Edge Products CS User manual

Color Touch Screen
Color Screen
User Guide
User Guide
**READ IMPORTANT SAFETY INFORMATION IN THIS MANUAL**

TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLE OF CONTENTS USER GUIDE
2
Table Of Contents
INTRODUCTION.............................................. 4
SAFETY WARNING & CAUTION ......................................... 4
SAFETY GUIDELINES ........................................................ 5
LIMITED 1 YEAR WARRANTY ............................................ 6
WARRANTY INFORMATION ............................................... 7
CARB/EPA COMPLIANCE .................................................. 9
PRODUCT REGISTRATION ............................................... 10
PRODUCT INFORMATION ................................................ 10
USING THE MANUAL........................................................ 12
PARTS INCLUDED ............................................................ 13
PARTS DESCRIPTION .................................. 13
OPERATING INSTRUCTIONS ....................... 16
CS GAUGE SCREEN LAYOUT ..........................................16
CTS GAUGE SCREEN LAYOUT......................................... 17
GAUGE DISPLAY INFORMATION .....................................18
GAUGE LAYOUT OPTIONS............................................. 18
SELECT NEW PID...................................................... 18
ALERT SETTINGS...................................................... 18
GAUGE COLOR......................................................... 18
PID INFORMATION.................................................... 18
EXIT MENU .............................................................. 18
NAVIGATING THE MAIN MENU ........................................19
MENU BUTTONS .......................................................... 19
VIEW CAMERA (CTS)..................................................... 19
SHOW ALERTS ............................................................ 20
SHOW MAINTENANCE DUE............................................ 21
DIAGNOSTICS............................................................. 21
TROUBLE CODES ..................................................... 21
MANUAL DPF REGENERATION.................................... 22
TRANSMISSION RELEARN ......................................... 24
PERFORMANCE TESTS .............................................. 24
RECORDS ............................................................... 25
INJECTOR BALANCE RATES ....................................... 25
MILEAGE COACH ...................................................... 26
MAINTENANCE MANAGER ............................................. 28
OPTIONS MENU .......................................................... 30
ALERT OPTIONS (SETTINGS)...................................... 30
SOUND DURATION ................................................... 31
SCREEN LAYOUT...................................................... 31
BACKLIGHT AUTODIM ............................................... 32
MENU TIMEOUT........................................................ 32

TABLE OF CONTENTS
3
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TIRE SIZE................................................................ 32
ACCESSORY OPTIONS .............................................. 33
UNITS..................................................................... 34
FACTORY RESET ...................................................... 35
HELP MENU................................................................ 35
PRODUCT INFO -CS/CTS............................................ 35
PRODUCT INFO - EAS................................................ 36
VEHICLE INFO ......................................................... 36
CONTACT INFO ........................................................ 36
TECH SUPPORT TOOLS ............................................. 36
EVOLUTION ..................................................................... 37
PROGRAMMING........................................................... 37
USING LEVELS ........................................................ 37
CUSTOM OPTIONS ................................................... 37
POWER LEVELS........................................................... 39
ATTITUDE......................................................................... 40
POWER LEVELS........................................................... 40
JUICE CONTROL ......................................................... 40
HOT UNLOCKER .......................................................... 42
PROGRAMMING........................................................... 42
INSIGHT........................................................................... 43
EFI LIVE™ ................................................................... 43
USING ACCESSORIES .................................................... 44
EAS ........................................................................... 44
JAB (EAS) ............................................................... 44
EGT PROBE (EAS)..................................................... 44
EGT PROBE [STANDARD] ........................................... 44
EDGE BACKUP CAMERA ............................................... 44
EDGE MOUNTING SOLUTIONS....................................... 45
CUSTOMIZATION............................................................. 46
BACK GROUND IMAGE ................................................. 46
USING MYSTYLE ...................................................... 47
INTERNET UPDATES ....................................48
FUSION UPDATE SOFTWARE ......................................... 48
USING THE SOFTWARE................................................. 48
PROGRAMMING ERRORS .............................................. 50
UPDATE REQUIRED .................................................. 50
NON-STOCK CONDITION ........................................... 50
APPENDIX..................................................... 16
OEM EGT LOCATIONS ......................................................51
TIPS/TROUBLE SHOOTING ............................................. 54
COMMONLY USED ACRONYMS ...................................... 56
INDEX .............................................................................. 57

