EG Athens 350DX User manual

ELECTRIC BICYCLE OWNER’S MANUAL
For Owners of EG Athens 350 X Electric Bicycle
Table of Contents
Descriptions: Page
Installation Instructions 2
How to install the bicycle out of the box 2
Operation Instructions 3
How to operate the Electric Bicycle 3
About the Brake Safety Feature on all our Electric Bikes 4
How to rea the Battery Meters an about the Li-on Battery 5
Care Instructions 5
Battery 5
Storage, Maintenance an Transport 6
Battery 6
Charger 6
Charger 6
Accessories 6
Electric Motor an Battery Features 7
Charging the Battery 7
Repair an Service 7
Inspection of the Bearings an Maintenance 8
Serial Numbers to your EG Electric Bike 8
How to etach the rear wheel of the Electric bike 8
1

INSTALLATION INSTRUCTIONS
How to install the bicycle out of the box
1. Unpack the bicycle from the box an cut all the ties that hel the bicycle together uring
shipping.
2. Install the han le bar by inserting the han lebar stem into the hea tube. An Allen key is
supplie to install the han le bar stem.
3. A just the han lebar by loosening the nut hol ing the han lebar an then re-tightening it with
the inclu e Allen wrench.
4. ! WARNING: Do NOT over tighten nut against the fork; for you will risk amaging your
suspension fork.
5. The front an rear LED/reflector run on the main Li-on battery, an is operate via the light
button on the han lebar isplay unit.
6. Install the pe als to the bike. Each of the pe als has a letter in icating which si e it nee s to
be installe to. R=Right an L=Left. Install them using the provi e wrench.
7. ! WARNING: Before ri ing the bicycle ensure the main Li-on battery is properly installe an
locke in before ri ing the bicycle. If the Battery is not firmly locke onto the rear rack, it may
sli e off the rack an cause amage to the battery.
8. Insert the battery into the rear rack an lock in your battery with provi e key. Ensure that the
rails are properly aligne below the battery. Ensure that the battery is locke in by lightly
tugging on the battery to ensure it will not sli e out.
2

OPERATION INSTRUCTIONS
How to operate the Electric Bicycle
The Electric bicycle can be operate in 3 ifferent mo es:
1. Manual Mode –
Make sure the Display on the bike is “OFF” an then, pe al the bicycle normally as you
woul any bicycle.
2a. Pedal Assist Level 1 –
Turn on the battery power to the electric bike by turning the key clockwise to the “ON”
position.
Press an hol “MODE” button on the pa locate to the left of the han lebar to turn “ON”
the system. Pe al the bicycle normally as you woul any bicycle.
The motor will stop if the brake lever is epresse even if you are still pe ling the bicycle.
The motor will stop when you stop pe ling in this mo e.
When first switche “ON” the motor starts off in the “Level 1”.
In this mo e the motor is very power efficient, an will assist you with the least power as
you pe al.
In “Level 1”, the system provi es you with the most “miles per charge” of battery power use
among the pe al assist mo es.
2b.Pedal Assist Mode Level 2 –
To put the bike in PAS “Level 2” pe al assist mo e, switch “ON” the bike by pressing an
hol ing the “MODE” button on the Pa locate to the left of the han lebar an then press
“UP” button on the pa until “2” appears on the LCD screen. Pe al the bicycle normally as
you woul any bicycle.
In PAS “Level 2” the motor will assist you with a mo erate amount of power as you pe al
the bicycle.
The motor will stop if the brake lever is epresse even if you are still pe ling the bicycle.
The motor will stop when you stop pe ling in this mo e.
This mo e will give you a balance “miles per charge” of battery power use among the
pe al assist mo es.
2c. Pedal Assist Mode Level 3 –
To put the bike in PAS “Level 3” pe al assist mo e, switch “ON” the bike by pressing an
hol ing the “MODE” button on the Pa locate to the left of the han lebar an then press
“UP” button on the pa until “3” appears on the LCD screen. Pe al the bicycle normally as
you woul any bicycle.
In this mo e, the motor will assist you with a high amount of power as you pe al the
bicycle.
! CAUTION: This mo e is esigne to achieve a spee of 20 MPH. User iscretion is
a vise
The motor will stop if the brake lever is epresse even if you are still pe ling the bicycle.
The motor will stop when you stop pe ling in this mo e.
This mo e will give you a low “miles per charge” of battery power use among the pe al
assist mo es.
2d.Pedal Assist and Throttle on demand PAS Level 0)–
3

