EdgeLight AF17 Series User manual

Shanghai Edge Light Industry Co.,LTD.
TEL:[phone]
FAX:[phone]
E-mail: [e-mail]
Published by EdegeLight ®Corporation
Copyright 2010 EdegeLight ®Corporation
All rights reserved.
is a trademark of Shanghai Edge Light Industry Co., Ltd
http://www.cnedgelight.com
AF17 Series Slim Light Box
Operating Instructions
(Read this manual carefully before using EdegeLight ® Product)
1
Edgelight®

Operating Instructions
WARNING
IMPORTANT
is a trademark of Shanghai Edge Light Industry Co., Ltd
http://www.cnedgelight.com
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing) instructions
in the literature accompanying the
appliance.
CAUTION:
TO PREVENT THE RISK OF
ELECTRIC SHOCK,DO NOT
REMOVE COVER (OR BACK).
NO USER-SERVICEABLE
PARTS INSIDE.REFER
SERVICING TO QUALIFIED
SERVICE PERSONNEL.
instructions so you will know how to operate your unit properly. After you have finished reading the
Thank you for buying this EdegeLight ®product. Please read through these operating
The lightning flash with
arrowhead symbol,within an
equilateral triangle, is intended
to alert the user to the
presence of uninsulated
"dangerous voltage"within the
product's enclosure that may
be of sufficient magnitude to
constitute a risk of electric
shock to persons.
INFORMATIOON TO USER
Alteration or modifications carride out without appropriate authorization may invalidate the user's right
to operate the equipment.
instructions,keep them in a safe place for future reference.
This product is not waterproof. To prevent a fire or shock hazard, do not place any container filed
with liquid near this equipment or expose it to dripping, splashing, rain or moisture.
CAUTION
DO NOT OPEN
2
Edgelight®

Operating Instructions
SAFETY INSTRUCTIONS
READ INSTRUCTIONS-Read all safety and operating instructions before operating this product.
RETAIN INSTRUCTIONS-Retain the safety and operating instructions for future reference.
FOLLOW INSTRUCTIONS-Follow all operating and use instructions.
HEED WARNINGS-All warnings must be adhered to.
WATER AND MOISTURE-DO NOT use this product near water.
is a trademark of Shanghai Edge Light Industry Co., Ltd
http://www.cnedgelight.com
OVERLOADING-DO NOT overload wall outlets and extension cords. Doing so can result in fire or
electric shock.
To ensure your personal safety and to maximize the full operating potential of this product, read and
follow these safety precautions:
ENVIRONMENT-DO NOT use the unit at places with high levels of dust, high temperature, or high
humidity. Please use the unit in a place where it is not subjected to vibrations or shocks.
POWER- Please use correct power as required for this product.
OBJECT AND LIQUID ENTRY-Never push objects of any kind into this product. Touching dangerous
voltage points may cause a short resulting in fire or electric shock.Do not spill liquid of any kind on this
product.
POWER SOURCES- Operate this product from the type of power source indicated on the marking
label. If you are not sure of the type of power available, consult Authorized EDGELIGHT TM Dealer.
CLEANING-DO NOT use aerosol cleaners. Use only a little alcohol or a damp cloth to clean the
exterior housing.
CONDENSATION-Moisture will form in the operating section of the product causing performance to be
impaired if it is brought from cool surroundings into a warmer environment.If you are moving the unit to
a location with a warmer temperature. let the product stand for 1 to 2 hours in the new location before
turning it back on.
3
Edgelight®

Operating Instructions
SPECIFICATIONS
Frame size Viewing size Thickness Film size Packing size Volume Gross weight
mm mm mm mm cm m3 Kg
B0 1452×1048 1382×978 1414×1000 162×9×121 0.18 25.1
B1 1038×755 968×685 1000×707 114×9×85 0.09 13
B2 745×548 675×478 707×500 84×9×65 0.05 6.8
A0 1227×889 1157×819 1189×841 134×9×102 0.12 17.7
A1 889×632 823×566 594×841 100×9×77 0.07 10.4
A1 632×889 562×819 594×841 100×9×77 0.07 10.4
A2 642×458 576×392 420×594 73×9×57 0.04 6.9
A2 458×642 392×576 420×594 73×9×57 0.04 6.9
A3 468×335 402×269 297×420 58×9×46 0.02 4.7
A3 335×468 269×402 297×420 58×9×46 0.02 4.7
A4 345×248 279×182 297×210 50×5×30 0.01 2.8
INSTALLATION
Graphic Replacement
1. Turn off power
2. Open the four upper covers
3. Remove front board and AD graphic
4. Change AD graphic
5. Place the front board
6. Close the four upper cover
is a trademark of Shanghai Edge Light Industry Co., Ltd
http://www.cnedgelight.com
Item
AF17
LED
28
Life span
Above 50000h
AF17 SERIES
4
Edgelight®

Operating Instructions
Please see as follows:
On the ceiling
1. Measure installation dimension
2. Hang the light box in the right place
A. If the wall is made of wood, plastic, aluminium and so on, you can directly hang the lightbox by ligntboxes pendants.
can directly hang the lightbox by
lightboxes pendants
B. If the wall is made of concrete, brick, marble and so on, you should firstly drill holes in the wall or ceiling
and screw expand screws, and then hang the lightbox by lightboxs pendants.
3. Connect the power supplier
is a trademark of Shanghai Edge Light Industry Co., Ltd
http://www.cnedgelight.com
5
Edgelight®

Operating Instructions
ACCESSORIES
Operating instruction x 1
Power supply (AC100-240V) x 1
(Various plugs are available for your needs，such as CE, UL, SAA, etc.)
CE UL SAA
NOTICE
*Pay more attention that Slim Light Box not to be crashed. While transporting or working, keep
sharp edge or instrument away from Slim Light Box . Use soft & wet textile to clean front board
to avoid being scratched. Make sure to use right voltage.
* Specifications and design subject to possible modifications without notice, due to improvements.
is a trademark of Shanghai Edge Light Industry Co., Ltd
http://www.cnedgelight.com
Neon