USER GUIDE
4
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
INTRODUCTION
S A F E T Y W A R N I N G & C A U T I O N
SAFETY WARNING & CAUTION
SAFETY TERMS
Throughout this User Guide (hereafter noted as User Manual or
Manual) you will see important messages regarding your safety or
the protection of your vehicle. These messages are designated by
the words WARNING or CAUTION.
WARNING indicates a condition that may cause serious
injury or death to you, your passengers or others nearby. Pay
careful attention to these Warning messages, and always comply
with them. They could save a life.
CAUTION indicates a condition that could cause damage to your
vehicle. It is important to install and operate your EDGE prod-
uct in conformance with instructions in this Manual. Caution
alerts you to particularly important things that will keep your
vehicle operating properly.
The Edge Product you have bought is a high-performance product.
As such, it does present some risks of which you should be fully
aware. Do not use this product until you have carefully read the
following safety information and the Owner Agreement.
NOTE: After the device has been installed, the screen and logo
will appear followed by a warning and compliance directive. To
indicate you accept and acknowledge the warning and compli-
ance, press the [ENTER] or [YES] button.

USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
INTRODUCTION
5
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
S A F E T Y G U I D E L I N E S
SAFETY GUIDELINES
SAFETY GUIDELINES
1. Do not exceed legal speed limits on public roadways. Use any
enhanced speed capabilities of this product only in closed circuit,
legally sanctioned racing environments expressly for this purpose.
Loss of control from speeding on a public road could seriously
injure you, your passengers, or others on the roadway.
2. Do not operate the device while driving. Perform all adjust-
ments or changes while stopped. Changing a setting while under
way can interfere with your attention to roadway conditions.
3. “Stacking” performance-enhancing devices or other improper
installation can cause power train failure on the road. Other
products may have features incompatible with your Edge device.
Follow all installation and operating instructions, and do not stack
products.
4. Some modifications may affect other parts of your vehicle. For
example, if you remove/adjust the speed limiter in your vehicle,
be sure your tires and other components are rated for the increased
speeds they will have to withstand. Not doing so can lead to loss
of vehicle control. Modify the speed limiter only for use in closed
circuit, legally sanctioned racing environments, not for use on
public roadways.
NOTE: Dispose of this product consistent with local codes. Re-
turn to your electronics supplier for proper handling.
WARNING
Misapplication or misuse of this product could lead to a seri-
ous or fatal accident. Comply with all safety information in this
manual, and your vehicle owner’s manual. Follow safety, instal-
lation and operating instructions in this User Manual to assure
proper use.