To put the bike in Pe al assist an “Throttle on eman ” mo e, switch “ON” the bike by
pressing an hol ing the “MODE” button on the Pa locate to the left of the han lebar
an then press “DOWN” button on the pa until “0” appears on the LCD screen. Pe al the
bicycle normally as you woul any bicycle.
In this mo e, the motor will only function with the use of the throttle.
The Pe al assist will not function in this mo e.
! CAUTION: This mo e can achieve a spee of 20 MPH. User iscretion is a vise
The motor will stop if the brake lever is epresse even if you are have the throttle
epresse /engage .
This mo e will give you a Me ium to low “miles per charge” of battery power use among
the pe al assist mo es, epen ing on your throttle use
To switch back to pe al assist mo es, press the “UP” button until you reach the esire
PAS level.
3. Fully Electric Mode –
To ri e the bike fully on “Electric Mo e”, switch “ON” the bike by pressing an hol ing the
“MODE” button on the Pa locate to the left of the han lebar.
Place the PAS on any level you esire, because while the thumb throttle is engage , the
pe al assist mo e is not active an has no effect on the spee or power of the electric
motor.
Depress the thumb throttle in any increments of power you esire to power the motor of the
bicycle an it will take off.
This mo e can be use in conjunction with any of the above mo es as the amount of motor
power supplie while twisting the thumb throttle overri es whatever mo e the PAS Level
the system is engage in.
You can engage this mo e whenever you want as long as the system is turne “ON”.
While pe ling will lighten the loa eman on the electric motor, you o NOT nee to
pe al in this mo e of operation.
! CAUTION: This mo e is esigne to achieve a spee of 20 MPH. User iscretion is
a vise
The motor will NOT stop when you stop pe ling while the thumb throttle is engage .
The motor will stop if the brake lever is epresse even if the thumb throttle is engage .
! CAUTION: Remember to let go of the thumb throttle when getting on or off the bike
weather or not the brake levers are engage .
In this mo e, the electric bike will use the most amount of battery power it will use even
more battery power than in any of the pe al assist mo es.
This mo e will give you the least “miles per charge” compare to any of the above mo es
of operation
About the Brake Safety Feature on all our Electric Bikes.
ALL our electric bikes make use of a wire brake lever kill switch for safety purposes. When
the brake lever is engage , it sen s a kill signal to the controller to isable the motor un er
all circumstances an con ition. This will ensure the motor oes not continue to spin when
you nee the bicycle to stop.
4

How to read the Battery Meters and about the Li-on battery
There are 2 Battery meters on your bike. 1 is locate conveniently on the top of the LCD screen on
the han le bar. The 4 re Bar graph in icates the state of the battery ischarge. The other Battery
meter is locate on to the top rear of battery with 4 green an 1 re LEDs showing the current
capacity of the battery in various states of ischarge.
As with any Lithium-ion batteries, there are a limite number of times a battery can be charge . While
priming Lithium-ion batteries are not necessary (which means it may be charge whenever you want
without affecting its charge capacity), the number of times it is charge oes affect the overall
longevity of the battery life.
To conserve battery power, switch off the electrical system by pressing the “ON/OFF” button on the
meter on the left of the han lebar, when the electric power is not nee e .
! NOTE: You can remove the keys from the bike after locking the battery onto the rack. You will nee
to insert an leave the key on the bike to operate the electrical system of this bicycle.
! WARNING: Please keep your keys to your electric bicycle in a safe place. Each set of keys are
unique to your particular electric bicycle an unfortunately we o not keep a copy of your keys on file.
Nor woul we have a way of repro ucing them.
CARE INSTRUCTIONS
Battery
！WARNING:
Never short circuit the charge or ischarge battery terminals.
Never charge the battery by the ischarge terminals or ischarge the battery by the charge
terminals.
Keep the battery away from excessive heat an or open flames.
Never pour on or submerge the battery in water.
To avoi amage to the battery, never subject the battery to intense physical impact, shock or
severe vibration.
Protect the battery from water or moisture at all times.
Protect the ischarge an charge terminals of the battery from rain or water logging.
Keep the battery away from chil ren.
When the battery is not in use for an exten e perio of time, remove the battery from the
battery hol er for storage.
Never isassemble the battery. The battery oes not contain serviceable parts.
Do not sit on or place any object on or over the battery.
Use only the supplie charger to charge the battery.
Battery capacity: 10Ah
Battery an Motor Voltage: 36V
Charge temperature range 0~45℃
Discharge temperature range –20~55℃
Total Charge time from total ischarge: 4-6 hours
Total Charge time for the initial first 3 charges: 12 hours
5

If you have any questions about this battery or its usage, please o not hesitate to contact us
Storage, Maintenance and transport
Battery
If the battery nee s to be store for an exten e perio of time, it shoul be kept at aroun
50% charge capacity (or charge the battery for about 2-3hours from empty) an shoul be
place in a ry an well ventilate place.
To maintain battery life expectancy, the battery nee s to be charge at least once for 2-3 hours
every two months.
The battery an charger shoul be kept in storage in a clean, ry an well ventilate place.
Avoi contact with corrosive substances an keep the battery away from excessive heat an
or open flames.
Shoul the battery nee to be transporte , pack it in a box, an ensure that it is always
protecte from intense physical impact, shock, severe vibrations, irect sunlight, or water
logging. The battery may be transporte in a vehicle such as an automobile, train, ship,
airplane an etc. Please check your local rules an regulations regar ing such transportation.
Battery Storage con itions: Room temperature -20～35℃,
Battery Storage relative humi ity: 5～65％RH
Charger
The charger shoul be isconnecte from the battery when it is kept in storage.
Shoul the charger nee to be transporte , pack it into a box an ensure that it is always
protecte from intense physical shock, severe vibrations, impact, irect sunlight, or water
logging. The battery may be transporte in a vehicle such as an automobile, train, ship,
airplane an etc. Please check your local rules an regulations regar ing such transportation.
Charger Storage con itions: Room temperature -20 ～ 35℃,
Charger relative humi ity: 5～65％RH
Charger
！WARNING:
Never place any object on the charger.
Never pour any liqui on or insert any metal into the charger.
Never isassemble or mo ify the charger in anyway.
Never plug or un-plug the charger with a wet han
Do not use the charger uring a lightning storm.
Use only the supplie charger to re-charge the battery.
Do not operate the charger in an unstable, usty or an excessively amp environment.
Avoi using the charger un er irect sunlight.
Operate the charger in a well ventilation environment.
Unplug the charger from the wall outlet when not in use.
Accessories
！WARNING :
Ensure you o NOT raise the seat post pass the safety mark etche on the seat posts.
Ensure that your assemble accessory oes not interfere with the steering, braking or the
natural movement of the bicycle.
6

