Glow Bricks LEGO JAZZ CLUB User manual

1

2
Let’s start from the first level, take the shown lighting parts be ready

3
Remove the shown tiles and take the lighting round brick at
the end to replace the lamp
Detach and separate the shown parts as shown

4
Restore the front door and be careful the wires have to be
placed in between the studs
Get the shown part, remove all the yellow rounds and replace
them by the lighting parts, assemble it as shown

5
Restore the wall and assemble the lighting round plates on the
lights after that
Now place the front door back to the building, and place the
remain round plates on the side to assemble on the lamps
*Remove the shown parts first to place the wires inside the wall
can hide the wires in purpose to make the model looks better

6
Assemble white lighting lamp and the yellow lamp, then place the
wire in between the studs and put the removed tiles back on it

7
Then lift off the bricks above the door a little bit to pass through
the remain yellow lighting plate to replace the round plate
Replace the white lamp and the yellow round plates on the spot
lights by the lighting parts

8
Then stick the led bar on the sign and restore the cover right after
At last, move the led bar to the sign area, lift off the sign to place
the wire underneath

9
Assemble the lights at the bottom and make sure to place the lights exactly
the same way as shown
Now it’s turn for the second floor, take the shown lighting parts be ready

10
Place the other connector to the above level, then combine the
floors and leave the plug at the stairway
Now combine the 1st and 2nd floor, connect the plugs as shown

11
Assemble the lighting plates to the bottom of 3rd floor
Now take the remain three lighting parts for the corresponding part of the house

12
The remain light will be assembled on the top, move it to the shown position
and cover the wire by the tiles
Assemble for the other side of 3rd floor

13
Now it’s turn for the roof, assemble the longer lighting plates first
Then put the greenhouse back on it

14
Remove the shown parts and move the remain lighting 1x2 plates to the front
and assemble them as shown

15
To combine the roof and 3rd floor, start by moving the plug of the 3rd floor to
the above level
There would be 2 connectors be pulled out of the building

16
Combine with the 2nd floor by connecting the plug mentioned on page 10
Then connect the cables with the roof

17
At last, replace the lamppost by the lighting lamppost, connect two
connectors to the USB cable then you can light it up
Connect with the 3rd floor with greenhouse attached