USER GUIDE
INTRODUCTION
6
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
L I M I T E D 1 Y E A R W A R R A N T Y
LIMITED 1 YEAR WARRANTY
LIMITED 1 YEAR WARRANTY
Edge Products, LLC, (hereafter “SELLER”) gives Limited Warranty as to
description, quality, merchantability, fitness for any product’s purpose, produc-
tiveness, or any other matter of SELLER’s product sold herewith. The SELLER
shall be in no way responsible for the product’s open use and service and the
BUYER hereby waives all rights other than those expressly written herein. This
Warranty shall not be extended or varied except by a written instrument signed
by SELLER and BUYER.
The Warranty is Limited to one (1) year from the date of sale and limited solely
to the parts contained within the product’s kit. All products that are in question
of Warranty must be returned shipping prepaid to the SELLER and must be ac-
companied by a dated proof of purchase receipt. All Warranty claims are subject
to approval by Edge Products Inc.
Under no circumstances shall the SELLER be liable for any labor charged or
travel time incurred in diagnosis for defects, removal, or reinstallation of this
product, or any other contingent expenses.
If the BUYER sends back a failed unit that is out of warranty and chooses to buy
a refurbished unit, the refurbished unit will only carry a 90 day warranty. If the
BUYER purchases a new unit at a predetermined discounted rate, it will have
the standard 1 year warranty.
Under no circumstances will the SELLER be liable for any damage or expenses
insured by reason of the use or sale of any such equipment.
THE INSTALLATION OF THIS PRODUCT INDICATES THAT THE BUYER
HAS READ AND UNDERSTANDS THIS AGREEMENT AND ACCEPTS ITS
TERMS AND CONDITIONS.
IN THE EVENT THAT THE BUYER DOES NOT AGREE WITH THIS
AGREEMENT, THE BUYER MAY PROMPTLY RETURN THIS PROD-
UCT, IN A NEWAND UNUSED CONDITION, WITH A DATED PROOF OF
PURCHASE, TO THE PLACE OF PURCHASE WITHIN THIRTY (30) DAYS
FROM DATE OF PURCHASE FOR A FULL REFUND.
NOTE: This warranty is void for any new products purchased through auction
web sites. Warranty is valid only for new products purchased through Autho-
rized Dealers (proof of purchase required for all warranty claims).

USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
INTRODUCTION
7
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
W A R R A N T Y I N F O R M A T I O N
WARRANTY INFORMATION
IMPORTANT INFORMATION ABOUT YOUR VEHICLE’S WARRANTY
Many of our customers ask, “Will your product void my vehicle’s manufac-
turer’s warranty?” While the answer is straightforward from a legal standpoint,
it’s important to educate our customers (and all aftermarket consumers) on some
industry realities and offer some common sense precautions to minimize your
risk. Edge is committed to providing quality products that are safe to use. Our
products do not cause damage to a vehicle when used as intended.
CAUTION: Operate your vehicle within manufactures recommended load and
weight limits as shown in the Manufactures Operator Manual. Please keep in
mind that towing in anything higher than the towing level and hard driving in
race or extreme performance levels using Edge products is not recommended.
Consumers of aftermarket products are protected by the Federal Magnusson-
Moss Warranty Act. The Act states that if something breaks on your vehicle and
you take it in for warranty repair, the dealer must honor your warranty unless
whatever modifications you have added to your vehicle actually caused the prob-
lem in question.
However, the reality is that many dealerships have been known to void warran-
ties on vehicles that use aftermarket products as a matter of policy. This applies
in particular to those aftermarket products that produce horsepower, such as
performance enhancement “chips,” modified intake manifolds, or aftermarket
exhaust systems, regardless of product brand.
You have strong legal protection as a consumer in regard to your vehicle’s war-
ranty. However, Edge strongly recommends you always disconnect and remove
your module/programmer and monitor when you take your vehicle to a dealer
for warranty work. In addition, leaving the product connected may affect dealer
diagnostic analysis and scan tool functions. Edge makes every effort to produce
product that can be easily removed.
NOTE: Even if you disconnect your unit, your dealer can detect the use of any
programmer—even if the unit has been removed.
Thank you for purchasing the Edge CS/CTS products. The CS and CTS products
have been developed and produced from the highest quality materials available
to ensure the best performance for years to come. If you have any concerns or
questions, please contact us.