Electric Motor and Battery Features
High efficiency and power saving Electric Motor–
A Brushless Motor with gears
High efficiency of up to 85%.
Efficiency>80%. 36V battery for a continuous run range of more than 40 miles on a single
charge in pe al assist mo e.
Pro uces a continuous an sustaine power of 350 Watt power with a peak of up to 600
Watts.
High power and high torque –
Fast pick up even un er heavy loa . Easily climb an ascen sloppy terrains.
Low power consumption, Long-battery life an a Compact esign.
The 36 Volt Battery pack weighs 8 Lbs.
Trouble-free, Low maintenance, Long life span and Easy to maintain electric motor –
High Quality Brushless Electric Disc motor with an a vance spee sensor an gears.
Close system motor requires only surface cleaning an ry storage.
Charging the Battery
Connect the battery to the charger; ensure the output terminal of the charger an the input
terminal of the battery are firmly connecte .
When the charger is plugge into a wall outlet, the charger LED in icator will turn RED to
in icate that the battery is charging
The LED in icator on the charger will turn GREEN when the battery is fully charge .
Disconnect the charger from the wall outlet before isconnecting the charger from the battery.
To ensure long battery life, fully charge the battery for at least twelve (12) hours uring the first
initial three charges an charge the battery at least once for 2-3 hours every 2 months
! NOTE: Only charge the battery pack using the supplie charger.
! NOTE: Always plug the charger onto the Battery pack before plugging the charger to the wall
socket.
! WARNING: Do NOT charge the battery for more than 24hrs for risk of amaging the battery.
Repair and Service
！WARNING:
Inspect the bicycle frequently. Failure to inspect the bicycle an to make repairs or
a justments, as necessary, can result in injury to the ri er or to others. Make sure all parts are
correctly assemble an a juste as written in the owner’s manual.
Imme iately replace any amage , missing, or worn parts.
Make sure all fasteners are correctly tightene as written in the owner’s manual
Parts that are not properly tightene can be lost or operate poorly.
Do not over tighten parts, as over-tightening may amage the part.
Make sure any replacement fasteners are of the correct type an size.
Your bike uses an Aluminum Alloy frame. Ensure that the bicycle frame is carefully an
frequently inspecte ; as Aluminum frames can evelop micro fractures from stress, severe
impact an shocks. If you see these micro fractures or cracks, stop ri ing the bicycle
imme iately.
In case of micro fractures, have the bicycle frame repaire an inspecte by a qualifie
professional before ri ing the bicycle again.
7

NOTE: Have a bicycle service shop make any repairs or a justments for which you o not have the
correct tools to or if you o not sufficiently un erstan the instructions set forth in this electric bicycle’s
manual supplement or the bicycle owner’s manual.
Inspection of the Bearings Maintenance
1. Frequently check the bearings of the bicycle. Have a bicycle service shop lubricate the bearing
once a year or any time they o not pass the tests as note in the Bicycle owner’s manual.
Serial Numbers to your EG Electric Bike
1. There are 3 serial numbers that are of importance on your EG Electric Bike. They are the
Frame serial number, the Motor serial number an the Battery pack serial number. All the serial
numbers except for the battery's can be foun on the outsi e of the box the bicycle was
shippe in.
2. The Bike Frame Serial number to your EG Electric Bike is locate on the un ersi e of the bike
below the bottom bracket on the frame.
3. The Motor serial number is locate on the si e of the motor.
4. The Battery serial number is locate neat the output posts of the Battery pack.
How to detach the rear wheel of the Electric bike
1. ! WARNING: We o not con one mo ifying the EG Electric Bicycle in any way shape or form.
Mo ifying the bike in any way, will voi your Warranty. The instructions below are written only
for the maintenance or repair of the bike.
2. To etach the rear wheel, first unhook the connector near the rear wheel on the right han si e
of the bike.
3. Remove the plastic covers over the screws on the rear axle.
4. Unscrew the nuts on both si es of the rear axle an the wheel shoul come right off.
5. Unhook the chains from the rear freewheel (gears)
6. To install it back on, please note an reverse all the etachment instructions.
8
