Eickemeyer LIFEVET O2 User manual

LIFEVET O2
OXYGEN ANALYSER
USER MANUAL
TELEPHONE [phone]
www.eickemeyer.com
Art. No. 213195

GENERAL
The LifeVet O2Oxygen Analyser is a battery-powered device suitable for monitoring the percentage
of oxygen in an anaesthetic or in free-air. The LifeVet O2uses a longlife galvanic cell and associated
micro-power electronics to measure and display the oxygen level. The unit is powered by a single
1.5 volt alkaline battery and is designed to run for approximately one year, based on a usage rate of
8 hours per day.
FEATURES
• Simple to use
• Main body can be rotated through 360 degrees on adaptor for preferred viewing position
• Simple calibration and span procedures
• Use in-circuit or in free-air
• Adaptor allows easy connection in 22 mm/ 15 mm circuits
• Long sensor life
• Long battery life
USER MANUAL
LIFEVET O2OXYGEN ANALYSER
LifeVet O2Main Body
Main screen
CALIBRATE Button
ON / OFF Button
LifeVet O2Back Panel22 mm / 15 mm Adaptor

USER CONTROLS
There are only 2 buttons on the LifeVet O2 unit. The left hand button is labelled 'CALIBRATE' and the right
hand button is labelled 'ON / OFF'. For routine use only the ON /OFF button need be used to turn the unit
on and off.
Button Use
ON / OFF
Press this button once to turn on the unit. When the unit is turned on, 6 horizontal lines will appear on the
screen for 3 seconds and then be replaced by the measured oxygen percentage value.
CALIBRATE
Press and hold this button for 5 seconds to start the calibration procedure.
CALIBRATION PROCEDURE
The calibration procedure can be run in two parts – a simple 21% recalibration or a 21–100 % span
calibration. To run a span calibration you must have a guaranteed source of 100 % oxygen, such as
from an oxygen bottle or hospital oxygen line.
Performing a 21% recalibration
1) PressandholdtheCALIBRATEbuttonuntilthescreenashesCS
2) Release the button
3) PresstheCALIBRATEbuttonfor1second–thescreenchangestoaashing21
4) Ensure that the unit is in clean room air for at least 60 seconds and then press the CALIBRATE
button again for 1 second
5) Thescreenchangestoaashing100
6) Turn the unit off using the ON / OFF button
Performing a 21–100 % span calibration
1) PressandholdtheCALIBRATEbuttonuntilthescreenashesCS
2) Release the button
3) PresstheCALIBRATEbuttonfor1second–thescreenchangestoaashing21
4) Ensure that the unit is in clean room air for at least 60 seconds and
then press the CALIBRATE button again for 1 second

5) Thescreenchangestoaashing100
6) Flow 100% oxygen through the LifeVet O2connector for 60 seconds
7) After 60 seconds press the CALIBRATE button for 1 second
8) ThescreenchangestoaashingCC,indicatingCalibrationComplete
9) Press the CALIBRATE button one more time to leave the calibration routine
RESTORING FACTORY DEFAULTS
If the calibration routine is not performed correctly, or the values obtained after a calibration routine
are not correct then the default factory settings can be loaded.
1) PressandholdtheCALIBRATEbuttonuntilthescreenashesCS
2) KeepholdingthebuttonuntilthescreenashesFS
3) Release the button
4) Press the CALIBRATE button again for 1 second - the screen changes to 6 horizontal lines
5) Release the button
6) After a second or two the 21 % value will be shown on the screen. If the actual value is not
21 then perform a 21% calibration as above.
With all units, restoring the factory values and performing a 21% calibration will restore the unit to
+/-5 % accuracy. For full +/- 1 % accuracy, perform a full 21–100 % span calibration.

MAINTENANCE
Changing the battery
1) Whenthebatterylevelislow,thescreenwillashslowlyaboutonceevery2seconds.
 Iftheashingiscontinuousthenthebatteryisbelowtheminimumlevelandshouldbereplaced.
2) Undo the back cover of the device by undoing the securing screws in the corner of the backplate.
Remove the battery from the battery holder and replace with a long life, low drain 1.5 volt alkaline
battery. Replace the backplate and tighten all the corner securing screws.
Replacing the 22 mm Adaptor seal
1) There is an O-ring seal in the 22 mm Adaptor that prevents the leakage of gas from the
anaesthetic circuit. If this seal becomes damaged or is lost it must be replaced. Use a small
screwdriver to ease out the old seal and then press the new seal into place.
Dichtung mit einem kleinen Schraubendreher heraus und drücken dann die neue Dichtung hinein.
2) New seals can be obtained from EICKEMEYER® under Replacement Part number E21319501.
TROUBLESHOOTING
Problem: There are 6 horizontal lines on the screen all the time.
Solution: The re-calibration procedure was executed incorrectly. Please restore the factory defaults
Problem: Thedisplayisconstantlyashingalthoughthenumbersseemcorrect.
Solution: The internal AA battery is low. Replace the battery.
Problem: There is nothing on the display and no response to the ON / OFF button.
Solution: Fit a new Long-life AA battery. If this does not resolve the problem, contact EICKEMEYER®
to arrange a unit service.