USER GUIDE
INTRODUCTION
8
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
SERVICE CENTER AND COMPATIBILITY CAUTIONS
CAUTION: RETURN YOUR VEHICLE TO STOCK BEFORE TAKING IT
TOA SERVICE CENTER. All Edge modules and programmers are built to
operate with OEM calibrations. If you take your vehicle to a service center they
may, by your request or otherwise, update your vehicle’s calibrations. If this
happens and your vehicle has not been returned to stock your device will no
longer be capable of programming your vehicle. Therefore it is important that
you return your vehicle to stock before taking it in for service. Edge updates
its active products (i.e. those currently being manufactured) to work effectively
with updated OEM calibrations. However, this process can take some time as
Edge is not always made aware of calibration changes made by the OEM. In
the case of discontinued products, Edge cannot ensure that your unit will work
effectively if you take your vehicle to a dealership and you are given, by your
request or otherwise, a new calibration.
CAUTION: If you have used another tuner/programmer on your vehicle, you
will need to program the vehicle back to stock and remove the device before
using the Edge Product. Failure to return to stock may result in PCM failure
or engine damage. Programming your vehicle may expose existing defects in
the vehicle’s PCM that could disable your vehicle. It is advised that you do not
program your vehicle in remote locations in case of vehicle failure.
CAUTION: The Evolution programmer was developed on a stock vehicle with
no aftermarket bolt-on parts; as such, the performance changes implemented
by the Evolution may not be compatible with certain aftermarket power add-
ons. See below for a brief explanation of how the Evolution tuning may be
affected by certain aftermarket devices.
COLD AIR INTAKE (CAI) KITS
Most modern-day vehicles use a Mass Air Flow (MAF) sensor. The MAF
sensor is generally located in the intake tube close to the factory air box. MAF
sensors play a key role in determining the amount of fuel an engine needs at any
given throttle position. MAF sensors are precisely calibrated for the factory
intake systems; changes in intake tube diameter, sensor placement, or filter flow
characteristics can adversely affect the reading from the MAF sensor. Most of
the CAI kits on the market change intake tube diameter, sensor placement, or
filter restriction. These changes may cause the sensor to command leaner fuel
conditions. Most of the CAI kits on the market are developed on stock vehicles,
where a leaner fuel curve may be acceptable. Due to the fact that the evolu-
tion already alters the vehicle’s fueling strategies, CAI kits that create a leaner
condition used in conjunction with the Evolution may cause the vehicle to run
excessively lean. Excessively lean conditions can cause pre-ignition which can
lead to detonation, a condition that could potentially damage an engine.

USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
INTRODUCTION
9
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
There are currently a large number of CAI kits on the market. These kits are de-
signed to improve air flow and temperature. Some of these kits may be compat-
ible with the Evolution programmer; however others may cause a lean condition
when used in conjunction with the Evolution tuning. If you use the Evolution
in conjunction with a CAI kit on E/F Series 1997 and newer (especially on a
2004 or newer Ford F-150) and you think you are experiencing a lean condition
you may need custom tuning. Please contact Power Hungry Performance at
www.gopowerhungry.com. They can provide custom tuning for your Evolution
programmer.
MECHANICAL MODIFICATIONS
Mechanical modifications such as headers, upgraded camshafts, displacement
changes, cylinder head improvements etc. will change the airflow characteristics
of an internal combustion engine. The Evolution is not tailored to take advan-
tage of these modifications, for the best results we recommend vehicle specific
custom tuning.
FORCED INDUCTION (TURBOCHARGERS OR SUPER-
CHARGERS)
Turbochargers and Superchargers drastically change the dynamics/performance
of the engine, and its fueling/timing needs. Additional hard parts and custom
tuning are required to run a forced induction system on an engine that was origi-
nally designed as a Naturally Aspirated (NA) engine. The Evolution does not
support the addition of an aftermarket forced induction kit.
* Power Hungry Performance can provide custom tuning for all aftermarket
power adders on Fords only: Visit: www.gopowerhungry.com
C A R B /
CARB/
E P A C O M P L I A N C E
EPA COMPLIANCE
This product meets the emissions compliance require-
ments of the California Air Resources Board and Fed-
eral Environmental Protection Agency and is legal for
sale and use on pollution-controlled vehicles operated
on public streets and highways. It must be installed and
operated according to the instructions provided in this
user’s manual. Included with this product is a sticker
like the one pictured for you to keep in your vehicle. You can either apply it
somewhere on the vehicle (e.g., the inside end of driver’s door) or simply store
it in your glove box. The purpose of these stickers is to inform anyone who
may have questions regarding the use of your Edge product and how it affects
emissions. For example, it would be something to show an emissions technician
if questioned when taking your vehicle in for an emissions check to let him/her
know the product is CARB emissions compliant.
NOTE: The stickers included in some products apply to products
that have received CARB exemption for emissions compliance.

