L, ECW5211-L2 or ECW5211-O access point
2. AC power adapter
3. Ceiling-mount kit—4 T-bar clips and 2 screws
4. Wall-mount kit—2 wall plugs and 2 screws
5. Four adhesive rubber feet
6. Documentation—Quick Start Guide (this document) and
Safety and Regulatory Information
Package Contents
2 5 64
13
Quick Start Guide

– 2 –
Lock the AP in Place
1. The AP includes a Kensington security slot on the side panel. To
prevent unauthorized removal of the AP, use a Kensington
security cable (not included) to attach the AP to a fixed object.
Insert the cable lock into the security slot, and then turn the key.
Hardware Specifications
4
1
AP Chassis
Size (WxDxH) 146.8 x 146.7 x 35.5 mm (5.77 x 5.77 x 1.39
in.)
Weight 0.36 kg (0.79 lb)
Temperature Operating: 0° C to 50° C (32° F to 122° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 10% to 90% (non-condensing)
Network Interfaces
Ports Eth1/PoE RJ-45 Port: 1000BASE-T, PoE PD
Eth2 RJ-45 Port: 1000BASE-T
2.4 GHz Radio IEEE 802.11b/g/n
5 GHz Radio IEEE 802.11a/ac/n
Bluetooth Radio IEEE 802.15.1
Radio Frequencies 2.4 – 2.4835 GHz (US, Canada, ETSI)
5.15 – 5.25 GHz (lower band) US/Canada,
Europe
5.725 – 5.825 GHz (upper band) US/Canada
Power Specifications
PoE Input Power 44-55 VDC, 0.63-0.3 A, 802.3af/at-
compliant
DC Input Power 12 VDC, 1A
Power Consumption PoE Input: PoE 44~55 VDC, 11 W max
DC Input: 12 VDC, 10 W max.
Regulatory Compliances
Radio EN300 328 V2.1.1(2016-11)
EN301 893 V2.1.1(2017-03)
47 CFR FCC Part 15.247
47 CFR FCC Part 15.407
AS/NZS 4268: 2017
Emissions EN 301 489-1 V2.1.1 (2017-02)
EN 301 489-17 V3.1.1 (2017-02)
EN 55032:2015
EN 55024:2010/A1:2015
AS/NZS CISPR 32:2015, Class B
47 CFR FCC Rules and Regulations Part 15
Subpart B, Class B Digital Device
Canada Standard ICES-003, Issue 6, Class B
CNS 13438
LP0002 (ECW5211-L only)
Safety Low Voltage Directive (2014/35/EU, formerly
2006/95/EC, formerly 73/23/EEC)
CNS 14336-1
Taiwan RoHS CNS 15663
Quick Start Guide