USER GUIDE
INTRODUCTION
10
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
INTRODUCING THE CSAND CTS MODELS
From the pioneers in display-based technology and engine performance manage-
ment, comes the CS (Color Screen) and CTS (Color Touch Screen) for popu-
lar late model vehicles. Edge has reinvented 3 of its most popular lines – the
Evolution, Juice/Attitude, and Insight– with an all-new look and exclusive new
features.
THE BREAKDOWN
Three product lines, two screen options. It’s just that simple. Edge has taken its
best-known products – the Evolution, Juice/Attitude, and Insight, – and given
them a fresh look, improved features and benefits, and pricing that will make the
competition obsolete. Consumers can pick the product that suits their needs and
then choose the screen option that best fits them.
P R O D U C T I N F O R M A T I O N
PRODUCT INFORMATION
PLEASE take the time to register your product on line at:
www.edgeproducts.com.
Follow the instructions at link:
http://www.edgeproducts.com/product_registration.php
BENEFITS OF PRODUCT REGISTRATION
-Your Safety - Registering your product allows us to know exactly which
product you have and provide important product updates to you that improve the
quality and/or safety of the product.
-Enhanced Features -Almost all Edge products are easily updated via the in-
ternet. We are constantly adding new features and improvements to our product
that we know you will want to enjoy.
-Confirmation of Ownership - Provides a record in case of product loss, theft,
or required warranty work. When you call us for support our team will already
have much of the information they need to help you.
-Improved Product Development - Helps us better understand you (our cus-
tomers) and design products that meet your needs.
-Special Offers - Allows us to inform you about special offers on accessories
and/or new products that fit your vehicle and enhance your driving experience.
P R O D U C T R E G I S T R A T I O N
PRODUCT REGISTRATION

USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
INTRODUCTION
11
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
THE CS (COLOR SCREEN)
The CS – an acronym for Color Screen – has a famil-
iar feel of Edge’s popular legacy Attitude and Evolu-
tion. This new full-color digital
display features a rugge-
dized case, user-friendly
buttons, an easy-to-nav-
igate menu, and a light
sensitivity sensor that
automatically adjusts the
brightness for improved
night viewing.
THE CTS (COLOR TOUCH SCREEN)
The CTS – an acronym for Color Touch Screen – is the pin-
nacle of what made Edge popular: Innovation. The CTS model
features a full-color,
button-free, touch-
screen digital display;
an easy-to-navigate
menu; a light sen-
sitivity sensor that
automatically adjusts
the brightness for im-
proved night viewing;
and a video-in jack
that supports most
off-the-shelf backup
cameras or DVD players with an RCA jack.

USER GUIDE
INTRODUCTION
12
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
For specific information regarding horsepower, torque, and other
features available for this product:
1. Go to www.edgeproducts.com
2. Type the part number of your product in the “KEYWORD/
PART# SEARCH” and press enter.
3. Click the link under “Description”
4. Scroll down to the “DOWNLOAD VEHICLE SPECIFIC
HORSEPOWER, TORQUE,AND FEATURES CHART” link and
click on it.
5. Find the information that is specific to your make and model.
This manual includes coverage of the best known Legacy Edge
Products – the Evolution, Juice/Attitude, and Insight. You may be
familiar with the products and this manual will help you navigate
through their operation on the CS/CTS device platform. Most of
the menus, features and operation are similar and common to each
other for the various products.
When features or operation are different, the various sections or
paragraphs will be identified to the product. (e.g., Evolution, At-
titude, Insight...). Look for those pages or sections related to your
product and then choose the screen, features or option that best fit
your needs.
NOTE: The display screens, menu items and operating instruc-
tions contained in the following pages are meant to cover a wide
variety of CS/CTS devices (Evolution, Attitude, Insight, ect.) as
well as multiple vehicles (Ford, Chevy, Dodge). Every menu
and feature is not shown in detail for each device, but selection
and changes are made in a similar manner using the different
devices. Also, some of the options/features covered in the operat-
ing instructions may not apply to your device or vehicle. Your
CS/CTS device will display only the menus, options and features
that are unique to your device and those features and options
your vehicle’s computer system is capable of executing. As such,
not every menu and screen is explained in this manual. Most are
user intuitive and similar in functionality.
U S I N G T H E M A N U A L
USING THE MANUAL

PARTS DESCRIPTION
13
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
P A R T S I N C L U D E D
PARTS INCLUDED
Supplied Items Suggested Tools
1. CS or CTS Device
2. Arkon Windshield Mount
3. OBDII Cable
4. Mini USB Cable
5. CD
(contains manual/update software)
6. Alcohol Wipe
7. Zip Tie Packet
• Flat head screwdriver
• Cutting Pliers
(NOTE: Refer to #4 below.
Plugging both USB connec-
tors into you computer will
give you the best results.)
1
2 3
4 5
6 7

PARTS DESCRIPTION
14
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
NOTE: The Parts Description section of this manual describes
each of the main parts included in your CS/CTS kit both physi-
cally as well as functionally. Refer to the “CS/CTS Quick install
Guide” for proper installation and windshield mounting.
CTS DEVICE
The CTS device provides you with an in-
terface to change the performance program-
ming on your vehicle as well as gives you
a multi-color touch screen display which
allows you to monitor multiple vehicle
parameters in real time. It is equipped with
a large touch screen, a USB port (for PC
communication and electronic updates),
a 16-pin connector (for main vehicle communication), a video-in
jack, and a six-pin accessories connector which allows you to fur-
ther extend the capabilities of the device (see the accessories page
in the back of the manual).
CS DEVICE
The CS device provides you with an
interface to change the performance
programming on your vehicle as well as
gives you a multi-color screen display
which allows you to monitor multiple
vehicle parameters in real time. It is
equipped with a full color screen, a Menu
button, Up and Down Arrow button, an
Enter button, USB port (for PC communication and electronic up-
dates), a 16-pin connector (for main vehicle communication), and a
six-pin connector.
CS/CTS WINDSHIELD MOUNT
The windshield mount supplied with your CS/
CTS kit is designed to give you flexibility in
mounting your device anywhere you’d like on
your windshield. It is equipped with a locking
suction cup, a vertically adjustable arm, and a
180 pivot head which allows you to fine tune
the viewing angle to your preference.

PARTS DESCRIPTION
15
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
MINI USB CABLE
The USB cable is used to connect your device
to your PC in order to perform firmware and
calibration updates using Edge Products Fusion
software. It is recommended you plug both USB
connectors into the computer, and complete the
Fusion software installation before connecting
the device.
CS/CTS COMPACT DISC
The CS/CTS compact disc contains the Fusion
update software, and PDF files for the Installa-
tion manual as well as the quick install guide.
Also includes the NEW MyStyle™ Software to
customize your display screen.
ALCOHOL PAD
The alcohol pad is supplied for cleaning the
windshield prior to mounting the suction cup
equipped Arkon mount.
ZIPTIES
The zip tie packet contains zip ties to help
you secure the OBDII cable out of the
way under the dash.
CS/CTS OBDII Connector
The OBDII connector/cable has two
plugs, a smaller male 16-pin plug that
connects to the back of your device, and a
larger rectangle style 16-pin male connec-
tor which connects to the OBDII port located under the driver’s
side dashboard. The purpose of this connector is to provide a com-
munication link between your vehicle and your device as well as
provide a power and ground source. (NOTE: This cable must be
plugged into both the OBDII port as well as the CS/CTS in order
for the Display to function.

OPERATING INSTRUCTIONS
16
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
1. Up/Down Arrow Button - On the ATTITUDE gauge screen these buttons are
used to toggle the power level up/down. The EVOLUTION gauge screen may
use these buttons in future feature enhancements. The INSIGHT uses these to
adjust power levels when using EFILive™. In the menus these buttons
are used to select the menu items and increase or decrease values.
2. Menu Button - The menu button gives you access to the main menu or can
be used to exit out of a menu screen.
3. Left Gauge - The left analog gauge. The displayed parameter for all gauges
can be changed by pressing the enter button, choosing the desired gauge,
and selecting a dierent parameter from the list.
4. Alert Indicator - The alert indicator light will illuminate (red) when an alert
limit is exceeded. When this light contains an “R,” it indicates that your Diesel
Particulate Filter (DPF) equipped vehicle is performing a regeneration cycle.
If the light is blue and contains a wrench your Maintenance Manager is
letting you know a maintenance item is ready to be serviced.
5. Power Level Indicator - The power level indicator represents the current
power level. 0represents stock. I stands for Insight which produces no ad-
ditional horsepower.
6. Back-down Indicator - (ATTITUDE with JUICE) The back-down indicator
light will illuminate (yellow) when the Juice module is decreasing power
added by the device, when approaching or exceeding the back-down set
point limit.
7. Right Gauge - The right analog gauge.
8. Enter Button - The enter button when pressed from the main screen will
allow you to change the gauge parameters (PID, Alert Settings, and Gauge
Color). In the menus it allows you to select the highlighted option.
9. Center Gauge - The center gauge.
654
9
2
8
1 73
Figure 1
C S G A U G E
CS GAUGE
S C R E E N L A Y O U T
SCREEN LAYOUT

OPERATING INSTRUCTIONS
17
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
5 3
10
32
8
1
9
7
64
1. Main Menu button - The main menu button gives you access to the main
menu.
2. Left Gauge - The left analog gauge. The displayed parameter for all
gauges can be changed by simply touching the gauge and choosing a dier-
ent parameter from the list. Use this menu to choose a new PID, change alert
settings, and choose a new gauge color.
3. Up/Down Arrow Buttons - On the ATTITUDE gauge screen these buttons
are used to toggle the power level up/down. The EVOLUTION gauge screen
may use these buttons in future feature enhancements. The INSIGHT uses
these to adjust power levels when using EFILive™. In the menus these
buttons are used to select the menu items and increase or decrease values.
4. Alert Indicator - The alert indicator light will illuminate (red) when an alert
limit is exceeded. When this light contains an “R,” it indicates that your Diesel
Particulate Filter (DPF) equipped vehicle is performing a regeneration cycle.
If the light is blue and contains a wrench your Maintenance Manager is
letting you know a maintenance item is ready to be serviced.
5. Power Level Indicator - The power level indicator represents the current
power level. 0 represents stock. I stands for Insight which produces no ad-
ditional horsepower.
6. Back-down Indicator - (ATTITUDE with JUICE) The back-down indicator
light will illuminate (yellow) when the Juice module is decreasing power
added by the device, when approaching or exceeding the back-down set
point limit.
7. Right Gauge - The right analog gauge.
8. Lower Left Gauge - The lower left digital gauge.
9. Center Gauge - The Center analog gauge.
10. Lower Right Gauge - The lower right digital gauge.
Figure 2
C T S G A U G E
CTS GAUGE
S C R E E N L A Y O U T
SCREEN LAYOUT

OPERATING INSTRUCTIONS
18
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
This feature allows you to
adjust gauge display informa-
tion directly from the main
gauge screen. To adjust what
the gauge displays, follow
these instructions:
1. CTS - While viewing the
main gauge screen, touch the
gauge you would like to
modify.
2. CS - While viewing the
main gauge screen, press the
enter button and select the
gauge location you would like
to modify.
The following screen will
appear.
Engine Coolant Temp
Gauge Color
PID Information
Exit Menu
Alert Settings
Select New PID
E
n
g
ine Coolant Tem
p
G
au
g
e
C
olor
P
ID In
fo
rm
a
ti
o
n
E
xit M
e
n
u
A
l
ert
S
ettin
g
s
S
e
l
ec
t N
e
w PID
MENU
ENTER
(Figure 2.1)
SELECT NEW PID
Select the PID that you would
like to monitor from the pro-
vided list.
GAUGELAYOUTOPTIONS ALERT SETTINGS
For more information, refer
to the “ALERT OPTIONS
(SETTINGS)” section under
the “OPTIONS MENU” sec-
tion of this manual.
GAUGE COLOR
Choose a color from the list.
This will modify the gauge in-
dicator. NOTE: Only Analog
gauges can be modified.
PID INFORMATION
This briefly explains what the
selected PID is and/or what it
monitors.
EXIT MENU
Brings you back to the main
gauge screen.
G A U G E D I S P L A Y I N F O R M A T I O N
GAUGE DISPLAY INFORMATION

OPERATING INSTRUCTIONS
19
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
N A V I G A T I N G T H E M A I N M E N U
NAVIGATING THE MAIN MENU
ATTITUDE
Figure 3
EVOLUTION
Figure 4
INSIGHT
Figure 5
NOTE: The following will only show under
certain circumstances:
1. “View Camera” will only show if a camera is
plugged into the video jack located on the back
side of the CTS. Does not apply to CS.
2. “Show Alerts” will only show if an alert is
active.
3. “Show Maintenance Due” will only show if
your Maintenance Manager is turned on and a
maintenance item is due.
MENUBUTTONS
Both the CS and CTS devices
provide you with the following
three buttons for navigating the
menu system:
Menu: The Menu button allows
you to enter the main menu.
Once you are in the main menu
you’ll use the Menu button to
return to the previous screen.
UP/Down Arrow: The Up/Down
Arrow button will allow you to
toggle up or down through the
menu options, you’ll notice it
highlights each option as you
toggle.
Enter: Pressing the enter Button
will select the currently high-
lighted option.
NOTE: With the CTS device
you can simply touch the
option you’d like to select on
the menu screen. As a touch
screen device it will automati-
cally select the option you’ve
touched and advance you to
the selected option screen.
VIEWCAMERA(CTS)
NOTE: If you have a back-up
camera or other RCA device
connected to the CTS, the view
camera menu item will be

OPERATING INSTRUCTIONS
20
USER GUIDE
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
TABLEOFCONTENTS INTRODUCTION PARTSDESCRIPTION OPERATINGINSTRUCTIONS INTERNET UPDATES APPENDIX
active within the main menu.
1. Selecting “View Camera” in
the “Main Menu” list, will
allow you to view the camera
image. If you would like to
stop viewing the camera image,
touch the screen and the main
gauge screen will re-appear.
WARNING: Do not rely
solely on the camera image for
backing up. It is possible for
the camera image to freeze.
Always use your mirrors, and
look behind you before backing
up. Objects in the view may be
closer than they appear. If you
are using a camera not manufac-
tured by Edge Products, the
image may be reversed.
SHOWALERTS
The CS/CTS device is equipped
with an alert system that notifies
the user when vehicle param-
eters are outside a user-defined
value. There are a few ways the
CS/CTS alerts are indicated and
accessed:
MAIN SCREEN METHOD
If one of your gauges on the main
screen (Refer to Figures 1 & 2)
contains the alert parameters, 2
things will occur:
1. The alert notification will sound
only if it is turned on. (Sound will
turn off after a few seconds
depending on the sound duration
you have set)
2. The gauge back-light will flash.
(Will continue flashing as long as
the parameter is outside the
user-defined value)
NOTE: The alert sound and
flashing will discontinue once
parameter is no longer out of the
user-defined value.
ALERTS SCREEN METHOD
This Alerts screen (Figure 6)
will show all parameters for
which an alert has been set. If
an alert value is outside the
user-defined setting, it will flash
red. The Alerts screen will stay
in view for a minimum of three
seconds, until no alert condition
exists, or until the screen/menu
button is touched, at which
point it will return to the main
gauge screen.
Figure 6
NOTE: This menu only ap-
pears when there is an alert
active. It shows the current,
active alerts and their current
values.
